Engine Control System (2GR-FE) (Diagnostic Codes (P0010 - P014F)) (Except Hybrid): Other Toyota Highlander III

VEHICLE CONTROL HISTORY [12/2013 - ]

1. VEHICLE CONTROL HISTORY HINT: A part of the control history can be confirmed using the vehicle control history. Refer to «VEHICLE CONTROL HISTORY [12/2013 - ]»(ref-636205-S13328145792014070700000)

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

ALL

CASE 1

CASE 2

TYPICAL MALFUNCTION THRESHOLDS

CASE 1

CASE 2

COMPONENT OPERATING RANGE

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0010 or P0020.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 333

CAUTION / NOTICE / HINT

HINT

1. If DTC P0010 is output, check the VVT system (for intake camshaft of bank 1) circuit.
2. If DTC P0020 is output, check the VVT system (for intake camshaft of bank 2) circuit.
3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

PROCEDURE

1. READ OUTPUT DTC (DTC P0010 OR P0020) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC after recording the freeze frame data and DTC. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and wait 5 seconds. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0010 or P0020 is output A DTCs are not output B Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 1 A See step 2
2. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for intake camshaft). Refer to «INSPECTION [12/2013 - ]»(ref-636218-S22617490372014070700000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [12/2013 - ]»(ref-636218-S32007268612014070700000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) - ECM) Disconnect the camshaft timing oil control valve assembly (for intake camshaft) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C37-1 (+R) - C1-35 (OC1+) Always Below 1 ohms C37-2 (-R) - C1-5 (OC1-) Always Below 1 ohms C38-1 (+) - C1-34 (OC2+) Always Below 1 ohms C38-2 (-) - C1-4 (OC2-) Always Below 1 ohms C37-1 (+R) or C1-35 (OC1+) - Body ground Always 10 kohms or higher C37-2 (-R) or C1-5 (OC1-) - Body ground Always 10 kohms or higher C38-1 (+) or C1-34 (OC2+) - Body ground Always 10 kohms or higher C38-2 (-) or C1-4 (OC2-) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

P0011 AND P0021: ADVANCED CAMSHAFT TIMING

P0012 AND P0022: RETARDED CAMSHAFT TIMING

If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator (camshaft timing oil control valve assembly) for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.

MONITOR RESULT

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [12/2013 - ]

P0011, P0012: EXHAUST GAS RECIRCULATION/VVT / IN VVT STUCK B1

P0021, P0022: EXHAUST GAS RECIRCULATION/VVT / IN VVT STUCK B2

Scheme 334

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Idle the engine for 3 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0011, P0012, P0021 or P0022.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
14. Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
15. Idle the engine for 3 minutes or more [G].
16. Enter the following menus: Powertrain / Engine / Trouble Codes [H].
17. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
19. Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. If DTC P0011 or P0012 is output, check the VVT system (for intake camshaft of bank 1) circuit.
2. If DTC P0021 or P0022 is output, check the VVT system (for intake camshaft of bank 2) circuit.
3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
5. DTC P0011, P0012, P0021 or P0022 may be stored when foreign matter in the engine oil is caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. That foreign matter may then be captured by the oil filter.
6. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 335

Scheme 336

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0011, P0012, P0021 OR P0022) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0011, P0012, P0021 or P0022 is output A DTC P0011, P0012, P0021 or P0022 and other DTCs are output B HINT: If any DTCs other than P0011, P0012, P0021 or P0022 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Powertrain > Engine > Active Test Tester Display Control the VVT Linear (Bank1) Powertrain > Engine > Active Test Tester Display Control the VVT Linear (Bank2) Check the engine speed while operating the camshaft timing oil control valve assembly (for intake camshaft) using the Techstream. OK Techstream Operation Engine Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1, VVT Change Angle #1, VVT OCV Duty #2, and VVT Change Angle #2]. Refer to «DATA LIST / ACTIVE TEST [12/2013 - ]»(ref-636036-S31466985402014070700000) Result Proceed to OK NG Result: 2 NG See step 4 Result: 1 OK See step 3
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0011, P0012, P0021 OR P0022) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0011, P0012, P0021 or P0022 is output B HINT: DTC P0011, P0012, P0021 or P0022 may be stored when foreign matter in the engine oil is caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. That foreign matter may then be captured by the oil filter. Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 2 B See step 4
4. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for intake camshaft). Refer to «INSPECTION [12/2013 - ]»(ref-636218-S22617490372014070700000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [12/2013 - ]»(ref-636218-S32007268612014070700000) Result: 1 OK See step 5
5. CHECK VALVE TIMING (CHECK FOR LOOSE TIMING CHAIN AND JUMPED TEETH) Remove the cylinder head cover sub-assembly and cylinder head cover sub-assembly LH. Refer to «PROCEDURE - Step 25»(ref-636179-S30297877712014070700000) *a Timing Mark - - Turn the crankshaft pulley, and align its groove with the "0" timing mark of the timing chain cover. Check that the timing marks of the camshaft timing gear assemblies and camshaft timing exhaust gear assemblies are aligned with the timing marks of the bearing cap as shown in the illustration. HINT: If the timing marks are not as shown, turn the crankshaft one revolution clockwise. OK The timing marks on the camshaft timing gear assemblies and camshaft timing exhaust gear assemblies are aligned as shown in the illustration. Result Proceed to OK NG Result: 2 NG ADJUST VALVE TIMING. Refer to «REASSEMBLY [12/2013 - ]»(ref-636179-S14423875652014070700000) Result: 1 OK See step 6
6. INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE *1 Oil Pipe *2 No. 1 Oil Pipe *a Bank 1 *b Bank 2 Remove the oil pipe or No. 1 oil pipe. Refer to «PROCEDURE - Step 14»(ref-636179-S30297877712014070700000) Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. Result Proceed to OK NG Result: 2 NG REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [12/2013 - ]»(ref-636179-S04153612802014070700000) Result: 1 OK See step 7
7. REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly (bank 1 or bank 2). Refer to «REMOVAL [12/2013 - ]»(ref-636179-S36053430212014070700000) HINT: Perform "Inspection After Repair" after replacing the camshaft timing gear assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to NEXT Result: 1 NEXT See step 8
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0011, P0012, P0021 OR P0022) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0011, P0012, P0021 or P0022 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000)

ALL

CASE 1

CASE 2

CASE 1

CASE 2

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0013 or P0023.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 337

