Engine Control System (2GR-FXE) (Diagnostic Codes (P0300 - P1423)) (Hybrid): Other Toyota Highlander III

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

MISFIRE

MONITOR PERIOD OF EMISSION-RELATED MISFIRE

MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)

TYPICAL MALFUNCTION THRESHOLDS

MONITOR PERIOD OF EMISSION-RELATED MISFIRE

MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)

MONITOR RESULT

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [02/2014 - ]

P0300: MISFIRE / EWMA MISFIRE

P0300: MISFIRE / MISFIRE RATE

P0301: MISFIRE / EWMA MISFIRE1

P0301: MISFIRE / MISFIRE RATE1

P0302: MISFIRE / EWMA MISFIRE2

P0302: MISFIRE / MISFIRE RATE2

P0303: MISFIRE / EWMA MISFIRE3

P0303: MISFIRE / MISFIRE RATE3

P0304: MISFIRE / EWMA MISFIRE4

P0304: MISFIRE / MISFIRE RATE4

P0305: MISFIRE / EWMA MISFIRE5

P0305: MISFIRE / MISFIRE RATE5

P0306: MISFIRE / EWMA MISFIRE6

P0306: MISFIRE / MISFIRE RATE6

HINT

*: EWMA (Exponential Weighted Moving Average) misfire counts for last 10 driving cycles (calculated) Calculation: 0.1 x (current counts) + 0.9 x (previous average)

Initial value for (previous average) = 0

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG).
3. Turn the Techstream on.
4. Record the DTC(s) and freeze frame data.
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE [02/2014 - ]»(ref-644155-S02505646652014072300000)
8. Read the misfire count of each cylinder (Cylinder #1 Misfire Count to Cylinder #6 Misfire Count) with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
9. Drive the vehicle so that the vehicle conditions displayed in Misfire RPM and Misfire Load of the Data List are the same as the freeze frame data. Perform this step several times. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, confirm the Misfire RPM and Misfire Load in the Data List. Engine speed Duration Idling 4.5 minutes or more 1000 4.5 minutes or more 2000 2.5 minutes or more 3000 1.5 minutes or more
10. Check whether misfires have occurred by checking for DTCs and freeze frame data. HINT: Do not turn the power switch off until the output DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data are cleared.
11. Record the DTC(s), freeze frame data and misfire counts.
12. Turn the power switch off and wait for at least 30 seconds.
13. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).

CAUTION / NOTICE / HINT

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. If any DTCs other than misfire DTCs are output, troubleshoot those DTCs first.
2. If the misfire does not recur when the vehicle is brought to the workshop, reproduce the conditions stored in the ECM as freeze frame data.
3. If the misfire still cannot be reproduced even though the conditions stored in the ECM as freeze frame data have been reproduced, the following factors can be considered to be a possible cause of the problem: There was insufficient fuel in the tank. Improper fuel was used. The spark plugs have been contaminated. The problem requires further diagnosis.
4. After finishing repairs, check the misfire counts of the cylinders (Cylinder #1 Misfire Count to Cylinder #6 Misfire Count).
5. Be sure to confirm that no misfiring cylinder DTCs are stored again by conducting the confirmation driving pattern after finishing repairs.
6. For 6 cylinder engine, the ECM intentionally does not set the specific misfiring cylinder DTCs at high engine speed. If misfires occur only in high engine speed areas, only DTC P0300 is set. In the event of DTC P0300 being present, perform the following operations: Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Start the engine and conduct the confirmation driving pattern. Read the misfiring counts of each cylinder or DTC(s) using the Techstream. Repair the cylinder(s) that has a high misfiring rate or is indicated by the DTC. After finishing repairs, conduct the confirmation driving pattern again, in order to verify that DTC P0300 is not set.
7. When one of Short FT #1, Long FT #1, Short FT #2 or Long FT #2 in the freeze frame data is outside the range of +/-20%, the air fuel ratio may be rich (-20% or less) or lean (+20% or higher).
8. When Coolant Temp in the freeze frame data is less than 75°C (167°F), the misfires have occurred only while warming up the engine.
9. An extremely imbalanced drive wheel which causes body vibration may cause misfire DTCs to be stored.
10. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

PROCEDURE

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO MISFIRE DTCS) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0300, P0301, P0302, P0303, P0304, P0305 and/or P0306 are output A DTC P0300, P0301, P0302, P0303, P0304, P0305 and/or P0306 and other DTCs are output B HINT: If any DTCs other than P0300, P0301, P0302, P0303, P0304, P0305 and/or P0306 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000) Result: 1 A See step 2
2. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS [02/2014 - ]»(ref-644279-S05903964552014072300000) OK PCV valve and hose are correctly connected and are not damaged. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE PCV HOSE Result: 1 OK See step 3
3. READ VALUE USING TECHSTREAM (MISFIRE RPM AND MISFIRE LOAD) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Misfire / Misfire RPM and Misfire Load. Powertrain > Engine and ECT > Data List Tester Display Misfire RPM Misfire Load Read and note the Misfire RPM and Misfire Load values. HINT: The Misfire RPM and Misfire Load values indicate the vehicle conditions under which the misfire occurred. Result Proceed to NEXT Result: 1 NEXT See step 4
4. READ VALUE USING TECHSTREAM (CYLINDER MISFIRE COUNT) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Misfire / Cylinder #1 Misfire Count, Cylinder #2 Misfire Count, Cylinder #3 Misfire Count, Cylinder #4 Misfire Count, Cylinder #5 Misfire Count and Cylinder #6 Misfire Count. Powertrain > Engine and ECT > Data List Tester Display Cylinder #1 Misfire Count Cylinder #2 Misfire Count Cylinder #3 Misfire Count Cylinder #4 Misfire Count Cylinder #5 Misfire Count Cylinder #6 Misfire Count Start the engine and allow the engine to idle. Read each value for Cylinder #1 Misfire Count to Cylinder #6 Misfire Count displayed on the Techstream. If no misfire counts occur in any cylinders, perform procedure [A] and [B] and then check the misfire counts again. Drive the vehicle with the Misfire RPM and Misfire Load noted in the "Read Value Using Techstream (Misfire RPM And Misfire Load)" procedures above [A]. Read the Cylinder #1 Misfire Count to Cylinder #6 Misfire Count or DTCs displayed on the Techstream [B]. Result Result Proceed to Most misfires occur in only 1 or 2 cylinders A 3 cylinders or more have equal misfire counts B HINT: If it is difficult to reproduce misfires for each cylinder, check the Data List item called Misfire Margin. Try to find vehicle driving conditions that lower the Misfire Margin value. Values above 30% are considered normal. If the freeze frame data record of the engine coolant temperature is less than 75°C (167°F), the misfire may be detected only when the engine is cold. Result: 2 B See step 18 Result: 1 A See step 5
5. INSPECT SPARK PLUG Inspect the spark plug of the misfiring cylinder. Refer to «PROCEDURE - Step 3»(ref-644277-S12162481162014072300000) HINT: Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE SPARK PLUG. Refer to «PROCEDURE - Step 3»(ref-644290-S26380278512014072300000) Result: 1 OK See step 6
6. CHECK FOR SPARKS (SPARK TEST) Perform a spark test. Refer to «PROCEDURE - Step 1»(ref-644277-S12162481162014072300000) HINT: If the result of the spark test is normal, proceed to the next step. Perform "Inspection After Repair" after repairing or replacing the ignition system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 7
7. CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «PROCEDURE - Step 10»(ref-644274-S21221184282014072300000) HINT: Perform "Inspection After Repair" after repairing or replacing the engine assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION Result: 1 OK See step 8
8. CHECK TERMINAL VOLTAGE (#10, #20, #30, #40, #50 AND/OR #60) *a Front view of wire harness connector (to ECM) Disconnect the ECM connector. Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C1-19 (#10) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-20 (#20) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-53 (#30) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-49 (#40) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-21 (#50) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-52 (#60) - C1-57 (E01) Power switch on (IG) 11 to 14 V Result Proceed to OK NG Result: 2 NG CHECK FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit [02/2014 - ]»(ref-644285-S05952920092014072300000) Result: 1 OK See step 9
9. CHECK FUEL INJECTOR ASSEMBLY OF MISFIRING CYLINDER Check the fuel injector assembly injection (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION [02/2014 - ]»(ref-644291-S11690153932014072300000) HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644291-S18186204592014072300000) Result: 1 OK See step 10
10. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [02/2014 - ]»(ref-644292-S41918904412014072300000) OK No leaks from intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE INTAKE SYSTEM Result: 1 OK See step 11
11. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «PROCEDURE - Step 2»(ref-644286-S07944289412014072300000) Result Proceed to OK NG Result: 2 NG See step 36 Result: 1 OK See step 12
12. READ VALUE USING TECHSTREAM (COOLANT TEMP) Refer to «PROCEDURE - Step 5»(ref-644287-S19143643832014072300000) Result Proceed to OK NG Result: 2 NG REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S34533675542014072300000) Result: 1 OK See step 13
13. READ VALUE USING TECHSTREAM (MAF) Refer to «PROCEDURE - Step 6»(ref-644287-S19143643832014072300000) Result Proceed to OK NG Result: 2 NG See step 31 Result: 1 OK See step 14
14. CHECK VALVE TIMING Refer to «PROCEDURE - Step 5»(ref-644287-S30639711242014072300000) Result Proceed to OK NG Result: 2 NG See step 17 Result: 1 OK See step 15
15. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 31 Result: 1 NG See step 16
16. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 1 OK See step 31 Result: 2 NG REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000)
17. CHECK ENGINE MECHANICAL SYSTEM Check for mechanical malfunctions that affect the valve timing, such as a jumped tooth or stretching of the timing chain. Result Proceed to OK NG Result: 1 OK See step 31 Result: 2 NG REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA
18. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [02/2014 - ]»(ref-644292-S41918904412014072300000) OK No leaks from intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE INTAKE SYSTEM Result: 1 OK See step 19
19. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «PROCEDURE - Step 2»(ref-644286-S07944289412014072300000) Result Proceed to OK NG Result: 2 NG See step 36 Result: 1 OK See step 20
20. READ VALUE USING TECHSTREAM (COOLANT TEMP) Refer to «PROCEDURE - Step 5»(ref-644287-S19143643832014072300000) Result Proceed to OK NG Result: 2 NG REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S34533675542014072300000) Result: 1 OK See step 21
21. READ VALUE USING TECHSTREAM (MAF) Refer to «PROCEDURE - Step 6»(ref-644287-S19143643832014072300000) Result Proceed to OK NG Result: 2 NG See step 31 Result: 1 OK See step 22
22. CHECK VALVE TIMING Refer to «PROCEDURE - Step 5»(ref-644287-S30639711242014072300000) Result Proceed to OK NG Result: 2 NG See step 30 Result: 1 OK See step 23
23. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 25 Result: 1 NG See step 24
24. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Result: 1 OK See step 25
25. INSPECT SPARK PLUG Inspect the spark plug of the misfiring cylinder. Refer to «PROCEDURE - Step 1»(ref-644277-S12162481162014072300000) HINT: Perform "Inspection After Repair" after replacing the spark plug. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE SPARK PLUG. Refer to «PROCEDURE - Step 3»(ref-644290-S26380278512014072300000) Result: 1 OK See step 26
26. CHECK FOR SPARKS (SPARK TEST) Perform a spark test. Refer to «PROCEDURE - Step 1»(ref-644277-S12162481162014072300000) HINT: If the result of the spark test is normal, proceed to the next step. Perform "Inspection After Repair" after repairing or replacing the ignition system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 27
27. CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «PROCEDURE - Step 10»(ref-644274-S21221184282014072300000) HINT: Perform "Inspection After Repair" after repairing or replacing the engine assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION Result: 1 OK See step 28
28. CHECK TERMINAL VOLTAGE (#10, #20, #30, #40, #50 AND/OR #60) *a Front view of wire harness connector (to ECM) Disconnect the ECM connector. Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C1-19 (#10) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-20 (#20) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-53 (#30) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-49 (#40) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-21 (#50) - C1-57 (E01) Power switch on (IG) 11 to 14 V C1-52 (#60) - C1-57 (E01) Power switch on (IG) 11 to 14 V Result Proceed to OK NG Result: 2 NG CHECK FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit [02/2014 - ]»(ref-644285-S05952920092014072300000) Result: 1 OK See step 29
29. CHECK FUEL INJECTOR ASSEMBLY OF MISFIRING CYLINDER Check the fuel injector assembly injection (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION [02/2014 - ]»(ref-644291-S11690153932014072300000) HINT: Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 1 OK See step 31 Result: 2 NG REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644291-S18186204592014072300000)
30. CHECK ENGINE MECHANICAL SYSTEM Check for mechanical malfunctions that affect the valve timing, such as a jumped tooth or stretching of the timing chain. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA Result: 1 OK See step 31
31. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [02/2014 - ]»(ref-644130-S10128349732014072300000) HINT: Repair any problems. Result Proceed to NEXT Result: 1 NEXT See step 32
32. CHECK WHETHER DTC OUTPUT RECURS (MISFIRE DTCS) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P0300, P0301, P0302, P0303, P0304, P0305 or P0306. Check the DTC judgment result. Result Result Proceed to ABNORMAL (DTC P0300, P0301, P0302, P0303, P0304, P0305 and/or P0306 is output) A NORMAL (DTCs are not output) B Result: 2 B END Result: 1 A See step 33
33. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Refer to «PROCEDURE - Step 3»(ref-644287-S31804337242014072300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 34
34. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S17648425442014072300000) HINT: If the results of the inspections performed in steps 13 and 21 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 35
35. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P0300, P0301, P0302, P0303, P0304, P0305 or P0306. Check the DTC judgment result. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P0300, P0301, P0302, P0303, P0304, P0305 and/or P0306 is output) B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)
36. CHECK FUEL LINE Check the fuel lines for leaks or blockage. HINT: Perform "Inspection After Repair" after replacing the fuel pump. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 1 OK REPLACE FUEL PUMP. Refer to «REMOVAL [02/2014 - ]»(ref-644291-S10945806622014072300000) Result: 2 NG REPAIR OR REPLACE FUEL LINE

