Engine Control System (Diagnostic Codes (P0010 - P0198)) (2ZR-FAE): Other Toyota Corolla XI

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

ALL

CASE 1

CASE 2

TYPICAL MALFUNCTION THRESHOLDS

CASE 1

CASE 2

COMPONENT OPERATING RANGE

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0010.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 142

CAUTION / NOTICE / HINT

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

PROCEDURE

1. READ OUTPUT DTC (DTC P0010) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC after recording the freeze frame data and DTC. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and wait 5 seconds. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0010 is output A DTCs are not output B Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 1 A See step 2
2. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for intake camshaft). Refer to «INSPECTION [08/2013 - ]»(ref-635602-S35926870272014070300000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09023557312014070300000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) - ECM) Disconnect the camshaft timing oil control valve assembly (for intake camshaft) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B23-1 - B33-75 (OC1+) Always Below 1 ohms B23-2 - B33-74 (OC1-) Always Below 1 ohms B23-1 or B33-75 (OC1+) - Body ground Always 10 kohms or higher B23-2 or B33-74 (OC1-) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

P0011: ADVANCED CAMSHAFT TIMING

P0012: RETARDED CAMSHAFT TIMING

If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator (camshaft timing oil control valve assembly) for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.

MONITOR RESULT

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [08/2013 - ]

P0011, P0012: EXHAUST GAS RECIRCULATION/VVT / IN VVT STUCK B1

Scheme 143

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Idle the engine for 3 minutes or more [D].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0011 or P0012.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
14. Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
15. Idle the engine for 3 minutes or more [G].
16. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
17. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
19. Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. DTC P0011 or P0012 may be stored when foreign matter in the engine oil is caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. That foreign matter may then be captured by the oil filter.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0011 OR P0012) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0011 or P0012 is output A DTC P0011 or P0012 and other DTCs are output B HINT: If any DTCs other than P0011 or P0012 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1). Powertrain > Engine and ECT > Active Test Tester Display Control the VVT Linear (Bank1) Check the engine speed while operating the camshaft timing oil control valve assembly (for intake camshaft) using the Techstream. OK Techstream Operation Engine Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1 and VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635448-S04095086102014070300000) If the result is not acceptable, cool the engine (engine coolant temperature is 50°C (122°F) or less) and perform the Active Test again. Result Proceed to OK NG Result: 2 NG See step 4 Result: 1 OK See step 3
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0011 OR P0012) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0011 or P0012 is output B HINT: DTC P0011 or P0012 may be stored when foreign matter in the engine oil is caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. That foreign matter may then be captured by the oil filter. Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 2 B See step 4
4. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for intake camshaft). Refer to «INSPECTION [08/2013 - ]»(ref-635602-S35926870272014070300000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09023557312014070300000) Result: 1 OK See step 5
5. INSPECT CAMSHAFT TIMING GEAR ASSEMBLY Inspect the camshaft timing gear assembly. Refer to «PROCEDURE - Step 5»(ref-635583-S14588169922014070300000) HINT: Perform "Inspection After Repair" after replacing the camshaft timing gear assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING GEAR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635583-S16066540612014070300000) Result: 1 OK See step 6
6. ADJUST VALVE TIMING HINT: There are no marks on the cylinder head to match up for the purpose of checking valve timing. Valve timing can only be inspected by lining up the colored plates on the timing chain with the marks on the pulleys. It may be necessary to remove and reinstall the chain to match up the alignment marks. Refer to «REASSEMBLY [08/2013 - 04/2014]»(ref-635583-S17611630232014070300000) & «REASSEMBLY [04/2014 - ]»(ref-635583-S11037511972014070300000) Result Proceed to NEXT Result: 1 NEXT See step 7
7. CHECK WHETHER DTC OUTPUT RECURS (DTC P0011 OR P0012) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0011 or P0012 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000)

ALL

CASE 1

CASE 2

CASE 1

CASE 2

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0013.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 144

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0013) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC after recording the freeze frame data and DTC. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and wait 5 seconds. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0013 is output A DTCs are not output B Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 1 A See step 2
2. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for exhaust camshaft). Refer to «INSPECTION [08/2013 - ]»(ref-635602-S35926870272014070300000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09023557312014070300000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) - ECM) Disconnect the camshaft timing oil control valve assembly (for exhaust camshaft) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B22-1 - B33-65 (OE1+) Always Below 1 ohms B22-2 - B33-64 (OE1-) Always Below 1 ohms B22-1 or B33-65 (OE1+) - Body ground Always 10 kohms or higher B22-2 or B33-64 (OE1-) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

P0014: ADVANCED CAMSHAFT TIMING

P0015: RETARDED CAMSHAFT TIMING

If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator (camshaft timing oil control valve assembly) for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [08/2013 - ]

P0014, P0015: EXHAUST GAS RECIRCULATION/VVT / EX VVT STUCK B1

Scheme 145

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Idle the engine for 3 minutes or more [D].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0014 or P0015.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
14. Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
15. Idle the engine for 3 minutes or more [G].
16. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
17. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
18. Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
19. Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. DTC P0014 or P0015 may be stored when foreign matter in the engine oil is caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. This foreign matter may then be captured by the oil filter.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0014 or P0015 is output A DTC P0014 or P0015 and other DTCs are output B HINT: If any DTCs other than P0014 or P0015 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Powertrain > Engine and ECT > Active Test Tester Display Control the VVT Exhaust Linear (Bank1) Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream. OK Techstream Operation Engine Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1, VVT Ex Chg Angle #1]. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635448-S04095086102014070300000) If the result is not acceptable, cool the engine (engine coolant temperature is 50°C (122°F) or less) and perform the Active Test again. Result Proceed to OK NG Result: 2 NG See step 4 Result: 1 OK See step 3
3. CHECK WHETHER DTC OUTPUT RECURS (DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0014 or P0015 is output B HINT: DTC P0014 or P0015 may be stored when foreign matter in the engine oil is caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. This foreign matter may then be captured by the oil filter. Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 2 B See step 4
4. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for exhaust camshaft). Refer to «INSPECTION [08/2013 - ]»(ref-635602-S35926870272014070300000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09023557312014070300000) Result: 1 OK See step 5
5. INSPECT CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Inspect the camshaft timing exhaust gear assembly. Refer to «PROCEDURE - Step 6»(ref-635583-S14588169922014070300000) HINT: Perform "Inspection After Repair" after replacing the camshaft timing exhaust gear assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635583-S16066540612014070300000) Result: 1 OK See step 6
6. ADJUST VALVE TIMING See step 6 Result Proceed to NEXT Result: 1 NEXT See step 7
7. CHECK WHETHER DTC OUTPUT RECURS (DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0014 or P0015 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000)

