11 0 240 Coupling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note. For adapting test probes to pressure gauge 11 0 162
Engine: All models
Order number: 11 0 240
Coupling
Scheme 1025
11 0 260 Engine hoist
Note. For removing and installing engine
Engine: N12, N14, S62
SI number: 1 23 98(390)
Order number: 11 0 260
Engine hoist
Consisting of
1 = 11 0 261 Lifting beam
Scheme 1026
11 1 480 Pliers
Minimum set: Mechanical tools
Note. For removing valve stem seal
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N12, N14, N45, N52, N53, N54, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11
Storage location: A10, B10
SI number: 1 01 93 (621)
Order number: 11 1 480
Pliers
Scheme 1027
11 4 190 1/4" extension piece
Minimum set: Mechanical tools
In conjunction with: 11 3 390, 00 2 050
Note. M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage location: B6
SI number: 1 06 94(801)
Order number: 11 4 190
1/4" extension piece
Scheme 1028
11 4 480 Placement boards (2 x)
Minimum set: Mechanical tools
Note. For storing individual components of cylinder head.
Engine: N12, N14, N45T, N51, N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 4 480
Placement boards (2 x)
Consisting of
1 = 11 4 481 Placement board, inlet side
2 = 11 4 482 Placement board, exhaust side
Scheme 1029
11 6 380 Bush
Minimum set: Mechanical tools
Note. For fitting valve stem seal
Engine: M47, M47TU, M57, M57T2, M57TU, N12, N14, N40, N42, N45, N45T, N46, N46T, N52, N53, N54, N62, N73
Storage location: B15
SI number: 1 06 98 (306)
Order number: 11 6 380
Bush
Scheme 1030
11 7 020 Socket wrench socket WAF 22
Minimum set: Mechanical tools
Note. For loosening and tightening oxygen sensor
Engine: M10, M20, M30, M40, M42, M50, M52TU, M54, M56, M57, M60, M70, M73, N12, N14, N42, N45, N46, N53, N54, S14, S38, S50B30, S50B32, S50US, S52US, S54
Storage location: C13
Order number: 11 7 020
Socket wrench socket WAF 22
Scheme 1031
11 8 730 Adapter
Minimum set: Mechanical tools
In conjunction with: 11 0 220
Note. For compression testing.
Engine: N12, N14, N43, N53, N54
SI number: 1 04 07 (352)
Order number: 11 8 730
Adapter
Scheme 1032
11 9 000 Cylinder head expander tool
Minimum set: Mechanical tools
In conjunction with: Assembly stand 00 1 450
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N12, N14, N40, N42, N45, N46, N51, N52, N53, N54, N62, N62TU, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Storage location: Single
SI number: 1 03 02 (833)
Order number: 11 9 000
Cylinder head expander tool
Consisting of
1 = 11 9 001 Fixture
2 = 11 9 002 Rod
3 = 11 9 003 Sliding block with M10 thread
4 = 11 9 004 Tab
5 = 11 9 005 Quick tensioner
6 = 11 9 006 Aluminium profile insert
7 = 11 9 007 Slide
8 = 11 9 008 Profile plastic part
9 = 11 9 009 Lever
10 = 11 9 011 Hook
11 = 11 9 012 Valve spring cage
Note. Engine M41, M51, S50
12 = 11 9 013 Valve spring cage
Note. Engine M43, M73
13 = 11 9 014 Valve spring cage
Note. Engine M44, M52, M54, M56, M62, S52, S54, S62
14 = 11 9 015 Valve spring cage
Note. Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
Scheme 1033
15 = 11 9 016 Valve spring cage
Note. Engine M21, M40
16 = 11 8 421 Valve spring cage
Note. Engine: W10, W11, W17
17 = 11 9 017 Valve spring cage
Note. Engine N52
11 9 150 Special wrench
Minimum set: Mechanical tools
In conjunction with: 11 7 030
Note. For releasing and tightening down oxygen sensors
Engine: M54, M56, N12, N14, N42, N45, N46, N53, N54, N62, N62TU, N73, S54, S85
Storage location: A42
SI number: 01 15 00 (609)
Order number: 11 9 150
Special wrench
Scheme 1034
11 9 280 Holder
Minimum set: Mechanical tools
Note. For crankshaft when releasing/tightening central bolt
Engine: N12, N14, N40, N42, N45, N46, N52
Storage location: A43, B43, C43
SI number: 1 01 01(662)
Order number: 11 9 280
Holder
Scheme 1035
11 9 340 Chain tensioner, complete
Minimum set: Mechanical tools
Note. For tensioning timing chain when adjusting timing
Engine: N12, N14, N40, N42, N45, N45T, N46, N46T, N51, N52, N53, N54
Storage location: B43
SI number: 1 01 01(662)
Order number: 11 9 340
Chain tensioner, complete
Consisting of
1 = 11 9 341 Screw
2 = 11 9 342 Spindle
Scheme 1036
11 9 530 Engine support plate
In conjunction with: 00 2 300" 00 1 450
Note. For supporting engine on assembly stand.
