Engine Control System (Service Information) (2ZR-FAE): Other Toyota Corolla XI

Testing & Diagnostics 45 illustrations ~8311 words

PROCEDURE

  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Inspect the camshaft timing oil control valve assembly (for intake side). Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1). Powertrain > Engine and ECT > Active Test Tester Display Control the VVT Linear (Bank1) Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Standard Condition Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: If the result is not as specified, allow the engine to cool (engine coolant temperature of 50°C (122°F) or less) and perform the Active Test again. DTCs related to the VVT system may be stored due to Active Test operation, but this does not indicate a malfunction. If the operation is not as specified, check the camshaft timing oil control valve assembly, wire harness and ECM. Inspect the camshaft timing oil control valve assembly (for exhaust side). Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Powertrain > Engine and ECT > Active Test Tester Display Control the VVT Exhaust Linear (Bank1) Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. Standard Condition Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: If the result is not as specified, allow the engine to cool (engine coolant temperature of 50°C (122°F) or less) and perform the Active Test again. DTCs related to the VVT system may be stored due to Active Test operation, but this does not indicate a malfunction. If the operation is not as specified, check the camshaft timing oil control valve assembly, wire harness and ECM.

Scheme 217

Scheme 217: PROCEDURE
Scheme 217: PROCEDURE
  1. REMOVE NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 11»(ref-635583-S18108834132014070300000)
  2. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side) Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt, wire harness bracket and camshaft timing oil control valve assembly from the cylinder head cover sub-assembly. NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). If the camshaft timing oil control valve assembly has been struck or dropped, replace it. Remove the O-ring from the camshaft timing oil control valve assembly. *1 O-ring
  3. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side) Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and camshaft timing oil control valve assembly from the cylinder head cover sub-assembly. NOTE: Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). If the camshaft timing oil control valve assembly has been struck or dropped, replace it. Remove the O-ring from the camshaft timing oil control valve assembly. *1 O-ring

Scheme 218

Scheme 218: PROCEDURE
Scheme 218: PROCEDURE
  1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms If the result is not as specified, replace the camshaft timing oil control valve assembly. Check the operation. Connect a battery positive (+) lead to terminal 1 and negative (-) lead to terminal 2, and check the movement of the spool valve. *a Component without harness connected (Camshaft Timing Oil Control Valve Assembly) *b When Applied *c When Cut Off *d Spool Valve OK Condition Specified Condition Battery voltage is applied Valve moves in left arrow direction shown in illustration Battery voltage is cut off Valve moves in right arrow direction shown in illustration NOTE: Accumulation of foreign matter can cause minor pressure leaks. Minor pressure leaks in the intake side oil control valve will cause the intake camshaft to advance. Minor pressure leaks in the exhaust side oil control valve will cause the exhaust camshaft to retard. The inappropriate camshaft timing that results from these leaks will cause a DTC to be stored. If the result is not as specified, replace the camshaft timing oil control valve assembly.
  1. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve assembly. Install the camshaft timing oil control valve assembly to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the camshaft timing oil control valve assembly has been struck or dropped, replace it. Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). Make sure that the O-ring is not cracked or moved out of place when installing the camshaft timing oil control valve assembly. Connect the camshaft timing oil control valve assembly connector.
  2. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side) Apply a light coat of engine oil to a new O-ring and install it to the camshaft timing oil control valve assembly. Install the camshaft timing oil control valve assembly and wire harness bracket to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the camshaft timing oil control valve assembly has been struck or dropped, replace it. Do not allow foreign matter to contact the oil seal face of the camshaft timing oil control valve assembly (connecting surface with the cylinder head cover sub-assembly). Make sure that the O-ring is not cracked or moved out of place when installing the camshaft timing oil control valve assembly. Connect the camshaft timing oil control valve assembly connector.
  3. INSPECT FOR ENGINE OIL LEAK Refer to «PROCEDURE - Step 5»(ref-635585-S29128501622014070300000)
  4. INSTALL NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 64»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 64»(ref-635583-S17790066882014070300000)

Scheme 219

Scheme 219: ILLUSTRATION
Scheme 219: ILLUSTRATION

*1 AIR CLEANER CAP WITH AIR CLEANER HOSE *2 AIR CLEANER CASE SUB-ASSEMBLY *3 BATTERY *4 ENGINE WIRE *5 NO. 2 CYLINDER HEAD COVER *6 AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY *7 BATTERY CLAMP BOLT *8 BATTERY CLAMP SUB-ASSEMBLY *9 NO. 2 VENTILATION HOSE - - N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 220

Scheme 220: ILLUSTRATION
Scheme 220: ILLUSTRATION

*1 CONTINUOUSLY VARIABLE VALVE LIFT CONTROLLER ASSEMBLY *2 CYLINDER HEAD COVER GASKET *3 CYLINDER HEAD COVER SUB-ASSEMBLY *4 IGNITION COIL ASSEMBLY *5 NO. 1 VACUUM SWITCHING VALVE ASSEMBLY *6 GASKET *7 O-RING *8 SEAL WASHER *9 STRAIGHT PIN *10 VALVE LIFT CONTROL ACTUATOR CONNECTOR *11 VALVE LIFT CONTROL ACTUATOR CONNECTOR CLIP *12 WIRE HARNESS CLAMP BRACKET *13 FUEL VAPOR FEED HOSE *14 NO. 1 FUEL VAPOR FEED HOSE N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part Do not apply lubricants to the threaded parts

Scheme 221

Scheme 221
Scheme 221
  1. INSPECT CONTINUOUSLY VARIABLE VALVE LIFT CONTROLLER ASSEMBLY Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Activate the VALVEMATIC(ENG ON). Powertrain > Engine and ECT > Active Test Tester Display Activate the VALVEMATIC(ENG ON) Maintain an engine speed of 3000 RPM with the shift lever in P or N and the vehicle stationary. Tester Display Measurement Item Condition Activate the VALVEMATIC (ENG ON) Operates VALVEMATIC system to set valve lift to maximum or minimum Vehicle is stopped Engine coolant temperature is 40 °C (104 °F) or higher Shift lever is in P or N OK Change in Manifold Absolute Pressure during the Active Test Techstream Operation Result High VALVEMATIC Current Angle: 260 deg (CA) Manifold Absolute Pressure: 25 to 40 kPa (188 to 300 mmHg) Low VALVEMATIC Current Angle: 106 deg (CA) Manifold Absolute Pressure: 35 to 65 kPa (263 to 488 mmHg) HINT: If the vehicle is driven while there is a malfunction in the VALVEMATIC system and the valve lift amount is fixed at the minimum, the vehicle speed cannot exceed 30 to 60 km/h (19 to 37 mph). If the intake valve advance angle is within the VALVEMATIC operation prohibition range, depending on the operating state of the VVT system, the Active Test "Activate the VALVEMATIC (ENG ON)" is prohibited. If the advance angle cannot be detected due to a malfunction in the VVT system, the Active Test "Activate the VALVEMATIC (ENG ON)" is prohibited.

