Brake Control System - Component Location Volvo S60 I

Anti-Lock/traction Control 3 illustrations ~365 words

Location of components for brake electronics

Note. In week 35 year 2001 a new brake control module is being introduced along with a new sensor in the brake electronics.

Scheme 151

Scheme 151: Location of components for brake electronics
  1. Contact reel / steering wheel angle sensor (Applies only to cars with DSTC (dynamic stability and traction control))
  2. Control module for the steering wheel angle sensor (Applies only to cars with DSTC (dynamic stability and traction control))
  3. Active yaw control sensor (Applies only to cars with DSTC (dynamic stability and traction control))
  4. Front wheel sensor
  5. Rear wheel sensor
  6. ABS modulator with control module
  7. Servo unit
  8. Pressure sensor.
  9. Pressure sensor.
  10. Pedal position sensor
  11. Warning lamp
  12. Switch.

Scheme 152

Scheme 152: Location of components

The brake system can be divided into following main components

  1. Wheel braking system
  2. Hydraulic braking system
  3. Parking brake system
  4. ABS, EBD and anti-spin systems

Certain components are located differently in the engine compartment depending if the car is left or right-hand drive.

The main systems consist of the following main components

Wheel braking system

  1. Front brake caliper and pad (1)
  2. Front brake disc (2)
  3. Rear brake caliper and pad (3)
  4. Rear brake disc (4)

Hydraulic braking system

  1. Brake fluid reservoir and level sensor (5)
  2. Master cylinder (6)
  3. Power brake booster overload relay (7)
  4. Brake pedal and stop (brake) light contact (8)
  5. Brake lines (9)
  6. Brake circuit warning indicator (10)

Parking brake system

  1. Parking brake lever (12)
  2. Brake wires (13)
  3. Brake shoes (14)
  4. Parking brake lever warning lamp (15)

ABS, EBD and anti-spin systems

  1. Control module for ABS, EBD and anti wheelspin (16)
  2. ABS warning lamp (20)
  3. Anti-wheelspin warning lamp (Only cars with anti wheelspin) (21)
  4. Anti-wheelspin switch (Only cars with anti wheel spin) (22)
  5. ABS hydraulic modulator with pump motor and valves (17)
  6. Front wheel sensor with pulse wheel (18)
  7. Rear wheel sensor with pulse wheel (19)

Scheme 153

Scheme 153: DSTC system components

1 Contact reel / steering wheel angle sensor

2 Control module for the steering wheel angle sensor

3 Yaw rate sensor 2

4 Front wheel sensor

5 Rear wheel sensor

6 Hydraulic unit with control module

7 Pressure sensor, primary line (1)

8 Pressure sensor, secondary line (2)

9 Lateral acceleration sensor

10 Yaw rate sensor 1

11 Warning lamp

12 Switch