P0016

P0017

P0016

P0017

Scheme 146

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C].
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P0016 or P0017.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [G].
13. Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Idle the engine for 5 minutes or more [F].
15. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
16. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Check the DTC judgment result.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. The monitor for this DTC detects when the timing chain is shifted by one tooth or more.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0017) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0016 or P0017 is output A DTC P0016 or P0017 and other DTCs are output B HINT: If any DTCs other than P0016 or P0017 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) HINT: If the VVT system can be operated through the Active Test, it can be assumed that the VVT system is operating normally. Connect the Techstream to the DLC3. Start the engine. Turn the A/C switch on. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 1) / Gas Valve Control / VVT Change Angle #1 or VVT Ex Chg Angle #1. Powertrain > Engine and ECT > Active Test Active Test Display Control the VVT Linear (Bank1) Data List Display VVT Change Angle #1 Powertrain > Engine and ECT > Active Test Active Test Display Control the VVT Exhaust Linear (Bank1) Data List Display VVT Ex Chg Angle #1 Perform the Active Test. Check that the displacement angle varies. OK Displacement angle varies. Result Proceed to OK NG Result: 2 NG See step 5 Result: 1 OK See step 3
3. ADJUST VALVE TIMING See step 6 Result Proceed to NEXT Result: 1 NEXT See step 4
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0017) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0016 or P0017 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000)
5. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE OR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for intake or exhaust camshaft). Refer to «INSPECTION [08/2013 - ]»(ref-635602-S35926870272014070300000) Result Proceed to OK NG Result: 2 NG REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE OR EXHAUST CAMSHAFT). Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09023557312014070300000) Result: 1 OK See step 6
6. REPLACE CAMSHAFT TIMING GEAR ASSEMBLY OR CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Replace the camshaft timing gear assembly or camshaft timing exhaust gear assembly. Refer to «REMOVAL [08/2013 - ]»(ref-635583-S16066540612014070300000) HINT: Perform "Inspection After Repair" after replacing the camshaft timing gear assembly or camshaft timing exhaust gear assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 4

ALL

P0031

P0032

P0031

P0032

P0031

P0032

Scheme 147

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and idle it for 5 minutes or more [B].
7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
8. Idle the engine for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0031 or P0032.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. Refer to "Data List / Active Test" [A/F Heater Duty #1]. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635448-S04095086102014070300000)
2. Sensor 1 refers to the sensor closest to the engine assembly.
3. Sensor 2 refers to the sensor farthest away from the engine assembly.
4. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
5. Change the fuel injection volume using the Control the Injection Volume for A/F Sensor function provided in the Active Test and monitor the air fuel ratio sensor output voltage (Refer to «CAUTION / NOTICE / HINT»(ref-635600-S01425922512014070300000) ). If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning.

1. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor. Refer to «INSPECTION [08/2013 - ]»(ref-635602-S06606712102014070300000) HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S25283492012014070300000) Result: 1 OK See step 2
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) Disconnect the air fuel ratio sensor connector. *a Front view of wire harness connector (to Air Fuel Ratio Sensor) Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B17-2 (+B) - Body ground Ignition switch ON 11 to 14 V Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - EFI-MAIN RELAY) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B17-1 (HA1A) - B33-23 (HA1A) Always Below 1 ohms B17-1 (HA1A) or B33-23 (HA1A) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P0031 OR P0032) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0031 or P0032 is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000)

ALL

P0037

P0038

P0141

P0037

P0038 (CASE 1)

P0038 (CASE 2)

P0141

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [08/2013 - ]

P0141: O2 SENSOR HEATER / O2 HEATER B1S2

Scheme 148

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and idle it for 5 minutes or more [B].
7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
8. Idle the engine for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0037, P0038 or P0141.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. Sensor 1 refers to the sensor closest to the engine assembly.
2. Sensor 2 refers to the sensor farthest away from the engine assembly.
3. Refer to "Data List / Active Test" [O2 Heater B1S2 and O2 Heater Curr Val B1S2]. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635448-S04095086102014070300000)
4. When the values for the Data List items O2 Heater Curr Val B1S2 is not 0 A, the heaters are on.
5. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
6. Change the fuel injection volume using the Control the Injection Volume for A/F Sensor function provided in the Active Test and monitor the heated oxygen sensor output voltage (Refer to «CAUTION / NOTICE / HINT»(ref-635600-S01425922512014070300000) ). If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning.

Scheme 149

1. INSPECT HEATED OXYGEN SENSOR (HEATER RESISTANCE) Inspect the heated oxygen sensor. Refer to «INSPECTION [08/2013 - ]»(ref-635602-S37829786042014070300000) HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40045604992014070300000) Result: 1 OK See step 2
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF HEATED OXYGEN SENSOR) Disconnect the heated oxygen sensor connector. *a Front view of wire harness connector (to Heated Oxygen Sensor) Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E36-2 (+B) - Body ground Ignition switch ON 11 to 14 V Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATED OXYGEN SENSOR - EFI-MAIN RELAY) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Disconnect the heated oxygen sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E36-1 (HT1B) - B33-22 (HT1B) Always Below 1 ohms E36-1 (HT1B) or B33-22 (HT1B) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. CHECK WHETHER DTC OUTPUT RECURS (DTC P0037, P0038 OR P0141) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0037, P0038 or P0141 is output B Result: 1 A CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 2 B REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000)

Scheme 150

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
8. Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0101.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-635604-S42089478752014070300000) OK No leaks from intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE INTAKE SYSTEM Result: 1 OK See step 3
3. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS [08/2013 - ]»(ref-635593-S03688383022014070300000) OK PCV valve and hose are connected correctly and are not damaged. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE PCV HOSE Result: 1 OK See step 4
4. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09280270452014070300000) HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 5
5. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P0101. Check the DTC judgment result. Result Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit Result Proceed to NEXT Result: 1 NEXT END

P0102

P0103

Scheme 151

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 5 seconds [B].
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Run the engine at an engine speed of 4000 RPM or higher for 5 seconds [D].
11. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
12. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
14. Input the DTC: P0102 or P0103.
15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 152

