Checking Voltage Supply and Wiring Audi TT 8N

Exhaust 1 illustration ~375 words
  1. Switch the ignition on.

Scheme 31

Scheme 31
  1. Using a Multimeter , check the Throttle Drive (for Electronic Power Control (EPC)) G186 at the Throttle Valve Control Module J338 electrical harness connector terminals 2 to 6 for voltage.

Specified value: at least 4.5 V

  1. Switch the ignition off.

If the specification was obtained

  1. Replace the Throttle Valve Control Module J338. Refer to --> «24 MULTIPORT FUEL INJECTION (MFI)»(ref-276275-S13244009452008010300000)

If the specification was not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box VAG1598/31. Refer to --> «24 MULTIPORT FUEL INJECTION (MFI)»(ref-276275-S13244009452008010300000) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Motronic Engine Control Module (ECM) J220. Refer to --> «Motronic Engine Control Module (ECM) J220, Replacing»(ref-276276-S39982482672008010300000) .
  1. Using a Multimeter , check the Throttle Drive (for Electronic Power Control (EPC)) G186 at Throttle Valve Control Module J338 electrical harness connector terminals to the Motronic Engine Control Module (ECM) J220 electrical harness connector terminals for resistance.
Throttle Valve Control Module J338 electrical harness connector terminalsMotronic Engine Control Module (ECM) J220 electrical harness connector terminals or test box sockets
192
283
3117
484
5118
691

Specified value: 1.5 ohms max.

If the specification is not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. If necessary, repair the faulty wiring connection.
  3. Check the electrical harness connector for damage, corrosion, loose or broken terminals.

If no malfunction is detected in the wiring and if the voltage supply was not OK

  1. Erase the DTC memory. Refer to --> «Diagnostic Mode 04: Reset/Delete Diagnostic Data»(ref-276276-S31279847122008010300000) .
  2. Perform a road test to verify repair.

If the DTC does not return

Repair complete, Generate readiness code. Refer to --> Readiness Code .

  1. End diagnosis.

If the DTC does return and no malfunction is detected in the wiring and the voltage supply was OK

  1. Replace the Motronic Engine Control Module (ECM) J220. Refer to --> «Motronic Engine Control Module (ECM) J220, Replacing»(ref-276276-S39982482672008010300000) .
  2. Assembly is performed in the reverse of the removal.

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/Delete Diagnostic Data»(ref-276276-S31279847122008010300000) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(ref-276276-S05799074302008010300000) .

End of diagnosis
