Engine Control System (2GR-FXE)(SERVICE Information) (Hybrid): Other Toyota Highlander III

Testing & Diagnostics 35 illustrations ~6990 words

PROCEDURE

  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Inspect the camshaft timing oil control valve assembly. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank1). Powertrain > Engine and ECT > Active Test Tester Display Control the VVT Linear (Bank1) Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Standard Condition Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: If the result is not as specified, allow the engine to cool (engine coolant temperature of 50°C (122°F) or less) and perform the Active Test again. DTCs related to the VVT system may be stored due to Active Test operation, but this does not indicate a malfunction. If the operation is not as specified, check the camshaft timing oil control valve assembly, wire harness and ECM. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank2). Powertrain > Engine and ECT > Active Test Tester Display Control the VVT Linear (Bank2) Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Standard Condition Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: If the result is not as specified, allow the engine to cool (engine coolant temperature of 50°C (122°F) or less) and perform the Active Test again. DTCs related to the VVT system may be stored due to Active Test operation, but this does not indicate a malfunction. If the operation is not as specified, check the camshaft timing oil control valve assembly, wire harness and ECM.
  1. REMOVE INTAKE AIR SURGE TANK ASSEMBLY Refer to «REMOVAL [02/2014 - ]»(ref-644297-S18861714072014072300000)
  2. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Bank 1) Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and camshaft timing oil control valve assembly from the cylinder head cover sub-assembly. NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). If the camshaft timing oil control valve assembly has been struck or dropped, replace it. Remove the O-ring from the camshaft timing oil control valve assembly.
  3. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Bank 2) Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and camshaft timing oil control valve assembly from the cylinder head cover sub-assembly LH. NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly LH). If the camshaft timing oil control valve assembly has been struck or dropped, replace it. Remove the O-ring from the camshaft timing oil control valve assembly.

Scheme 616

Scheme 616: PROCEDURE
Scheme 616: PROCEDURE
  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms If the result is not as specified, replace the camshaft timing oil control valve assembly. Check the operation. Connect an auxiliary battery positive (+) lead to terminal 1 and negative (-) lead to terminal 2, and check the movement of the spool valve. *a Component without harness connected (Camshaft Timing Oil Control Valve Assembly) *b When Applied *c When Cut Off *d Spool Valve OK Condition Specified Condition Auxiliary battery voltage is applied Valve moves in left arrow direction shown in illustration Auxiliary battery voltage is cut off Valve moves in right arrow direction shown in illustration NOTE: Accumulation of foreign matter can cause minor pressure leaks. Minor pressure leaks in the intake side camshaft timing oil control valve assembly will cause the intake camshaft to advance. Minor pressure leaks in the exhaust side camshaft timing oil control valve assembly will cause the exhaust camshaft to retard. The inappropriate camshaft timing that results from these leaks will cause a DTC to be stored. If the result is not as specified, replace the camshaft timing oil control valve assembly.
  1. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Bank 2) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve assembly. Install the camshaft timing oil control valve assembly to the cylinder head cover sub-assembly LH with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the camshaft timing oil control valve assembly has been struck or dropped, replace it. Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly LH). Make sure that the O-ring is not cracked or moved out of place when installing the camshaft timing oil control valve assembly. Connect the camshaft timing oil control valve assembly connector.
  2. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Bank 1) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve assembly. Install the camshaft timing oil control valve assembly to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the camshaft timing oil control valve assembly has been struck or dropped, replace it. Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). Make sure that the O-ring is not cracked or moved out of place when installing the camshaft timing oil control valve assembly. Connect the camshaft timing oil control valve assembly connector.
  3. INSTALL INTAKE AIR SURGE TANK ASSEMBLY Refer to «INSTALLATION [02/2014 - ]»(ref-644297-S34176357002014072300000)
  4. INSPECT FOR ENGINE OIL LEAK Refer to «PROCEDURE - Step 5»(ref-644275-S24116787552014072300000)

Scheme 617

Scheme 617: ILLUSTRATION
Scheme 617: ILLUSTRATION

*1 COOL AIR INTAKE DUCT SEAL *2 OUTER COWL TOP PANEL SUB-ASSEMBLY *3 RADIATOR SIDE DEFLECTOR SEAL LH *4 RADIATOR SIDE SEAL RH *5 V-BANK COVER SUB-ASSEMBLY - - N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 618

Scheme 618: ILLUSTRATION
Scheme 618: ILLUSTRATION

*1 AIR CLEANER ASSEMBLY WITH AIR CLEANER HOSE *2 INLET NO. 1 AIR CLEANER *3 INLET NO. 2 AIR CLEANER *4 INTAKE AIR RESONATOR SUB-ASSEMBLY N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 619

Scheme 619: ILLUSTRATION
Scheme 619: ILLUSTRATION

*1 THROTTLE BODY GASKET *2 THROTTLE BODY WITH MOTOR ASSEMBLY *3 NO. 2 WATER BY-PASS HOSE *4 NO. 3 WATER BY-PASS HOSE *5 WIRE HARNESS CLAMP BRACKET - - N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part

  1. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Start the engine and check that the MIL is not illuminated. After the engine is warmed up, check that the idle speed is within the specified range with the A/C switch off. Standard 850 to 950 RPM NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in P. Perform a road test and confirm that there are no abnormalities.

