Oil Level/temperature Sensor Chrysler Crossfire I final

1. Position the oil level/temperature sensor in the upper oil pan with the screws (1).
2. Position the harness retainer in the upper oil pan with the screws (2).
3. Tighten all screws for the oil level/temperature sensor to 10 N.m (89 in. lbs.).
4. Connect the oil level/temperature sensor harness connector (1).
5. Install the lower oil pan. See «INSTALLATION»(ref-306563-S27064216822008121700000) .

Scheme 106

1. Remove the upper oil pan. See «REMOVAL»(ref-306563-S17026739872008121700000) .
2. If necessary, rotate the crankshaft slightly at the vibration damper.
3. Remove the oil spray nozzle bolts (1) and the oil spray nozzles. NOTE: Do not use hard objects to clean the oil spray nozzles. Replace the oil spray nozzles if they are blocked.
4. Use compressed air only in the oil flow direction to clean the oil spray nozzles.