P0327 AND P0332: KNOCK CONTROL SENSOR RANGE CHECK (LOW VOLTAGE)

P0328 AND P0333: KNOCK CONTROL SENSOR RANGE CHECK (HIGH VOLTAGE)

COMPONENT OPERATING RANGE

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine and wait 5 minutes.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P0327, P0328, P0332 or P0333.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 5 minutes and check the DTC judgment result again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 600

HINT

1. DTCs P0327 and P0328 are for the bank 1 knock control sensor circuit.
2. DTCs P0332 and P0333 are for the bank 2 knock control sensor circuit.
3. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
4. Bank 2 refers to the bank that does not include the No. 1 cylinder.
5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (KNOCK FEEDBACK VALUE) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Knock Feedback Value. Powertrain > Engine and ECT > Data List Tester Display Knock Feedback Value Read the value while driving the vehicle. OK The value changes. HINT: Malfunction does not occur Knock Feedback Value changes Malfunctions occur Knock Feedback Value does not change The Knock Feedback Value change can be confirmed by running the engine with a high load, for example, by activating the air conditioning system and racing the engine. Result Proceed to OK NG Result: 1 OK CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 NG See step 2
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF KNOCK CONTROL SENSOR) *a Front view of wire harness connector (to Knock Control Sensor) *b Bank 1 *c Bank 2 Disconnect the knock control sensor connector. Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition Z2-2 - Z2-1 Power switch on (IG) 4.5 to 5.5 V Z1-2 - Z1-1 Power switch on (IG) 4.5 to 5.5 V Result Proceed to OK NG Result: 2 NG See step 4 Result: 1 OK See step 3
3. INSPECT KNOCK CONTROL SENSOR Inspect the knock control sensor. Refer to «INSPECTION [02/2014 - ]»(ref-644290-S35071352452014072300000) HINT: Perform "Inspection After Repair" after replacing the knock control sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 NG REPLACE KNOCK CONTROL SENSOR. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S41465369202014072300000)
4. CHECK HARNESS AND CONNECTOR (KNOCK CONTROL SENSOR - ECM) Disconnect the knock control sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Z2-2 - C1-116 (KNK1) Always Below 1 ohms Z2-1 - C1-117 (EKNK) Always Below 1 ohms Z1-2 - C1-83 (KNK2) Always Below 1 ohms Z1-1 - C1-84 (EKN2) Always Below 1 ohms Z2-2 or C1-116 (KNK1) - Body ground Always 10 kohms or higher Z1-2 or C1-83 (KNK2) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

ALL

RANGE CHECK/RATIONALITY

VERIFY PULSE INPUT (CASE 1)

VERIFY PULSE INPUT (CASE 2)

RANGE CHECK/RATIONALITY

VERIFY PULSE INPUT

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine.
8. Idle the engine for 20 seconds or more [A].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0335.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 601

HINT

1. After performing the inspection procedure for the crankshaft position sensor, if DTC P0335 is output again, check the following items related to the VVT sensor. Installation condition of the VVT sensor. Installation condition of the camshaft. Connection of the VVT sensor connector.
2. If no problem is found through this diagnostic troubleshooting procedure, troubleshoot the engine mechanical system.
3. The engine speed can be checked by using the Techstream. To perform the check, follow the procedures below: Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Engine Speed. The engine speed may be indicated as zero despite the engine running normally. This is caused by a lack of NE signals from the crankshaft position sensor. Alternatively, the engine speed may be indicated as lower than the actual engine speed if the crankshaft position sensor output voltage is insufficient.
4. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (ENGINE SPEED) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Engine Speed. Powertrain > Engine and ECT > Data List Tester Display Engine Speed Start the engine. Read the values displayed on the Techstream while the engine is running. Standard Correct values are displayed. HINT: To check the engine speed change, display the graph on the Techstream. If the engine does not start, check the engine speed while cranking. If the engine speed indicated on the Techstream remains zero (0), there may be an open or short in the crankshaft position sensor circuit. Result Proceed to OK NG Result: 1 OK CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 NG See step 2
2. INSPECT CRANKSHAFT POSITION SENSOR Inspect the crankshaft position sensor. Refer to «INSPECTION [02/2014 - ]»(ref-644290-S07144349282014072300000) Result Proceed to OK NG Result: 2 NG REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S38762287652014072300000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Disconnect the crankshaft position sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C34-1 - C1-76 (NE+) Always Below 1 ohms C34-2 - C1-77 (NE-) Always Below 1 ohms C34-1 or C1-76 (NE+) - Body ground Always 10 kohms or higher C34-2 or C1-77 (NE-) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. CHECK SENSOR INSTALLATION (CRANKSHAFT POSITION SENSOR) *a Clearance Check the crankshaft position sensor installation condition. OK Crankshaft position sensor is installed correctly. Result Proceed to OK NG Result: 2 NG SECURELY REINSTALL CRANKSHAFT POSITION SENSOR. Refer to «INSTALLATION [02/2014 - ]»(ref-644290-S22096539152014072300000) Result: 1 OK See step 5
5. INSPECT CRANKSHAFT (TEETH OF CRANK ANGLE SENSOR PLATE) Inspect the teeth of the crank angle sensor plate. OK Crank angle sensor plate does not have any cracks or deformation. Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 NG REPLACE CRANKSHAFT. Refer to «COMPONENTS [02/2014 - ]»(ref-644274-S04335207272014072300000)