Scheme 222

Scheme 222: PROCEDURE
Scheme 222: PROCEDURE

Scheme 223

Scheme 223
Scheme 223

Scheme 224

Scheme 224
Scheme 224

Scheme 225

Scheme 225
Scheme 225

Scheme 226

Scheme 226
Scheme 226
  1. REMOVE NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 11»(ref-635583-S18108834132014070300000)
  2. REMOVE AIR CLEANER CAP WITH AIR CLEANER HOSE See step 3
  3. REMOVE AIR CLEANER CASE SUB-ASSEMBLY Refer to «PROCEDURE - Step 13»(ref-635583-S18108834132014070300000)
  4. REMOVE BATTERY Refer to «PROCEDURE - Step 14»(ref-635583-S18108834132014070300000)
  5. DISCONNECT ENGINE WIRE Disengage the 9 clamps, and then disconnect the 22 connectors. Remove the 3 bolts and 2 nuts, and disconnect the engine wire. *a Bolt *b Nut
  6. REMOVE IGNITION COIL ASSEMBLY Remove the 4 bolts and 4 ignition coil assemblies from the cylinder head cover sub-assembly.
  7. REMOVE NO. 1 VACUUM SWITCHING VALVE ASSEMBLY Disconnect the No. 1 fuel vapor feed hose from the intake manifold. Slide the clip and disconnect the fuel vapor feed hose from the No. 1 vacuum switching valve assembly. Remove the 2 bolts and No. 1 vacuum switching valve assembly from the cylinder head cover sub-assembly.
  8. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 13»(ref-635583-S08391405402014070300000) & «PROCEDURE - Step 13»(ref-635583-S06481895862014070300000)
  9. REMOVE CYLINDER HEAD COVER GASKET Refer to «PROCEDURE - Step 14»(ref-635583-S08391405402014070300000) & «PROCEDURE - Step 14»(ref-635583-S06481895862014070300000)
  10. REMOVE CONTINUOUSLY VARIABLE VALVE LIFT CONTROLLER ASSEMBLY Using a screwdriver, slide the valve lift control actuator connector clip from the valve lift control actuator connector. NOTE: Slide only the upper part of the valve lift control actuator connector clip, as the straight pin will fall out from the bottom if the valve lift control actuator connector clip is completely removed. Rotate the crankshaft clockwise until the intake camshaft position at the No. 1 cylinder and No. 3 cylinder are as shown in the illustration. *a No. 1 Cylinder *b No. 3 Cylinder HINT: If the intake camshaft position is not as shown in the illustration, rotate the crankshaft clockwise again so that the intake camshaft is aligned as shown in the illustration. Using a screwdriver, lightly pry the valve lift control actuator connector to make a space between the continuously variable valve lift controller assembly and camshaft housing sub-assembly. NOTE: Do not forcibly pry the valve lift control actuator connector. Do not damage the camshaft housing sub-assembly and camshaft bearing cap. Using a magnet hand, remove the straight pin from the valve lift control actuator connector. NOTE: Do not drop the straight pin into the engine. HINT: The straight pin can be removed by utilizing the space between the continuously variable valve lift controller assembly and camshaft housing sub-assembly to move the continuously variable valve lift controller assembly so that there is no load on the straight pin. Using a screwdriver, remove the valve lift control actuator connector clip from the valve lift control actuator connector. NOTE: Do not drop the valve lift control actuator connector clip into the engine. Remove the 2 nuts and wire harness clamp bracket from the camshaft housing sub-assembly. Remove the bolt from the continuously variable valve lift controller assembly. Remove the continuously variable valve lift controller assembly from the camshaft housing sub-assembly. NOTE: If the continuously variable valve lift controller assembly has been struck or dropped, replace it. Remove the O-ring from the continuously variable valve lift controller assembly. *1 O-ring Remove the valve lift control actuator connector from the valve rocker shaft assembly.

