Illustration
- 1. Cylinder head height
- 2. Installation height of valve guide
- 3. Installation height of valve
- 4. Valve seat width in cylinder head
- 5. Valve seat angle in cylinder head
- 6. Valve stem diameter
- 7. Valve seat angle at valve
- 8. Valve length
- 9. Valve head – diameter
| Engine | | Z-17 DTL |
|---|
| Cylinder head height 1) | mm | 94.95 – 95.05 |
| Valve seat width in cylinder head | | |
| Intake valve | mm | 1.6 – 1.8 |
| Exhaust valve | mm | 1.4 – 1.6 |
| Valve seat angle in cylinder head | | 89.5° |
| Valve guide inside diameter | mm | 6.0 |
| Length of valve guide | | |
| Intake valve | mm | 41.75 – 42.25 |
| Exhaust valve | mm | 41.75 – 42.25 |
| Installation height of valve guide | | |
| Intake valve | mm | 11.1 – 11.3 |
| Exhaust valve | mm | 11.1 – 11.3 |
| Installation height of valves | | |
| Intake valve | mm | 36.85 – 37.25 |
| Exhaust valve | mm | 36.76 - 37.16 |
| Engine | | Z-17 DTL |
|---|
| Valve length | | |
| Standard size | | |
| | Intake valve | mm | 98.45 |
| | Exhaust valve | mm | 98.10 |
| Ø Valve stem | | |
| Standard size | | |
| | Intake valve | mm | 5.97 |
| | Exhaust valve | mm | 5.96 |
| Valve play | | |
| Standard size | | |
| | Intake valve | mm | 0.40 |
| | Exhaust valve | mm | 0.40 |
| Engine | | Z-17 DTL |
|---|
| Valve stem play | | |
| | Intake valve | mm | 0.0190 |
| | Exhaust valve | mm | 0.0215 |
| perm. runout of the valve stem | mm | 0.01 |
| Ø Valve head | | |
| | Intake valve | mm | 27.5 |
| | Exhaust valve | mm | 26.5 |
| Valve seat angle at valve head | mm | 89° |
| Valve rotator | | |
| | Intake valve | | No code |
| | Exhaust valve | | No code |
| Camshaft | | |
| Cam lift | | |
| | Intake | mm | 7.80 (new) -7.75 (used) |
| | Exhaust | mm | 7.95 (new) -7.90 (used) |
) Resurfacing of the cylinder head is only permissible within the specified tolerance. If the minimum dimension of 94.95 mm is not met, replace the cylinder head.
