Flywheel/flexplate Chrysler Crossfire I final

Note. New flywheel/flexplate bolts must be used.

1. Position the flywheel/flexplate (3) and align on the crankshaft pin.
2. Install the spacer and new flywheel/flexplate bolts (1). Tighten bolts to 45 N.m (33 ft. lbs.)
3. Rotate the flywheel/flexplate bolts an additional 90° clockwise.
4. Install the clutch if equipped. Refer to «INSTALLATION»(ref-306583-S24314899932008121700000) .
5. Remove Special Tool 9102 Flywheel Locking Tool (1).
6. Install the starter. Refer to «INSTALLATION»(ref-306562-S22126829442008121700000) .
7. Install the transmission. For automatic, refer to «INSTALLATION»(ref-306559-S24957390122008121700000) , or for manual, refer to «INSTALLATION»(ref-306584-S24680645932008121700000) .

Scheme 85

1. Remove the engine mount. See «REMOVAL»(ref-306563-S28378055962008121700000) .
2. Remove and discard the engine mount bracket bolts (2).
3. Remove the engine mount bracket (1).

Scheme 86

1. Remove the engine mount. See «REMOVAL»(ref-306563-S28378055962008121700000) .
2. Remove and discard the engine mount bracket bolts (1).
3. Remove the engine mount bracket (2).