Scheme 227

Scheme 227
Scheme 227
  1. INSTALL CONTINUOUSLY VARIABLE VALVE LIFT CONTROLLER ASSEMBLY HINT: Perform "Inspection After Repair" after replacing the continuously variable valve lift controller assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Measure the protrusion length of the continuously variable valve lift controller assembly. *1 Valve Lift Control Actuator Connector *a Protrusion length Standard Protrusion Length 34.57 to 34.73 mm (1.36 to 1.37 in.) HINT: When reinstalling the continuously variable valve lift controller assembly, perform the measurement after the valve lift control actuator connector is installed. It is not necessary to perform this measurement when installing a new continuously variable valve lift controller assembly as the protrusion length is 34.57 to 34.73 mm (1.36 to 1.37 in.). If the protrusion length of the continuously variable valve lift controller assembly is not 34.57 to 34.73 mm (1.36 to 1.37 in.), perform the Active Test and adjust the protrusion length to the specified value. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-635602-S09753887422014070300000) Install a new O-ring to the continuously variable valve lift controller assembly. *1 O-ring *a Protrusion NOTE: Align the protrusion of the O-ring with the protrusion of the continuously variable valve lift controller assembly. Make sure that the O-ring is not protruding from the groove in the continuously variable valve lift controller assembly. Rotate the crankshaft clockwise to retract the valve rocker shaft assembly. Rotate the crankshaft clockwise again until the intake camshaft position at the No. 1 cylinder and No. 3 cylinder are as shown in the illustration. *a No. 1 Cylinder *b No. 3 Cylinder Install the valve lift control actuator connector clip to the valve lift control actuator connector. NOTE: Be sure to insert the protrusions of the valve lift control actuator connector clip into the holes in the valve lift control actuator connector. HINT: A new continuously variable valve lift controller assembly is supplied with the valve lift control actuator connector installed. Make sure to remove the valve lift control actuator connector before installation. Install the valve lift control actuator connector to the valve rocker shaft assembly. Insert the continuously variable valve lift controller assembly into the camshaft housing sub-assembly. Install the continuously variable valve lift controller assembly to the camshaft housing sub-assembly with the bolt. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) NOTE: Make sure the O-ring is not caught between the parts. If the continuously variable valve lift controller assembly has been struck or dropped, replace it. Install the wire harness clamp bracket to the camshaft housing sub-assembly with the 2 nuts. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) Using a screwdriver, slide the valve lift control actuator connector clip from the valve lift control actuator connector. NOTE: Slide only the upper part of the valve lift control actuator connector clip, as the straight pin will fall out from the bottom if the valve lift control actuator connector clip is completely removed. Using a screwdriver, lightly pry the valve lift control actuator connector and align the hole in the valve lift control actuator connector with the hole in the continuously variable valve lift controller assembly. NOTE: Do not forcibly pry the valve lift control actuator connector. Do not damage the camshaft housing sub-assembly or camshaft bearing cap. Insert the straight pin into the valve lift control actuator connector. *1 Continuously Variable Valve Lift Controller Assembly *2 Valve Lift Control Actuator Connector *3 Valve Lift Control Actuator Connector Clip *4 Valve Rocker Shaft Assembly *5 Straight Pin NOTE: Do not use a tool to insert the straight pin. Insert the straight pin by hand. HINT: If the straight pin is difficult to insert, insert the straight pin while lightly prying the valve lift control actuator connector. Using a screwdriver, install the valve lift control actuator connector clip to the valve lift control actuator connector. NOTE: Insert the protrusion of the valve lift control actuator connector clip into the hole in the valve lift control actuator connector.
  2. INSTALL CYLINDER HEAD COVER GASKET Refer to «PROCEDURE - Step 37»(ref-635583-S25045397672014070300000) & «PROCEDURE - Step 37»(ref-635583-S36421822772014070300000)
  3. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY Refer to «PROCEDURE - Step 38»(ref-635583-S25045397672014070300000) & «PROCEDURE - Step 38»(ref-635583-S36421822772014070300000)
  4. INSTALL NO. 1 VACUUM SWITCHING VALVE ASSEMBLY Install the No. 1 vacuum switching valve assembly to the cylinder head cover sub-assembly with the 2 bolts. Bolt A Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf) Bolt B Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Make sure that there is no oil on the bolt threads. Connect the fuel vapor feed hose to the No. 1 vacuum switching valve assembly and slide the clip to secure it. Connect the No. 1 fuel vapor feed hose to the intake manifold.
  5. INSTALL IGNITION COIL ASSEMBLY Install the 4 ignition coil assemblies to the cylinder head cover sub-assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
  6. CONNECT ENGINE WIRE Connect the engine wire with the 3 bolts and 2 nuts. Torque: 8.4 N*m (86 kgf*cm, 74 in.*lbf) Engage the 9 clamps and connect the 22 connectors.
  7. INSTALL BATTERY Refer to «PROCEDURE - Step 42»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 42»(ref-635583-S17790066882014070300000)
  8. INSTALL AIR CLEANER CASE SUB-ASSEMBLY Refer to «PROCEDURE - Step 43»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 43»(ref-635583-S17790066882014070300000)
  9. INSTALL AIR CLEANER CAP WITH AIR CLEANER HOSE See step 3
  10. INSPECT FOR ENGINE OIL LEAK Refer to «PROCEDURE - Step 5»(ref-635585-S29128501622014070300000)
  11. INSTALL NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 64»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 64»(ref-635583-S17790066882014070300000)
  12. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the continuously variable valve lift controller assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000)

Scheme 228

Scheme 228: ILLUSTRATION
Scheme 228: ILLUSTRATION

*A w/ Stud Bolt *B w/o Stud Bolt *1 AIR CLEANER CAP WITH AIR CLEANER HOSE *2 NO. 2 CYLINDER HEAD COVER *3 THROTTLE BODY ASSEMBLY *4 THROTTLE BODY GASKET *5 NO. 1 WATER BY-PASS HOSE *6 NO. 2 WATER BY-PASS HOSE *7 NO. 2 VENTILATION HOSE - - N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part

