Automatic Transmission - External Controls: Removal & Installation Volvo V70 II

Automatic Trans 16 illustrations ~965 words

Removal Procedure

  1. the catch for the bevel arm
  2. bevel arm with bushing and spring
  3. the cover for the gear selector lever ball joint. Pull up the ball joint, gear selector lever and rubber sleeve from the gear selector assembly
  4. the solenoid.

Scheme 1322

Scheme 1322: Removing the old link caps from the gear selector lever

Install new link caps.

Lubricate the new link caps using grease, P/N 1161241-3.

Tap the lower cap onto the gear selector using a rubber mallet.

Removal

Removing the air cleaner (ACL) housing

Scheme 1323

Scheme 1323: Removal

Remove

  1. the fresh air intake hose
  2. the air cleaner (ACL) housing assembly with the intake pipe.

Remove the mechanical gear selector cables from the bracket and the levers on the gearbox

Scheme 1324

Scheme 1324

Remove

  1. the gear selector cables from the levers. Use jimmy bar «9997077»(/volvo/v70/ii-2000-2004/remont/oem-general-information/#special-tools)
  2. the mechanical cables from the bracket by moving the sleeves back on the cable sleeves.

Removing center tunnel console

Remove the center console. See Center console, replacing .

Removing the rubber lead-in

Scheme 1325

Scheme 1325

Fold and roll the carpet under the accelerator pedal (AP). Fold and roll the carpet under the accelerator pedal (AP).

Remove the 2 nuts for the grommet for the gear selector cables at the firewall. Pull the gear selector cables approximately 10 cm into the passenger compartment.

Removing the gear selector cable from the ball joint

Scheme 1326

Scheme 1326

Remove the gear selector cable from the ball joint. Use puller 9997071 .

HINT: The screw on the puller is turned counter-clockwise to pull the gear selector cable loose.

Removing the gear selector assembly

Scheme 1327

Scheme 1327

Remove

  1. the connector
  2. the screws for the gear selector assembly.

Lift the gear selector assembly and twist it so that the lower gear selector cable is accessible.

Removing the gear selector cable from the ball joint and gear selector assembly

Scheme 1328

Scheme 1328

Remove the gear selector cable from the ball joint. Use puller 9997071 .

HINT: The screw on the puller is turned counter-clockwise to pull the gear selector cable loose.

Carefully pry up the catches (1) and slide the cable sleeves upwards on both the gear selector cables.

Remove the gear selector assembly.

Preparations for installing the mechanical cables

Secure a cable using tape to the engine compartment end of the mechanical cable before pulling it out to make reinstallation easier

Removing the gear selector cables

Pull the gear selector cables straight out.

HINT: It is easier taking one gear selector cable through the firewall at a time.

HINT: Do not damage the cable harnesses in the center console when removing the gear selector cable.

Installation

Installing the gear selector cables from the inside of the passenger compartment

Scheme 1329

Scheme 1329: Installation

Install the gear selector cables under the heater unit on the left-hand side, down towards the hole in the firewall.

Note. Be extremely careful when running the rubber bellows for the gear selector cables through the hole in the firewall. Do not damage the gear selector cables.

Feed the gear selector cables through the hole slightly.

HINT: Have a colleague pull through the pre-routed cable.

Pull out the gear selector cables so that the rubber grommet is approximately 10 cm from the firewall.

Installing the gear selector cables and gear selector assembly

Scheme 1330

Scheme 1330

Install

  1. the gear selector cables on the levers on the gear selector assembly. Press into place by hand
  2. the sleeves for the gear selector cables on the gear selector assembly
  3. the gear selector assembly on the bodywork (M8)
  4. the connector on the gear selector assembly.

Installing service clips

Scheme 1331

Scheme 1331

Note. The automatic transmission has a gear selector cable while the manual transmission has two gear selector cables.

Ensure that the gear selector cable is engaged before fitting the blue clip. Press the clip into position as illustrated.

Scheme 1332

Scheme 1332

Check that the clip is positioned in the groove as illustrated.

Installing the rubber grommet

Align the grommet on the studs. Install the M6 nuts.

Feeding in the gear selector cable from the engine compartment

Use the cable to correctly route the gear selector cables. The gear selector cable must be routed past the steering gear and up to the gearbox bracket.

Installing the center tunnel console

Install the center console. See Center console, replacing .

Installing the gear selector cables on the gearbox

Scheme 1333

Scheme 1333

Note. Connect the gear selector cable with the white sleeve to the inner hole on the bracket and the inner lever to the gearbox.

Release the adjuster on the mechanical cable before installing it.

Install

  1. the gear selector cables on the bracket
  2. the outer gear selector cable on the gear selector cable. Press into place by hand.

Scheme 1334

Scheme 1334

Check that the gear selector lever is in neutral.

Scheme 1335

Scheme 1335

Install the inner gear selector cable on the lever. Press into place by hand.

Press the adjuster into place so that it is locked on the cable.

Installing service clips

Scheme 1336

Scheme 1336

Note. The automatic transmission has a gear selector cable while the manual transmission has two gear selector cables.

Ensure that the gear selector cable is engaged before fitting the blue clip. Press the clip into position as illustrated.

Scheme 1337

Scheme 1337

Check that the clip is positioned in the groove as illustrated.

Installing the air cleaner (ACL) housing

Install the air cleaner (ACL) housing, including all hoses and electrical terminals.

Final check

Check that the gear positions are working.

  1. the catch for the bevel arm
  2. bevel arm with bushing and spring
  3. the cover for the gear selector lever ball joint. Pull up the ball joint, gear selector lever and rubber sleeve from the gear selector assembly
  4. the solenoid.

Installation Procedure

  1. the rubber sleeve
  2. the gear selector lever with ball joints and cover
  3. the bevel arm with bushings, spring and retaining clip
  4. the solenoid.