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0102 OR P0103) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0102 is output A DTC P0103 is output B Result: 2 B See step 5 Result: 1 A See step 2
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF MASS AIR FLOW METER SUB-ASSEMBLY) Disconnect the mass air flow meter sub-assembly connector. *a Front view of wire harness connector (to Mass Air Flow Meter Sub-assembly) Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B2-3 (+B) - Body ground Ignition switch ON 11 to 14 V Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - EFI-MAIN RELAY) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B33-91 (VG) Always Below 1 ohms B2-4 (E2G) - B33-92 (E2G) Always Below 1 ohms B2-5 (VG) or B33-91 (VG) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. INSPECT MASS AIR FLOW METER SUB-ASSEMBLY Inspect the mass air flow meter sub-assembly, referring to the On-vehicle Inspection for Mass Air Flow Meter. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-635602-S06622389842014070300000) Inspect the mass air flow meter sub-assembly, referring to the Inspection for Mass Air Flow Meter. Refer to «INSPECTION [08/2013 - ]»(ref-635602-S20334434262014070300000) Inspect the function of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / MAF. Powertrain > Engine and ECT > Data List Tester Display MAF Start the engine. Check that the MAF value changes when the engine is raced. OK The reading changes. HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09280270452014070300000)
5. CHECK HARNESS AND CONNECTOR (SENSOR GROUND) Disconnect the mass air flow meter sub-assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-4 (E2G) - Body ground Always Below 1 ohms HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09280270452014070300000) Result: 2 NG See step 6
6. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-4 (E2G) - B33-92 (E2G) Always Below 1 ohms Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

Scheme 153

The manifold absolute pressure sensor detects pressure inside the intake manifold as an absolute pressure with a built-in sensor and outputs it as voltage. Based on the voltage from the manifold absolute pressure sensor, the ECM controls the purge VSV and corrects any errors in the air fuel ratio due to change in pressure.

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher.
7. Move the shift lever to N.
8. Idle the engine for 10 seconds or more [A].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0106.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0106) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0106 is output A DTC P0106 and other DTCs are output B HINT: If any DTCs other than P0106 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (MAP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / MAP. Powertrain > Engine and ECT > Data List Tester Display MAP Read the MAP value. Start the engine. Read the MAP value at idling. Standard Engine Condition Techstream Display Ignition Switch ON 80 to 110 kPa(abs) [600 to 825 mmHg(abs)] Idling 20 to 40 kPa(abs) [150 to 300 mmHg(abs)] Result Proceed to OK NG Result: 1 OK CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 2 NG See step 3
3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-635604-S42089478752014070300000) OK No leaks in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635593-S09867586482014070300000) Result: 2 NG REPAIR OR REPLACE INTAKE SYSTEM

P0107

P0108

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and wait 5 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0107 or P0108.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result shows INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 154

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (MAP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / MAP. Powertrain > Engine and ECT > Data List Tester Display MAP Read the MAP value. OK Same value as the actual atmospheric pressure. HINT: Standard atmospheric pressure is 101 kPa(abs) [758 mmHg(abs)]. For every 100 m (328 ft.) increase in altitude, atmospheric pressure drops by approximately 1 kPa (7.5 mmHg). The pressure also varies due to the weather (high atmospheric pressure, low atmospheric pressure). Check "Atmosphere Pressure" in the Data List. Result Proceed to OK NG Result: 1 OK CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 2 NG See step 2
2. CHECK TERMINAL VOLTAGE (POWER SOURCE OF MANIFOLD ABSOLUTE PRESSURE SENSOR) Disconnect the manifold absolute pressure sensor connector. *a Front view of wire harness connector (to Manifold Absolute Pressure Sensor) Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B39-3 (VC) - B39-1 (E2) Ignition switch ON 4.75 to 5.25 V B39-2 (PIM) - B39-1 (E2) Ignition switch ON 3.0 to 5.25 V Result Proceed to OK NG Result: 2 NG See step 5 Result: 1 OK See step 3
3. REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace the manifold absolute pressure sensor. Refer to «REMOVAL [08/2013 - ]»(ref-635593-S09867586482014070300000) Result Proceed to NEXT Result: 1 NEXT See step 4
4. CHECK WHETHER DTC OUTPUT RECURS (P0107 OR P0108) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0107 or P0108 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000)
5. CHECK HARNESS AND CONNECTOR (MANIFOLD ABSOLUTE PRESSURE SENSOR - ECM) Disconnect the manifold absolute pressure sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B39-3 (VC) - B33-118 (VCPM) Always Below 1 ohms B39-1 (E2) - B33-119 (EPIM) Always Below 1 ohms B39-2 (PIM) - B33-87 (PIM) Always Below 1 ohms B39-3 (VC) or B33-118 (VCPM) - Body ground Always 10 kohms or higher B39-2 (PIM) or B33-87 (PIM) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

ALL

AFTER ENGINE STOP

AFTER COLD ENGINE START

AFTER ENGINE STOP

AFTER COLD ENGINE START

Scheme 155

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter sub-assembly) is malfunctioning. It is not necessary to continue this procedure.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P0111.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F].
13. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
14. Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F] again.
15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result: 1 A GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 2 B REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09280270452014070300000)

Scheme 156

The intake air temperature sensor, mounted on the mass air flow meter sub-assembly, monitors the intake air temperature. The intake air temperature sensor has a built-in thermistor with a resistance that varies according to the temperature of the intake air. When the intake air temperature is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes ( see scheme 1above).

The intake air temperature sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.

Resistor R and the intake air temperature sensor are connected in series. When the resistance value of the intake air temperature sensor changes, according to changes in the intake air temperature, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability.

HINT

When DTC P0112 or P0113 is stored, the ECM enters fail-safe mode. During fail-safe mode, the intake air temperature is estimated to be 20°C (68°F) by the ECM. Fail-safe mode continues until a pass condition is detected.

HINT

When any of these DTCs are output, check the intake air temperature using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Intake Air.

P0112

P0113

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 0.5 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0112 or P0113.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 157

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (INTAKE AIR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Intake Air. Powertrain > Engine and ECT > Data List Tester Display Intake Air Read the value displayed on the Techstream. OK Same as actual intake air temperature. Result Result Proceed to -40°C (-40°F) A Higher than 128°C (262°F) B Same as actual intake air temperature C HINT: If there is an open circuit, the Techstream indicates -40°C (-40°F). If there is a short circuit, the Techstream indicates higher than 128°C (262°F). Result: 2 B See step 4 Result: 3 C CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (CHECK FOR OPEN IN WIRE HARNESS) Disconnect the mass air flow meter sub-assembly connector. *1 Mass Air Flow Meter Sub-assembly *2 ECM *a Front view of wire harness connector (to Mass Air Flow Meter Sub-assembly) - - Connect terminals 1 (THA) and 2 (E2) of the mass air flow meter sub-assembly connector on the wire harness side. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Intake Air. Powertrain > Engine and ECT > Data List Tester Display Intake Air Read the value displayed on the Techstream. Standard Value Higher than 128°C (262°F) HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09280270452014070300000) Result: 2 NG See step 3
3. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-1 (THA) - B33-90 (THA) Always Below 1 ohms B2-2 (E2) - B33-122 (ETHA) Always Below 1 ohms Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
4. READ VALUE USING TECHSTREAM (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the mass air flow meter sub-assembly connector. *1 Mass Air Flow Meter Sub-assembly *2 ECM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Intake Air. Powertrain > Engine and ECT > Data List Tester Display Intake Air Read the value displayed on the Techstream. Standard Value -40°C (-40°F) HINT: Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09280270452014070300000) Result: 2 NG See step 5
5. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-1 (THA) or B33-90 (THA) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

P0115

P0117

P0118

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 0.5 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0115, P0117 or P0118.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 158

HINT

1. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
2. If DTC P0117 is stored, check that the engine does not overheat (the DTC P0117 may be stored due to engine overheating).

1. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Read the value displayed on the Techstream. Standard Value Between 75 and 100°C (167 and 212°F) with warm engine. Result Result Proceed to -40°C (-40°F) A Higher than 135°C (275°F) B Between 75 and 100°C (167 and 212°F) C HINT: If there is an open circuit, the Techstream indicates -40°C (-40°F). If there is a short circuit, the Techstream indicates higher than 135°C (275°F). Result: 2 B See step 4 Result: 3 C CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (CHECK FOR OPEN IN WIRE HARNESS) Disconnect the engine coolant temperature sensor connector. *1 Engine Coolant Temperature Sensor *2 ECM *a Front view of wire harness connector (to Engine Coolant Temperature Sensor) - - Connect terminals 1 and 2 of the engine coolant temperature sensor connector on the wire harness side. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Read the value displayed on the Techstream. Standard Value Higher than 135°C (275°F) HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S02864556602014070300000) Result: 2 NG See step 3
3. CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the engine coolant temperature sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B4-2 - B33-93 (THW) Always Below 1 ohms B4-1 - B33-94 (ETHW) Always Below 1 ohms Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
4. READ VALUE USING TECHSTREAM (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the engine coolant temperature sensor connector. *1 Engine Coolant Temperature Sensor *2 ECM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Read the value displayed on the Techstream. Standard Value -40°C (-40°F) HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S02864556602014070300000) Result: 2 NG See step 5
5. CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the engine coolant temperature sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B4-2 or B33-93 (THW) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR

ALL

COLD START MONITOR

SOAK MONITOR

COLD START MONITOR

SOAK MONITOR

Scheme 159

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
4. Check that the engine coolant temperature is 60°C (140°F) or less.
5. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
6. Turn the ignition switch off and wait for at least 30 seconds.
7. Turn the ignition switch to ON and turn the Techstream on [A].
8. Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0116.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E].
14. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
15. Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E] again.
16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. If any of DTCs P0115, P0117, P0118 or P0125 are output simultaneously with DTC P0116, the engine coolant temperature sensor may have an open or a short circuit. Troubleshoot those DTCs first.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
3. When the DTC is output, check the engine coolant temperature using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. If the Coolant Temp value is lower than the actual engine coolant temperature, the engine coolant temperature sensor circuit may be malfunctioning. In this case, check the wire harnesses and connectors (and those connections) between the ECM and the engine coolant temperature sensor first.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs and other than P0116 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. INSPECT THERMOSTAT Inspect the thermostat (thermostat opening temperature). Refer to «INSPECTION [08/2013 - ]»(ref-635587-S23538294722014070300000) HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S02864556602014070300000) Result: 2 NG REPLACE THERMOSTAT. Refer to «REMOVAL [08/2013 - ]»(ref-635587-S41086038242014070300000)

Scheme 160

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on [A].
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off.
5. With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine and wait 60 seconds or more [C].
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P011B.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] through [D] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (INTAKE AIR) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to create conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Intake Air. Powertrain > Engine and ECT > Data List Tester Display Intake Air Read the value displayed on the Techstream. Standard Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the outside temperature gauge of the vehicle (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent swings in the temperature display. Use an accurate thermometer to determine the outside air temperature. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09280270452014070300000) Result: 1 OK See step 3
3. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Read the value displayed on the Techstream. Standard The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are no heat sources such as a block heater in the engine compartment. Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S02864556602014070300000)

ALL

P0120, P0122, P0123, P0220, P0222, P0223 AND P2135

P0121

P0120

P0121

P0122

P0123

P0220

P0222

P0223

P2135 (CASE 1)

P2135 (CASE 2)

Scheme 161

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. With the vehicle stationary, fully depress and release the accelerator pedal [B].
8. Idle the engine for 2 seconds or more [C].
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [D] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When any of these DTCs or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle valve opening angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is turned off.

Scheme 162

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ VALUE USING TECHSTREAM (THROTTLE POSITION SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Throttle Position No. 1 and Throttle Position No. 2. Powertrain > Engine and ECT > Data List Tester Display Throttle Position No. 1 Throttle Position No. 2 Read the values displayed on the Techstream. Result When Accelerator Pedal Fully Released When Accelerator Pedal Fully Depressed Trouble Area Proceed to Throttle Position No. 1 (VTA1) Throttle Position No. 2 (VTA2) Throttle Position No. 1 (VTA1) Throttle Position No. 2 (VTA2) 0 to 0.2 V 0 to 0.2 V 0 to 0.2 V 0 to 0.2 V VCTA circuit open A 4.5 to 4.98 V 4.5 to 4.98 V 4.5 to 4.98 V 4.5 to 4.98 V ETA circuit open 0 to 0.2 V, or 4.5 to 4.98 V 2.1 to 3.1 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V 2.1 to 3.1 V (Fail-safe) VTA1 circuit open or shorted to ground 0.6 to 1.4 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V 0.6 to 1.4 V (Fail-safe) 0 to 0.2 V, or 4.5 to 4.98 V VTA2 circuit open or shorted to ground 0.5 to 1.1 V 2.1 to 3.1 V 3.2 to 4.8 V (Not fail-safe) 4.6 to 4.98 V (Not fail-safe) Throttle position sensor circuit normal B HINT: DTC P0121 is stored when the VTA1 and VTA2 output voltages are not consistent with the sensor characteristics. Therefore, check the freeze frame data when this DTC is stored. Use the following formula to confirm the relative differences in voltage. Characteristic Sensor Output VTA2 x 0.8 is approximately equal to VTA1 + 1.11 V VTA1: Throttle Position No. 1 VTA2: Throttle Position No. 2 If DTC P0121 is output, proceed to "Check Harness And Connector (Throttle Position Sensor - ECM)". Result: 2 B See step 5 Result: 1 A See step 2
2. CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - ECM) Disconnect the throttle body assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B24-5 (VC) - B33-115 (VCTA) Always Below 1 ohms B24-6 (VTA) - B33-84 (VTA1) Always Below 1 ohms B24-4 (VTA2) - B33-83 (VTA2) Always Below 1 ohms B24-3 (E2) - B33-116 (ETA) Always Below 1 ohms B24-5 (VC) or B33-115 (VCTA) - Body ground Always 10 kohms or higher B24-6 (VTA) or B33-84 (VTA1) - Body ground Always 10 kohms or higher B24-4 (VTA2) or B33-83 (VTA2) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 3
3. INSPECT ECM (VC VOLTAGE) Disconnect the throttle body assembly connector. *a Front view of wire harness connector (to Throttle Body Assembly) Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B24-5 (VC) - B24-3 (E2) Ignition switch ON 4.5 to 5.5 V Result Proceed to OK NG Result: 2 NG REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 1 OK See step 4
4. REPLACE THROTTLE BODY ASSEMBLY Replace the throttle body assembly. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S41226622892014070300000) HINT: Perform "Inspection After Repair" after replacing the throttle body assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 5
5. CHECK WHETHER DTC OUTPUT RECURS (THROTTLE POSITION SENSOR DTCS) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0120, P0121, P0122, P0123, P0220, P0222, P0223, and/or P2135 are output A DTCs are not output B Result: 1 A REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 B END