  1. INSPECT THROTTLE BODY ASSEMBLY Check the throttle control motor operating sound. Turn the ignition switch to ON. When depressing the accelerator pedal, check the operating sound of the throttle control motor. Make sure that no friction noise is emitted from the throttle control motor. If any friction noise exists, replace the throttle body assembly. Check the throttle position sensor. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Throttle Sensor Position. Powertrain > Engine and ECT > Data List Tester Display Throttle Sensor Position Depress the accelerator pedal. When the throttle valve is fully open, check that the Throttle Sensor Position value is within specification. Standard Throttle Valve Opening Percentage Tester Display Specified Condition Throttle Sensor Position 60% or higher NOTE: When checking the throttle valve opening percentage, the shift lever should be in N. Fully depress the accelerator pedal. If the percentage is less than 60%, check the throttle body assembly, wire harness and ECM.
  1. DRAIN ENGINE COOLANT Refer to «PROCEDURE - Step 1»(ref-635587-S34221687702014070300000)
  2. REMOVE NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 11»(ref-635583-S18108834132014070300000)
  3. REMOVE AIR CLEANER CAP WITH AIR CLEANER HOSE Disconnect the mass air flow meter sub-assembly connector and disengage the 2 wire harness clamps. Disengage the 2 clamps. Slide the clip and disconnect the No. 2 ventilation hose from the cylinder head cover sub-assembly. Loosen the hose clamp and remove the air cleaner cap with air cleaner hose.
  4. REMOVE THROTTLE BODY ASSEMBLY Disconnect the throttle body assembly connector. *1 No. 1 Water By-pass Hose *2 No. 2 Water By-pass Hose Slide the 2 clips and disconnect the No. 1 water by-pass hose and No. 2 water by-pass hose from the throttle body assembly. w/ Stud Bolt: Remove the 2 bolts, 2 nuts and throttle body assembly from the intake manifold. NOTE: If the throttle body assembly has been struck or dropped, replace it. w/o Stud Bolt: Remove the 4 bolts and throttle body assembly from the intake manifold. NOTE: If the throttle body assembly has been struck or dropped, replace it.
  5. REMOVE THROTTLE BODY GASKET Remove the throttle body gasket from the intake manifold.
  1. INSPECT THROTTLE BODY ASSEMBLY Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Throttle Body Assembly) Standard Resistance Tester Connection Condition Specified Condition 1 (M-) - 2 (M+) 20°C (68°F) 0.3 to 100 ohms If the result is not as specified, replace the throttle body assembly.
  1. INSTALL THROTTLE BODY GASKET Install a new throttle body gasket onto the intake manifold with the protrusion of the throttle body gasket oriented as shown in the illustration. *a Protrusion
  2. INSTALL THROTTLE BODY ASSEMBLY w/ Stud Bolt: Install the throttle body assembly to the intake manifold with the 2 bolts and 2 nuts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the throttle body assembly has been struck or dropped, replace it. w/o Stud Bolt: Install the throttle body assembly to the intake manifold with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the throttle body assembly has been struck or dropped, replace it. Connect the No. 1 water by-pass hose and No. 2 water by-pass hose to the throttle body assembly and slide the 2 clips to secure them. Connect the throttle body assembly connector.
  3. INSTALL AIR CLEANER CAP WITH AIR CLEANER HOSE Connect the air cleaner cap with air cleaner hose to the throttle body assembly. Engage the 2 clamps to install the air cleaner cap with air cleaner hose. Tighten the hose clamp. Torque: 4.0 N*m (41 kgf*cm, 35 in.*lbf) Connect the No. 2 ventilation hose to the cylinder head cover sub-assembly and slide the clip to secure it. Connect the mass air flow meter sub-assembly connector and engage the 2 wire harness clamps.
  4. INSTALL NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 64»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 64»(ref-635583-S17790066882014070300000)
  5. ADD ENGINE COOLANT Refer to «PROCEDURE - Step 2»(ref-635587-S34221687702014070300000)
  6. INSPECT FOR ENGINE COOLANT LEAK Refer to «PROCEDURE - Step 1»(ref-635615-S30243093042014070300000)
  7. PERFORM INITIALIZATION NOTE: Be sure to perform this procedure after removing and reinstalling the throttle body assembly or any throttle body assembly components. Perform the following procedure after replacing the throttle body assembly or any throttle body assembly components. The following procedure should also be performed if the throttle body assembly is cleaned. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Turn the ignition switch to ON without operating the accelerator pedal. Perform the "Inspection After Repair". Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Start the engine and check that the MIL is not illuminated. After the engine is warmed up, check that the idle speed is within the specified range with the A/C switch off. Standard Idle Speed 600 to 700 RPM NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in P or N. Enter the following menus: Powertrain / Engine and ECT / Data List / Throttle Sensor Position. Powertrain > Engine and ECT > Data List Tester Display Throttle Sensor Position Fully depress the accelerator pedal and check that the value is 60% or higher. Perform a road test and confirm that there are no abnormalities.

Scheme 229

Scheme 229: ILLUSTRATION
Scheme 229: ILLUSTRATION

*1 ECM *2 ECM BRACKET *3 NO. 2 ECM BRACKET - - N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 230

Scheme 230: PROCEDURE
Scheme 230: PROCEDURE

Scheme 231

Scheme 231
Scheme 231

Scheme 232

Scheme 232
Scheme 232
  1. PRECAUTION NOTE: Perform the Vehicle Identification Number (VIN) registration when replacing the ECM. Refer to «REGISTRATION [08/2013 - ]»(ref-635448-S33258955722014070300000) After turning the ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notice before proceeding with work. Refer to «PRECAUTION [08/2013 - ]»(ref-635429-S26537304232014070300000)
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [08/2013 - ]»(ref-635429-S20696467122014070300000)
  3. SEPARATE INLET NO. 1 AIR CLEANER Remove the bolt and separate the inlet No. 1 air cleaner from the air cleaner case sub-assembly.
  4. REMOVE ECM Raise the 2 levers while pushing the locks on the levers, and disconnect the 2 ECM connectors. NOTE: After disconnecting the ECM connectors, make sure that dirt, water or other foreign matter does not contact the connecting parts of the ECM connectors. Disengage the wire harness clamp. Remove the 3 bolts. Disengage the clamp and remove the ECM. NOTE: If the ECM has been struck or dropped, replace it.
  5. REMOVE ECM BRACKET Remove the 2 screws and ECM bracket from the ECM.
  6. REMOVE NO. 2 ECM BRACKET Remove the 2 screws and No. 2 ECM bracket from the ECM.

Scheme 233

Scheme 233
Scheme 233
  1. INSTALL NO. 2 ECM BRACKET Install the No. 2 ECM bracket to the ECM with the 2 screws. Torque: 3.0 N*m (31 kgf*cm, 27 in.*lbf)
  2. INSTALL ECM BRACKET Install the ECM bracket to the ECM with the 2 screws. Torque: 3.0 N*m (31 kgf*cm, 27 in.*lbf)
  3. INSTALL ECM Engage the clamp and install the ECM with the 3 bolts. Torque: 12.5 N*m (127 kgf*cm, 9 ft.*lbf) NOTE: If the ECM has been struck or dropped, replace it. Connect the 2 ECM connectors and lower the 2 levers. NOTE: When connecting the ECM connectors, make sure that dirt, water or other foreign matter does not contact the connecting parts of the ECM connectors. Be sure to securely connect the ECM connectors. Engage the wire harness clamp.
  4. INSTALL INLET NO. 1 AIR CLEANER Install the inlet No. 1 air cleaner to the air cleaner case sub-assembly with the bolt. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf)
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [08/2013 - ]»(ref-635429-S20696467122014070300000)
  6. PERFORM INITIALIZATION Refer to «INITIALIZATION [08/2013 - ]»(ref-635429-S20696467122014070300000)

Scheme 234

Scheme 234: ILLUSTRATION
Scheme 234: ILLUSTRATION

*A w/ Instrument Panel Under Cover - - *1 ACCELERATOR PEDAL SENSOR ASSEMBLY *2 FRONT NO. 1 CONSOLE BOX INSERT *3 NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY - - N*m (kgf*cm, ft.*lbf): Specified torque

  1. INSPECT ACCELERATOR PEDAL SENSOR ASSEMBLY Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Powertrain > Engine and ECT > Data List Tester Display Accel Sensor Out No. 1 Accel Sensor Out No. 2 Read the values displayed on the Techstream. Standard Voltage Tester Display Condition Specified Condition Accel Sensor Out No. 1 Accelerator pedal is fully released 0.5 to 1.1 V Accelerator pedal is fully depressed 2.6 to 4.5 V Accel Sensor Out No. 2 Accelerator pedal is fully released 1.2 to 2.0 V Accelerator pedal is fully depressed 3.4 to 4.75 V If the result is not as specified, check the accelerator pedal sensor assembly, wire harness and ECM.