Scheme 620

Scheme 620: PROCEDURE
Scheme 620: PROCEDURE
  1. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «REMOVAL [02/2014 - ]»(ref-644300-S39234674122014072300000)
  2. REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 3»(ref-644301-S39975480232014072300000)
  3. REMOVE V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 22»(ref-644274-S35421255692014072300000)
  4. REMOVE RADIATOR SIDE DEFLECTOR SEAL LH Refer to «PROCEDURE - Step 1»(ref-644302-S22278092522014072300000)
  5. REMOVE RADIATOR SIDE SEAL RH Refer to «PROCEDURE - Step 2»(ref-644302-S22278092522014072300000)
  6. REMOVE COOL AIR INTAKE DUCT SEAL Refer to «PROCEDURE - Step 3»(ref-644302-S22278092522014072300000)
  7. DRAIN ENGINE COOLANT Refer to «PROCEDURE - Step 2»(ref-644276-S05654971142014072300000)
  8. REMOVE INTAKE AIR RESONATOR SUB-ASSEMBLY Disengage the 3 hose clamps from the intake air resonator sub-assembly. Remove the 2 bolts. Remove the intake air resonator sub-assembly from the inlet No. 2 air cleaner.
  9. REMOVE INLET NO. 2 AIR CLEANER Remove the 2 bolts. Remove the inlet No. 2 air cleaner from the inlet No. 1 air cleaner.
  10. REMOVE INLET NO. 1 AIR CLEANER Disengage the hose clamp from the inlet No. 1 air cleaner. Remove the bolt. Remove the inlet No. 1 air cleaner from the air cleaner assembly.
  11. REMOVE AIR CLEANER ASSEMBLY WITH AIR CLEANER HOSE Disengage the hose clamp from the air cleaner hose. Disconnect the mass air flow meter sub-assembly connector and disengage the wire harness clamp. Slide the clip and disconnect the ventilation hose from the air cleaner hose. Loosen the hose clamp and disconnect the air cleaner hose from the throttle body with motor assembly. Remove the 2 bolts. Disengage the clamp to remove the air cleaner assembly with air cleaner hose.
  12. REMOVE THROTTLE BODY WITH MOTOR ASSEMBLY Disconnect the throttle body with motor assembly connector and disengage the wire harness clamp. Slide the 2 clips and disconnect the No. 2 water by-pass hose and No. 3 water by-pass hose from the throttle body with motor assembly. *1 No. 2 Water By-pass Hose *2 No. 3 Water By-pass Hose Remove the 4 bolts, wire harness clamp bracket and throttle body with motor assembly from the intake air surge tank assembly. NOTE: If the throttle body with motor assembly has been struck or dropped, replace it.
  13. REMOVE THROTTLE BODY GASKET Remove the throttle body gasket from the intake air surge tank assembly.
  1. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Throttle Body with Motor Assembly) Standard Resistance Tester Connection Condition Specified Condition 1 (M-) - 2 (M+) 20°C (68°F) 0.3 to 100 ohms If the result is not as specified, replace the throttle body with motor assembly.
  1. INSTALL THROTTLE BODY GASKET Install a new throttle body gasket to the intake air surge tank assembly with the protrusion of the throttle body gasket oriented as shown in the illustration. *a Protrusion
  2. INSTALL THROTTLE BODY WITH MOTOR ASSEMBLY Install the throttle body with motor assembly and wire harness clamp bracket to the intake air surge tank assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the throttle body with motor assembly has been struck or dropped, replace it. Connect the No. 2 water by-pass hose and No. 3 water by-pass hose to the throttle body with motor assembly and slide the 2 clips to secure them. Connect the throttle body with motor assembly connector and engage the wire harness clamp.
  3. INSTALL AIR CLEANER ASSEMBLY WITH AIR CLEANER HOSE Engage the clamp to install the air cleaner assembly with air cleaner hose. Connect the air cleaner hose to the throttle body with motor assembly. Install the 2 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Tighten the hose clamp. Connect the ventilation hose to the air cleaner hose and slide the clip to secure it. Connect the mass air flow meter sub-assembly connector and engage the wire harness clamp. Engage the hose clamp to the air cleaner hose.
  4. INSTALL INLET NO. 1 AIR CLEANER Connect the inlet No. 1 air cleaner to the air cleaner assembly. Install the bolt. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Engage the hose clamp to the inlet No. 1 air cleaner.
  5. INSTALL INLET NO. 2 AIR CLEANER Connect the inlet No. 2 air cleaner to the inlet No. 1 air cleaner. Install the 2 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
  6. INSTALL INTAKE AIR RESONATOR SUB-ASSEMBLY Connect the intake air resonator sub-assembly to the inlet No. 2 air cleaner. Install the 2 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Engage the 3 hose clamps to the intake air resonator sub-assembly.
  7. INSTALL COOL AIR INTAKE DUCT SEAL Refer to «PROCEDURE - Step 4»(ref-644302-S05444920862014072300000)
  8. INSTALL RADIATOR SIDE SEAL RH Refer to «PROCEDURE - Step 5»(ref-644302-S05444920862014072300000)
  9. INSTALL RADIATOR SIDE DEFLECTOR SEAL LH Refer to «PROCEDURE - Step 6»(ref-644302-S05444920862014072300000)
  10. INSTALL V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 68»(ref-644274-S28656707772014072300000)
  11. INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 10»(ref-644301-S35417214522014072300000)
  12. INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «INSTALLATION [02/2014 - ]»(ref-644300-S24392291732014072300000)
  13. ADD ENGINE COOLANT Refer to «PROCEDURE - Step 3»(ref-644276-S05654971142014072300000)
  14. INSPECT FOR COOLANT LEAK Refer to «PROCEDURE - Step 1»(ref-644303-S35736762952014072300000)
  15. PERFORM INITIALIZATION NOTE: Be sure to perform this procedure after removing and reinstalling the throttle body with motor assembly or any throttle body with motor assembly components. Perform the following procedure after replacing the throttle body with motor assembly or any throttle body with motor assembly components. The following procedure should also be performed if the throttle body with motor assembly is cleaned. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Turn the power switch on (IG) without operating the accelerator pedal. Perform the "Inspection After Repair". Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Start the engine and check that the MIL is not illuminated. After the engine is warmed up, check that the idle speed is within the specified range with the A/C switch off. Standard Idle Speed 850 to 950 RPM NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in P. Perform a road test and confirm that there are no abnormalities.