ALL

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT

P0342 AND P0343: VVT SENSOR (BANK 1) RANGE CHECK

P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT

P0347 AND P0348: VVT SENSOR (BANK 2) RANGE CHECK

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT

P0342 AND P0347: VVT SENSOR (BANK 1, 2) RANGE CHECK (LOW VOLTAGE)

P0343 AND P0348: VVT SENSOR (BANK 1, 2) RANGE CHECK (HIGH VOLTAGE)

P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine.
8. Idle the engine for 10 seconds or more [A].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0340, P0342, P0343, P0345, P0347 or P0348.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. If no problem is found through this diagnostic troubleshooting procedure, there may be a mechanical problem with the engine.
2. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
3. Bank 2 refers to the bank that does not include the No. 1 cylinder.
4. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 602

1. CHECK TERMINAL VOLTAGE (POWER SOURCE OF VVT SENSOR) *a Front view of wire harness connector (to VVT Sensor) *b Bank 1 *c Bank 2 Disconnect the VVT sensor connector. Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C35-3 (VC) - Body ground Power switch on (IG) 4.5 to 5.5 V C36-3 (VC) - Body ground Power switch on (IG) 4.5 to 5.5 V Result Proceed to OK NG Result: 2 NG See step 10 Result: 1 OK See step 2
2. CHECK HARNESS AND CONNECTOR (VVT SENSOR - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C35-1 (VVR+) - C1-109 (VV1+) Always Below 1 ohms C35-2 (VVR-) - C1-110 (VV1-) Always Below 1 ohms C36-1 (VVL+) - C1-112 (VV2+) Always Below 1 ohms C36-2 (VVL-) - C1-111 (VV2-) Always Below 1 ohms C35-1 (VVR+) or C1-109 (VV1+) - Body ground Always 10 kohms or higher C35-2 (VVR-) or C1-110 (VV1-) - Body ground Always 10 kohms or higher C36-1 (VVL+) or C1-112 (VV2+) - Body ground Always 10 kohms or higher C36-2 (VVL-) or C1-111 (VV2-) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 3
3. CHECK SENSOR INSTALLATION (VVT SENSOR) *a Clearance Check the VVT sensor installation. OK VVT sensor is installed correctly. Result Proceed to OK NG Result: 2 NG SECURELY REINSTALL VVT SENSOR. Refer to «INSTALLATION [02/2014 - ]»(ref-644290-S10300743682014072300000) Result: 1 OK See step 4
4. INSPECT CAMSHAFT TIMING GEAR ASSEMBLY (TEETH OF SENSOR PLATE) Inspect the teeth of the sensor plate. OK Sensor plate teeth do not have any cracks or deformation. HINT: Perform "Inspection After Repair" after replacing the camshaft timing gear assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING GEAR ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644274-S20466702452014072300000) Result: 1 OK See step 5
5. CHECK VALVE TIMING Refer to «PROCEDURE - Step 5»(ref-644287-S30639711242014072300000) Result Proceed to OK NG Result: 2 NG See step 8 Result: 1 OK See step 6
6. REPLACE VVT SENSOR Replace the VVT sensor. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S04684280892014072300000) Result Proceed to NEXT Result: 1 NEXT See step 7
7. CHECK WHETHER DTC OUTPUT RECURS (DTC P0340, P0342, P0343, P0345, P0347 OR P0348) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0340, P0342, P0343, P0345, P0347 or P0348 is output A DTCs are not output B HINT: If the engine does not start, replace the ECM. Result: 1 A REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 B END
8. CHECK ENGINE MECHANICAL SYSTEM Check for mechanical malfunctions that affect the valve timing, such as a jumped tooth or stretching of the timing chain. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA Result: 1 OK See step 9
9. CHECK WHETHER DTC OUTPUT RECURS (DTC P0340, P0342, P0343, P0345, P0347 OR P0348) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0340, P0342, P0343, P0345, P0347 or P0348 is output A DTCs are not output B HINT: If the engine does not start, replace the ECM. Result: 1 A REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000)
10. CHECK HARNESS AND CONNECTOR (VVT SENSOR - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C35-3 (VC) - C1-78 (VCV1) Always Below 1 ohms C36-3 (VC) - C1-79 (VCV2) Always Below 1 ohms C35-3 (VC) or C1-78 (VCV1) - Body ground Always 10 kohms or higher C36-3 (VC) or C1-79 (VCV2) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine.
8. Idle the engine for 10 seconds or more [A].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0351, P0352, P0353, P0354, P0355 or P0356.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 603

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTCS (DTC P0351, P0352, P0353, P0354, P0355 OR P0356) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Shuffle the arrangement of the ignition coil assemblies (among No. 1 to No. 6 cylinders). NOTE: Do not change the location of the connectors. Perform a simulation test. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to Same DTC output A Different ignition coil DTC output B HINT: Perform "Inspection After Repair" after replacing the ignition coil assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result: 2 B REPLACE IGNITION COIL ASSEMBLY. Refer to «PROCEDURE - Step 2»(ref-644290-S26380278512014072300000) Result: 1 A See step 2
2. CHECK HARNESS AND CONNECTOR (IGNITION COIL ASSEMBLY - BODY GROUND) Disconnect the ignition coil assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C42-4 (GND) - Body ground Always Below 1 ohms C43-4 (GND) - Body ground Always Below 1 ohms C45-4 (GND) - Body ground Always Below 1 ohms C46-4 (GND) - Body ground Always Below 1 ohms C48-4 (GND) - Body ground Always Below 1 ohms C49-4 (GND) - Body ground Always Below 1 ohms Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 3
3. CHECK TERMINAL VOLTAGE (POWER SOURCE OF IGNITION COIL ASSEMBLY) *a Front view of wire harness connector (to Ignition Coil Assembly) Disconnect the ignition coil assembly connector. Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C42-1 (+B) - C42-4 (GND) Power switch on (IG) 11 to 14 V C43-1 (+B) - C43-4 (GND) Power switch on (IG) 11 to 14 V C45-1 (+B) - C45-4 (GND) Power switch on (IG) 11 to 14 V C46-1 (+B) - C46-4 (GND) Power switch on (IG) 11 to 14 V C48-1 (+B) - C48-4 (GND) Power switch on (IG) 11 to 14 V C49-1 (+B) - C49-4 (GND) Power switch on (IG) 11 to 14 V Result Proceed to OK NG Result: 2 NG See step 5 Result: 1 OK See step 4
4. CHECK HARNESS AND CONNECTOR (IGNITION COIL ASSEMBLY - ECM) Disconnect the ignition coil assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C42-3 (IGT1) - C1-138 (IGT1) Always Below 1 ohms C43-3 (IGT2) - C1-106 (IGT2) Always Below 1 ohms C45-3 (IGT3) - C1-139 (IGT3) Always Below 1 ohms C46-3 (IGT4) - C1-107 (IGT4) Always Below 1 ohms C48-3 (IGT5) - C1-105 (IGT5) Always Below 1 ohms C49-3 (IGT6) - C1-137 (IGT6) Always Below 1 ohms C42-2 (IGF) - C1-54 (IGF1) Always Below 1 ohms C43-2 (IGF) - C1-54 (IGF1) Always Below 1 ohms C45-2 (IGF) - C1-54 (IGF1) Always Below 1 ohms C46-2 (IGF) - C1-54 (IGF1) Always Below 1 ohms C48-2 (IGF) - C1-54 (IGF1) Always Below 1 ohms C49-2 (IGF) - C1-54 (IGF1) Always Below 1 ohms C42-3 (IGT1) or C1-138 (IGT1) - Body ground Always 10 kohms or higher C43-3 (IGT2) or C1-106 (IGT2) - Body ground Always 10 kohms or higher C45-3 (IGT3) or C1-139 (IGT3) - Body ground Always 10 kohms or higher C46-3 (IGT4) or C1-107 (IGT4) - Body ground Always 10 kohms or higher C48-3 (IGT5) or C1-105 (IGT5) - Body ground Always 10 kohms or higher C49-3 (IGT6) or C1-137 (IGT6) - Body ground Always 10 kohms or higher C42-2 (IGF) or C1-54 (IGF1) - Body ground Always 10 kohms or higher C43-2 (IGF) or C1-54 (IGF1) - Body ground Always 10 kohms or higher C45-2 (IGF) or C1-54 (IGF1) - Body ground Always 10 kohms or higher C46-2 (IGF) or C1-54 (IGF1) - Body ground Always 10 kohms or higher C48-2 (IGF) or C1-54 (IGF1) - Body ground Always 10 kohms or higher C49-2 (IGF) or C1-54 (IGF1) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
5. CHECK HARNESS AND CONNECTOR (IGNITION COIL ASSEMBLY - SEMICONDUCTOR PWR INTEGRATION ECU) Disconnect the ignition coil assembly connector. Disconnect the semiconductor pwr integration ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C42-1 (+B) - 1G-3 Always Below 1 ohms C43-1 (+B) - 1G-3 Always Below 1 ohms C45-1 (+B) - 1G-3 Always Below 1 ohms C46-1 (+B) - 1G-3 Always Below 1 ohms C48-1 (+B) - 1G-3 Always Below 1 ohms C49-1 (+B) - 1G-3 Always Below 1 ohms C42-1 (+B) or 1G-3 - Body ground Always 10 kohms or higher C43-1 (+B) or 1G-3 - Body ground Always 10 kohms or higher C45-1 (+B) or 1G-3 - Body ground Always 10 kohms or higher C46-1 (+B) or 1G-3 - Body ground Always 10 kohms or higher C48-1 (+B) or 1G-3 - Body ground Always 10 kohms or higher C49-1 (+B) or 1G-3 - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE SEMICONDUCTOR PWR INTEGRATION ECU. Refer to «REMOVAL [02/2014 - ]»(ref-644295-S41599895942014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [02/2014 - ]