HINT

1. If DTC P0013 is output, check the VVT system (for exhaust camshaft of bank 1) circuit.
2. If DTC P0023 is output, check the VVT system (for exhaust camshaft of bank 2) circuit.
3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0013 OR P0023) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC after recording the freeze frame data and DTC. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and wait 5 seconds. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0013 or P0023 is output A DTCs are not output B Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 1 A See step 2
2. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for exhaust camshaft). Refer to «INSPECTION [12/2013 - ]»(ref-636218-S22617490372014070700000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [12/2013 - ]»(ref-636218-S32007268612014070700000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) - ECM) Disconnect the camshaft timing oil control valve assembly (for exhaust camshaft) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C55-1 (+) - C1-33 (OE1+) Always Below 1 ohms C55-2 (-) - C1-3 (OE1-) Always Below 1 ohms C52-1 (+) - C1-32 (OE2+) Always Below 1 ohms C52-2 (-) - C1-2 (OE2-) Always Below 1 ohms C55-1 (+) or C1-33 (OE1+) - Body ground Always 10 kohms or higher C55-2 (-) or C1-3 (OE1-) - Body ground Always 10 kohms or higher C52-1 (+) or C1-32 (OE2+) - Body ground Always 10 kohms or higher C52-2 (-) or C1-2 (OE2-) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

P0014 AND P0024: ADVANCED CAMSHAFT TIMING

P0015 AND P0025: RETARDED CAMSHAFT TIMING

If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator (camshaft timing oil control valve assembly) for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [12/2013 - ]

P0014, P0015: EXHAUST GAS RECIRCULATION/VVT / EX VVT STUCK B1

P0024, P0025: EXHAUST GAS RECIRCULATION/VVT / EX VVT STUCK B2

Scheme 338

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Idle the engine for 3 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0014, P0015, P0024 or P0025.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
14. Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
15. Idle the engine for 3 minutes or more [G].
16. Enter the following menus: Powertrain / Engine / Trouble Codes [H].
17. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
19. Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. If DTC P0014 or P0015 is output, check the VVT system (for exhaust camshaft of bank 1) circuit.
2. If DTC P0024 or P0025 is output, check the VVT system (for exhaust camshaft of bank 2) circuit.
3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
5. DTC P0014, P0015, P0024 or P0025 may be stored when foreign matter in the engine oil is caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. This foreign matter may then be captured by the oil filter.
6. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0014, P0015, P0024 or P0025 is output A DTC P0014, P0015, P0024 or P0025 and other DTCs are output B HINT: If any DTCs other than P0014, P0015, P0024 or P0025 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Powertrain > Engine > Active Test Tester Display Control the VVT Exhaust Linear (Bank1) Powertrain > Engine > Active Test Tester Display Control the VVT Exhaust Linear (Bank2) Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream. OK Techstream Operation Engine Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1, VVT Ex Chg Angle #1, VVT Ex OCV Duty #2 and VVT Ex Chg Angle #2]. Refer to «DATA LIST / ACTIVE TEST [12/2013 - ]»(ref-636036-S31466985402014070700000) Result Proceed to OK NG Result: 2 NG See step 4 Result: 1 OK See step 3
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0014, P0015, P0024 or P0025 is output B HINT: DTC P0014, P0015, P0024 or P0025 may be stored when foreign matter in the engine oil is caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. This foreign matter may then be captured by the oil filter. Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 2 B See step 4
4. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for exhaust camshaft). Refer to «INSPECTION [12/2013 - ]»(ref-636218-S22617490372014070700000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [12/2013 - ]»(ref-636218-S32007268612014070700000) Result: 1 OK See step 5
5. CHECK VALVE TIMING (CHECK FOR LOOSE TIMING CHAIN AND JUMPED TEETH) See step 5 Result Proceed to OK NG Result: 2 NG ADJUST VALVE TIMING. Refer to «REASSEMBLY [12/2013 - ]»(ref-636179-S14423875652014070700000) Result: 1 OK See step 6
6. INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE See step 6 Result Proceed to OK NG Result: 2 NG REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [12/2013 - ]»(ref-636179-S04153612802014070700000) Result: 1 OK See step 7
7. REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Replace the camshaft timing exhaust gear assembly (bank 1 or bank 2). Refer to «REMOVAL [12/2013 - ]»(ref-636179-S36053430212014070700000) HINT: Perform "Inspection After Repair" after replacing the camshaft timing exhaust gear assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to NEXT Result: 1 NEXT See step 8
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0014, P0015, P0024 or P0025 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000)

