Engine Control - Specifications, Removal & Installation: Removal & Installation Volvo V70 II

Installation of lambda probes

Install lambda probes using tool 9995543 . Tighten to 45 Nm. (33.2 ft lb)

Secure wiring.

Lower the car slightly.

Connect the connectors.

Secure wiring.

Install LH front wheel. Tighten to 110 Nm. (81 ft lb)

Lower the car.

Installation of driver information control unit

Install in reverse order.

Injector/pulsation damper, replacement (B5xx4T; -2002)

Note. For model year 2001-, see Injectors/pulsation dampers, replacing .

Note. Since the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information is always correct.

Scheme 397

Depressurize the fuel system acc. to: Fuel system pressure release .

Remove the cover over the fuel rail.

Disconnect the injector connectors.

Blow clean around the injectors.

Remove the mounting screws from the fuel rail

Separate the fuel line quick-release connector.

Spray universal oil or similar around the injector terminals on the intake manifold.

Pull out the fuel rail and injectors. Do not work them loose from side to side.

Note. Handle the injectors carefully to avoid damaging the injectors' fuel nozzles and fuel needles.

Scheme 398

Remove

1. the screws holding the mounting rail to the fuel rail
2. the mounting rail
3. the injector and the pulsation damper.

Injectors/pulsation dampers, replacement (B5234T3; B5244T5; B5254T2; B5254T4; 2001-2007)

S60, V70 2000-, V70 XC 2001-/XC70

1. For B5xx4T -2002, see «Injector/pulse damper, replacement»(ref-406871-S28628143922011070100000)
2. For B5xx4T 2003-, see «Injector/pulse damper, replacement»(ref-406871-S28058638752011070100000)
3. For B5xx4Tx 2005-, see «Injector/pulse damper, replacement»(ref-406871-S33729485432011070100000) .

S60, V70 2000

1. For B5254T4, see «Injector/pulse damper, replacement»(ref-406871-S33729485432011070100000) .

Remove fuel filler pipe

1. Remove circlip securing rubber seal.
2. Release rubber seal from bodywork.

Remove fuel tank

1. Position mobile jack with fixture «9995972»(ref-403953-S08076234722011061000000) under fuel tank, check that the lifting platform is flat so as not to damage the fuel tank.
2. Undo tank retaining straps and lower tank slightly.

Remove front holder

1. Remove the entire mounting from the bracket by pulling it towards the right of the car.
2. Disconnect the hose between the EVAP canister shut-off valve and air cleaner (ACL) from the clamp on the fuel tank. HINT: Note position of hose in the clamp in case it opens. The hoses must be reinstalled in their original positions.