Scheme 235

Scheme 235: PROCEDURE
Scheme 235: PROCEDURE
  1. REMOVE FRONT NO. 1 CONSOLE BOX INSERT Refer to «PROCEDURE - Step 1»(ref-635616-S37412679762014070300000)
  2. REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (w/ Instrument Panel Under Cover) Refer to «PROCEDURE - Step 9»(ref-635616-S21331348922014070300000)
  3. REMOVE ACCELERATOR PEDAL SENSOR ASSEMBLY NOTE: Avoid physical shock to the accelerator pedal sensor assembly. Do not disassemble the accelerator pedal sensor assembly. The accelerator pedal sensor assembly does not require lubrication. Do not apply oil or other lubricants to the accelerator pedal sensor assembly. If applied, the accelerator pedal sensor assembly must be replaced. Disconnect the accelerator pedal sensor assembly connector. Remove the 2 bolts and accelerator pedal sensor assembly. NOTE: If the accelerator pedal sensor assembly has been struck or dropped, replace it.
  1. INSTALL ACCELERATOR PEDAL SENSOR ASSEMBLY NOTE: Avoid physical shock to the accelerator pedal sensor assembly. Do not disassemble the accelerator pedal sensor assembly. The accelerator pedal sensor assembly does not require lubrication. Do not apply oil or other lubricants to the accelerator pedal sensor assembly. If applied, the accelerator pedal sensor assembly must be replaced. Install the accelerator pedal sensor assembly with the 2 bolts. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) NOTE: If the accelerator pedal sensor assembly has been struck or dropped, replace it. Connect the accelerator pedal sensor assembly connector.
  2. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (w/ Instrument Panel Under Cover) Refer to «PROCEDURE - Step 16»(ref-635616-S27786647472014070300000)
  3. INSTALL FRONT NO. 1 CONSOLE BOX INSERT Refer to «PROCEDURE - Step 9»(ref-635616-S39884561052014070300000)

Scheme 236

Scheme 236: ILLUSTRATION
Scheme 236: ILLUSTRATION
*1MASS AIR FLOW METER SUB-ASSEMBLY

CAUTION / NOTICE / HINT

Note. Perform the mass air flow meter sub-assembly inspection according to the following procedure. Only replace the mass air flow meter sub-assembly when the mass air flow meter sub-assembly value in the Data List (with the engine stopped) is not within the normal operating range or there is foreign matter on the mass air flow meter sub-assembly platinum hot wire (heater).

  1. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Read the value using the Techstream (MAF). NOTE: Perform the inspection with the vehicle indoors and on a level surface. Perform the inspection of the mass air flow meter sub-assembly while it is installed to the air cleaner cap sub-assembly (installed to the vehicle). During the test, do not use an exhaust air duct on the exhaust pipe. Connect the Techstream to the DLC3. Turn the ignition switch to ON (do not start the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAF. Powertrain > Engine and ECT > Data List Tester Display MAF Wait for 30 seconds, and read the value on the Techstream. Standard Condition Tester Display Condition Standard Condition MAF Engine not running 30 seconds after ignition switch turned to ON 0.31 gm/sec or less If the result is not as specified, replace the mass air flow meter sub-assembly. If the result is within the specified range, inspect the mass air flow meter sub-assembly. Refer to «INSPECTION [08/2013 - ]»(ref-635602-S20334434262014070300000)
  2. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000)
  1. REMOVE MASS AIR FLOW METER SUB-ASSEMBLY Disconnect the mass air flow meter sub-assembly connector. Remove the 2 screws and mass air flow meter sub-assembly from the air cleaner cap sub-assembly. NOTE: If the mass air flow meter sub-assembly has been struck or dropped, replace it.

Scheme 237

Scheme 237: PROCEDURE
Scheme 237: PROCEDURE
  1. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Perform a visual check for any foreign matter on the platinum hot wire (heater) and temperature sensor (thermistor) of the mass air flow meter sub-assembly shown in the illustration. *a Platinum Hot Wire (Heater) *b Temperature Sensor (Thermistor) OK There is no foreign matter. If the result is not as specified, replace the mass air flow meter sub-assembly. Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Mass Air Flow Meter Sub-assembly) Standard Resistance Tester Connection Condition Specified Condition 1 (THA) - 2 (E2) -20°C (-4°F) 13.6 to 18.4 kohms 20°C (68°F) 2.21 to 2.69 kohms 60°C (140°F) 0.49 to 0.67 kohms If the result is not as specified, replace the mass air flow meter sub-assembly.
  1. INSTALL MASS AIR FLOW METER SUB-ASSEMBLY HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Install the mass air flow meter sub-assembly to the air cleaner cap sub-assembly with the 2 screws. NOTE: If the mass air flow meter sub-assembly has been struck or dropped, replace it. If reusing the mass air flow meter sub-assembly, be sure to inspect the O-ring. Make sure that the O-ring is not cracked or moved out of place when installing the mass air flow meter sub-assembly. Connect the mass air flow meter sub-assembly connector.
  2. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000)

Scheme 238

Scheme 238: ILLUSTRATION
Scheme 238: ILLUSTRATION

*1 CAMSHAFT POSITION SENSOR (NO. 1 CRANK POSITION SENSOR) (for Intake Side) *2 NO. 2 CYLINDER HEAD COVER *3 CAMSHAFT POSITION SENSOR (NO. 1 CRANK POSITION SENSOR) (for Exhaust Side) - - N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 239

