Engine - Repair - Cooper (W10 Engine): NVH MINI Cooper I

Mechanical 5 illustrations ~207 words

11 23 010 Removing and installing or replacing vibration damper

Note. For Special Tool identification, see ENGINE- SPECIAL TOOLS - COOPER (1.6L) R50/W10 .

Special Tools Required

  1. 11 2 150
  2. 11 8 241
  3. 11 8 242
  4. 11 8 270
  5. 11 8 310
  6. 11 8 320

Necessary Preliminary Tasks

  1. Remove right wheel. Refer to «36 10 300 REMOVING OR INSTALLING FRONT OR REAR WHEEL»(ref-203076-S22577949262005103000000) .
  2. Remove right wheel arch liner. Refer to «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH LINER»(ref-203078-S35135088012005103000000) .
  3. Remove alternator drive belt. Refer to «11 28 010 REPLACING ALTERNATOR DRIVE BELT (W10)»(ref-203045-S40060016012005103000000) .

Remove central bolt of vibration damper with special tools 11 2 150 and 11 8 320.

Scheme 7

Scheme 7
Scheme 7

Insert special tool 11 8 270 and tighten down.

Installation

Central bolt of crankshaft belt pulley.

Tightening torque, refer to 11 23 1AZ in ENGINE - TIGHTENING TORQUES- COOPER (1.6L) R50/W10 .

Scheme 8

Scheme 8
Scheme 8

Attach special tool 11 8 310 (three-claw extractor tool) and remove belt pulley.

Scheme 9

Scheme 9
Scheme 9

Remove special tool 11 8 270 and install special tool 11 8 242.

Scheme 10

Scheme 10
Scheme 10

Reinstall belt pulley with special tool 11 8 242 and 11 8 241.

Scheme 11

Scheme 11
Scheme 11

Assemble engine.
