Replace Ribbed V-Belt Guide Roller Opel Astra G

Remove

1. 1. Open bonnet
2. 2. Remove air cleaner housing (4) • 1 wiring harness plug (1) • 1 fastening bolt (3) • Air intake manifold – 1 clamp (2)

3. 3. Remove ribbed V-belt • Mark direction of rotation • Tension ribbed V-belt tensioner in direction of arrow – using fastening bolt (1) • Remove ribbed-V-belt

4. 4. Remove ribbed V-belt guide roller (2) • 1 tightening bolt (1)

Install

5. 5. Fit ribbed V-belt guide roller • 1 fastening bolt – Tightening torque 38.2 Nm
6. 6. Insert ribbed V-belt • Tension ribbed V-belt tensioner in direction of arrow using fastening bolt (1) and place ribbed V-belt in position – I. Ribbed V-belt without air conditioning – II. Ribbed V-belt with air conditioning

7. 7. Install air cleaner housing • 1 fastening bolt – Tightening torque 15 Nm • Air intake manifold – 1 clip – Tightening torque 3.5 Nm • 1 mass air flow meter wiring harness plug
8. 8. Close bonnet