P0401: EXHAUST GAS RECIRCULATION / VVT / EGR FLOW INSUFFICIENCY

Scheme 604

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
8. Accelerate the vehicle to 75 km/h (47 mph) or more by depressing the accelerator pedal for at least 10 seconds [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: When accelerating the vehicle, depress the accelerator pedal more than normal to start the engine.
9. Idle the engine for 30 seconds or more [C].
10. Accelerate the vehicle to 75 km/h (47 mph) with the shift lever in S [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Perform the fuel cut operation for 5 seconds or more, with the accelerator pedal fully released [E]. HINT: When the fuel cut is operating, "Idle Fuel Cut" in Data List is ON.
12. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor [F].
13. Check that Exhaust Gas Recirculation/VVT / Current is Complete. HINT: If the monitor item Exhaust Gas Recirculation/VVT / Current is Incomplete, perform the driving pattern again.
14. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Exhaust Gas Recirculation / VVT / Details.
15. Check the Details (EGR FLOW INSUFFICIENCY). HINT: Make sure that the value is between MIN and MAX.
16. If the monitor item Exhaust Gas Recirculation/VVT / Current is still Incomplete, perform the following procedure.
17. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
18. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
19. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
20. Input the DTC P0401.
21. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
22. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. By using the Control the EGR Step Position Active Test, the operation of the EGR valve can be checked.
2. When the engine is idling steadily with the EGR valve fully closed, if the EGR valve is normal and it is opened using the Active Test, the Data List value changes as follows. Data List Item Change in Data List when Number of Steps is Increased Using Control the EGR Step Position Active Test Engine Speed Idle becomes rough MAP Pressure rises
3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P0401) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0401 is output A DTC P0401 and other DTCs are output B HINT: If any DTCs other than P0401 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 NG See step 4 Result: 1 OK See step 3
3. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check for contamination between the EGR valve and housing. OK EGR valve is closed and no deposits. Result Proceed to OK NG Result: 2 OK See step 5 Result: 1 NG See step 4
4. REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 5
5. CHECK FOR DEPOSIT (INTAKE MANIFOLD - EGR VALVE ASSEMBLY - EXHAUST MANIFOLD) Check for exhaust gas leaks at each connection point. Check for cracks, damage, and clogs in the pipes between the exhaust manifold sub-assembly, the intake manifold and the EGR valve assembly. This check may require the removal of components. Check if there is a built-up of deposits in the EGR valve of pipes. OK No deposits Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENTS AND AREAS Result: 1 OK See step 6
6. INSPECT EGR COOLER ASSEMBLY Check for blockage of the EGR cooler assembly. OK No blockage. Result Proceed to OK NG Result: 2 NG REPLACE EGR COOLER ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S07002836932014072300000) Result: 1 OK See step 7
7. READ VALUE USING TECHSTREAM (MAP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / MAP. Powertrain > Engine and ECT > Data List Tester Display MAP Read the MAP value. Standard Engine condition Techstream Display Power switch on (IG) 80 to 110 kPa(abs) [600 to 825 mmHg(abs)] Result Proceed to OK NG Result: 2 OK See step 10 Result: 1 NG See step 8
8. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [02/2014 - ]»(ref-644292-S41918904412014072300000) OK No leaks in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE INTAKE SYSTEM Result: 1 OK See step 9
9. REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace the manifold absolute pressure sensor. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S18283371122014072300000) Result Proceed to NEXT Result: 1 NEXT See step 10
10. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P0401. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit Result Proceed to NEXT Result: 1 NEXT END

Scheme 605

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine and warm it up [B].
8. Drive the vehicle at 20 km/h (12 mph) or more for 10 minutes [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0403.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 606

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 607

1. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 1 NG See step 2
2. INSPECT EGR VALVE ASSEMBLY Inspect the EGR valve assembly. Refer to «INSPECTION [02/2014 - ]»(ref-644279-S41721747302014072300000) HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Result: 1 OK See step 3
3. CHECK TERMINAL VOLTAGE (POWER SOURCE OF EGR VALVE ASSEMBLY) Disconnect the EGR valve assembly connector. *a Front view of wire harness connector (to EGR Valve Assembly) Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C56-2 (+B1) - Body ground Power switch on (IG) 11 to 14 V C56-5 (+B2) - Body ground Power switch on (IG) 11 to 14 V Result Result OK NG Result: 2 NG See step 5 Result: 1 OK See step 4
4. CHECK HARNESS AND CONNECTOR (EGR VALVE ASSEMBLY - ECM) Disconnect the EGR valve assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C56-4 (EGR1) - C1-14 (EGR1) Always Below 1 ohms C56-3 (EGR2) - C1-13 (EGR2) Always Below 1 ohms C56-6 (EGR3) - C1-12 (EGR3) Always Below 1 ohms C56-1 (EGR4) - C1-15 (EGR4) Always Below 1 ohms C56-4 (EGR1) or C1-14 (EGR1) - Body ground Always 10 kohms or higher C56-3 (EGR2) or C1-13 (EGR2) - Body ground Always 10 kohms or higher C56-6 (EGR3) or C1-12 (EGR3) - Body ground Always 10 kohms or higher C56-1 (EGR4) or C1-15 (EGR4) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
5. CHECK HARNESS AND CONNECTOR (SEMICONDUCTOR PWR INTEGRATION ECU - EGR VALVE ASSEMBLY) Disconnect the EGR valve assembly connector. Disconnect the semiconductor pwr integration ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1G-7 - C56-2 (+B1) Always Below 1 ohms 1G-7 - C56-5 (+B2) Always Below 1 ohms 1G-7 or C56-2 (+B1) - Body ground Always 10 kohms or higher 1G-7 or C56-5 (+B2) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE SEMICONDUCTOR PWR INTEGRATION ECU. Refer to «REMOVAL [02/2014 - ]»(ref-644295-S41599895942014072300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [02/2014 - ]

P0420: CATALYST EFFICIENCY / O2 STORAGE B1

P0430: CATALYST EFFICIENCY / O2 STORAGE B2

HINT

1. It is necessary for the response of the heated oxygen sensor to be normal in order to confirm DTCs P0420 and P0430. Therefore, perform the confirmation driving pattern for the heated oxygen sensor monitor before performing the confirmation driving pattern for the catalyst efficiency monitor.
2. Performing this confirmation driving pattern will activate the catalyst efficiency monitor. This is very useful for verifying the completion of a repair.