Scheme 339

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0016 or P0018.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [G].
13. Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Idle the engine for 5 minutes or more [F].
15. Enter the following menus: Powertrain / Engine / Trouble Codes [G].
16. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Check the DTC judgment result.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
2. Bank 2 refers to the bank that does not include the No. 1 cylinder.
3. The monitor for this DTC detects when the timing chain is shifted by one tooth or more (except for Mexico models).
4. The monitor for this DTC detects when the timing chain is shifted by 2 to 3 teeth or more (for Mexico models).
5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0016 or P0018 is output A DTC P0016 or P0018 and other DTCs are output B HINT: If any DTCs other than P0016 or P0018 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) HINT: If the VVT system can be operated through the Active Test, it can be assumed that the VVT system is operating normally. Connect the Techstream to the DLC3. Start the engine. Turn the A/C switch on. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2) / Gas Valve Control / VVT Change Angle #1 or VVT Change Angle #2. Powertrain > Engine > Active Test Active Test Display Control the VVT Linear (Bank1) Data List Display VVT Change Angle #1 Powertrain > Engine > Active Test Active Test Display Control the VVT Linear (Bank2) Data List Display VVT Change Angle #2 Perform the Active Test. Check that the displacement angle varies. OK Displacement angle varies. Result Proceed to OK NG Result: 2 NG See step 4 Result: 1 OK See step 3
3. ADJUST VALVE TIMING Adjust the valve timing. Refer to «REASSEMBLY [12/2013 - ]»(ref-636179-S14423875652014070700000) Result Proceed to NEXT Result: 1 NEXT See step 7
4. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) See step 2 Result Proceed to OK NG Result: 2 NG REPLACE CAM TIMING OIL CONTROL VALVE ASSEMBLY RH (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [12/2013 - ]»(ref-636218-S32007268612014070700000) Result: 1 OK See step 5
5. INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE See step 6 Result Proceed to OK NG Result: 2 NG REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [12/2013 - ]»(ref-636179-S04153612802014070700000) Result: 1 OK See step 6
6. INSPECT CAMSHAFT TIMING GEAR ASSEMBLY Inspect the camshaft timing gear assembly. Refer to «PROCEDURE - Step 4»(ref-636179-S21343292072014070700000) HINT: Perform "Inspection After Repair" after replacing the camshaft timing gear assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING GEAR ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-636179-S36053430212014070700000) Result: 1 OK See step 7
7. CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0016 or P0018 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0017 or P0019.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [G].
13. Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Idle the engine for 5 minutes or more [F].
15. Enter the following menus: Powertrain / Engine / Trouble Codes [G].
16. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Check the DTC judgment result.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
2. Bank 2 refers to the bank that does not include the No. 1 cylinder.
3. The monitor for this DTC detects when the timing chain is shifted by one tooth or more (except for Mexico models).
4. The monitor for this DTC detects when the timing chain is shifted by 2 to 3 teeth or more (for Mexico models).
5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 OR P0019) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0017 or P0019 is output A DTC P0017 or P0019 and other DTCs are output B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR) HINT: If the VVT system can be operated through the Active Test, it can be assumed that the VVT system is operating normally. Connect the Techstream to the DLC3. Start the engine. Turn the A/C switch on. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2) / Gas Valve Control / VVT Ex Chg Angle #1 or VVT Ex Chg Angle #2. Powertrain > Engine > Active Test Active Test Display Control the VVT Exhaust Linear (Bank1) Data List Display VVT Ex Chg Angle #1 Powertrain > Engine > Active Test Active Test Display Control the VVT Exhaust Linear (Bank2) Data List Display VVT Ex Chg Angle #2 Perform the Active Test. Check that the displacement angle varies. OK Displacement angle varies. Result Proceed to OK NG Result: 2 NG See step 4 Result: 1 OK See step 3
3. ADJUST VALVE TIMING Adjust the valve timing. Refer to «REASSEMBLY [12/2013 - ]»(ref-636179-S14423875652014070700000) Result Proceed to NEXT Result: 1 NEXT See step 7
4. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) See step 2 Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [12/2013 - ]»(ref-636218-S32007268612014070700000) Result: 1 OK See step 5
5. INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE See step 6 Result Proceed to OK NG Result: 2 NG REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY [12/2013 - ]»(ref-636179-S04153612802014070700000) Result: 1 OK See step 6
6. INSPECT CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Inspect the camshaft timing exhaust gear assembly. Refer to «PROCEDURE - Step 5»(ref-636179-S21343292072014070700000) HINT: Perform "Inspection After Repair" after replacing the camshaft timing exhaust gear assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-636179-S36053430212014070700000) Result: 1 OK See step 7
7. CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0017 or P0019 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000)

ALL

P0031 AND P0051

P0032 AND P0052

P101D AND P103D

P0031 AND P0051

P0032 AND P0052

P101D AND P103D

P0031 AND P0051

P0032 AND P0052

P101D AND P103D

Scheme 340

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and idle it for 5 minutes or more [B].
7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
8. Idle the engine for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0031, P0032, P0051, P0052, P101D or P103D.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. Refer to "Data List / Active Test" [A/F Heater Duty #1 and A/F Heater Duty #2]. Refer to «DATA LIST / ACTIVE TEST [12/2013 - ]»(ref-636036-S31466985402014070700000)
2. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
3. Bank 2 refers to the bank that does not include the No. 1 cylinder.
4. Sensor 1 refers to the sensor closest to the engine assembly.
5. Sensor 2 refers to the sensor farthest away from the engine assembly.
6. Change the fuel injection volume using the Control the Injection Volume for A/F Sensor function provided in the Active Test and monitor the air fuel ratio sensor output voltage (Refer to «CAUTION / NOTICE / HINT»(ref-636215-S02071655722014070700000) ). If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning.
7. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 341

1. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor. Refer to «INSPECTION [12/2013 - ]»(ref-636218-S28884510522014070700000) HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S18049298032014070700000) Result: 1 OK See step 2
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) *a Front view of wire harness connector (to Air Fuel Ratio Sensor) *b Bank 1 *c Bank 2 Disconnect the air fuel ratio sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C33-2 (+B) - Body ground Ignition switch ON 11 to 14 V C32-2 (+B) - Body ground Ignition switch ON 11 to 14 V Result Proceed to OK NG Result: 2 NG See step 5 Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C33-1 (HA1A) - C1-26 (HA1A) Always Below 1 ohms C32-1 (HA2A) - C1-20 (HA2A) Always Below 1 ohms C33-1 (HA1A) or C1-26 (HA1A) - Body ground Always 10 kohms or higher C32-1 (HA2A) or C1-20 (HA2A) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P0031, P0032, P0051, P0052, P101D OR P103D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0031, P0032, P0051, P0052, P101D or P103D is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000)
5. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - SEMICONDUCTOR PWR INTEGRATION ECU) Disconnect the air fuel ratio sensor connector. Disconnect the semiconductor pwr integration ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C33-2 (+B) - 1F-1 Always Below 1 ohms C32-2 (+B) - 1F-1 Always Below 1 ohms C33-2 (+B) or 1F-1 - Body ground Always 10 kohms or higher C32-2 (+B) or 1F-1 - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE SEMICONDUCTOR PWR INTEGRATION ECU. Refer to «REMOVAL [12/2013 - ]»(ref-636206-S22415638132014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

ALL

P0037 AND P0057 (CASE 1)

P0037 AND P0057 (CASE 2)

P0038 AND P0058

P0141 AND P0161

P102D AND P105D

P0037 AND P0057 (CASE 1)

P0037 AND P0057 (CASE 2)

P0038 AND P0058

P0141 AND P0161

P102D AND P105D

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [12/2013 - ]

P0141: O2 SENSOR HEATER / O2 HEATER B1S2

P0161: O2 SENSOR HEATER / O2 HEATER B2S2

Scheme 342

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and idle it for 5 minutes or more [B].
7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
8. Idle the engine for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0037, P0038, P0057, P0058, P0141, P0161, P102D or P105D.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
2. Bank 2 refers to the bank that does not include the No. 1 cylinder.
3. Sensor 1 refers to the sensor closest to the engine assembly.
4. Sensor 2 refers to the sensor farthest away from the engine assembly.
5. Refer to "Data List / Active Test" [O2 Heater B1S2, O2 Heater B2S2, O2 Heater Curr Val B1S2 and O2 Heater Curr Val B2S2]. Refer to «DATA LIST / ACTIVE TEST [12/2013 - ]»(ref-636036-S31466985402014070700000)
6. When the values for the Data List items O2 Heater Curr Val B1S2 and O2 Heater Curr Val B2S2 are not 0 A, the heaters are on.
7. Change the fuel injection volume using the Control the Injection Volume for A/F Sensor function provided in the Active Test and monitor the heated oxygen sensor output voltage (Refer to «CAUTION / NOTICE / HINT»(ref-636215-S02071655722014070700000) ). If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning.
8. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 343

