Engine- Special Tools - N12 Engine: Other MINI Cooper I

Mechanical 23 illustrations ~1280 words

11 0 240 Coupling

In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225

Note: For adapting test probes to pressure gauge 11 0 162

Engine: All models

Order number: 11 0 240

Coupling

Scheme 790

Scheme 790: 11 0 240 Coupling

11 0 260 Engine hoist

Note: For removing and installing engine

Engine: N12, N14, S62

SI number: 1 23 98(390)

Order number: 11 0 260

Engine hoist

Consisting of

1 = 11 0 261 Lifting beam

Scheme 791

Scheme 791: 11 0 260 Engine hoist

11 1 480 Pliers

Minimum set: Mechanical tools

Note: For removing valve stem seal

Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N12, N14, N45, N52, N53, N54, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11

Storage location: A10, B10

SI number: 1 01 93 (621)

Order number: 11 1 480

Pliers

Scheme 792

Scheme 792: 11 1 480 Pliers

11 4 190 1/4" extension piece

Minimum set: Mechanical tools

In conjunction with: 11 3 390, 00 2 050

Note: M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit

Series: All models

Storage location: B6

SI number: 1 06 94(801)

Order number: 11 4 190

1/4" extension piece

Scheme 793

Scheme 793: 11 4 190 1/4" extension piece

11 4 480 Placement boards (2 x)

Minimum set: Mechanical tools

Note: For storing individual components of cylinder head.

Engine: N12, N14, N51, N52, N53, N54

SI number: 1 17 04 (130)

Order number: 11 4 480

Placement boards (2 x)

Consisting of

1 = 11 4 481 Placement board, inlet side

2 = 11 4 482 Placement board, exhaust side

Scheme 794

Scheme 794: 11 4 480 Placement boards (2 x)

11 6 380 Bush

Minimum set: Mechanical tools

Note: For fitting valve stem seal

Engine: M47, M47TU, M57, M57T2, M57TU, N12, N14, N40, N42, N45, N46, N52, N53, N54, N62, N73

Storage location: A36

SI number: 1 06 98 (306)

Order number: 11 6 380

Bush

Scheme 795

Scheme 795: 11 6 380 Bush

11 7 020 Socket wrench socket WAF 22

Minimum set: Mechanical tools

Note: For loosening and tightening oxygen sensor

Engine: M10, M20, M30, M40, M42, M50, M52TU, M54, M56, M57, M60, M70, M73, N12, N14, N42, N45, N46, N53, N54, S14, S38, S50B30, S50B32, S50US, S52US, S54

Storage location: C13

Order number: 11 7 020

Socket wrench socket WAF 22

Scheme 796

Scheme 796: 11 7 020 Socket wrench socket WAF 22

11 8 730 Adapter

Minimum set: Mechanical tools

In conjunction with: 11 0 220

Note: For compression testing.

Engine: N12, N14, N43, N53, N54

SI number: 1 04 07 (352)

Order number: 11 8 730

Adapter

Scheme 797

Scheme 797: 11 8 730 Adapter

11 9 000 Cylinder head expander tool

Minimum set: Mechanical tools

In conjunction with: Assembly stand 00 1 450

Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N12, N14, N40, N42, N45, N46, N51, N52, N53, N54, N62, N62TU, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17

Storage location: Single

SI number: 1 03 02 (833)

Order number: 11 9 000

Cylinder head expander tool

Consisting of

1 = 11 9 001 Fixture

2 = 11 9 002 Rod

3 = 11 9 003 Sliding block with M10 thread

4 = 11 9 004 Tab

5 = 11 9 005 Quick tensioner

6 = 11 9 006 Aluminium profile insert

7 = 11 9 007 Slide

8 = 11 9 008 Profile plastic part

9 = 11 9 009 Lever

10 = 11 9 011 Hook

11 = 11 9 012 Valve spring cage

Note: Engine M41, M51, S50

12 = 11 9 013 Valve spring cage

Note: Engine M43, M73

13 = 11 9 014 Valve spring cage

Note: Engine M44, M52, M54, M56, M62, S52, S54, S62

14 = 11 9 015 Valve spring cage

Note: Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73

Scheme 798

Scheme 798: 11 9 000 Cylinder head expander tool

15 = 11 9 016 Valve spring cage

Note: Engine M21, M40

16 = 11 8 421 Valve spring cage

Note: Engine: W10, W11, W17

17 = 11 9 017 Valve spring cage

Note: Engine N52

11 9 150 Special wrench

Minimum set: Mechanical tools

In conjunction with: 11 7 030

Note: For releasing and tightening down oxygen sensors

Engine: M54, M56, N12, N14, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S85