Scheme 621

Scheme 621: ILLUSTRATION
Scheme 621: ILLUSTRATION

*1 DECK BOARD ASSEMBLY *2 NO. 3 DECK BOARD SUB-ASSEMBLY *3 NEGATIVE AUXILIARY BATTERY TERMINAL - - N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 622

Scheme 622: ILLUSTRATION
Scheme 622: ILLUSTRATION

*1 ECM *2 ECM BRACKET *3 ENGINE ROOM ECU BOX *4 ENGINE ROOM ECU COVER *5 NO. 2 ECM BRACKET *6 WIRE HARNESS CLAMP BRACKET N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 623

Scheme 623: PROCEDURE
Scheme 623: PROCEDURE

Scheme 624

Scheme 624
Scheme 624

Scheme 625

Scheme 625
Scheme 625

Scheme 626

Scheme 626
Scheme 626

Scheme 627

Scheme 627
Scheme 627
  1. PRECAUTION NOTE: Perform the Vehicle Identification Number (VIN) registration when replacing the ECM. Refer to «REGISTRATION [02/2014 - ]»(ref-644155-S13472793272014072300000) After turning the power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notice before proceeding with work. Refer to «PRECAUTION [02/2014 - ]»(ref-644130-S10815781242014072300000)
  2. REMOVE DECK BOARD ASSEMBLY Refer to «PROCEDURE - Step 1»(ref-644304-S21131690512014072300000)
  3. REMOVE NO. 3 DECK BOARD SUB-ASSEMBLY Refer to «PROCEDURE - Step 2»(ref-644304-S21131690512014072300000)
  4. DISCONNECT CABLE FROM NEGATIVE AUXILIARY BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [02/2014 - ]»(ref-644130-S03070085902014072300000)
  5. REMOVE ECM Raise the 2 levers while pushing the locks on the levers, and disconnect the 2 ECM connectors. NOTE: After disconnecting the ECM connectors, make sure that dirt, water or other foreign matter does not contact the connecting parts of the ECM connectors. Disengage the wire harness clamp. Disengage the 2 wire harness clamps. Disengage the cooler pipe clamp. Remove the 3 bolts and ECM. NOTE: If the ECM has been struck or dropped, replace it. Remove the 2 bolts and wire harness clamp bracket from the ECM.
  6. REMOVE ECM BRACKET Remove the 2 bolts and ECM bracket from the engine room ECU cover.
  7. REMOVE NO. 2 ECM BRACKET Remove the 2 bolts and No. 2 ECM bracket from the engine room ECU box.
  8. REMOVE ENGINE ROOM ECU COVER Disengage the 3 claws to remove the engine room ECU cover from the engine room ECU box.
  9. REMOVE ENGINE ROOM ECU BOX Remove the engine room ECU box from the ECM.
  1. INSTALL ENGINE ROOM ECU BOX Install the engine room ECU box to the ECM.
  2. INSTALL ENGINE ROOM ECU COVER Engage the 3 claws to install the engine room ECU cover to the engine room ECU box.
  3. INSTALL NO. 2 ECM BRACKET Install the No. 2 ECM bracket to the engine room ECU box with the 2 bolts. Torque: 4.5 N*m (46 kgf*cm, 40 in.*lbf)
  4. INSTALL ECM BRACKET Install the ECM bracket to the engine room ECU cover with the 2 bolts. Torque: 4.5 N*m (46 kgf*cm, 40 in.*lbf)
  5. INSTALL ECM Install the wire harness clamp bracket to the ECM with the 2 bolts. Torque: 4.5 N*m (46 kgf*cm, 40 in.*lbf) Install the ECM with the 3 bolts. Bolt (A) Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf) Bolt (B) Torque: 30 N*m (306 kgf*cm, 22 ft.*lbf) NOTE: If the ECM has been struck or dropped, replace it. Engage the cooler pipe clamp. Engage the 2 wire harness clamps. Engage the wire harness clamp. Connect the 2 ECM connectors and lower the 2 levers. NOTE: When connecting the ECM connectors, make sure that dirt, water or other foreign matter does not contact the connecting parts of the ECM connectors. Be sure to securely connect the ECM connectors.
  6. CONNECT CABLE FROM NEGATIVE AUXILIARY BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [02/2014 - ]»(ref-644130-S03070085902014072300000)
  7. INSTALL NO. 3 DECK BOARD SUB-ASSEMBLY Refer to «PROCEDURE - Step 71»(ref-644304-S14394005692014072300000)
  8. INSTALL DECK BOARD ASSEMBLY Refer to «PROCEDURE - Step 72»(ref-644304-S14394005692014072300000)
  9. PERFORM INITIALIZATION Refer to «INITIALIZATION [02/2014 - ]»(ref-644130-S03070085902014072300000)

