Transmission - Specifications, Electrical/electronic: Other Volvo V70 II

Automatic Trans 6 illustrations ~266 words

Component resistance values

The resistance values assume a temperature of +20°C unless otherwise stated.

ComponentRemarksResistance (ohms)
Shift solenoid S1Resistance between the solenoid pin and the solenoid sleeve or transmission housing12-16
Shift solenoid S2Resistance between the solenoid pin and the solenoid sleeve or transmission housing11-15
Shift solenoid S3Resistance between the solenoid pin and the solenoid sleeve or transmission housing11-15
Shift solenoid S4Resistance between the solenoid pin and the solenoid sleeve or transmission housing11-15
Shift solenoid S5Resistance between the solenoid pin and the solenoid sleeve or transmission housing11-15
Lock-up solenoid SLUResistance between the solenoid pins5.0-5.6
Throttle solenoid SLTResistance between the solenoid pins5.0-5.6
Throttle solenoid SLSResistance between the solenoid pins5.0-5.6
Oil temperature sensor, temperature (°C)0
205800-7900
40
80
100261-263
150

Scheme 83

Scheme 83: 4-pin connector

Control module terminals #A1-#A60 correspond to terminals #A1-#A60 on the breakout box, terminals #A61-#A70 correspond to terminals #B1-#B10 on the breakout box.

TerminalSignalConnected to control module terminal #
A1Signal ground, transmission input speed sensor (SP2)A41
A2Power supply, engine speed (RPM) sensor (SP2)A59
A3Signal ground, transmission output speed sensor (SP1)A39
A4Power supply, speed sensor (SP1)A57

Scheme 84

Scheme 84: 6-pin connector

Control module terminals #A1-#A60 correspond to terminals #A1-#A60 on the breakout box, terminals #A61-#A70 correspond to terminals #B1-#B10 on the breakout box.

TerminalSignalConnected to control module terminal #
B1Shift lock solenoid, replacement
B2Shift lock solenoid, replacement
B4Ground terminal, gear-shift position sensor
B5Gear-shift position sensor, signal AA46
B6Gear-shift position sensor, signal BA64
B7Gear-shift position sensor, signal CA45
B8Gear-shift position sensor, signal PAA63

Scheme 85

Scheme 85: 6-pin connector

Control module terminals #A1-#A60 correspond to terminals #A1-#A60 on the breakout box, terminals #A61-#A70 correspond to terminals #B1-#B10 on the breakout box.

TerminalSignalConnected to control module terminal #
C1S1A50
C2S2A68
C3S3A48
C4S4A47
C5S5A66
C6

Scheme 86

Scheme 86: 8-pin connector

Control module terminals #A1-#A60 correspond to terminals #A1-#A60 on the breakout box, terminals #A61-#A70 correspond to terminals #B1-#B10 on the breakout box.

TerminalSignalConnected to control module terminal #
D1Control signal, Lock-up solenoid SLUA51
D2Signal ground, Lock-up solenoid SLUGA69
D3Control signal, line pressure solenoid SLTA52
D4Signal ground, line pressure solenoid SLTGA70
D5Control signal, line pressure solenoid SLSA49
D6Signal ground, line pressure solenoid SLSGA67
D7Power supply, oil temperature sensor OTA37
D8Signal ground, oil temperature sensor OTGA55

6-pin connector

Control module terminals #A1-#A60 correspond to #A1-#A60 on the breakout box, #A61-#A70 correspond to #B1-#B10 on the breakout box.

PinSignalConnected to control module #
1Control signal, solenoid S3A48
2Control signal, solenoid S5A66
3Control signal (SLS), line pressure solenoid SLSA49
4Control signal, solenoid S4A47
5
6Signal ground (SLSG), line pressure solenoid SLSA67

Scheme 87

Scheme 87: 4-way, 26-pin connector

Control module terminals #A1-#A60 correspond to #A1-#A60 on the breakout box, #A61-#A70 correspond to #B1-#B10 on the breakout box.

PinSignalConnected to control module #
1Signal, gear-shift position sensor terminal AA46
2Signal, gear-shift position sensor terminal BA64
3Signal, gear-shift position sensor terminal CA45
4Signal, gear-shift position sensor terminal PAA63
5
6
7
8Signal ground, gear-shift position sensorA53
9
12Signal (OT), oil temperature sensorA37
13Signal ground (OTG), oil temperature sensorA55
16Signal (NC1), engine speed (RPM) sensorA59
17Signal ground (NC1G), engine speed (RPM) sensorA41
21Control signal, solenoid S1A50
22Control signal, solenoid S2A68
23Control signal (SLU), lock-up solenoid SLUA51
24Control signal (SLT), throttle solenoid SLTA52
25Signal ground (SLTG), throttle solenoid SLTA70
26Signal ground (SLUG), lock-up solenoid SLUA69

Gear shift solenoids

ComponentRemarksResistance (ohms)
Shift solenoids S1, S2, S3, S4 and S5Resistance between the solenoid pin and the solenoid sleeve or transmission housing+20 °C= 11-16 ohms

For other values, see diagram. When taking readings at temperatures other than +20 °C, a control reading must be taken at +20 °C. This is done to check whether the resistance is correct or not.

Linear pressure solenoid SLT, SLS/Lock-up solenoid SLU

ComponentRemarksResistance (ohms)
Lock-up solenoid (SLU) Linear pressure solenoid (SLT) (SLS)Resistance between the solenoid pins+20 °C= 5.0-5.6 ohms

For other values, see diagram. When taking readings at temperatures other than +20 °C, a control reading must be taken at +20 °C. This is done to check whether the resistance is correct or not.

Oil temperature sensor

ComponentRemarksResistance (ohms)
Oil temperature sensorResistance between the terminals on the temperature sensor+10 °C= 5800-7090 ohms
+110 °C= 231-263 ohms

The resistance decreases with increasing temperature.

The control reading should be taken at both temperatures to check whether the resistance is correct or not.

Scheme 88

Scheme 88: Solenoid Park / neutral position (PNP) switch
ComponentRemarksResistance (ohms)
Solenoid Park / neutral position (PNP) switchResistance between the solenoid terminals+20 °C= 24.5 - 29.3 ohms