Scheme 608

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG).
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the power switch off and wait for at least 30 seconds.
6. Turn the power switch on (IG) and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
8. Check that Catalyst Efficiency / Current is Incomplete.
9. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
10. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with the shift lever in P [A]. HINT: In order to keep the idle stable, turn the A/C and all other electric loads off and do not perform any shift operations.
11. Drive the vehicle at approximately 75 km/h (47 mph) for 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible.
12. With the shift lever in S, drive the vehicle at 75 km/h (47 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
13. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / RL F/C B1S2, RL F/C B2S2 [D].
14. Check the Test Value for RL F/C B1S2, RL F/C B2S2. HINT: If Test Value displays a value larger than 0, perform the following procedure, as the O2 Sensor monitor is finished. If Test Value displays 0, perform step [C] until it displays a value larger than 0, as the O2 Sensor monitor is not finished.
15. Turn the power switch off and wait for at least 30 seconds [F].
16. Turn the power switch on (IG) and turn the Techstream on.
17. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [G].
18. Drive the vehicle at approximately 75 km/h (47 mph) for 10 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the Catalyst Efficiency monitor operates.
19. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [I].
20. Check if any DTCs are stored. HINT: If the monitor item does not change to Complete, and no DTCs are stored, perform the following procedure.
21. Drive the vehicle at approximately 100 km/h (62 mph) for 10 minutes or more [J]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the Catalyst Efficiency monitor operates.
22. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [K].
23. Check if any DTCs are stored. HINT: If the monitor item does not change to Complete, and no DTCs are stored, extend the driving time.
24. If no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. If a malfunction cannot be found when troubleshooting DTC P0420 or P0430, a lean or rich abnormality may be the cause. Perform troubleshooting by following the inspection procedure for P0171 and P0174 (System Too Lean), and P0172 and P0175 (System Too Rich).
2. Bank 1 refers to the bank that includes the No. 1 cylinder*. *: The No. 1 cylinder is the cylinder which is farthest from the transaxle.
3. Bank 2 refers to the bank that does not include the No. 1 cylinder.
4. Sensor 1 refers to the sensor closest to the engine assembly.
5. Sensor 2 refers to the sensor farthest away from the engine assembly.
6. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 AND/OR P0430) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0420 and/or P0430 are output A DTC P0420 and/or P0430 and other DTCs are output B HINT: If any DTCs other than P0420 and/or P0430 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine warm it up. Idle the engine for 5 minutes or more with the shift lever in P. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2. Powertrain > Engine and ECT > Active Test Active Test Display Control the Injection Volume for A/F Sensor Data List Display AFS Voltage B1S1 AFS Voltage B2S1 O2S B1S2 O2S B2S2 Perform the Active Test operation with the engine idling (press the 12.5% or -12.5% button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 AFS Voltage B2S1 (Air fuel ratio) 12.5% Rich Below 3.1 V -12.5% Lean Higher than 3.4 V O2S B1S2 O2S B2S2 (Heated oxygen) 12.5% Rich Higher than 0.55 V -12.5% Lean Below 0.4 V Result Status AFS Voltage B1S1 or AFS Voltage B2S1 Status O2S B1S2 or O2S B2S2 Actual air fuel ratio, air fuel ratio sensor and heated oxygen sensor condition Misfire Main Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leak from exhaust system EGR valve assembly A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leak from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leak from exhaust system Lean Lean Actual air fuel ratio lean May occur Extremely lean actual air fuel ratio Gas leak from exhaust system EGR valve assembly D Rich Rich Actual air fuel ratio rich - Extremely rich actual air fuel ratio Gas leak from exhaust system EGR valve assembly Lean: During Control the Injection Volume for A/F Sensor Active Test, the air fuel ratio sensor output voltage (AFS Voltage B1S1 or AFS Voltage B2S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2 or O2S B2S2) is consistently below 0.4 V. Rich: During Control the Injection Volume for A/F Sensor Active Test, AFS Voltage B1S1 or AFS Voltage B2S1 is consistently below 3.1 V, and O2S B1S2 or O2S B2S2 is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor Active Test, the output voltage of the air fuel ratio sensor and heated oxygen sensor alternate correctly. Result: 2 B See step 6 Result: 3 C See step 7 Result: 4 D See step 9 Result: 1 A See step 3
3. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. Result Proceed to OK NG Result: 2 NG See step 13 Result: 1 OK See step 4
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 15 Result: 1 NG See step 5
5. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 1 OK See step 15 Result: 2 NG REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000)
6. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S03554699972014072300000) HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 14
7. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. Result Proceed to OK NG Result: 2 NG See step 13 Result: 1 OK See step 8
8. REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S25737962532014072300000) HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 14
9. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. Result Proceed to OK NG Result: 2 NG See step 13 Result: 1 OK See step 10
10. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 12 Result: 1 NG See step 11
11. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Result: 1 OK See step 12
12. CHECK CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO Check the cause of extremely rich or lean actual air fuel ratio, referring to the DTC P0171, P0172, P0174 or P0175 Inspection Procedure. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2) [02/2014 - ]»(ref-644287-S34947666722014072300000) Result Proceed to NEXT Result: 1 NEXT See step 14
13. REPAIR OR REPLACE EXHAUST GAS LEAK POINT Repair or replace exhaust gas leak point. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 14
14. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0420 and/or P0430 is output A DTCs are not output B Result: 2 B END Result: 1 A See step 15
15. CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) NOTE: If DTC P0420 is output, replace the exhaust manifold sub-assembly RH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. If DTC P0430 is output, replace the exhaust manifold sub-assembly LH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in Catalyst Location. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0420 is output A DTC P0430 is output B DTC P0420 and P0430 are output C Result: 1 A REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH (TWC: FRONT CATALYST) AND CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST) Refer to «COMPONENTS [02/2014 - ]»(ref-644297-S05906720252014072300000) Refer to «COMPONENTS [02/2014 - ]»(ref-644297-S24169614752014072300000) Result: 2 B REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY LH (TWC: FRONT CATALYST) AND CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST) Refer to «COMPONENTS [02/2014 - ]»(ref-644297-S05906720252014072300000) Refer to «COMPONENTS [02/2014 - ]»(ref-644297-S24169614752014072300000) Result: 3 C REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH AND LH (TWC: FRONT CATALYST) AND FRONT EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST) Refer to «COMPONENTS [02/2014 - ]»(ref-644297-S05906720252014072300000) Refer to «COMPONENTS [02/2014 - ]»(ref-644297-S24169614752014072300000)

Key-off Monitor Sequence 1 to 15

1. ATMOSPHERIC PRESSURE MEASUREMENT

2. FIRST REFERENCE PRESSURE MEASUREMENT

3. VENT VALVE STUCK CLOSED CHECK

4. VACUUM INTRODUCTION FOR CANISTER

5. PURGE VSV STUCK CLOSED CHECK

6. SECOND REFERENCE PRESSURE MEASUREMENT

7. CANISTER LEAK CHECK

8. FUEL VAPOR-CONTAINMENT VALVE (FVCV) STUCK CLOSED CHECK

9. VACUUM INTRODUCTION FOR FUEL TANK

10. FUEL VAPOR-CONTAINMENT VALVE STUCK CLOSED CHECK

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

12 THIRD REFERENCE PRESSURE MEASUREMENT

13. FUEL TANK LEAK CHECK

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

15. ATMOSPHERIC PRESSURE MEASUREMENT

Refer to EVAP System.

Refer to MONITOR RESULT

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
7. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
8. Input the DTC: P043E, P043F, P2401, P2402 or P2419.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. GO TO EVAP SYSTEM Refer to EVAP System. Refer to «EVAP System [02/2014 - ]»(ref-644285-S11103700972014072300000) Result Proceed to NEXT Result: 1 NEXT END

ALL

PURGE FLOW MONITOR

KEY-OFF MONITOR

Key-off Monitor Sequence 1 to 15

1. ATMOSPHERIC PRESSURE MEASUREMENT

2. FIRST REFERENCE PRESSURE MEASUREMENT

3. VENT VALVE STUCK CLOSED CHECK

4. VACUUM INTRODUCTION FOR CANISTER

5. PURGE VSV STUCK CLOSED CHECK

6. SECOND REFERENCE PRESSURE MEASUREMENT

7. CANISTER LEAK CHECK

8. FUEL VAPOR-CONTAINMENT VALVE (FVCV) STUCK CLOSED CHECK

9. VACUUM INTRODUCTION FOR FUEL TANK

10. FUEL VAPOR-CONTAINMENT VALVE STUCK CLOSED CHECK

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

12 THIRD REFERENCE PRESSURE MEASUREMENT

13. FUEL TANK LEAK CHECK

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

15. ATMOSPHERIC PRESSURE MEASUREMENT

PURGE VSV STUCK OPEN

PURGE VSV STUCK CLOSED

PURGE FLOW

Refer to EVAP System.

Refer to MONITOR RESULT

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine and wait 15 minutes or more.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P0441.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure. NOTE: The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).
13. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
14. Turn the power switch off and wait for at least 30 seconds.
15. Turn the power switch on (IG) and turn the Techstream on.
16. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
17. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
18. Input the DTC: P0441.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
20. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P0441) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0441 is output A DTC P0441 and other DTCs are output B HINT: If any DTCs other than DTC P0441 are output, troubleshoot those DTCs first. Result: 1 A GO TO EVAP SYSTEM. Refer to «EVAP System [02/2014 - ]»(ref-644285-S11103700972014072300000) Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000)

ALL

P0451

P0452 AND P0453

P0451: CANISTER PRESSURE SENSOR NOISE MONITORING

P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE

P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Intake Air.
4. Check that the intake air temperature is between 4.4 and 50°C (40 and 122°F).
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
6. Turn the power switch off and wait for at least 30 seconds.
7. Turn the power switch on (IG) and turn the Techstream on.
8. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
9. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0451, P0452 or P0453.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 609

Scheme 610

Note. When a vehicle is brought into the workshop, leave it as it is. Do not change the vehicle condition. For example, do not tighten the fuel cap. The Techstream is required to conduct the following diagnostic troubleshooting procedure. Inspect the fuses for circuits related to this system before performing the following procedure.