Engine: N12, N14, W16
SI number: 1 26 06 321
Order number: 11 9 530
Engine support plate
Consisting of
1 = 11 9 531 Engine support plate
2 = 11 9 532 Set of screws
Scheme 1037
11 9 550 Gauge
Minimum set: Mechanical tools
Note. For locating camshaft in TDC position.
Engine: N14
Storage location: A86
SI number: 1 26 06 321
Order number: 11 9 550
Gauge
Consisting of
1 = 11 9 551 Gauge
2 = 11 9 552 Counter-support
3 = 11 9 553 Set of screws
Scheme 1038
11 9 560 Adapter
Minimum set: Mechanical tools
Note. For oil pressure testing.
Engine: N12, N14
Storage location: A86
SI number: 1 26 06 321
Order number: 11 9 560
Adapter
Scheme 1039
11 9 580 Socket ring wrench
Minimum set: Mechanical tools
Note. For removing and installing friction gear and auxiliary water pump.
Engine: N12, N14
Storage location: A85
SI number: 1 26 06 321
Order number: 11 9 580
Socket ring wrench
Consisting of
1 = 11 9 581 Ring wrench
2 = 11 9 582 Socket WAF 8
3 = 11 9 583 Socket WAF 10
Scheme 1040
11 9 590 Plug mandrel
Minimum set: Mechanical tools
Note. For locating crankshaft in TDC position.
Engine: N12, N14
Storage location: C85
SI number: 1 26 06 321
Order number: 11 9 590
Plug mandrel
Scheme 1041
11 9 600 Installer
Minimum set: Mechanical tools
Note. For installing front crankshaft seal.
Engine: N12, N14
Storage location: C85
SI number: 1 26 06 321
Order number: 11 9 600
Installer
Consisting of
1 = 11 9 601 Basic body
2 = 11 9 602 Pressure sleeve
3 = 11 9 603 Nut with bearing
Scheme 1042
11 9 610 Installer
Minimum set: Mechanical tools
Note. For installing rear shaft seal on crankshaft.
Engine: N12, N14
Storage location: C85, C86
SI number: 1 26 06 321
Order number: 11 9 610
Installer
Consisting of
1 = 11 9 611 Basic body
2 = 11 9 612 Pressure sleeve
3 = 11 9 613 Nut with bearing
Scheme 1043
11 9 620 Insertion tool
Note. For installing piston with conrod in crankcase.
Engine: N12, N14
SI number: 1 26 06 321
Order number: 11 9 620
Insertion tool
Scheme 1044
11 9 660 Press-down device
Note. For pressing down camshafts during removal and installation.
Engine: N14
SI number: 1 26 06 321
Order number: 11 9 660
Press-down device
Consisting of
1 = 11 9 661 Basic body
2 = 11 9 662 Set of screws
Scheme 1045
11 9 670 Slip bush
Note. For installing piston in crankcase.
Engine: N12, N14
SI number: 1 26 06 321
Order number: 11 9 670
Slip bush
Scheme 1046
11 9 811 Holder
Order number: 11 9 811
Holder
Scheme 1047
11 9 812 Screw
Order number: 11 9 812
Screw