Scheme 239: PROCEDURE
Scheme 239: PROCEDURE

Scheme 240

Scheme 240
Scheme 240
  1. REMOVE NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 11»(ref-635583-S18108834132014070300000)
  2. REMOVE CAMSHAFT POSITION SENSOR (NO. 1 CRANK POSITION SENSOR) for Exhaust Side: Disconnect the camshaft position sensor (No. 1 crank position sensor) connector. Remove the bolt and camshaft position sensor (No. 1 crank position sensor) from the cylinder head cover sub-assembly. NOTE: If the camshaft position sensor (No. 1 crank position sensor) has been struck or dropped, replace it. for Intake Side: Disconnect the camshaft position sensor (No. 1 crank position sensor) connector. Remove the bolt and camshaft position sensor (No. 1 crank position sensor) from the cylinder head cover sub-assembly. NOTE: If the camshaft position sensor (No. 1 crank position sensor) has been struck or dropped, replace it.
  1. INSTALL CAMSHAFT POSITION SENSOR (NO. 1 CRANK POSITION SENSOR) for Intake Side: Clean and degrease the threads of the bolt for the camshaft position sensor (No. 1 crank position sensor). Apply a light coat of engine oil to the O-ring of the camshaft position sensor (No. 1 crank position sensor). *a O-ring Install the camshaft position sensor (No. 1 crank position sensor) to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the camshaft position sensor (No. 1 crank position sensor) has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the camshaft position sensor (No. 1 crank position sensor) connector. for Exhaust Side: Clean and degrease the threads of the bolt for the camshaft position sensor (No. 1 crank position sensor). Apply a light coat of engine oil to the O-ring of the camshaft position sensor (No. 1 crank position sensor). *a O-ring Install the camshaft position sensor (No. 1 crank position sensor) to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the camshaft position sensor (No. 1 crank position sensor) has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the camshaft position sensor (No. 1 crank position sensor) connector.
  2. INSPECT FOR ENGINE OIL LEAK Refer to «PROCEDURE - Step 5»(ref-635585-S29128501622014070300000)
  3. INSTALL NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 64»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 64»(ref-635583-S17790066882014070300000)

Scheme 241

Scheme 241: ILLUSTRATION
Scheme 241: ILLUSTRATION

*1 NO. 2 CYLINDER HEAD COVER *2 VALVEMATIC SHAFT SENSOR (NO. 1 CRANK POSITION SENSOR) N*m (kgf*cm, ft.*lbf): Specified torque

  1. REMOVE NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 11»(ref-635583-S18108834132014070300000)
  2. REMOVE VALVEMATIC SHAFT SENSOR (NO. 1 CRANK POSITION SENSOR) Disconnect the VALVEMATIC shaft sensor (No. 1 crank position sensor) connector. Remove the bolt and VALVEMATIC shaft sensor (No. 1 crank position sensor) from the cylinder head cover sub-assembly. NOTE: If the VALVEMATIC shaft sensor (No. 1 crank position sensor) has been struck or dropped, replace it.
  1. INSTALL VALVEMATIC SHAFT SENSOR (NO. 1 CRANK POSITION SENSOR) Clean and degrease the threads of the bolt for the VALVEMATIC shaft sensor (No. 1 crank position sensor). *a O-ring Apply a light coat of engine oil to the O-ring of the VALVEMATIC shaft sensor (No. 1 crank position sensor). Install the VALVEMATIC shaft sensor (No. 1 crank position sensor) to the cylinder head cover sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the VALVEMATIC shaft sensor (No. 1 crank position sensor) has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the VALVEMATIC shaft sensor (No. 1 crank position sensor) connector.
  2. INSPECT FOR ENGINE OIL LEAK Refer to «PROCEDURE - Step 5»(ref-635585-S29128501622014070300000)
  3. INSTALL NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 64»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 64»(ref-635583-S17790066882014070300000)

Scheme 242

Scheme 242: ILLUSTRATION
Scheme 242: ILLUSTRATION

*1 CRANKSHAFT POSITION SENSOR - - N*m (kgf*cm, ft.*lbf): Specified torque

  1. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the crankshaft position sensor connector. Remove the bolt and crankshaft position sensor from the cylinder block sub-assembly. NOTE: If the crankshaft position sensor has been struck or dropped, replace it.
  1. INSPECT CRANKSHAFT POSITION SENSOR Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Crankshaft Position Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 - 2 Cold 1630 to 2740 ohms Hot 2065 to 3225 ohms HINT: In the table above, the terms "Cold" and "Hot" mean the temperature of the coils themselves. "Cold" is from -10 to 50°C (14 to 122 °F) and "Hot" is from 50 to 100°C (122 to 212°F). If the result is not as specified, replace the crankshaft position sensor.
  1. INSTALL CRANKSHAFT POSITION SENSOR Clean and degrease the threads of the bolt for the crankshaft position sensor. Apply a light coat of engine oil to the O-ring of the crankshaft position sensor. *a O-ring Install the crankshaft position sensor to the cylinder block sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If the crankshaft position sensor has been struck or dropped, replace it. Make sure that the O-ring is not cracked or does not move out of place during installation. Connect the crankshaft position sensor connector.
  2. INSPECT FOR ENGINE OIL LEAK

Scheme 243

Scheme 243: ILLUSTRATION
Scheme 243: ILLUSTRATION

*1 IGNITION COIL ASSEMBLY *2 NO. 2 CYLINDER HEAD COVER *3 SPARK PLUG - - N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 244

Scheme 244: PROCEDURE
Scheme 244: PROCEDURE

Scheme 245

Scheme 245
Scheme 245
  1. REMOVE NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 11»(ref-635583-S18108834132014070300000)
  2. REMOVE IGNITION COIL ASSEMBLY Disconnect the 4 ignition coil assembly connectors. Remove the 4 bolts and 4 ignition coil assemblies from the cylinder head cover sub-assembly. NOTE: If an ignition coil assembly has been struck or dropped, replace it. HINT: Arrange the removed parts in the correct order.
  3. REMOVE SPARK PLUG Using a 14 mm spark plug wrench, remove the 4 spark plugs from the cylinder head sub-assembly. *a 14 mm Spark Plug Wrench NOTE: If a spark plug has been struck or dropped, replace it. HINT: Arrange the removed parts in the correct order.
  1. INSTALL SPARK PLUG HINT: Perform "Inspection After Repair" after replacing a spark plug. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Using a 14 mm spark plug wrench, install the 4 spark plugs to the cylinder head sub-assembly. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) NOTE: If a spark plug has been struck or dropped, replace it. HINT: Install the same parts to their original positions.
  2. INSTALL IGNITION COIL ASSEMBLY HINT: Perform "Inspection After Repair" after replacing an ignition coil assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Install the 4 ignition coil assemblies to the cylinder head cover sub-assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: If an ignition coil assembly has been struck or dropped, replace it. HINT: Install the same parts to their original positions. Connect the 4 ignition coil assembly connectors.
  3. INSTALL NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 64»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 64»(ref-635583-S17790066882014070300000)

