Engine, Repair Using Short-Block
Remove engine - see operation "Engine, Remove and Install".
Remove all cable and hose connections from engine.
Attach engine with transmission to workshop hoist and detach from front axle body.
Remove transmission from cylinder block.
Mount engine on Installation Stand KM-412 with Adapters KM-412-8-1 and KM-412-16 - remove attaching parts as necessary.
Remove all attaching parts from engine - see corresponding operations.
Drive new centring sleeves (1) into cylinder block up to stop.
Emboss engine number in cylinder block (arrow) with numbers punch.
Install all attaching parts on engine - see corresponding operations. Required tightening torques - see "Recommended Torque Values".
Remove engine from installation stand and remove Adapters KM-412-8-1 and KM-412-16 from engine.
Attach transmission to cylinder block.
Attach engine with transmission to front axle body. Install/attach all engine attaching parts, hose and cable connections.
Install engine - see operation "Engine, Remove and Install".
