Gearbox, Selector Cable, Selector Knob - Removal & Installation: Maintenance Volvo V70 II

Gearbox fluid, replacing

V70

1. For AW55-50 and AW50AWD 2000-, see «Transmission fluid, replacing»(ref-406844-S42049221692011070100000) .
2. For TF-80SC and TF-80SCAWD D5244TX 2006-, see «Transmission fluid, changing»(ref-406959-S17270613082011070100000) .

Draining the gearbox fluid

Undo the drain plug.

Collect the oil in a container.

Scheme 2118

Remove the screw.

Applies only to cars with parking heaters

Remove the 3 screws.

Tie up the engine block heater.

Remove the fuel line from the clips on the sub-frame.

Scheme 2119

Remove the nuts and screws from the steering gear.

Scheme 2120

Hang up the steering gear in a tie strap.

Use the hole in the body

This must be done so that the steering shaft bearing does not slide out of the steering column.

Scheme 2121

Remove the 2 hose clamps for the charge air pipe under the engine.

Remove the 3 screws on the gearbox for the charge air pipe mounting.

Separate and remove the pressure pipe.

Remove

1. the screws for the torque rod from the gearbox
2. the screw for the front engine mounting.