1. CONFIRM DTC AND EVAP PRESSURE Connect the Techstream to the DLC3. Turn the power switch on (IG) (do not start the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Evaporative / Vapor Pressure Pump. Powertrain > Engine and ECT > Data List Tester Display Vapor Pressure Pump Read the EVAP (Evaporative Emission) pressure displayed on the Techstream. Result Display (DTC Output) Test Result Suspected Trouble Area Proceed to P0451 - Canister pressure sensor C P0452 Less than 42.11009 kPa(abs) [315.82568 mmHg(abs)] Wire harness/connector (ECM - canister pressure sensor) Canister pressure sensor Short in ECM circuit A P0453 Higher than 123.76147 kPa(abs) [928.21103 mmHg(abs)] Wire harness/connector (ECM - canister pressure sensor) Canister pressure sensor Open in ECM circuit B Result: 2 B See step 5 Result: 3 C See step 6 Result: 1 A See step 2
2. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Result Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to A43-52 (PPMP) - Body ground Always Below 10 ohms Wire harness/connector (ECM - canister pressure sensor) Short in canister pressure sensor circuit A 10 kohms or higher Wire harness/connector (ECM - canister pressure sensor) Short in ECM circuit B Result: 2 B See step 4 Result: 1 A See step 3
3. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the canister pump module connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Result Tester Connection Condition Specified Condition Suspected Trouble Area Proceed to A43-52 (PPMP) - Body ground Always 10 kohms or higher Short in canister pressure sensor circuit A Below 10 ohms Short in wire harness/connector (ECM - canister pressure sensor) B Result: 1 A See step 6 Result: 2 B See step 7
4. REPLACE ECM Replace the ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result Proceed to NEXT Result: 1 NEXT See step 8
5. CHECK HARNESS AND CONNECTOR (CANISTER PUMP MODULE - ECM) Disconnect the canister pump module connector. *a Front view of wire harness connector (to Canister Pump Module) - - Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M11-8 (SGND) - Body ground Always 100 ohms or less Turn the power switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition M11-6 (VCC) - Body ground Power switch on (IG) 4.5 to 5.5 V M11-7 (VOUT) - Body ground Power switch on (IG) 4.5 to 5.5 V Result Test Result Suspected Trouble Area Proceed to Voltage and resistance within standard ranges Open in canister pressure sensor circuit A Voltage and/or resistance outside standard ranges Open in wire harness/connector (ECM - canister pressure sensor) B Result: 2 B See step 7 Result: 1 A See step 6
6. REPLACE CANISTER PUMP MODULE Replace the canister pump module. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S12571784502014072300000) NOTE: When replacing the canister pump module, check the canister pump module interior, canister interior and related pipes for water, fuel and other liquids. If liquids are present, check for disconnections and/or cracks in the following: 1) the pipe from the air inlet port to the canister pump module; 2) the canister filter; and 3) the fuel tank vent hose. If liquids are present in the canister interior, replace canister and canister pump module together. Check for filter blockage in the canister. If the charcoal filter inside the canister is clogged, replace canister and the canister pump module together. Check for filter blockage in the canister filter. If the canister filter has blockage, replace the canister filter. *1 Fuel Tank Vent Hose *2 Air Inlet Port *3 Vent Hose *4 Fuel Tank *5 Canister Pump Module - Canister Pressure Sensor - Leak Detection Pump - Vent Valve *6 Canister *7 Canister Filter *8 Fuel Tank Pressure Sensor *9 Fuel Cap *10 Fuel Vapor-containment Valve *a Inspection Area (Check for disconnection and/or cracks) - - Result Proceed to NEXT Result: 1 NEXT See step 8
7. REPAIR OR REPLACE HARNESS OR CONNECTOR (CANISTER PUMP MODULE - ECM) Result Proceed to NEXT Result: 1 NEXT See step 8
8. CHECK WHETHER DTC OUTPUT RECURS (AFTER REPAIR) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Perform the Evaporative System Check using the Techstream, referring to the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P0451, P0452 or P0453. Check the DTC judgment result. Result Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit Result Proceed to NEXT Result: 1 NEXT END

Scheme 611

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on [A].
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
8. Turn the power switch off and wait for at least 30 seconds.
9. Disconnect the cable from the negative (-) auxiliary battery terminal.
10. Reconnect the cable to the negative (-) auxiliary battery terminal.
11. Turn the power switch on (IG) and turn the Techstream on.
12. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
13. Start the engine and rev the engine for 5 seconds with shift lever in P [C].
14. Idle the engine for 5 minutes or more [D]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
15. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
16. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
18. Input the DTC: P0505.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [I].
20. Accelerate the vehicle to 10 km/h (6.25 mph) or more [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
21. Stop the vehicle and rev the engine for 5 seconds with shift lever in P [G].
22. Idle the engine for 20 seconds or more [H].
23. Repeat the steps [F] through [H] 10 times.
24. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [I].
25. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
26. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
27. Input the DTC: P0505.
28. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
29. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

1. The following conditions may also cause DTC P0505 to be stored: The floor carpet overlapping slightly onto the accelerator pedal, causing the accelerator pedal to be slightly depressed and therefore the throttle valve position to be slightly open. The accelerator pedal being not fully released.
2. Refer to "Data List / Active Test" [Engine Speed, ISC Feedback Value and ISC Learning Value]. Refer to «DATA LIST / ACTIVE TEST [02/2014 - ]»(ref-644155-S09753896022014072300000)
3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0505 is output A DTC P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000) Result: 1 A See step 2
2. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS [02/2014 - ]»(ref-644279-S05903964552014072300000) OK PCV valve and hose are connected correctly and are not damaged. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE PCV HOSE Result: 1 OK See step 3
3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [02/2014 - ]»(ref-644292-S41918904412014072300000) OK No leaks from the intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE INTAKE SYSTEM Result: 1 OK See step 4
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 6 Result: 1 NG See step 5
5. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Result: 1 OK See step 6
6. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (THROTTLE VALVE) Check the throttle body with motor assembly condition. OK Throttle valve is not contaminated with foreign matter and moves smoothly. HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to OK NG Result: 2 NG REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S40484084302014072300000) Result: 1 OK See step 7
7. CONFIRM WHETHER DTC OUTPUT RECURS (DTC P0505) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG). Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0505 is output A DTCs are not output B Result: 1 A REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 B END

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine and warm it up for 5 minutes or more.
8. Stop the engine.
9. Leave the vehicle outside overnight.
10. Turn the power switch on (IG) and turn the Techstream on [A].
11. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
12. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
13. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
14. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
15. Idle the engine for 1 minute or more [B].
16. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
17. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
19. Input the DTC: P050A.
20. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] and [B].
21. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas AF Control / Short FT #1, Long FT #1, Short FT #2 and Long FT #2. Powertrain > Engine and ECT > Data List Tester Display Short FT #1 Long FT #1 Short FT #2 Long FT #2 Read the values displayed on the Techstream at engine idle. Add together the Short FT #1 and Long FT #1 values, and the Short FT #2 and Long FT #2 values to obtain the total fuel trim. Standard The total of the Short FT #1 and Long FT #1 values, and the total of the Short FT #2 and Long FT #2 values is between -20% and 20%. Result Proceed to OK NG Result: 2 NG See step 7 Result: 1 OK See step 3
3. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (THROTTLE VALVE) Inspect that there are no deposits around the throttle valve and throttle valve condition. OK No deposits around the throttle valve and throttle valve moves smoothly. Result Proceed to OK NG Result: 1 NG See step 6 Result: 2 OK See step 4
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 14 Result: 1 NG See step 5
5. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Result Proceed to OK NG Result: 1 OK See step 14 Result: 2 NG See step 16
6. REPAIR OR REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY Repair or replace the throttle body with motor assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S40484084302014072300000) HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 20
7. CHECK PCV SYSTEM Check the PCV hose connections. Refer to «COMPONENTS [02/2014 - ]»(ref-644279-S05903964552014072300000) OK PCV valve and hose are connected correctly and are not damaged. Result Proceed to OK NG Result: 2 NG See step 19 Result: 1 OK See step 8
8. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [02/2014 - ]»(ref-644292-S41918904412014072300000) OK No leaks from intake system. Result Proceed to OK NG Result: 2 NG See step 18 Result: 1 OK See step 9
9. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK The air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. Result Proceed to OK NG Result: 2 NG See step 17 Result: 1 OK See step 10
10. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 12 Result: 1 NG See step 11
11. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Result Proceed to OK NG Result: 2 NG See step 16 Result: 1 OK See step 12
12. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Operate the VVT system through the Active Test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 Procedure. Refer to «PROCEDURE - Step 2»(ref-644287-S30639711242014072300000) Result Proceed to OK NG Result: 2 NG See step 15 Result: 1 OK See step 13
13. READ VALUE USING TECHSTREAM (MAF) Refer to «PROCEDURE - Step 6»(ref-644287-S19143643832014072300000) Result Proceed to OK NG Result: 2 NG See step 21 Result: 1 OK See step 14
14. CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P050A. Check the DTC judgment result. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P050A is output) B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B See step 21
15. CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. HINT: Refer to DTC P0011 Procedure. Refer to «DTC P0011: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 1); DTC P0012: Camshaft Position "A" - Timing Over-Retarded (Bank 1); DTC P0021: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 2); DTC P0022: Camshaft Position "A" - Timing Over-Retarded (Bank 2) [02/2014 - ]»(ref-644287-S23051203492014072300000) Result Proceed to NEXT Result: 1 NEXT See step 20
16. REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 20
17. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. Result Proceed to NEXT Result: 1 NEXT See step 20
18. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 20
19. REPAIR OR REPLACE PCV HOSE Repair or replace PCV valve or hose. Result Proceed to NEXT Result: 1 NEXT See step 20
20. CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P050A. Check the DTC judgment result. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P050A is output) B Result: 1 A END Result: 2 B See step 21
21. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [02/2014 - ]»(ref-644130-S10128349732014072300000) HINT: Repair any problems. Result Proceed to NEXT Result: 1 NEXT See step 22
22. CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P050A. Check the DTC judgment result. Result Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTCs are not output) B Result: 2 B END Result: 1 A See step 23
23. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Refer to «PROCEDURE - Step 3»(ref-644287-S31804337242014072300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 24
24. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S17648425442014072300000) HINT: If the result of the inspection performed in step 13 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 25
25. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED HINT: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P050A. Check the DTC judgment result. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P050A is output) B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine and warm it up for 5 minutes or more.
8. Stop the engine.
9. Leave the vehicle outside overnight.
10. Turn the power switch on (IG) and turn the Techstream on [A].
11. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
12. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
13. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
14. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
15. Idle the engine for 1 minute or more [B].
16. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
17. Read the pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
19. Input the DTC: P050B.
20. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] and [B].
21. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. DTC P050B may be set when the engine has the symptoms listed below. If necessary, check the trouble areas listed below. Symptoms Factor Trouble Area Low idle speed when engine is cold (immediately after engine start) Excessive engine friction Engine oil deterioration Rough idle when engine is cold (immediately after engine start) Abnormal combustion Fuel quality
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P050B is output A DTC P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas AF Control / Short FT #1, Long FT #1, Short FT #2 and Long FT #2. Powertrain > Engine and ECT > Data List Tester Display Short FT #1 Long FT #1 Short FT #2 Long FT #2 Read the values displayed on the Techstream at engine idle. Add together the Short FT #1 and Long FT #1 values, and the Short FT #2 and Long FT #2 values to obtain the total fuel trim. Standard The total of the Short FT #1 and Long FT #1 values, and the total of the Short FT #2 and Long FT #2 values is between -20% and 20%. Result Proceed to OK NG Result: 2 NG See step 7 Result: 1 OK See step 3
3. INSPECT THROTTLE BODY WITH MOTOR ASSEMBLY (THROTTLE VALVE) Inspect that there are no deposits around the throttle valve and throttle valve condition. OK No deposits around the throttle valve and throttle valve moves smoothly. Result Proceed to OK NG Result: 1 NG See step 6 Result: 2 OK See step 4
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 14 Result: 1 NG See step 5
5. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Result Proceed to OK NG Result: 1 OK See step 14 Result: 2 NG See step 16
6. REPAIR OR REPLACE THROTTLE BODY WITH MOTOR ASSEMBLY Repair or replace the throttle body with motor assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S40484084302014072300000) HINT: Perform "Inspection After Repair" after replacing the throttle body with motor assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 20
7. CHECK PCV SYSTEM Check the PCV hose connections. Refer to «COMPONENTS [02/2014 - ]»(ref-644279-S05903964552014072300000) OK PCV valve and hose are connected correctly and are not damaged. Result Proceed to OK NG Result: 2 NG See step 19 Result: 1 OK See step 8
8. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [02/2014 - ]»(ref-644292-S41918904412014072300000) OK No leaks from intake system. Result Proceed to OK NG Result: 2 NG See step 18 Result: 1 OK See step 9
9. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK The air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. Result Proceed to OK NG Result: 2 NG See step 17 Result: 1 OK See step 10
10. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position / Primary / MAP and Throttle Idle Position. Powertrain > Engine and ECT > Active Test Active Test Display Control the EGR Step Position Data List Display MAP Throttle Idle Position Confirm that the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when the Active Test is completed. Do not open the EGR valve 30 steps or more during the Active Test. OK MAP and idling condition change in response to EGR step position when Throttle Idle Position is ON in Data List. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition (Throttle Idle Position: ON) Steady idling Idling changes from steady to rough idling or engine stalls MAP (Data List) MAP value is 20 to 40 kPa(abs) (150 to 300 mmHg(abs)) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, the EGR valve may be malfunctioning. Result Proceed to OK NG Result: 2 OK See step 12 Result: 1 NG See step 11
11. INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Result Proceed to OK NG Result: 2 NG See step 16 Result: 1 OK See step 12
12. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Operate the VVT system through the Active Test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 procedure. Refer to «PROCEDURE - Step 2»(ref-644287-S30639711242014072300000) Result Proceed to OK NG Result: 2 NG See step 15 Result: 1 OK See step 13
13. READ VALUE USING TECHSTREAM (MAF) Refer to «PROCEDURE - Step 6»(ref-644287-S19143643832014072300000) Result Proceed to OK NG Result: 2 NG See step 21 Result: 1 OK See step 14
14. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P050B. Check the DTC judgment result. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P050B is output) B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B See step 21
15. CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. HINT: Refer to DTC P0011 Procedure. Refer to «DTC P0011: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 1); DTC P0012: Camshaft Position "A" - Timing Over-Retarded (Bank 1); DTC P0021: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 2); DTC P0022: Camshaft Position "A" - Timing Over-Retarded (Bank 2) [02/2014 - ]»(ref-644287-S23051203492014072300000) Result Proceed to NEXT Result: 1 NEXT See step 20
16. REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S14478430422014072300000) HINT: Perform "Inspection After Repair" after replacing the EGR valve assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 20
17. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. Result Proceed to NEXT Result: 1 NEXT See step 20
18. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 20
19. REPAIR OR REPLACE PCV HOSE Repair or replace the PCV valve or hose. Result Proceed to NEXT Result: 1 NEXT See step 20
20. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P050B. Check the DTC judgment result. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P050B is output) B Result: 1 A END Result: 2 B See step 21
21. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [02/2014 - ]»(ref-644130-S10128349732014072300000) HINT: Repair any problems. Result Proceed to NEXT Result: 1 NEXT See step 22
22. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P050B. Check the DTC judgment result. Result Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTCs are not output) B Result: 2 B END Result: 1 A See step 23
23. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Refer to «PROCEDURE - Step 3»(ref-644287-S31804337242014072300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 24
24. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S17648425442014072300000) HINT: If the result of the inspection performed in step 13 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 25
25. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P050B. Check the DTC judgment result. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P050B is output) B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 5 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0560.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 612