1. INSPECT HEATED OXYGEN SENSOR (HEATER RESISTANCE) Inspect the heated oxygen sensor. Refer to «INSPECTION [12/2013 - ]»(ref-636218-S07613137782014070700000) HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S05737657262014070700000) Result: 1 OK See step 2
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF HEATED OXYGEN SENSOR) Disconnect the heated oxygen sensor connector. *a Front view of wire harness connector (to Heated Oxygen Sensor) *b Bank 1 *c Bank 2 - - Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition P1-1 (+B) - Body ground Ignition switch ON 11 to 14 V C51-2 (+B) - Body ground Ignition switch ON 11 to 14 V Result Proceed to OK NG Result: 2 NG See step 5 Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Disconnect the heated oxygen sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition P1-2 (HT1B) - C1-28 (HT1B) Always Below 1 ohms C51-1 (HT2B) - C1-22 (HT2B) Always Below 1 ohms P1-2 (HT1B) or C1-28 (HT1B) - Body ground Always 10 kohms or higher C51-1 (HT2B) or C1-22 (HT2B) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P0037, P0038, P0057, P0058, P0141, P0161, P102D OR P105D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0037, P0038, P0057, P0058, P0141, P0161, P102D or P105D is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000)
5. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - SEMICONDUCTOR PWR INTEGRATION ECU) Disconnect the heated oxygen sensor connector. Disconnect the semiconductor pwr integration ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition P1-1 (+B) - 1G-7 Always Below 1 ohms C51-2 (+B) - 1G-7 Always Below 1 ohms P1-1 (+B) or 1G-7 - Body ground Always 10 kohms or higher C51-2 (+B) or 1G-7 - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE SEMICONDUCTOR PWR INTEGRATION ECU. Refer to «REMOVAL [12/2013 - ]»(ref-636206-S22415638132014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

Scheme 344

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
8. Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
9. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0101.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [12/2013 - ]»(ref-636220-S13405134682014070700000) OK No leaks from intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE INTAKE SYSTEM Result: 1 OK See step 3
3. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS [12/2013 - ]»(ref-636189-S21220954782014070700000) OK PCV valve and hose are connected correctly and are not damaged. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE PCV HOSE Result: 1 OK See step 4
4. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S19888308122014070700000) HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to NEXT Result: 1 NEXT See step 5
5. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Powertrain > Engine > Utility Tester Display All Readiness Input the DTC: P0101. Check the DTC judgment result. Result Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit Result Proceed to NEXT Result: 1 NEXT END

P0102

P0103

Scheme 345

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 5 seconds [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Run the engine at an engine speed of 4000 RPM or higher for 5 seconds [D].
11. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
12. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Input the DTC: P0102 or P0103.
15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 346

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0102 OR P0103) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0102 is output A DTC P0103 is output B Result: 2 B See step 6 Result: 1 A See step 2
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF MASS AIR FLOW METER SUB-ASSEMBLY) *a Front view of wire harness connector (to Mass Air Flow Meter Sub-assembly) Disconnect the mass air flow meter sub-assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C8-3 (+B) - Body ground Ignition switch ON 11 to 14 V Result Proceed to OK NG Result: 2 NG See step 5 Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C8-5 (VG) - C1-98 (VG) Always Below 1 ohms C8-4 (E2G) - C1-130 (E2G) Always Below 1 ohms C8-5 (VG) or C1-98 (VG) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Inspect the mass air flow meter sub-assembly, referring to the On-vehicle Inspection for Mass Air Flow Meter. Refer to «ON-VEHICLE INSPECTION [12/2013 - ]»(ref-636218-S40834121882014070700000) Inspect the mass air flow meter sub-assembly, referring to the Inspection for Mass Air Flow Meter. Refer to «INSPECTION [12/2013 - ]»(ref-636218-S26554695922014070700000) Inspect the function of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / MAF. Powertrain > Engine > Data List Tester Display MAF Start the engine. Check that the MAF value changes when the engine is raced. OK The reading changes. HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S19888308122014070700000)
5. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - SEMICONDUCTOR PWR INTEGRATION ECU) Disconnect the mass air flow meter sub-assembly connector. Disconnect the semiconductor pwr integration ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C8-3 (+B) - 1G-7 Always Below 1 ohms C8-3 (+B) or 1G-7 - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE SEMICONDUCTOR PWR INTEGRATION ECU. Refer to «REMOVAL [12/2013 - ]»(ref-636206-S22415638132014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
6. CHECK HARNESS AND CONNECTOR (SENSOR GROUND) Disconnect the mass air flow meter sub-assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C8-4 (E2G) - Body ground Always Below 1 ohms HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S19888308122014070700000) Result: 2 NG See step 7
7. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C8-4 (E2G) - C1-130 (E2G) Always Below 1 ohms Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

ALL

AFTER ENGINE STOP

AFTER COLD ENGINE START

AFTER ENGINE STOP

AFTER COLD ENGINE START

Scheme 347

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter sub-assembly) is malfunctioning. It is not necessary to continue this procedure.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0111.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F].
13. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F] again.
15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result: 1 A GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 2 B REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S19888308122014070700000)

Scheme 348

The intake air temperature sensor, mounted on the mass air flow meter sub-assembly, monitors the intake air temperature. The intake air temperature sensor has a built-in thermistor with a resistance that varies according to the temperature of the intake air. When the intake air temperature is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes see scheme 1

The intake air temperature sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.

Resistor R and the intake air temperature sensor are connected in series. When the resistance value of the intake air temperature sensor changes, according to changes in the intake air temperature, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability.

HINT

When DTC P0112 or P0113 is stored, the ECM enters fail-safe mode. During fail-safe mode, the intake air temperature is estimated to be 20°C (68°F) by the ECM. Fail-safe mode continues until a pass condition is detected.