Scheme 628

Scheme 628: ILLUSTRATION
Scheme 628: ILLUSTRATION

*1 MASS AIR FLOW METER SUB-ASSEMBLY *2 OUTER COWL TOP PANEL SUB-ASSEMBLY N*m (kgf*cm, ft.*lbf): Specified torque

CAUTION / NOTICE / HINT

Note. Perform the mass air flow meter sub-assembly inspection according to the following procedure. Only replace the mass air flow meter sub-assembly when the mass air flow meter sub-assembly value in the Data List (with the engine stopped) is not within the normal operating range or there is foreign matter on the mass air flow meter sub-assembly platinum hot wire (heater).

  1. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Read the value using the Techstream (MAF). NOTE: Perform the inspection with the vehicle indoors and on a level surface. Perform the inspection of the mass air flow meter sub-assembly while it is installed to the air cleaner cap sub-assembly (installed to the vehicle). During the test, do not use an exhaust air duct on the exhaust pipe. Connect the Techstream to the DLC3. Turn the power switch on (IG) (do not start the hybrid system). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAF. Powertrain > Engine and ECT > Data List Tester Display MAF Wait for 30 seconds, and read the value on the Techstream. Standard Condition Tester Display Condition Standard Condition MAF Engine not running 30 seconds after power switch turned on (IG) 0.53 gm/sec or less If the result is not as specified, replace the mass air flow meter sub-assembly. If the result is within the specified range, inspect the mass air flow meter sub-assembly. Refer to «INSPECTION [02/2014 - ]»(ref-644290-S06202442242014072300000)
  2. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000)

Scheme 629

Scheme 629: PROCEDURE
Scheme 629: PROCEDURE
  1. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «REMOVAL [02/2014 - ]»(ref-644300-S39234674122014072300000)
  2. REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 3»(ref-644301-S39975480232014072300000)
  3. REMOVE MASS AIR FLOW METER SUB-ASSEMBLY Disconnect the mass air flow meter sub-assembly connector. Remove the 2 screws and mass air flow meter sub-assembly from the air cleaner cap sub-assembly. NOTE: If the mass air flow meter sub-assembly has been struck or dropped, replace it.

Scheme 630

Scheme 630: PROCEDURE
Scheme 630: PROCEDURE
  1. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Perform a visual check for any foreign matter on the platinum hot wire (heater) and temperature sensor (thermistor) of the mass air flow meter sub-assembly shown in the illustration. *a Platinum Hot Wire (Heater) *b Temperature Sensor (Thermistor) OK There is no foreign matter. If the result is not as specified, replace the mass air flow meter sub-assembly. Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Mass Air Flow Meter Sub-assembly) Standard Resistance Tester Connection Condition Specified Condition 1 (THA) - 2 (E2) -20°C (-4°F) 13.6 to 18.4 kohms 20°C (68°F) 2.21 to 2.69 kohms 60°C (140°F) 0.49 to 0.67 kohms If the result is not as specified, replace the mass air flow meter sub-assembly.
  1. INSTALL MASS AIR FLOW METER SUB-ASSEMBLY HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Install the mass air flow meter sub-assembly to the air cleaner cap sub-assembly with the 2 screws. NOTE: If the mass air flow meter sub-assembly has been struck or dropped, replace it. If reusing the mass air flow meter sub-assembly, be sure to inspect the O-ring. Make sure that the O-ring is not cracked or moved out of place when installing the mass air flow meter sub-assembly. Connect the mass air flow meter sub-assembly connector.
  2. INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 10»(ref-644301-S35417214522014072300000)
  3. INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «INSTALLATION [02/2014 - ]»(ref-644300-S24392291732014072300000)
  4. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000)

Scheme 631

Scheme 631: ILLUSTRATION
Scheme 631: ILLUSTRATION

*1 CAMSHAFT POSITION SENSOR (for Bank 1) *2 CAMSHAFT POSITION SENSOR (for Bank 2) N*m (kgf*cm, ft.*lbf): Specified torque