1. Leave the vehicle outside overnight.
2. Connect the Techstream to the DLC3.
3. Turn the ignition switch to ON and turn the Techstream on.
4. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
5. Read the DTC and record the Freeze Frame Data.
6. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
7. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
8. Check that Coolant Temp is the same or less than Initial Engine Coolant Temp in the freeze frame data.
9. Turn the ignition switch off and wait for at least 30 seconds.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Start the engine.
12. Wait 20 minutes or more.
13. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
14. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
16. Input the DTC: P0125.
17. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

1. If any of DTCs P0115, P0116, P0117 or P0118 are output simultaneously with DTC P0125, the engine coolant temperature sensor may have an open or a short circuit. Troubleshoot those DTCs first.
2. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. INSPECT THERMOSTAT Inspect the thermostat (thermostat opening temperature). Refer to «INSPECTION [08/2013 - ]»(ref-635587-S23538294722014070300000) Result Proceed to OK NG Result: 2 NG REPLACE THERMOSTAT. Refer to «REMOVAL [08/2013 - ]»(ref-635587-S41086038242014070300000) Result: 1 OK See step 3
3. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal cooling fan operation or any modifications. HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S02864556602014070300000) Result: 2 NG REPAIR OR REPLACE COOLING SYSTEM

Scheme 163

1. Stop the engine and allow it to soak.
2. Connect the Techstream to the DLC3.
3. Turn the ignition switch to ON and turn the Techstream on [A].
4. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp and Intake Air.
5. Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
6. Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
7. Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snapshot Configure / Duration / 5 min. Data capture can be started by using the target point function. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or higher will cause data capture to start.
8. After "Coolant Temp" stabilizes, check that "Coolant Temp" is 73°C (163.4°F) or higher [C]. HINT: If "Coolant Temp" is less than 73°C (163.4°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.

HINT

1. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
2. When the DTC is output, check the engine coolant temperature using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. If the Coolant Temp value is lower than the actual engine coolant temperature, the engine coolant temperature sensor circuit may be malfunctioning. In this case, check the wire harnesses and connectors (and those connections) between the ECM and the engine coolant temperature sensor first.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal cooling fan operation or any modifications. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE COOLING SYSTEM Result: 1 OK See step 3
3. INSPECT THERMOSTAT Inspect the thermostat (thermostat opening temperature). Refer to «INSPECTION [08/2013 - ]»(ref-635587-S23538294722014070300000) Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPLACE THERMOSTAT. Refer to «REMOVAL [08/2013 - ]»(ref-635587-S41086038242014070300000)

P0136, P0137, P0138 AND P0139

P0136 AND P0137: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION AND LOW VOLTAGE)

P0136: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)

P0137: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)

P0138: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)

P0139: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT

P013A: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT FROM RICH CONDITION

P0136: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION)

P0137: HEATED OXYGEN SENSOR VOLTAGE CHECK (LOW VOLTAGE)

P0136: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)

P0137: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)

P0138: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)

P0139: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT

P013A: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT FROM RICH CONDITION

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [08/2013 - ]

P0137: O2 SENSOR / MAX VOL B1S2

P0139: O2 SENSOR / F/C TIME B1S2

P0136: O2 SENSOR / MAX OSC B1S2

P013A: O2 SENSOR / RL F/C B1S2

HINT

1. This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
2. Performing this confirmation driving pattern will activate the heated oxygen sensor monitor (the catalyst monitor is performed simultaneously). This is very useful for verifying the completion of a repair.

P0136, P0137 and P0138

Scheme 164

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. With the shift lever in D, drive the vehicle at 60 to 120 km/h (37 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
9. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
11. Input the DTC: P0136, P0137 or P0138.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] and [D] again.
13. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

P0139 and P013A

Scheme 165

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
8. Check that Catalyst Efficiency / Current is Incomplete.
9. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with the shift lever in P [A]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
10. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible.
11. With the shift lever in S, drive the vehicle at 60 km/h (37 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
12. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / RL F/C B1S2 [D].
13. Check the Test Value for RL F/C B1S2. HINT: If Test Value displays 0, perform step [C] until it displays a value larger than 0, as the O2 sensor monitor is not finished.
14. Repeat step [C] 2 times or more in one driving cycle.
15. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
16. Read the pending DTCs [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
17. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
18. Input the DTC: P0139 or P013A.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, drive the vehicle with the shift lever in S, and then perform step [C] again.
20. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 166

HINT

Malfunctioning areas can be identified by performing the Control the Injection Volume for A/F Sensor function provided in the Active Test. The Control the Injection Volume for A/F Sensor function can help to determine whether the air fuel ratio sensor, heated oxygen sensor and other potential trouble areas are malfunctioning.

The following instructions describe how to conduct the Control the Injection Volume for A/F Sensor operation using the Techstream.

1. Connect the Techstream to the DLC3.
2. Start the engine.
3. Turn the Techstream on.
4. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds.
5. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2.
6. Perform the Active Test operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume).
7. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream.

HINT

1. The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%.
2. Each sensor reacts in accordance with increases and decreases in the fuel injection volume.