HINT

When any of these DTCs are output, check the intake air temperature using the Techstream. Enter the following menus: Powertrain / Engine / Data List / Primary / Intake Air.

P0112

P0113

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 0.5 seconds or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0112 or P0113.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 349

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (INTAKE AIR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Intake Air. Powertrain > Engine > Data List Tester Display Intake Air Read the value displayed on the Techstream. OK Same as actual intake air temperature. Result Result Proceed to -40°C (-40°F) A Higher than 128°C (262°F) B Same as actual intake air temperature C HINT: If there is an open circuit, the Techstream indicates -40°C (-40°F). If there is a short circuit, the Techstream indicates higher than 128°C (262°F). Result: 2 B See step 4 Result: 3 C CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (CHECK FOR OPEN IN WIRE HARNESS) Disconnect the mass air flow meter sub-assembly connector. *1 Mass Air Flow Meter Sub-assembly *2 ECM *a Front view of wire harness connector (to Mass Air Flow Meter Sub-assembly) - - Connect terminals C8-1 (THA) and C8-2 (E2) of the mass air flow meter sub-assembly connector on the wire harness side. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Intake Air. Powertrain > Engine > Data List Tester Display Intake Air Read the value displayed on the Techstream. Standard Value Higher than 128°C (262°F) HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S19888308122014070700000) Result: 2 NG See step 3
3. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C8-1 (THA) - C1-96 (THA) Always Below 1 ohms C8-2 (E2) - C1-118 (ETHA) Always Below 1 ohms Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
4. READ VALUE USING TECHSTREAM (CHECK FOR SHORT IN WIRE HARNESS) *1 Mass Air Flow Meter Sub-assembly *2 ECM Disconnect the mass air flow meter sub-assembly connector. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Intake Air. Powertrain > Engine > Data List Tester Display Intake Air Read the value displayed on the Techstream. Standard Value -40°C (-40°F) HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S19888308122014070700000) Result: 2 NG See step 5
5. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C8-1 (THA) or C1-96 (THA) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

P0115

P0117

P0118

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 0.5 seconds or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0115, P0117 or P0118.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 350

HINT

1. If DTC P0117 is stored, check that the engine does not overheat (the DTC P0117 may be stored due to engine overheating).
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp. Powertrain > Engine > Data List Tester Display Coolant Temp Read the value displayed on the Techstream. Standard Value Between 75 and 100°C (167 and 212°F) with warm engine. Result Result Proceed to -40°C (-40°F) A Higher than 135°C (275°F) B Between 75 and 100°C (167 and 212°F) C HINT: If there is an open circuit, the Techstream indicates -40°C (-40°F). If there is a short circuit, the Techstream indicates higher than 135°C (275°F). Result: 2 B See step 4 Result: 3 C CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (CHECK FOR OPEN IN WIRE HARNESS) Disconnect the engine coolant temperature sensor connector. *1 Engine Coolant Temperature Sensor *2 ECM *a Front view of wire harness connector (to Engine Coolant Temperature Sensor) - - Connect terminals C17-1 and C17-2 of the engine coolant temperature sensor connector on the wire harness side. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp. Powertrain > Engine > Data List Tester Display Coolant Temp Read the value displayed on the Techstream. Standard Value Higher than 135°C (275°F) HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S21413699072014070700000) Result: 2 NG See step 3
3. CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the engine coolant temperature sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C17-2 - C1-114 (THW) Always Below 1 ohms C17-1 - C1-117 (ETHW) Always Below 1 ohms Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
4. READ VALUE USING TECHSTREAM (CHECK FOR SHORT IN WIRE HARNESS) *1 Engine Coolant Temperature Sensor *2 ECM Disconnect the engine coolant temperature sensor connector. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp. Powertrain > Engine > Data List Tester Display Coolant Temp Read the value displayed on the Techstream. Standard Value -40°C (-40°F) HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S21413699072014070700000) Result: 2 NG See step 5
5. CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the engine coolant temperature sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C17-2 or C1-114 (THW) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

ALL

COLD START MONITOR

SOAK MONITOR

COLD START MONITOR

SOAK MONITOR

Scheme 351

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp.
4. Check that the engine coolant temperature is 60°C (140°F) or less.
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
6. Turn the ignition switch off and wait for at least 30 seconds.
7. Turn the ignition switch to ON and turn the Techstream on [A].
8. Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
9. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0116.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E].
14. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
15. Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E] again.
16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. If any of DTCs P0115, P0117, P0118 or P0125 are output simultaneously with DTC P0116, the engine coolant temperature sensor may have an open or a short circuit. Troubleshoot those DTCs first.
2. When the DTC is output, check the engine coolant temperature using the Techstream. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp. If the Coolant Temp value is lower than the actual engine coolant temperature, the engine coolant temperature sensor circuit may be malfunctioning. In this case, check the wire harnesses and connectors (and those connections) between the ECM and the engine coolant temperature sensor first.
3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs and other than P0116 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. INSPECT THERMOSTAT Inspect the thermostat (thermostat opening temperature). Refer to «INSPECTION [12/2013 - ]»(ref-636183-S25770826382014070700000) HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S21413699072014070700000) Result: 2 NG REPLACE THERMOSTAT. Refer to «REMOVAL [12/2013 - ]»(ref-636183-S40218269612014070700000)

Scheme 352

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on [A].
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off.
5. With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine and wait 60 seconds or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P011B.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] through [D] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (INTAKE AIR) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to create conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Intake Air. Powertrain > Engine > Data List Tester Display Intake Air Read the value displayed on the Techstream. Standard Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the outside temperature gauge of the vehicle (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent swings in the temperature display. Use an accurate thermometer to determine the outside air temperature. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S19888308122014070700000) Result: 1 OK See step 3
3. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp. Powertrain > Engine > Data List Tester Display Coolant Temp Read the value displayed on the Techstream. Standard The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are no heat sources such as a block heater in the engine compartment. Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S21413699072014070700000)

ALL

P0120, P0122, P0123, P0220, P0222, P0223 AND P2135

P0121

P0120

P0121

P0122

P0123

P0220

P0222

P0223

P2135 (CASE 1)

P2135 (CASE 2)

Scheme 353

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. With the vehicle stationary, fully depress and release the accelerator pedal [B].
8. Idle the engine for 2 seconds or more [C].
9. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [D] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When any of these DTCs or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle valve opening angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is turned off.