  1. REMOVE EGR DELIVERY CHAMBER Refer to «REMOVAL [02/2014 - ]»(ref-644297-S18861714072014072300000)
  2. REMOVE CAMSHAFT POSITION SENSOR (for Bank 1) Disconnect the camshaft position sensor connector. Remove the bolt and camshaft position sensor from the cylinder head cover sub-assembly. NOTE: If the camshaft position sensor has been struck or dropped, replace it.
  3. REMOVE CAMSHAFT POSITION SENSOR (for Bank 2) Disconnect the camshaft position sensor connector. Remove the bolt and camshaft position sensor from the cylinder head cover sub-assembly LH. NOTE: If the camshaft position sensor has been struck or dropped, replace it.
  1. INSTALL CAMSHAFT POSITION SENSOR (for Bank 2) Apply a light coat of engine oil to the O-ring of the camshaft position sensor. *a O-ring Install the camshaft position sensor to the cylinder head cover sub-assembly LH with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the camshaft position sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the camshaft position sensor connector.
  2. INSTALL CAMSHAFT POSITION SENSOR (for Bank 1) Apply a light coat of engine oil to the O-ring of the camshaft position sensor. *a O-ring Install the camshaft position sensor to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the camshaft position sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the camshaft position sensor connector.
  3. INSTALL EGR DELIVERY CHAMBER Refer to «INSTALLATION [02/2014 - ]»(ref-644297-S34176357002014072300000)
  4. INSPECT FOR ENGINE OIL LEAK Refer to «PROCEDURE - Step 5»(ref-644275-S24116787552014072300000)

Scheme 632

Scheme 632: ILLUSTRATION
Scheme 632: ILLUSTRATION

*1 CRANKSHAFT POSITION SENSOR - - N*m (kgf*cm, ft.*lbf): Specified torque

  1. REMOVE COMPRESSOR WITH MOTOR ASSEMBLY Refer to «REMOVAL [02/2014 - ]»(ref-644284-S30727755012014072300000)
  2. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the crankshaft position sensor connector. Remove the bolt and crankshaft position sensor from the cylinder block sub-assembly. NOTE: If the crankshaft position sensor has been struck or dropped, replace it.
  1. INSPECT CRANKSHAFT POSITION SENSOR Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Crankshaft Position Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 - 2 Cold 1630 to 2740 ohms Hot 2065 to 3225 ohms HINT: In the table above, the terms "Cold" and "Hot" mean the temperature of the coils themselves. "Cold" is from -10 to 50°C (14 to 122°F) and "Hot" is from 50 to 100°C (122 to 212°F). If the result is not as specified, replace the crankshaft position sensor.
  1. INSTALL CRANKSHAFT POSITION SENSOR Apply a light coat of engine oil to the O-ring of the crankshaft position sensor. *a O-ring Install the crankshaft position sensor to the cylinder block sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the crankshaft position sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the crankshaft position sensor connector.
  2. INSTALL COMPRESSOR WITH MOTOR ASSEMBLY Refer to «INSTALLATION [02/2014 - ]»(ref-644284-S01515244262014072300000)
  3. INSPECT FOR ENGINE OIL LEAK Refer to «PROCEDURE - Step 5»(ref-644275-S24116787552014072300000)

Scheme 633

Scheme 633: ILLUSTRATION
Scheme 633: ILLUSTRATION

*1 IGNITION COIL ASSEMBLY *2 SPARK PLUG N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 634

Scheme 634: PROCEDURE
Scheme 634: PROCEDURE
  1. REMOVE EGR COOLER ASSEMBLY Refer to «REMOVAL [02/2014 - ]»(ref-644279-S07002836932014072300000)
  2. REMOVE IGNITION COIL ASSEMBLY Disconnect the 6 ignition coil assembly connectors. *A for Bank 1 *B for Bank 2 Remove the 6 bolts and 6 ignition coil assemblies from the cylinder head cover sub-assembly. NOTE: If an ignition coil assembly has been struck or dropped, replace it. HINT: Arrange the removed parts in the correct order.
  3. REMOVE SPARK PLUG Remove the 6 spark plugs from the cylinder head sub-assembly. NOTE: If a spark plug has been struck or dropped, replace it. HINT: Arrange the removed parts in the correct order.
  1. INSTALL SPARK PLUG HINT: Perform "Inspection After Repair" after replacing a spark plug. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Install the 6 spark plugs to the cylinder head sub-assembly. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) NOTE: If a spark plug has been struck or dropped, replace it. HINT: Install the same parts to their original positions.
  2. INSTALL IGNITION COIL ASSEMBLY HINT: Perform "Inspection After Repair" after replacing an ignition coil assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Install the 6 ignition coil assemblies to the cylinder head cover sub-assembly with the 6 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If an ignition coil assembly has been struck or dropped, replace it. HINT: Install the same parts to their original positions. Connect the 6 ignition coil assembly connectors.
  3. INSTALL EGR COOLER ASSEMBLY Refer to «INSTALLATION [02/2014 - ]»(ref-644279-S38777971232014072300000)
  4. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing a spark plug or ignition coil assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000)

Scheme 635

Scheme 635: ILLUSTRATION
Scheme 635: ILLUSTRATION

*1 AIR CLEANER ASSEMBLY WITH AIR CLEANER HOSE *2 COOL AIR INTAKE DUCT SEAL *3 INLET NO. 1 AIR CLEANER *4 INLET NO. 2 AIR CLEANER *5 OUTER COWL TOP PANEL SUB-ASSEMBLY *6 RADIATOR SIDE DEFLECTOR SEAL LH *7 RADIATOR SIDE SEAL RH *8 V-BANK COVER SUB-ASSEMBLY N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 636