Note. Inspect the fuses for circuits related to this system before performing the following procedure. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 613

1. INSPECT AUXILIARY BATTERY Inspect the auxiliary battery. Refer to «PROCEDURE - Step 1»(ref-644278-S34455179332014072300000) OK Auxiliary battery is not depleted Result Proceed to OK NG Result: 2 NG CHARGE OR REPLACE AUXILIARY BATTERY Result: 1 OK See step 2
2. CHECK AUXILIARY BATTERY TERMINAL Check that the auxiliary battery terminals are not loose or corroded. Refer to «PROCEDURE - Step 4»(ref-644278-S34455179332014072300000) OK Auxiliary battery terminals are not loose or corroded. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE AUXILIARY BATTERY TERMINAL Result: 1 OK See step 3
3. CHECK TERMINAL VOLTAGE (POWER SOURCE OF ECM) *a Front view of wire harness connector (to ECM) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A43-15 (BATT) - Body ground Always 11 to 14 V Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR (AUXILIARY BATTERY - ECM) Result: 1 OK See step 4
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P0560) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0560 is output A DTCs are not output B Result: 1 A REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000)

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the power switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) auxiliary battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the power switch on (IG) and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
15. Input the DTC: P0604.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0604) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the Techstream off. Turn the power switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0604 is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the power switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) auxiliary battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the power switch on (IG) and turn the Techstream on.
11. Wait 1 second or more.
12. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
15. Input the DTC: P0606.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the Techstream off. Turn the power switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait for 1 second or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0606 is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

Scheme 614

1. Stop the engine for 30 minutes or more [A].
2. Connect the Techstream to the DLC3.
3. Turn the power switch on (IG) and turn the Techstream on [B].
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the power switch off and wait for at least 30 seconds.
6. Turn the power switch on (IG) and turn the Techstream on [C].
7. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
8. Start the engine and wait 2 minutes [D].
9. Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [E].
10. Idle the engine for 1 minute [F].
11. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
12. Drive the vehicle at 56 to 80 km/h (35 to 50 mph) for 5 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
13. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [I].
14. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
16. Input the DTC: P0607, P0136, P0137, P0138, P0156, P0157 or P0158.
17. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [I] again.
18. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A DTC P0607 is output B Result: 2 B See step 3 Result: 1 A See step 2
2. INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Refer to the P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first (Refer to «DTC P0136: Oxygen Sensor Circuit (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2; DTC P013C: Oxygen Sensor Slow Response - Rich to Lean Bank 2 Sensor 2; DTC P0156: Oxygen Sensor Circuit (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2) [02/2014 - ]»(ref-644287-S12328112902014072300000) ). Then proceed to "Inspect ECM". If P0137 or P0157 is output, troubleshoot for that DTC first (Refer to «DTC P0136: Oxygen Sensor Circuit (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2; DTC P013C: Oxygen Sensor Slow Response - Rich to Lean Bank 2 Sensor 2; DTC P0156: Oxygen Sensor Circuit (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2) [02/2014 - ]»(ref-644287-S12328112902014072300000) ). Then proceed to "Inspect ECM". If P0138 or P0158 is output, troubleshoot for that DTC first (Refer to «DTC P0136: Oxygen Sensor Circuit (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2; DTC P013C: Oxygen Sensor Slow Response - Rich to Lean Bank 2 Sensor 2; DTC P0156: Oxygen Sensor Circuit (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2) [02/2014 - ]»(ref-644287-S12328112902014072300000) ). Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). Result Proceed to NEXT Result: 1 NEXT See step 6
3. CHECK FOR EXHAUST GAS LEAK Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine. Allow the engine to idle and then rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to "Perform Confirmation Driving Pattern". If no exhaust gas leaks are present, proceed to "Perform Confirmation Driving Pattern". HINT: If no exhaust gas leaks are present, there may be a malfunction in the heated oxygen sensor circuit. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [02/2014 - ]»(ref-644155-S26546829062014072300000) Result Proceed to NEXT Result: 1 NEXT See step 4
4. PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and wait for at least 30 seconds. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or higher. Perform the driving pattern. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. Accelerate the vehicle until 80 km/h (50 mph) and stop the vehicle. Drive the vehicle between 60 to 80 km/h (37 to 50 mph) for 5 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A DTC P0607 is output B DTCs are not output C Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 3 C See step 6 Result: 1 A See step 5
5. INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Refer to the P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first (Refer to «DTC P0136: Oxygen Sensor Circuit (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2; DTC P013C: Oxygen Sensor Slow Response - Rich to Lean Bank 2 Sensor 2; DTC P0156: Oxygen Sensor Circuit (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2) [02/2014 - ]»(ref-644287-S12328112902014072300000) ). Then proceed to "Inspect ECM". If P0137 or P0157 is output, troubleshoot for that DTC first (Refer to «DTC P0136: Oxygen Sensor Circuit (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2; DTC P013C: Oxygen Sensor Slow Response - Rich to Lean Bank 2 Sensor 2; DTC P0156: Oxygen Sensor Circuit (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2) [02/2014 - ]»(ref-644287-S12328112902014072300000) ). Then proceed to "Inspect ECM". If P0138 or P0158 is output, troubleshoot for that DTC first (Refer to «DTC P0136: Oxygen Sensor Circuit (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P013A: Oxygen Sensor Slow Response - Rich to Lean Bank 1 Sensor 2; DTC P013C: Oxygen Sensor Slow Response - Rich to Lean Bank 2 Sensor 2; DTC P0156: Oxygen Sensor Circuit (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2) [02/2014 - ]»(ref-644287-S12328112902014072300000) ). Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). Result Proceed to NEXT Result: 1 NEXT See step 6
6. INSPECT ECM Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Stop the engine and wait for 30 minutes. Turn the power switch on (IG) and turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0607 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the power switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) auxiliary battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the power switch on (IG) and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
15. Input the DTC: P060A.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the Techstream off. Turn the power switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P060A is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