Scheme 354

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (THROTTLE POSITION SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Gas Throttle / Throttle Position No. 1 and Throttle Position No. 2. Powertrain > Engine > Data List Tester Display Throttle Position No. 1 Throttle Position No. 2 Read the values displayed on the Techstream. Result When Accelerator Pedal Fully Released When Accelerator Pedal Fully Depressed Trouble Area Proceed to Throttle Position No. 1 (VTA1) Throttle Position No. 2 (VTA2) Throttle Position No. 1 (VTA1) Throttle Position No. 2 (VTA2) 0 to 0.2 V 0 to 0.2 V 0 to 0.2 V 0 to 0.2 V VCTA circuit open A 4.5 to 4.98 V 4.5 to 4.98 V 4.5 to 4.98 V 4.5 to 4.98 V ETA circuit open 0 to 0.2 V, or 4.5 to 4.98 V 2.1 to 3.1 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V 2.1 to 3.1 V (Fail-safe) VTA1 circuit open or shorted to ground 0.6 to 1.4 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V 0.6 to 1.4 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V VTA2 circuit open or shorted to ground 0.5 to 1.1 V 2.1 to 3.1 V 3.2 to 4.8 V (Not fail-safe) 4.6 to 4.98 V (Not fail-safe) Throttle position sensor circuit normal B HINT: DTC P0121 is stored when the VTA1 and VTA2 output voltages are not consistent with the sensor characteristics. Therefore, check the freeze frame data when this DTC is stored. Use the following formula to confirm the relative differences in voltage. Characteristic Sensor Output VTA2 x 0.8 is approximately equal to VTA1 + 1.11 V VTA1: Throttle Position No. 1 VTA2: Throttle Position No. 2 If DTC P0121 is output, proceed to "Check Harness And Connector (Throttle Position Sensor - ECM)". Result: 2 B See step 5 Result: 1 A See step 2
2. CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - ECM) Disconnect the throttle body with motor assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C41-5 (VC) - C1-126 (VCTA) Always Below 1 ohms C41-6 (VTA) - C1-128 (VTA1) Always Below 1 ohms C41-4 (VTA2) - C1-127 (VTA2) Always Below 1 ohms C41-3 (E2) - C1-125 (ETA) Always Below 1 ohms C41-5 (VC) or C1-126 (VCTA) - Body ground Always 10 kohms or higher C41-6 (VTA) or C1-128 (VTA1) - Body ground Always 10 kohms or higher C41-4 (VTA2) or C1-127 (VTA2) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 3
3. INSPECT ECM (VC VOLTAGE) *a Front view of wire harness connector (to Throttle Body with Motor Assembly) Disconnect the throttle body with motor assembly connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C41-5 (VC) - C41-3 (E2) Ignition switch ON 4.5 to 5.5 V Result Proceed to OK NG Result: 2 NG REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 1 OK See step 4
4. REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY Replace the throttle body with motor assembly. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S20287519552014070700000) HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to NEXT Result: 1 NEXT See step 5
5. CHECK WHETHER DTC OUTPUT RECURS (THROTTLE POSITION SENSOR DTCS) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) Powertrain > Engine > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0120, P0121, P0122, P0123, P0220, P0222, P0223, and/or P2135 are output A DTCs are not output B Result: 1 A REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 B END

1. Leave the vehicle outside overnight.
2. Connect the Techstream to the DLC3.
3. Turn the ignition switch to ON and turn the Techstream on.
4. Enter the following menus: Powertrain / Engine / Trouble Codes.
5. Read the DTC and record the Freeze Frame Data.
6. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
7. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp.
8. Check that the Coolant Temp is the same or less than Initial Engine Coolant Temp in the freeze frame data.
9. Turn the ignition switch off and wait for at least 30 seconds.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Start the engine.
12. Wait 21 minutes or more.
13. Enter the following menus: Powertrain / Engine / Trouble Codes.
14. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
16. Input the DTC: P0125.
17. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. If any of DTCs P0115, P0116, P0117 or P0118 are output simultaneously with DTC P0125, the engine coolant temperature sensor may have an open or a short circuit. Troubleshoot those DTCs first.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. INSPECT THERMOSTAT Inspect the thermostat (thermostat opening temperature). Refer to «INSPECTION [12/2013 - ]»(ref-636183-S25770826382014070700000) Result Proceed to OK NG Result: 2 NG REPLACE THERMOSTAT. Refer to «REMOVAL [12/2013 - ]»(ref-636183-S40218269612014070700000) Result: 1 OK See step 3
3. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal cooling fan operation or any modifications. HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S21413699072014070700000) Result: 2 NG REPAIR OR REPLACE COOLING SYSTEM

Scheme 355

1. Stop the engine and allow it to soak.
2. Connect the Techstream to the DLC3.
3. Turn the ignition switch to ON and turn the Techstream on [A].
4. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp and Intake Air.
5. Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
6. Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
7. Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snapshot Configure / Duration / 5 min. Data capture can be started by using the target point function. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or higher will cause data capture to start.
8. After "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is less than 75°C (167°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.

HINT

1. When the DTC is output, check the engine coolant temperature using the Techstream. Enter the following menus: Powertrain / Engine / Data List / Primary / Coolant Temp. If the Coolant Temp value is lower than the actual engine coolant temperature, the engine coolant temperature sensor circuit may be malfunctioning. In this case, check the wire harnesses and connectors (and those connections) between the ECM and the engine coolant temperature sensor first.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal cooling fan operation or any modifications. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE COOLING SYSTEM Result: 1 OK See step 3
3. INSPECT THERMOSTAT Inspect the thermostat (thermostat opening temperature). Refer to «INSPECTION [12/2013 - ]»(ref-636183-S25770826382014070700000) Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPLACE THERMOSTAT. Refer to «REMOVAL [12/2013 - ]»(ref-636183-S40218269612014070700000)

P0136, P0137, P0138, P0139, P0156, P0157, P0158 AND P0159

P013A AND P013C

P0136, P0137, P0156 AND P0157: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION AND LOW VOLTAGE)

P0136 AND P0156: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)

P0137 AND P0157: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)

P0138 AND P0158: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)

P0139 AND P0159: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT

P013A AND P013C: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT FROM RICH CONDITION

P0136 AND P0156: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION)

P0137 AND P0157: HEATED OXYGEN SENSOR VOLTAGE CHECK (LOW VOLTAGE)

P0136 AND P0156: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)

P0137 AND P0157: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)

P0138 AND P0158: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)

P0139 AND P0159: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT

P013A AND P013C: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT FROM RICH CONDITION

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [12/2013 - ]

P0137: O2 SENSOR / MAX VOL B1S2

P0139: O2 SENSOR / F/C TIME B1S2

P0136: O2 SENSOR / MAX OSC B1S2

P013A: O2 SENSOR / RL F/C B1S2

P013C: O2 SENSOR / RL F/C B2S2

P0157: O2 SENSOR / MAX VOL B2S2

P0159: O2 SENSOR / F/C TIME B2S2

P0156: O2 SENSOR / MAX OSC B2S2

HINT

1. This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
2. Performing this confirmation driving pattern will activate the heated oxygen sensor monitor (the catalyst monitor is performed simultaneously). This is very useful for verifying the completion of a repair.