Scheme 636: ILLUSTRATION
Scheme 636: ILLUSTRATION

*1 ENGINE COOLANT TEMPERATURE SENSOR *2 GASKET N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part

Scheme 637

Scheme 637: PROCEDURE
Scheme 637: PROCEDURE
  1. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «REMOVAL [02/2014 - ]»(ref-644300-S39234674122014072300000)
  2. REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 3»(ref-644301-S39975480232014072300000)
  3. REMOVE V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 22»(ref-644274-S35421255692014072300000)
  4. REMOVE RADIATOR SIDE DEFLECTOR SEAL LH Refer to «PROCEDURE - Step 1»(ref-644302-S22278092522014072300000)
  5. REMOVE RADIATOR SIDE SEAL RH Refer to «PROCEDURE - Step 2»(ref-644302-S22278092522014072300000)
  6. REMOVE COOL AIR INTAKE DUCT SEAL Refer to «PROCEDURE - Step 3»(ref-644302-S22278092522014072300000)
  7. DRAIN ENGINE COOLANT Refer to «PROCEDURE - Step 2»(ref-644276-S05654971142014072300000)
  8. REMOVE INLET NO. 2 AIR CLEANER See step 9
  9. REMOVE INLET NO. 1 AIR CLEANER See step 10
  10. REMOVE AIR CLEANER ASSEMBLY WITH AIR CLEANER HOSE See step 11
  11. REMOVE ENGINE COOLANT TEMPERATURE SENSOR Disconnect the engine coolant temperature sensor connector. Using a 19 mm union nut wrench, remove the engine coolant temperature sensor from the water outlet. NOTE: If the engine coolant temperature sensor has been struck or dropped, replace it. Remove the gasket from the engine coolant temperature sensor.

Scheme 638

Scheme 638: PROCEDURE
Scheme 638: PROCEDURE
  1. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Engine Coolant Temperature Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 2.32 to 2.59 kohms 80°C (176°F) 0.310 to 0.326 kohms NOTE: If checking the engine coolant temperature sensor in water, be careful not to allow water to contact the terminals. After checking, wipe the water off the engine coolant temperature sensor. If the result is not as specified, replace the engine coolant temperature sensor.
  1. INSTALL ENGINE COOLANT TEMPERATURE SENSOR HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Install a new gasket to the engine coolant temperature sensor. Using a 19 mm union nut wrench, install the engine coolant temperature sensor to the water outlet. Torque: 19.6 N*m (200 kgf*cm, 14 ft.*lbf) NOTE: If the engine coolant temperature sensor has been struck or dropped, replace it. Use the torque value compensation formula to calculate the torque value for use when a torque wrench is combined with a tool such as a union nut wrench. Refer to «PRECAUTION [02/2014 - ]»(ref-644130-S10815781242014072300000) Connect the engine coolant temperature sensor connector.
  2. INSTALL AIR CLEANER ASSEMBLY WITH AIR CLEANER HOSE See step 3
  3. INSTALL INLET NO. 1 AIR CLEANER See step 4
  4. INSTALL INLET NO. 2 AIR CLEANER See step 5
  5. INSTALL COOL AIR INTAKE DUCT SEAL Refer to «PROCEDURE - Step 4»(ref-644302-S05444920862014072300000)
  6. INSTALL RADIATOR SIDE SEAL RH Refer to «PROCEDURE - Step 5»(ref-644302-S05444920862014072300000)
  7. INSTALL RADIATOR SIDE DEFLECTOR SEAL LH Refer to «PROCEDURE - Step 6»(ref-644302-S05444920862014072300000)
  8. INSTALL V-BANK COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 68»(ref-644274-S28656707772014072300000)
  9. INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 10»(ref-644301-S35417214522014072300000)
  10. INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «INSTALLATION [02/2014 - ]»(ref-644300-S24392291732014072300000)
  11. ADD ENGINE COOLANT Refer to «PROCEDURE - Step 3»(ref-644276-S05654971142014072300000)
  12. INSPECT FOR COOLANT LEAK (for Engine) Refer to «PROCEDURE - Step 1»(ref-644303-S35736762952014072300000)
  13. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000)

Scheme 639

Scheme 639: ILLUSTRATION
Scheme 639: ILLUSTRATION

*1 KNOCK CONTROL SENSOR (for Bank 1) *2 KNOCK CONTROL SENSOR (for Bank 2) N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 640

Scheme 640: PROCEDURE
Scheme 640: PROCEDURE
  1. REMOVE INTAKE MANIFOLD Refer to «REMOVAL [02/2014 - ]»(ref-644297-S18861714072014072300000)
  2. REMOVE KNOCK CONTROL SENSOR Disconnect the 2 knock control sensor connectors. *A for Bank 1 *B for Bank 2 Remove the 2 bolts and 2 knock control sensors from the cylinder block sub-assembly. NOTE: If the knock control sensor has been struck or dropped, replace it.
  1. INSPECT KNOCK CONTROL SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 25 °C (77 °F) 120 to 280 kohms If the result is not as specified, replace the knock control sensor. *a Component without harness connected (Knock Control Sensor)
  1. INSTALL KNOCK CONTROL SENSOR HINT: Perform "Inspection After Repair" after replacing the knock control sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Install the 2 knock control sensors to the cylinder block sub-assembly with the 2 bolts so that the knock control sensor installation position is as shown in the illustration. *A for Bank 1 *B for Bank 2 *a Front of Vehicle *b 5° *c 10° Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) NOTE: If the knock control sensor has been struck or dropped, replace it. Make sure that the knock control sensor is in the correct position. Connect the 2 knock control sensor connectors.
  2. INSTALL INTAKE MANIFOLD Refer to «INSTALLATION [02/2014 - ]»(ref-644297-S34176357002014072300000)
  3. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the knock control sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000)