CASE 1 AND 4

CASE 2 AND 3

CASE 1

CASE 2

CASE 3

CASE 4

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the power switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) auxiliary battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the power switch on (IG) and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
15. Input the DTC: P060B.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P060B) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the Techstream off. Turn the power switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P060B is output B DTC P060B and P0327, P0328, P0332 or P0333 are output C Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000) Result: 3 C GO TO DTC (P0327, P0328, P0332 AND P0333). Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor); DTC P0332: Knock Sensor 2 Circuit Low Input (Bank 2); DTC P0333: Knock Sensor 2 Circuit High Input (Bank 2) [02/2014 - ]»(ref-644288-S33058569242014072300000)

CASE 1

CASE 2

CASE 1

CASE 2

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the power switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) auxiliary battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the power switch on (IG) and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
15. Input the DTC: P060E.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the Techstream off. Turn the power switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P060E is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the power switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) auxiliary battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the power switch on (IG) and turn the Techstream on.
11. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
12. Start the engine and wait 30 seconds or more.
13. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
14. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
16. Input the DTC: P062F.
17. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. There is a possibility that the DTC P062F is issued from the ECUs of the ECM and power management control ECU. Use Techstream to conduct a health check to confirm which ECU the DTC is issued from and then inspect the related system. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the power switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000) Powertrain > Hybrid Control > Utility Tester Display Inspection Mode Start the engine and wait 30 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P062F is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Wait 5 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0630.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0630) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes NOTE: If P0630 is output, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when the VIN is input. If DTCs other than P0630 are output, troubleshoot them first. Result Result Proceed to DTC P0630 is output A DTC P0630 and other DTCs are output B Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000) Result: 1 A See step 2
2. INPUT VIN Input the VIN. Refer to «REGISTRATION [02/2014 - ]»(ref-644155-S13472793272014072300000) Result Proceed to NEXT Result: 1 NEXT END

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the Techstream off.
5. Turn the power switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) auxiliary battery terminal.
9. Turn the power switch on (IG).
10. Wait 10 seconds or more.
11. Turn the power switch off.
12. Wait 15 seconds or more.
13. Connect the Techstream to the DLC3.
14. Turn the power switch on (IG) and turn the Techstream on.
15. Wait 5 seconds or more.
16. Enter the following menus: Powertrain / Engine and ECT/ Trouble Codes.
17. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
19. Input the DTC: P0657.
20. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
21. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. After turning power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work. Refer to PRECAUTION [02/2014 - ]

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0657) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) Powertrain > Engine and ECT > Clear DTCs Turn the Techstream off. Turn the power switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) auxiliary battery terminal and wait for 1 minute. Connect the cable to the negative (-) auxiliary battery terminal. Turn the power switch on (IG). Wait 10 seconds or more. Turn the power switch off. Wait 15 seconds or more. Connect the Techstream to the DLC3. Turn the power switch on (IG) and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0657 is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [02/2014 - ]»(ref-644155-S34606825722014072300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S21701891502014072300000)

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Put the engine in inspection mode (maintenance mode). Refer to «INSPECTION MODE PROCEDURE [02/2014 - ]»(ref-644130-S00209877232014072300000)
7. Start the engine and Idle for 10 seconds [A].
8. Turn the power switch off.
9. Leave the power switch off for 55 minutes [B].
10. Turn the power switch on (IG) and turn the Techstream on.
11. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
12. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
14. Input the DTC: P106A.
15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] through [C] again.
16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. Refer to "Data List / Active Test" [Vapor Pressure Pump and MAP]. Refer to «DATA LIST / ACTIVE TEST [02/2014 - ]»(ref-644155-S09753896022014072300000)
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P106A) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P106A is output A DTC P106A and other DTCs are output B HINT: If any DTCs other than P106A are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [02/2014 - ]»(ref-644155-S10604133742014072300000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (VAPOR PRESSURE PUMP AND MAP) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Vapor Pressure Pump and MAP. Powertrain > Engine and ECT > Data List Tester Display MAP Vapor Pressure Pump Compare the Vapor Pressure Pump and MAP data from the Data List with day's atmospheric pressure*. Read the Data List twice, when the engine is both cold and warmed up. HINT: *: Standard atmospheric pressure is 101 kPa(abs) [760 mmHg(abs)]. For every 100 m (328 ft) increase in altitude, pressure drops by 1 kPa (7.5 mmHg). The pressure also varies due to the weather (high atmospheric pressure, low atmospheric pressure). Also, check "Atmosphere Pressure" in the Data List. If you do not know the atmospheric pressure refer to the Vapor Pressure Pump value of other vehicles in the workshop and check the difference in pressure. Result Result Proceed to If the Vapor Pressure Pump value differs from the atmospheric pressure by 3.5 kPa [26.254 mmHg] or higher A If the MAP value differs from the atmospheric pressure by 3.5 kPa [26.254 mmHg] or higher B Result: 2 B See step 4 Result: 1 A See step 3
3. REPLACE CANISTER PUMP MODULE Replace the canister pump module. Refer to «REMOVAL [02/2014 - ]»(ref-644279-S12571784502014072300000) Result Proceed to NEXT Result: 1 NEXT See step 5
4. REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace the manifold absolute pressure sensor. Refer to «REMOVAL [02/2014 - ]»(ref-644290-S18283371122014072300000) Result Proceed to NEXT Result: 1 NEXT See step 5
5. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the power switch on (IG) and the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Vapor Pressure Pump and MAP. Powertrain > Engine and ECT > Data List Tester Display MAP Vapor Pressure Pump Confirm that the difference between Vapor Pressure Pump and MAP are 3.5 kPa [26.25 mmHg] or less. Result Proceed to NEXT Result: 1 NEXT END

Key-off Monitor Sequence 1 to 15

1. ATMOSPHERIC PRESSURE MEASUREMENT

2. FIRST REFERENCE PRESSURE MEASUREMENT

3. VENT VALVE STUCK CLOSED CHECK

4. VACUUM INTRODUCTION FOR CANISTER

5. PURGE VSV STUCK CLOSED CHECK

6. SECOND REFERENCE PRESSURE MEASUREMENT

7. CANISTER LEAK CHECK

8. FUEL VAPOR-CONTAINMENT VALVE (FVCV) STUCK CLOSED CHECK

9. VACUUM INTRODUCTION FOR FUEL TANK

10. FUEL VAPOR-CONTAINMENT VALVE STUCK CLOSED CHECK

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

12 THIRD REFERENCE PRESSURE MEASUREMENT

13. FUEL TANK LEAK CHECK

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

15. ATMOSPHERIC PRESSURE MEASUREMENT

P1420: EVAP SMALL LEAK

P1421: EVAP GROSS LEAK

Refer to EVAP system.

Refer to MONITOR RESULT

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
7. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
8. Input the DTC: P1420 or P1421.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. GO TO EVAP SYSTEM Refer to EVAP System. Refer to «EVAP System [02/2014 - ]»(ref-644285-S11103700972014072300000) Result Proceed to NEXT Result: 1 NEXT END

Key-off Monitor Sequence 1 to 15

1. ATMOSPHERIC PRESSURE MEASUREMENT

2. FIRST REFERENCE PRESSURE MEASUREMENT

3. VENT VALVE STUCK CLOSED CHECK

4. VACUUM INTRODUCTION FOR CANISTER

5. PURGE VSV STUCK CLOSED CHECK

6. SECOND REFERENCE PRESSURE MEASUREMENT

7. CANISTER LEAK CHECK

8. FUEL VAPOR-CONTAINMENT VALVE (FVCV) STUCK CLOSED CHECK

9. VACUUM INTRODUCTION FOR FUEL TANK

10. FUEL VAPOR-CONTAINMENT VALVE STUCK CLOSED CHECK

11. FUEL TANK PRESSURE SENSOR STUCK CHECK

12 THIRD REFERENCE PRESSURE MEASUREMENT

13. FUEL TANK LEAK CHECK

14. FUEL TANK PRESSURE SENSOR STUCK CHECK

15. ATMOSPHERIC PRESSURE MEASUREMENT

P1422: FUEL TANK SMALL LEAK

P1423: FUEL TANK GROSS LEAK

Refer to EVAP system.

Refer to MONITOR RESULT

Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 40 minutes. Do not perform the Evaporative System Check when the fuel tank is higher than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature less than 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the power switch on (IG) and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the power switch off and wait for at least 30 seconds.
5. Turn the power switch on (IG) and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
7. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
8. Input the DTC: P1422 or P1423.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [02/2014 - ]»(ref-644155-S24908012272014072300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. GO TO EVAP SYSTEM Refer to EVAP System. Refer to «EVAP System [02/2014 - ]»(ref-644285-S11103700972014072300000) Result Proceed to NEXT Result: 1 NEXT END