Storage location: A42

SI number: 01 15 00 (609)

Order number: 11 9 150

Special wrench

Scheme 799

Scheme 799: 11 9 150 Special wrench

11 9 280 Holder

Minimum set: Mechanical tools

Note: For crankshaft when releasing/tightening central bolt

Engine: N12, N14, N40, N42, N45, N46, N52

Storage location: A43, B43, C43

SI number: 1 01 01(662)

Order number: 11 9 280

Holder

Scheme 800

Scheme 800: 11 9 280 Holder

11 9 340 Chain tensioner, complete

Minimum set: Mechanical tools

Note: For tensioning timing chain when adjusting timing

Engine: N12, N14, N40, N42, N45, N46, N51, N52, N53, N54

Storage location: B43

SI number: 1 01 01(662)

Order number: 11 9 340

Chain tensioner, complete

Consisting of

1 = 11 9 341 Screw

2 = 11 9 342 Spindle

Scheme 801

Scheme 801: 11 9 340 Chain tensioner, complete

11 9 530 Engine support plate

In conjunction with: 00 2 300" 00 1 450

Note: For supporting engine on assembly stand.

Engine: N12, N14

SI number: 1 26 06 321

Order number: 11 9 530

Engine support plate

Consisting of

1 = 11 9 531 Engine support plate

2 = 11 9 532 Set of screws

Scheme 802

Scheme 802: 11 9 530 Engine support plate

11 9 540 Gauge

Note: For locating camshaft in TDC position.

Engine: N12

SI number: 1 26 06 321

Order number: 11 9 540

Gauge

Scheme 803

Scheme 803: 11 9 540 Gauge

11 9 560 Adapter

Note: For oil pressure testing.

Engine: N12, N14

SI number: 1 26 06 321

Order number: 11 9 560

Adapter

Scheme 804

Scheme 804: 11 9 560 Adapter

11 9 580 Socket ring wrench

Note: For removing and installing friction gear and auxiliary water pump.

Engine: N12, N14

SI number: 1 26 06 321

Order number: 11 9 580

Socket ring wrench

Consisting of

1 = 11 9 581 Ring wrench

2 = 11 9 582 Socket WAF 8

3 = 11 9 583 Socket WAF 10

Scheme 805

Scheme 805: 11 9 580 Socket ring wrench

11 9 590 Plug mandrel

Note: For locating crankshaft in TDC position.

Engine: N12, N14

SI number: 1 26 06 321

Order number: 11 9 590

Plug mandrel

Scheme 806

Scheme 806: 11 9 590 Plug mandrel

11 9 600 Installer

Note: For installing front crankshaft seal.

Engine: N12, N14

SI number: 1 26 06 321

Order number: 11 9 600

Installer

Consisting of

1 = 11 9 601 Basic body

2 = 11 9 602 Pressure sleeve

3 = 11 9 603 Nut with bearing

Scheme 807

Scheme 807: 11 9 600 Installer

11 9 610 Installer

Note: For installing rear shaft seal on crankshaft.

Engine: N12, N14

SI number: 1 26 06 321

Order number: 11 9 610

Installer

Consisting of

1 = 11 9 611 Basic body

2 = 11 9 612 Pressure sleeve

3 = 11 9 613 Nut with bearing

Scheme 808

Scheme 808: 11 9 610 Installer

11 9 620 Insertion tool

Note: For installing piston with conrod in crankcase.

Engine: N12, N14

SI number: 1 26 06 321

Order number: 11 9 620

Insertion tool

Scheme 809

Scheme 809: 11 9 620 Insertion tool

11 9 650 Press-down device

Note: For pressing down camshafts during removal and installation.

Engine: N12

SI number: 1 26 06 321

Order number: 11 9 650

Press-down device

Consisting of

1 = 11 9 651 Basic body

2 = 11 9 652 Set of screws

Scheme 810

Scheme 810: 11 9 650 Press-down device

11 9 670 Slip bush

Note: For installing piston in crankcase.

Engine: N12, N14

SI number: 1 26 06 321

Order number: 11 9 670

Slip bush

Scheme 811

Scheme 811: 11 9 670 Slip bush

11 9 811 Holder

Order number: 11 9 811

Holder

Scheme 812

Scheme 812: 11 9 811 Holder

11 9 812 Screw

Order number: 11 9 812

Screw