Scheme 641

Scheme 641: ILLUSTRATION
Scheme 641: ILLUSTRATION

*1 OUTER COWL TOP PANEL SUB-ASSEMBLY *2 VACUUM SENSOR ASSEMBLY N*m (kgf*cm, ft.*lbf): Specified torque

  1. INSPECT VACUUM SENSOR ASSEMBLY *a Front view of wire harness connector (to Vacuum Sensor Assembly) Check the terminal voltage. Disconnect the vacuum sensor assembly connector. Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C57-3 (VC) - C57-2 (E2) Power switch on (IG) 4.75 to 5.25 V C57-1 (PIM) - C57-2 (E2) Power switch on (IG) 3.0 to 5.0 V If the result is not as specified, open or short in VC or E2 circuit. Check the intake manifold pressure. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAP. Powertrain > Engine and ECT > Data List Tester Display MAP Read the values displayed on the Techstream. OK Equivalent to atmospheric pressure. HINT: Standard atmospheric pressure is 101 kPa (abs) [758 mmHg (abs)]. For every 100 m (328 ft) increase in altitude, pressure drops by 1 kPa (7.5 mmHg). This varies by weather.
  1. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «REMOVAL [02/2014 - ]»(ref-644300-S39234674122014072300000)
  2. REMOVE OUTER COWL TOP PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 3»(ref-644301-S39975480232014072300000)
  3. REMOVE VACUUM SENSOR ASSEMBLY Disconnect the vacuum sensor assembly connector. Remove the 2 bolts and vacuum sensor assembly from the intake air surge tank assembly.
  1. INSTALL VACUUM SENSOR ASSEMBLY Install the vacuum sensor assembly to the intake air surge tank assembly with the 2 bolts. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) NOTE: If a vacuum sensor assembly has been struck or dropped, replace it. Connect the vacuum sensor assembly connector.
  2. INSTALL OUTER COWL TOP PANEL SUB-ASSEMBLY Refer to «PROCEDURE - Step 10»(ref-644301-S35417214522014072300000)
  3. INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «INSTALLATION [02/2014 - ]»(ref-644300-S24392291732014072300000)

Scheme 642

Scheme 642: ILLUSTRATION
Scheme 642: ILLUSTRATION

*1 AIR FUEL RATIO SENSOR (for Bank 1) *2 AIR FUEL RATIO SENSOR (for Bank 2) *3 EXHAUST MANIFOLD SUB-ASSEMBLY RH *4 MANIFOLD STAY *5 NO. 1 EGR PIPE *6 INLET EGR GASKET N*m (kgf*cm, ft.*lbf): Specified torque * For use with SST • Non-reusable part

Scheme 643

Scheme 643: PROCEDURE
Scheme 643: PROCEDURE
  1. REMOVE AIR FUEL RATIO SENSOR (for Bank 2) Disengage the wire harness clamp. Disconnect the air fuel ratio sensor connector. Using SST, remove the air fuel ratio sensor from the exhaust manifold sub-assembly LH. SST: 09224-00010 NOTE: If the air fuel ratio sensor has been struck or dropped, replace it.
  2. REMOVE MANIFOLD STAY Refer to «PROCEDURE - Step 6»(ref-644297-S39486579362014072300000)
  3. REMOVE NO. 1 EGR PIPE Refer to «PROCEDURE - Step 7»(ref-644297-S39486579362014072300000)
  4. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY RH Refer to «PROCEDURE - Step 8»(ref-644297-S39486579362014072300000)
  5. REMOVE AIR FUEL RATIO SENSOR (for Bank 1) Using SST, remove the air fuel ratio sensor from the exhaust manifold sub-assembly RH. SST: 09224-00010 NOTE: If the air fuel ratio sensor has been struck or dropped, replace it.

Scheme 644

Scheme 644: PROCEDURE
Scheme 644: PROCEDURE
  1. INSPECT AIR FUEL RATIO SENSOR Measure the resistance according to the value(s) in the table below. *A for Bank 1 *B for Bank 2 *a Component without harness connected (Air Fuel Ratio Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 (HA1A) - 2 (+B) 1 (HA2A) - 2 (+B) 20°C (68°F) 1.6 to 3.2 ohms 1 (HA1A) - 4 (A1A-) 1 (HA2A) - 4 (A2A-) Always 10 kohms or higher If the result is not as specified, replace the air fuel ratio sensor.
  1. INSTALL AIR FUEL RATIO SENSOR (for Bank 1) HINT: Perform "Inspection After Repair" after replacing an air fuel ratio sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Using SST, install the air fuel ratio sensor to the exhaust manifold sub-assembly RH. *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If the air fuel ratio sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [02/2014 - ]»(ref-644130-S10815781242014072300000)
  2. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY RH Refer to «PROCEDURE - Step 10»(ref-644297-S35891318872014072300000)
  3. INSTALL NO. 1 EGR PIPE Refer to «PROCEDURE - Step 11»(ref-644297-S35891318872014072300000)
  4. INSTALL MANIFOLD STAY Refer to «PROCEDURE - Step 12»(ref-644297-S35891318872014072300000)
  5. INSTALL AIR FUEL RATIO SENSOR (for Bank 2) HINT: Perform "Inspection After Repair" after replacing an air fuel ratio sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Using SST, install the air fuel ratio sensor to the exhaust manifold sub-assembly LH. SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If the air fuel ratio sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [02/2014 - ]»(ref-644130-S10815781242014072300000) *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) Connect the air fuel ratio sensor connector. Engage the wire harness clamp.
  6. INSPECT FOR EXHAUST GAS LEAK Refer to «PROCEDURE - Step 14»(ref-644297-S36309194732014072300000)
  7. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing an air fuel ratio sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000)