Scheme 246

Scheme 246: ILLUSTRATION
Scheme 246: ILLUSTRATION

*1 ENGINE COOLANT TEMPERATURE SENSOR *2 GASKET N*m (kgf*cm, ft.*lbf): Specified torque

Scheme 247

Scheme 247: PROCEDURE
Scheme 247: PROCEDURE
  1. DISCHARGE FUEL SYSTEM PRESSURE Refer to «PRECAUTION [08/2013 - ]»(ref-635599-S18137407982014070300000)
  2. DRAIN ENGINE COOLANT Refer to «PROCEDURE - Step 1»(ref-635587-S34221687702014070300000)
  3. REMOVE FUEL INJECTOR ASSEMBLY Refer to «REMOVAL [08/2013 - ]»(ref-635603-S09560524192014070300000)
  4. REMOVE ENGINE COOLANT TEMPERATURE SENSOR Using a 19 mm union nut wrench, remove the engine coolant temperature sensor from the cylinder head sub-assembly. NOTE: If the engine coolant temperature sensor has been struck or dropped, replace it. Remove the gasket from the engine coolant temperature sensor.

Scheme 248

Scheme 248: PROCEDURE
Scheme 248: PROCEDURE
  1. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Engine Coolant Temperature Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 2.32 to 2.59 kohms 80°C (176°F) 0.310 to 0.326 kohms NOTE: If checking the engine coolant temperature sensor in water, be careful not to allow water to contact the terminals. After checking, wipe the water off the engine coolant temperature sensor. If the result is not as specified, replace the engine coolant temperature sensor.
  1. INSTALL ENGINE COOLANT TEMPERATURE SENSOR HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Install a new gasket to the engine coolant temperature sensor. Using a 19 mm union nut wrench, install the engine coolant temperature sensor to the cylinder head sub-assembly. Torque: 19.6 N*m (200 kgf*cm, 14 ft.*lbf) NOTE: If the engine coolant temperature sensor has been struck or dropped, replace it. Use the torque value compensation formula to calculate the torque value for use when a torque wrench is combined with a tool such as a union nut wrench. Refer to «PRECAUTION [08/2013 - ]»(ref-635429-S26537304232014070300000)
  2. INSTALL FUEL INJECTOR ASSEMBLY Refer to «INSTALLATION [08/2013 - ]»(ref-635603-S26135717572014070300000)
  3. ADD ENGINE COOLANT Refer to «PROCEDURE - Step 2»(ref-635587-S34221687702014070300000)
  4. INSPECT FOR ENGINE COOLANT LEAK Refer to «PROCEDURE - Step 1»(ref-635615-S30243093042014070300000)
  5. PERFORM INITIALIZATION Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000)

Scheme 249

Scheme 249: ILLUSTRATION
Scheme 249: ILLUSTRATION

*1 ENGINE OIL TEMPERATURE SENSOR *2 GASKET N*m (kgf*cm, ft.*lbf): Specified torque • Non-reusable part

  1. REMOVE ENGINE OIL TEMPERATURE SENSOR Disconnect the engine oil temperature sensor connector. Using a 19 mm deep socket wrench, remove the engine oil temperature sensor from the timing chain cover sub-assembly. NOTE: If an engine oil temperature sensor has been struck or dropped, replace it. *a 19 mm Deep Socket Wrench Remove the gasket from the engine oil temperature sensor.
  1. INSPECT ENGINE OIL TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Engine Oil Temperature Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 - 2 30°C (86°F) 2.465 to 3.213 kohms NOTE: If checking the engine oil temperature sensor in water, be careful not to allow water to contact the terminals. After checking, wipe the water off the engine oil temperature sensor. If the result is not as specified, replace the engine oil temperature sensor.
  1. INSTALL ENGINE OIL TEMPERATURE SENSOR Install a new gasket onto the engine oil temperature sensor. Using a 19 mm deep socket wrench, install the engine oil temperature sensor to the timing chain cover sub-assembly. Torque: 19.6 N*m (200 kgf*cm, 14 ft.*lbf) Connect the engine oil temperature sensor connector.

Scheme 250

Scheme 250: ILLUSTRATION
Scheme 250: ILLUSTRATION

*1 KNOCK CONTROL SENSOR - - N*m (kgf*cm, ft.*lbf): Specified torque

  1. REMOVE INTAKE MANIFOLD Refer to «REMOVAL [08/2013 - ]»(ref-635608-S16289482312014070300000)
  2. REMOVE KNOCK CONTROL SENSOR Disconnect the knock control sensor connector. Remove the bolt and knock control sensor from the cylinder block sub-assembly. NOTE: If the knock control sensor has been struck or dropped, replace it.
  1. INSPECT KNOCK CONTROL SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 25 °C (77 °F) 120 to 280 kohms If the result is not as specified, replace the knock control sensor.

Scheme 251

Scheme 251: PROCEDURE
Scheme 251: PROCEDURE
  1. INSTALL KNOCK CONTROL SENSOR HINT: Perform "Inspection After Repair" after replacing the knock control sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Install the knock control sensor to the cylinder block sub-assembly with the bolt so that the knock control sensor installation position is as shown in the illustration. *a Top Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) NOTE: If the knock control sensor has been struck or dropped, replace it. Make sure that the knock control sensor is in the correct position. Connect the knock control sensor connector.
  2. INSTALL INTAKE MANIFOLD Refer to «INSTALLATION [08/2013 - ]»(ref-635608-S27358700852014070300000)

Scheme 252

Scheme 252: ILLUSTRATION
Scheme 252: ILLUSTRATION

*1 AIR CLEANER CAP WITH AIR CLEANER HOSE *2 AIR CLEANER CASE SUB-ASSEMBLY *3 AIR FUEL RATIO SENSOR *4 NO. 2 CYLINDER HEAD COVER *5 AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY *6 NO. 2 VENTILATION HOSE N*m (kgf*cm, ft.*lbf): Specified torque * For use with SST

Scheme 253

Scheme 253: PROCEDURE
Scheme 253: PROCEDURE

Scheme 254

Scheme 254
Scheme 254
  1. REMOVE NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 11»(ref-635583-S18108834132014070300000)
  2. REMOVE AIR CLEANER CAP WITH AIR CLEANER HOSE See step 3
  3. REMOVE AIR CLEANER CASE SUB-ASSEMBLY Refer to «PROCEDURE - Step 13»(ref-635583-S18108834132014070300000)
  4. REMOVE AIR FUEL RATIO SENSOR Disconnect the air fuel ratio sensor wire from the wire harness clamp bracket. Disconnect the air fuel ratio sensor connector. Using SST, remove the air fuel ratio sensor from the exhaust manifold. SST: 09224-00010 NOTE: If the air fuel ratio sensor has been struck or dropped, replace it.
  1. INSPECT AIR FUEL RATIO SENSOR Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Air Fuel Ratio Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 (HA1A) - 2 (+B) 20°C (68°F) 1.6 to 3.2 ohms 1 (HA1A) - 4 (A1A-) Always 10 kohms or higher If the result is not as specified, replace the air fuel ratio sensor.