P0136, P0137, P0138, P0156, P0157 and P0158

Scheme 356

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. With the shift lever in D, drive the vehicle at 60 to 120 km/h (37 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Enter the following menus: Powertrain / Engine / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] and [D] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

P0139, P013A, P013C and P0159

Scheme 357

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor.
8. Check that Catalyst Efficiency / Current is Incomplete.
9. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with the shift lever in P [A]. HINT: In order to keep the idle stable, turn the A/C and all other electric loads off and do not perform any shift operations.
10. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible.
11. With the shift lever in S, drive the vehicle at 60 km/h (37 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
12. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / O2 Sensor / RL F/C B1S2, RL F/C B2S2 [D].
13. Check the Test Value for RL F/C B1S2, RL F/C B2S2. HINT: If Test Value displays 0, perform step [C] until it displays a value larger than 0, as the O2 sensor monitor is not finished.
14. Repeat step [C] 2 times or more in one driving cycle.
15. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
16. Read the pending DTCs [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
18. Input the DTC: P0139, P013A, P013C or P0159.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, drive the vehicle with the shift lever in S, and then perform step [C] again.
20. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 358

HINT

Malfunctioning areas can be identified by performing the Control the Injection Volume for A/F Sensor function provided in the Active Test. The Control the Injection Volume for A/F Sensor function can help to determine whether the air fuel ratio sensor, heated oxygen sensor and other potential trouble areas are malfunctioning.

The following instructions describe how to conduct the Control the Injection Volume for A/F Sensor operation using the Techstream.

1. Connect the Techstream to the DLC3.
2. Start the engine.
3. Turn the Techstream on.
4. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds.
5. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2.
6. Perform the Active Test operation with the engine idling (press the 12.5% or -12.5% button to change the fuel injection volume).
7. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream.

HINT

1. The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%.
2. Each sensor reacts in accordance with increases and decreases in the fuel injection volume.

Note. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds.

Scheme 359

1. Following the Control the Injection Volume for A/F Sensor procedure enables technicians to check and graph the voltage outputs of both the air fuel ratio and heated oxygen sensors.
2. To display the graph, enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2; and then press the graph button on the Data List view.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
2. Bank 2 refers to the bank that does not include the No. 1 cylinder.
3. Sensor 1 refers to the sensor closest to the engine assembly.
4. Sensor 2 refers to the sensor farthest away from the engine assembly.
5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0136, P0137, P0138, P0139, P013A, P013C, P0156, P0157, P0158 OR P0159) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P0138 or P0158 is output A DTC P0137 or P0157 is output B DTC P0136 or P0156 is output C DTC P0139, P013A, P013C or P0159 is output D DTC P0136, P0137, P0138, P0139, P013A, P013C, P0156, P0157, P0158 or P0159 and other DTCs are output E HINT: If any DTCs other than P0136, P0137, P0138, P0139, P013A, P013C, P0156, P0157, P0158 or P0159 are output, troubleshoot those DTCs first. Result: 2 B See step 9 Result: 3 C See step 4 Result: 4 D See step 15 Result: 5 E GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) *a Component without harness connected (Heated Oxygen Sensor) *b Bank 1 *c Bank 2 Disconnect the heated oxygen sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (+B) - 3 (E2) Always 10 kohms or higher 1 (+B) - 4 (OX1B) Always 10 kohms or higher 2 (+B) - 4 (E2) Always 10 kohms or higher 2 (+B) - 3 (OX2B) Always 10 kohms or higher HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S05737657262014070700000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT) Turn the ignition switch off and wait for 5 minutes or more. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C1-28 (HT1B) - C1-101 (OX1B) Always 10 kohms or higher C1-22 (HT2B) - C1-133 (OX2B) Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S23761333972014070700000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / O2S B1S2 or O2S B2S2. Powertrain > Engine > Active Test Active Test Display Control the Injection Volume for A/F Sensor Data List Display O2S B1S2 O2S B2S2 Change the fuel injection volume using the Techstream, and monitor the voltage output of the heated oxygen sensor displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%. The heated oxygen sensor has a maximum output delay of approximately 20 seconds. Standard Voltage Fluctuates between 0.4 V or less, and 0.55 V or higher. Result Proceed to OK NG Result: 2 NG See step 9 Result: 1 OK See step 5
5. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2. Powertrain > Engine > Active Test Active Test Display Control the Injection Volume for A/F Sensor Data List Display AFS Voltage B1S1 AFS Voltage B2S1 O2S B1S2 O2S B2S2 Change the fuel injection volume using the Techstream, and monitor the voltage output of the air fuel ratio and heated oxygen sensors displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%. The air fuel ratio sensor is displayed as AFS Voltage B1S1 or AFS Voltage B2S1, and the heated oxygen sensor is displayed as O2S B1S2 or O2S B2S2 on the Techstream. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Result Techstream Display (Sensor) Voltage Variation Proceed to AFS Voltage B1S1 AFS Voltage B2S1 (Air fuel ratio) Alternates between higher and less than 3.3 V OK Remains at higher than 3.3 V NG Remains at less than 3.3 V HINT: A normal heated oxygen sensor voltage (O2S B1S2 or O2S B2S2) reacts in accordance with increases and decreases in fuel injection volumes. When the air fuel ratio sensor voltage (AFS Voltage B1S1 or AFS Voltage B2S1) remains at either less or higher than 3.3 V despite the heated oxygen sensor indicating a normal reaction, the air fuel ratio sensor is malfunctioning. Result: 1 OK CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO (FUEL INJECTOR ASSEMBLY, FUEL SYSTEM, INTAKE SYSTEM, ETC.). Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2) [12/2013 - ]»(ref-636216-S03521412142014070700000) Result: 2 NG See step 6
6. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S18049298032014070700000) HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to NEXT Result: 1 NEXT See step 7
7. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0136, P0137, P0138, P0156, P0157 and P0158). Result Proceed to NEXT Result: 1 NEXT See step 8
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136 OR P0156) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Powertrain > Engine > Utility Tester Display All Readiness Input the DTC: P0136 or P0156. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the drive pattern again but increase the vehicle speed. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P0136 or P0156 is output) B HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result: 1 A END Result: 2 B REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S05737657262014070700000)
9. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE EXHAUST GAS LEAK POINT Result: 1 OK See step 10
10. INSPECT HEATED OXYGEN SENSOR (HEATER RESISTANCE) See step 1 Result Proceed to OK NG Result: 2 NG REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S05737657262014070700000) Result: 1 OK See step 11
11. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Disconnect the heated oxygen sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition P1-2 (HT1B) - C1-28 (HT1B) Always Below 1 ohms P1-4 (OX1B) - C1-101 (OX1B) Always Below 1 ohms P1-3 (E2) - C1-102 (EX1B) Always Below 1 ohms C51-1 (HT2B) - C1-22 (HT2B) Always Below 1 ohms C51-3 (OX2B) - C1-133 (OX2B) Always Below 1 ohms C51-4 (E2) - C1-134 (EX2B) Always Below 1 ohms P1-2 (HT1B) or C1-28 (HT1B) - Body ground Always 10 kohms or higher P1-4 (OX1B) or C1-101 (OX1B) - Body ground Always 10 kohms or higher C51-1 (HT2B) or C1-22 (HT2B) - Body ground Always 10 kohms or higher C51-3 (OX2B) or C1-133 (OX2B) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 12
12. REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S05737657262014070700000) HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to NEXT Result: 1 NEXT See step 13
13. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0136, P0137, P0138, P0156, P0157 and P0158). Result Proceed to NEXT Result: 1 NEXT See step 14
14. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136, P0137, P0156 OR P0157) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Powertrain > Engine > Utility Tester Display All Readiness Input the DTC: P0136, P0137, P0156 or P0157. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the drive pattern again but increase the vehicle speed. Result Result Proceed to ABNORMAL (DTC P0136, P0137, P0156 or P0157 is output) A NORMAL (DTCs are not output) B HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result: 1 A REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S18049298032014070700000) Result: 2 B END
15. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE EXHAUST GAS LEAK POINT Result: 1 OK See step 16
16. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Turn the ignition switch off and wait for 5 minutes or more. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C1-28 (HT1B) - C1-101 (OX1B) Always 10 kohms or higher C1-22 (HT2B) - C1-133 (OX2B) Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 17
17. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0139, P013A, P013C and P0159). Result Proceed to NEXT Result: 1 NEXT See step 18
18. READ OUTPUT DTC (DTC P0139, P013A, P013C OR P0159 IS OUTPUT AGAIN) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Powertrain > Engine > Utility Tester Display All Readiness Input the DTC: P0139, P013A, P013C or P0159. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the drive pattern again but increase the vehicle speed. Result Result Proceed to ABNORMAL (DTC P0139, P013A, P013C or P0159 is output) A NORMAL (DTCs are not output) B HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result: 1 A REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S05737657262014070700000) Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000)