Note. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds.

Scheme 167

1. Following the Control the Injection Volume for A/F Sensor procedure enables technicians to check and graph the voltage outputs of both the air fuel ratio and heated oxygen sensors.
2. To display the graph, enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2; and then press the graph button on the Data List view.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. Sensor 1 refers to the sensor closest to the engine assembly.
2. Sensor 2 refers to the sensor farthest away from the engine assembly.
3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. READ OUTPUT DTC (DTC P0136, P0137, P0138, P0139 OR P013A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0138 is output A DTC P0137 is output B DTC P0136 is output C DTC P0139 or P013A is output D DTC P0136, P0137, P0138, P0139 or P013A and other DTCs are output E HINT: If any DTCs other than P0136, P0137, P0138, P0139 or P013A are output, troubleshoot those DTCs first. Result: 2 B See step 9 Result: 3 C See step 4 Result: 4 D See step 15 Result: 5 E GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Disconnect the heated oxygen sensor connector. *a Component without harness connected (Heated Oxygen Sensor) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (+B) - 4 (E2) Always 10 kohms or higher 2 (+B) - 3 (OX1B) Always 10 kohms or higher HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40045604992014070300000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT) Turn the ignition switch to off and wait for 5 minutes or more. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-22 (HT1B) - B33-103 (OX1B) Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / O2S B1S2. Powertrain > Engine and ECT > Active Test Active Test Display Control the Injection Volume for A/F Sensor Data List Display O2S B1S2 Change the fuel injection volume using the Techstream, and monitor the voltage output of the heated oxygen sensor displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%. The heated oxygen sensor has a maximum output delay of approximately 20 seconds. Standard Voltage Fluctuates between 0.4 V or less, and 0.55 V or higher. Result Proceed to OK NG Result: 2 NG See step 9 Result: 1 OK See step 5
5. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2. Powertrain > Engine and ECT > Active Test Active Test Display Control the Injection Volume for A/F Sensor Data List Display AFS Voltage B1S1 O2S B1S2 Change the fuel injection volume using the Techstream, and monitor the voltage output of the air fuel ratio and heated oxygen sensors displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%. The air fuel ratio sensor is displayed as AFS Voltage B1S1, and the heated oxygen sensor is displayed as O2S B1S2 on the Techstream. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Result Techstream Display (Sensor) Voltage Variation Proceed to AFS Voltage B1S1 (Air fuel ratio) Alternates between higher and less than 3.3 V OK Remains at higher than 3.3 V NG Remains at less than 3.3 V HINT: A normal heated oxygen sensor voltage (O2S B1S2) reacts in accordance with increases and decreases in fuel injection volumes. When the air fuel ratio sensor voltage (AFS Voltage B1S1) remains at either less or higher than 3.3 V despite the heated oxygen sensor indicating a normal reaction, the air fuel ratio sensor is malfunctioning. Result: 1 OK CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO (FUEL INJECTOR ASSEMBLY, FUEL SYSTEM, INTAKE SYSTEM, ETC.). Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1) [08/2013 - ]»(ref-635600-S23920310912014070300000) Result: 2 NG See step 6
6. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S25283492012014070300000) HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 7
7. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0136, P0137 and P0138). Result Proceed to NEXT Result: 1 NEXT See step 8
8. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P0136. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the drive pattern again but increase the vehicle speed. Result Result Proceed to NORMAL (DTCs are not output) A ABNORMAL (DTC P0136 is output) B HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result: 1 A END Result: 2 B REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40045604992014070300000)
9. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE EXHAUST GAS LEAK POINT Result: 1 OK See step 10
10. INSPECT HEATED OXYGEN SENSOR (HEATER RESISTANCE) See step 1 Result Proceed to OK NG Result: 2 NG REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40045604992014070300000) Result: 1 OK See step 11
11. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Disconnect the heated oxygen sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E36-1 (HT1B) - B33-22 (HT1B) Always Below 1 ohms E36-3 (OX1B) - B33-103 (OX1B) Always Below 1 ohms E36-4 (E2) - B33-135 (EX1B) Always Below 1 ohms E36-1 (HT1B) or B33-22 (HT1B) - Body ground Always 10 kohms or higher E36-3 (OX1B) or B33-103 (OX1B) - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 12
12. REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40045604992014070300000) HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 13
13. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0136, P0137 and P0138). Result Proceed to NEXT Result: 1 NEXT See step 14
14. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136 OR P0137) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P0136 or P0137. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the drive pattern again but increase the vehicle speed. Result Result Proceed to ABNORMAL (DTC P0136 or P0137 is output) A NORMAL (DTCs are not output) B HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result: 1 A REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S25283492012014070300000) Result: 2 B END
15. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE EXHAUST GAS LEAK POINT Result: 1 OK See step 16
16. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Turn the ignition switch off and wait for 5 minutes or more. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-22 (HT1B) - B33-103 (OX1B) Always 10 kohms or higher Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 17
17. PERFORM CONFIRMATION DRIVING PATTERN Perform the Confirmation Driving Pattern (P0139 and P013A). Result Proceed to NEXT Result: 1 NEXT See step 18
18. READ OUTPUT DTC (DTC P0139 OR P013A IS OUTPUT AGAIN) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Powertrain > Engine and ECT > Utility Tester Display All Readiness Input the DTC: P0139 or P013A. Check that the DTC monitor is NORMAL. If the DTC monitor is INCOMPLETE, perform the drive pattern again but increase the vehicle speed. Result Result Proceed to ABNORMAL (DTC P0139 or P013A is output) A NORMAL (DTCs are not output) B HINT: Perform "Inspection After Repair" after replacing the heated oxygen sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result: 1 A REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40045604992014070300000) Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000)

P014C: AIR FUEL RATIO SENSOR RESPONSE RATE (RICH TO LEAN RESPONSE RATE)

P014D: AIR FUEL RATIO SENSOR RESPONSE RATE (LEAN TO RICH RESPONSE RATE)

P015A: AIR FUEL RATIO SENSOR RESPONSE RATE (RICH TO LEAN DELAY)

P015B: AIR FUEL RATIO SENSOR RESPONSE RATE (LEAN TO RICH DELAY)

Refer to detailed information in Checking Monitor Status.

Refer to CHECKING MONITOR STATUS [08/2013 - ]

P014C: O2 SENSOR / RL RES RATE B1S1

P014D: O2 SENSOR / LR RES RATE B1S1

P015A: O2 SENSOR / RL DELAY B1S1

P015B: O2 SENSOR / LR DELAY B1S1

HINT

Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.