Scheme 645

Scheme 645: ILLUSTRATION
Scheme 645: ILLUSTRATION

*1 FRONT FLOOR COVER LH *2 HEATED OXYGEN SENSOR (for Bank 1) *3 HEATED OXYGEN SENSOR (for Bank 2) *4 WIRE HARNESS CLAMP BRACKET N*m (kgf*cm, ft.*lbf): Specified torque * For use with SST

Scheme 646

Scheme 646: PROCEDURE
Scheme 646: PROCEDURE
  1. REMOVE HEATED OXYGEN SENSOR (for Bank 2) Disengage the 3 wire harness clamps. Disconnect the heated oxygen sensor connector. Remove the wire harness clamp bracket from the heated oxygen sensor. Using SST, remove the heated oxygen sensor from the front exhaust pipe assembly. SST: 09224-00010 NOTE: If the heated oxygen sensor has been struck or dropped, replace it.
  2. REMOVE FRONT FLOOR COVER LH Refer to «PROCEDURE - Step 4»(ref-644297-S39486579362014072300000)
  3. REMOVE HEATED OXYGEN SENSOR (for Bank 1) Disengage the 3 wire harness clamps. Disconnect the heated oxygen sensor connector. Using SST, remove the heated oxygen sensor from the front No. 3 exhaust pipe sub-assembly. SST: 09224-00010 NOTE: If the heated oxygen sensor has been struck or dropped, replace it.

Scheme 647

Scheme 647: PROCEDURE
Scheme 647: PROCEDURE
  1. INSPECT HEATED OXYGEN SENSOR Measure the resistance according to the value(s) in the table below. *A for Bank 1 *B for Bank 2 *a Component without harness connected (Heated Oxygen Sensor) Standard Resistance Tester Connection Condition Specified Condition 2 (HT1B) - 1 (+B) 1 (HT2B) - 2 (+B) 20°C (68°F) 11 to 16 ohms 2 (HT1B) - 3 (E2) 1 (HT2B) - 4 (E2) Always 10 kohms or higher If the result is not as specified, replace the heated oxygen sensor.

Scheme 648

Scheme 648: PROCEDURE
Scheme 648: PROCEDURE
  1. INSTALL HEATED OXYGEN SENSOR (for Bank 1) HINT: Perform "Inspection After Repair" after replacing a heated oxygen sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Using SST, install the heated oxygen sensor to the front No. 3 exhaust pipe sub-assembly. *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If the heated oxygen sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [02/2014 - ]»(ref-644130-S10815781242014072300000) Connect the heated oxygen sensor connector. Engage the 3 wire harness clamps.
  2. INSTALL FRONT FLOOR COVER LH Refer to «PROCEDURE - Step 14»(ref-644297-S35891318872014072300000)
  3. INSTALL HEATED OXYGEN SENSOR (for Bank 2) HINT: Perform "Inspection After Repair" after replacing a heated oxygen sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Using SST, install the heated oxygen sensor to the front exhaust pipe assembly. SST: 09224-00010 without SST [Torque (N*m (kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m (kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If the heated oxygen sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [02/2014 - ]»(ref-644130-S10815781242014072300000) *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) Connect the heated oxygen sensor connector. Engage the 3 wire harness clamps.
  4. INSPECT FOR EXHAUST GAS LEAK Refer to «PROCEDURE - Step 14»(ref-644297-S36309194732014072300000)
  5. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing a heated oxygen sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000)

Scheme 649

Scheme 649: PROCEDURE
Scheme 649: PROCEDURE

Scheme 650

Scheme 650
Scheme 650
  1. INSPECT CIRCUIT OPENING RELAY (C/OPN) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Auxiliary battery voltage not applied between terminals 1 and 2 10 kohms or higher Auxiliary battery voltage applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the circuit opening relay (C/OPN).
  2. INSPECT FUEL PUMP RELAY (FUEL PMP) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 4 Auxiliary battery voltage not applied between terminals 1 and 2 Below 1 ohms Auxiliary battery voltage applied between terminals 1 and 2 10 kohms or higher 3 - 5 Auxiliary battery voltage not applied between terminals 1 and 2 10 kohms or higher Auxiliary battery voltage applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the fuel pump relay (FUEL PMP).

More articles — Engine Control System (2GR-FXE)(SERVICE Information) (Hybrid)