P014C AND P014E: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (RICH TO LEAN RESPONSE RATE)

P014D AND P014F: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (LEAN TO RICH RESPONSE RATE)

P015A AND P015C: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (RICH TO LEAN DELAY)

P015B AND P015D: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (LEAN TO RICH DELAY)

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [12/2013 - ]

P014C: O2 SENSOR / RL RES RATE B1S1

P014D: O2 SENSOR / LR RES RATE B1S1

P014E: O2 SENSOR / RL RES RATE B2S1

P014F: O2 SENSOR / LR RES RATE B2S1

P015A: O2 SENSOR / RL DELAY B1S1

P015B: O2 SENSOR / LR DELAY B1S1

P015C: O2 SENSOR / RL DELAY B2S1

P015D: O2 SENSOR / LR DELAY B2S1

HINT

Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.

Scheme 360

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor.
8. Check that O2 Sensor / Current is Incomplete. HINT: The test values for the test items RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1 do not exist in the Detail of O2 Sensor monitor at this time (the initial value of "0.000" is indicated in each test item).
9. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
10. Drive the vehicle at a constant speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Check that O2 Sensor / Current becomes Complete. HINT: Check the test values on the Techstream by entering the following menus: Powertrain / Engine / Monitor / Current Monitor / O2 Sensor / Details / RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1.
12. If the monitor item O2 Sensor / Current does not become Complete (if the test values indicated on the Techstream do not change), perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «CHECKING MONITOR STATUS [12/2013 - ]»(ref-636036-S22540846182014070700000)
13. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
14. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
16. Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D.
17. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [12/2013 - ]»(ref-636036-S39197130512014070700000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. A low air fuel ratio sensor voltage could be caused by a rich air fuel mixture. Check for conditions that would cause the engine to run rich.
2. A high air fuel ratio sensor voltage could be caused by a lean air fuel mixture. Check for conditions that would cause the engine to run lean.
3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
5. Sensor 1 refers to the sensor closest to the engine assembly.
6. Sensor 2 refers to the sensor farthest away from the engine assembly.
7. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was moving or stationary, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-636036-S07011333302014070700000) Result: 1 A See step 2
2. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 Result Proceed to OK NG Result: 2 NG REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S18049298032014070700000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Refer to «PROCEDURE - Step 1»(ref-636213-S28700571332014070700000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. CHECK AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensor is installed to the vehicle. HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to OK NG Result: 2 NG REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S18049298032014070700000) Result: 1 OK See step 5
5. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to Confirmation Driving Pattern. Result Proceed to NEXT Result: 1 NEXT See step 6
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTCs are not output B Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [12/2013 - ]»(ref-636036-S34982925422014070700000) Result: 1 A See step 7
7. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [12/2013 - ]»(ref-636218-S18049298032014070700000) HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [12/2013 - ]»(ref-636036-S08872600722014070700000) Result Proceed to NEXT Result: 1 NEXT See step 8
8. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to Confirmation Driving Pattern. Result Proceed to NEXT Result: 1 NEXT See step 9
9. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine > Trouble Codes Result Result Proceed to DTCs are not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output B Result: 1 A END Result: 2 B CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2) [12/2013 - ]»(ref-636216-S03521412142014070700000)