Scheme 255

Scheme 255: PROCEDURE
Scheme 255: PROCEDURE
  1. INSTALL AIR FUEL RATIO SENSOR HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Using SST, install the air fuel ratio sensor to the exhaust manifold. *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) SST: 09224-00010 without SST [Torque (N*m(kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m(kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If the air fuel ratio sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [08/2013 - ]»(ref-635429-S26537304232014070300000) Connect the air fuel ratio sensor connector. Connect the air fuel ratio sensor wire to the wire harness clamp bracket.
  2. INSTALL AIR CLEANER CASE SUB-ASSEMBLY Refer to «PROCEDURE - Step 43»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 43»(ref-635583-S17790066882014070300000)
  3. INSTALL AIR CLEANER CAP WITH AIR CLEANER HOSE See step 3
  4. INSPECT FOR EXHAUST GAS LEAK
  5. INSTALL NO. 2 CYLINDER HEAD COVER Refer to «PROCEDURE - Step 64»(ref-635583-S10843495692014070300000) & «PROCEDURE - Step 64»(ref-635583-S17790066882014070300000)

Scheme 256

Scheme 256: ILLUSTRATION
Scheme 256: ILLUSTRATION
*1FRONT NO. 1 CONSOLE BOX INSERT

Scheme 257

Scheme 257: ILLUSTRATION
Scheme 257: ILLUSTRATION

*1 FRONT CENTER FLOOR COVER LH *2 HEATED OXYGEN SENSOR *3 WIRE HARNESS CLAMP BRACKET - - N*m (kgf*cm, ft.*lbf): Specified torque * For use with SST

Scheme 258

Scheme 258: PROCEDURE
Scheme 258: PROCEDURE

Scheme 259

Scheme 259
Scheme 259
  1. REMOVE FRONT NO. 1 CONSOLE BOX INSERT Refer to «PROCEDURE - Step 1»(ref-635616-S37412679762014070300000)
  2. DISCONNECT HEATED OXYGEN SENSOR CONNECTOR Remove the clip. Turn back the floor carpet. Disconnect the heated oxygen sensor connector.
  3. REMOVE FRONT CENTER FLOOR COVER LH Disengage the 5 clips to remove the front center floor cover LH.
  4. REMOVE HEATED OXYGEN SENSOR Disengage the clamp and remove the wire harness clamp bracket from the heated oxygen sensor. *1 Wire Harness Clamp Bracket Disengage the clamp and heated oxygen sensor grommet from the vehicle body. *a Grommet Using SST, remove the heated oxygen sensor from the front exhaust pipe assembly (TWC: Front and rear catalyst). SST: 09224-00010 NOTE: If the heated oxygen sensor has been struck or dropped, replace it.

Scheme 260

Scheme 260: PROCEDURE
Scheme 260: PROCEDURE
  1. INSPECT HEATED OXYGEN SENSOR Measure the resistance according to the value(s) in the table below. *a Component without harness connected (Heated Oxygen Sensor) Standard Resistance Tester Connection Condition Specified Condition 1 (HT1B) - 2 (+B) 20°C (68°F) 11 to 16 ohms 1 (HT1B) - 4 (E2) Always 10 kohms or higher If the result is not as specified, replace the heated oxygen sensor.

Scheme 261

Scheme 261: PROCEDURE
Scheme 261: PROCEDURE
  1. INSTALL HEATED OXYGEN SENSOR Using SST, install the heated oxygen sensor to the front exhaust pipe assembly (TWC: Front and rear catalyst). *a Length of SST 30 mm (1.18 in.) *b Length of Torque Wrench 260 mm (10.2 in.) SST: 09224-00010 without SST [Torque (N*m(kgf*cm, ft.*lbf))] Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST [Reading of Torque wrench (N*m(kgf*cm, ft.*lbf))] Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf) NOTE: If the heated oxygen sensor has been struck or dropped, replace it. HINT: This torque value is effective when SST is parallel to the torque wrench. The "with SST" torque value is effective when using SST with a fulcrum length of 30 mm (1.18 in.). The "with SST" torque value is effective when using a torque wrench with a fulcrum length of 260 mm (10.2 in.). If using a torque wrench with a different length, or connecting the torque wrench and SST at an angle, refer to the alternate torque values. Refer to «PRECAUTION [08/2013 - ]»(ref-635429-S26537304232014070300000) Engage the clamp and heated oxygen sensor grommet to the vehicle body. *a Grommet Install the wire harness clamp bracket to the heated oxygen sensor and engage the clamp. *1 Wire Harness Clamp Bracket
  2. INSTALL FRONT CENTER FLOOR COVER LH Engage the 5 clips to install the front center floor cover LH.
  3. CONNECT HEATED OXYGEN SENSOR CONNECTOR Connect the heated oxygen sensor connector. Install the floor carpet. Install the clip.
  4. INSTALL FRONT NO. 1 CONSOLE BOX INSERT Refer to «PROCEDURE - Step 9»(ref-635616-S39884561052014070300000)
  5. INSPECT FOR EXHAUST GAS LEAK
  1. INSPECT IG2 RELAY (IG2) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage not applied between terminals 1 and 2 10 kohms or higher Battery voltage applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the IG2 relay (IG2).
  2. INSPECT EFI-MAIN RELAY (EFI-MAIN) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage not applied between terminals 1 and 2 10 kohms or higher Battery voltage applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the EFI-MAIN relay (EFI-MAIN).
  3. INSPECT INJ RELAY (IGT/INJ) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage not applied between terminals 1 and 2 10 kohms or higher Battery voltage applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the INJ relay (IGT/INJ).

More articles — Engine Control System (Service Information) (2ZR-FAE)