Scheme 168

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
8. Check that O2 Sensor / Current is Incomplete. HINT: The test values for the test items RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1 and LR DELAY B1S1 do not exist in the Detail of O2 Sensor monitor at this time (the initial value of "0.000" is indicated in each test item).
9. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
10. Drive the vehicle at a constant speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
11. Check that O2 Sensor / Current becomes Complete. HINT: Check the test values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details / RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1 and LR DELAY B1S1.
12. If the monitor item O2 Sensor / Current does not become Complete (if the test values indicated on the Techstream do not change), perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «CHECKING MONITOR STATUS [08/2013 - ]»(ref-635448-S34033824282014070300000)
13. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
14. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
15. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
16. Input the DTC: P014C, P014D, P015A or P015B.
17. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
18. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. A low air fuel ratio sensor voltage could be caused by a rich air fuel mixture. Check for conditions that would cause the engine to run rich.
2. A high air fuel ratio sensor voltage could be caused by a lean air fuel mixture. Check for conditions that would cause the engine to run lean.
3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was moving or stationary, whether the engine was warmed up or not, whether the air fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction.
4. Sensor 1 refers to the sensor closest to the engine assembly.
5. Sensor 2 refers to the sensor farthest away from the engine assembly.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P014C, P014D, P015A OR P015B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P014C, P014D, P015A or P015B is output A DTC P014C, P014D, P015A or P015B and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P015A or P015B are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 Result Proceed to OK NG Result: 2 NG REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S25283492012014070300000) Result: 1 OK See step 3
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Refer to «PROCEDURE - Step 1»(ref-635598-S33704215082014070300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 4
4. CHECK AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensor is installed to the vehicle. HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S25283492012014070300000) Result: 1 OK See step 5
5. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to Confirmation Driving Pattern. Result Proceed to NEXT Result: 1 NEXT See step 6
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P015A OR P015B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P014C, P014D, P015A or P015B is output A DTCs are not output B Result: 2 B CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 1 A See step 7
7. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S25283492012014070300000) HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 8
8. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to Confirmation Driving Pattern. Result Proceed to NEXT Result: 1 NEXT See step 9
9. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P015A OR P015B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P014C, P014D, P015A or P015B is output B Result: 1 A END Result: 2 B CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1) [08/2013 - ]»(ref-635600-S23920310912014070300000)

P0171 AND P0172: FUEL-TRIM LEAN/RICH

Scheme 169

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on. [A]
6. Start the engine and warm it up (until the engine coolant temperature 75°C (167°F) or higher) with all the accessories switched off. [B]
7. With the engine warmed up, idle the engine for 2 minutes or more. [C]
8. Drive the vehicle at a speed between 60 and 135 km/h (37 and 84 mph) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
11. If on pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Note. Inspect the fuses for circuits related to this system before performing the following procedure.

HINT

1. Sensor 1 refers to the sensor closest to the engine assembly.
2. Sensor 2 refers to the sensor farthest away from the engine assembly.
3. Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.
4. A low air fuel ratio sensor voltage could be caused by a rich air fuel mixture. Check for conditions that would cause the engine to run rich.
5. A high air fuel ratio sensor voltage could be caused by a lean air fuel mixture. Check for conditions that would cause the engine to run lean.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0171 or P0172 is output A DTC P0171 or P0172 and other DTCs are output B HINT: If any DTCs other than P0171 or P0172 are output, troubleshoot those DTCs first. Result: 2 B GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 1 A See step 2
2. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS [08/2013 - ]»(ref-635593-S03688383022014070300000) OK PCV valve and hose are connected correctly and are not damaged. Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE PCV HOSE Result: 1 OK See step 3
3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [08/2013 - ]»(ref-635604-S42089478752014070300000) OK No leaks in intake system. HINT: Perform "Inspection After Repair" after repairing or replacing the intake system. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE INTAKE SYSTEM Result: 1 OK See step 4
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine and run the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Gas AF Control / AFS Voltage B1S1 and O2S B1S2. Powertrain > Engine and ECT > Active Test Active Test Display Control the Injection Volume for A/F Sensor Data List Display AFS Voltage B1S1 O2S B1S2 Perform the Control the Injection Volume for A/F Sensor operation with the engine idling (press the 12.5% or -12.5% button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and the heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 12.5%. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) 12.5% Rich Below 3.1 V -12.5% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) 12.5% Rich Higher than 0.55 V -12.5% Lean Below 0.4 V Result Status AFS Voltage B1S1 Status O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - A Lean Lean Actual air fuel ratio lean PCV valve and hose PCV hose connections Fuel injector assembly blockage Gas leak from exhaust system Intake system Fuel pressure Mass air flow meter sub-assembly Engine coolant temperature sensor Rich Rich Actual air fuel ratio rich Fuel injector assembly leak or blockage Gas leak from exhaust system Ignition system Fuel pressure Mass air flow meter sub-assembly Engine coolant temperature sensor Lean Lean/Rich Air fuel ratio sensor malfunction Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction Air fuel ratio sensor Lean: During Control the Injection Volume for A/F Sensor Active Test, the air fuel ratio sensor output voltage (AFS Voltage B1S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2) is consistently below 0.4 V. Rich: During Control the Injection Volume for A/F Sensor Active Test, AFS Voltage B1S1 is consistently below 3.1 V, and O2S B1S2 is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor Active Test, the output voltage of the air fuel ratio sensor and the heated oxygen sensor alternate correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1 and O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635448-S04095086102014070300000) Result: 2 B See step 11 Result: 1 A See step 5
5. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp. Powertrain > Engine and ECT > Data List Tester Display Coolant Temp Read the Data List twice, when the engine is both cold and warmed up. Standard Techstream Display Condition Specified Condition Coolant Temp Cold engine Same as ambient air temperature Warm engine Between 75 and 100°C (167 and 212°F) HINT: Perform "Inspection After Repair" after replacing the engine coolant temperature sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S02864556602014070300000) Result: 1 OK See step 6
6. READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / MAF, Coolant Temp and Engine Speed. Powertrain > Engine and ECT > Data List Tester Display Engine Speed MAF Coolant Temp Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Techstream Display Condition Specified Condition MAF Shift lever position: N A/C: Off Engine Speed: 3000 RPM Between 3.0 gm/sec and 8.0 gm/sec Result Proceed to OK NG Result: 2 NG See step 16 Result: 1 OK See step 7
7. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «PROCEDURE - Step 2»(ref-635599-S06683354202014070300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE FUEL SYSTEM Result: 1 OK See step 8
8. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. HINT: Perform "Inspection After Repair" after repairing or replacing the exhaust system. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE EXHAUST SYSTEM Result: 1 OK See step 9
9. CHECK FOR SPARK (SPARK TEST) Perform a spark test. Refer to «PROCEDURE - Step 1»(ref-635589-S09514342912014070300000) HINT: If the result of the spark test is normal, proceed to the next step. If the spark plugs or ignition system malfunctions, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Misfire / Cylinder #1 Misfire Count (to Cylinder #4 Misfire Count). Perform "Inspection After Repair" after repairing or replacing the ignition system. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 10
10. INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) Check the injection and volume. HINT: Refer to the fuel injector assembly inspection procedure. Refer to «INSPECTION [08/2013 - ]»(ref-635603-S38375835602014070300000) If the fuel injector assemblies malfunction, engine misfire may occur. The misfire count can be read using the Techstream. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Misfire / Cylinder #1 Misfire Count (to Cylinder #4 Misfire Count). Perform "Inspection After Repair" after replacing the fuel injector assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to OK NG Result: 1 OK See step 15 Result: 2 NG REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL [08/2013 - ]»(ref-635603-S09560524192014070300000)
11. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 Result Proceed to OK NG Result: 2 NG REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S25283492012014070300000) Result: 1 OK See step 12
12. CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) See step 2 Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - EFI-MAIN RELAY) Result: 1 OK See step 13
13. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Refer to «PROCEDURE - Step 1»(ref-635598-S33704215082014070300000) Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 14
14. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S25283492012014070300000) HINT: Perform "Inspection After Repair" after replacing the air fuel ratio sensor. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 15
15. CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0171 or P0172 is output A DTCs are not output B Result: 2 B END Result: 1 A See step 16
16. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [08/2013 - ]»(ref-635429-S33489855532014070300000) HINT: Repair any problems. Result Proceed to NEXT Result: 1 NEXT See step 17
17. CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0171 or P0172 is output A DTCs are not output B Result: 2 B END Result: 1 A See step 18
18. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) See step 3 Result Proceed to OK NG Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR Result: 1 OK See step 19
19. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S09280270452014070300000) HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. Perform "Inspection After Repair" after replacing the mass air flow meter sub-assembly. Refer to «INITIALIZATION [08/2013 - ]»(ref-635448-S41213245822014070300000) Result Proceed to NEXT Result: 1 NEXT See step 20
20. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) Powertrain > Engine and ECT > Clear DTCs Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTCs are not output A DTC P0171 or P0172 is output B Result: 1 A END Result: 2 B REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000)

Scheme 170

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off.
5. With the engine stopped, leave the vehicle as is for 470 minutes or more [A].
6. Turn the ignition switch to ON and turn the Techstream on [B].
7. Enter the following menus: Powertrain / Engine and ECT / Data List / Primary / Coolant Temp.
8. Check that the coolant temperature is -10°C (14°F or higher).
9. Start the engine [C].
10. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
11. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
13. Input the DTC: P0196.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [G].
15. Turn the ignition switch off.
16. Turn the ignition switch to ON and turn the Techstream on [E].
17. Start the engine [F].
18. Wait 3 minutes or more.
19. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
20. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
21. Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
22. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION P0196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Powertrain > Engine and ECT > Trouble Codes Result Result Proceed to DTC P0196 and other DTCs are output A DTC P0196 is output B HINT: If any DTCs other than P0196 are output, troubleshoot those DTCs first. Result: 1 A GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635448-S30152302212014070300000) Result: 2 B REPLACE ENGINE OIL TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40645855912014070300000)

ALL

P0197

P0198

P0197

P0198

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 10 seconds or more.
7. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
8. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
10. Input the DTC: P0197 or P0198.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635448-S28277682012014070300000) HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 171

HINT

Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air fuel ratio was lean or rich, and other data from the time the malfunction occurred.

Scheme 172

1. READ VALUE USING TECHSTREAM (ENGINE OIL TEMPERATURE SENSOR) Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Engine Control / Engine Oil Temperature Sensor. Powertrain > Engine and ECT > Data List Tester Display Engine Oil Temperature Sensor Read the value displayed on the Techstream. Standard value Between 80 and 110°C (176 and 230°F) with warm engine and engine idling Result Result Proceed to -40°C (-40°F) A Higher than 180°C (356°F) B Between 80 and 110°C (176 and 230°F) C HINT: If there is an open circuit, the Techstream indicates -40°C (-40°F). If there is a short circuit, the Techstream indicates higher than 180°C (356°F). Result: 2 B See step 4 Result: 3 C CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [08/2013 - ]»(ref-635448-S17281189312014070300000) Result: 1 A See step 2
2. READ VALUE USING TECHSTREAM (CHECK FOR OPEN IN WIRE HARNESS) Disconnect the engine oil temperature sensor connector. *1 Engine Oil Temperature Sensor *2 ECM *a Front view of wore harness connector (to Engine Oil Temperature Sensor) - - Connect terminals 1 and 2 of the engine oil temperature sensor connector on the wire harness side. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Engine Control / Engine Oil Temperature Sensor. Powertrain > Engine and ECT > Data List Tester Display Engine Oil Temperature Sensor Read the value displayed on the Techstream. Standard Value Higher than 180°C (356°F) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE OIL TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40645855912014070300000) Result: 2 NG See step 3
3. CHECK HARNESS AND CONNECTOR (ENGINE OIL TEMPERATURE SENSOR - ECM) Disconnect the engine oil temperature sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B38-2 - B33-131 (THEO) Always Below 1 ohms B38-1 - B33-132 (ETHE) Always Below 1 ohms Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
4. READ VALUE USING TECHSTREAM (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the engine oil temperature sensor connector. *1 Engine Oil Temperature Sensor *2 ECM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Engine Control / Engine Oil Temperature Sensor. Powertrain > Engine and ECT > Data List Tester Display Engine Oil Temperature Sensor Read the value displayed on the Techstream. Standard Value -40°C (-40°F) Result Proceed to OK NG Result: 1 OK REPLACE ENGINE OIL TEMPERATURE SENSOR. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S40645855912014070300000) Result: 2 NG See step 5
5. CHECK HARNESS AND CONNECTOR (ENGINE OIL TEMPERATURE SENSOR - ECM) Disconnect the engine oil temperature sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B33-131 (THEO) or B38-2 - Body ground Always 10 kohms or higher Result Proceed to OK NG Result: 1 OK REPLACE ECM. Refer to «REMOVAL [08/2013 - ]»(ref-635602-S16348185712014070300000) Result: 2 NG REPAIR OR REPLACE HARNESS OR CONNECTOR
