11 00 670 SECURING ENGINE IN INSTALLATION POSITION (N12, N14)
Special tools required
- 00 0 200
- 00 0 202
- 00 0 204
- 00 0 208
- 00 0 490
| WARNING | Risk of injury! Observe following instructions relating to special tool: Prior to each use, check the special tools for defects, modifications and operational reliability. Damaged/modified special tools must not be used! No changes or modifications may be made to the special tools! Keep special tools dry, clean and free of grease. |
Necessary preliminary tasks
- Remove lock bridge.
Assemble cross member 00 0 200 with special tools 00 0 202 , 00 0 204 , 00 0 208 .
Modification
Remove front supports (1).
Scheme 472
Attach special tool 00 0 490 on left and right to cross member 00 0 200 .
Scheme 473
| IMPORTANT | Do not damage Bowden cable (1)! |
With the aid of an assistant, place cross member 00 0 200 on spring strut tower and secure special tool 00 0 490 with knurled screws (2) on engine support.
Scheme 474
| IMPORTANT | Avoid a change of engine position in the transverse or longitudinal direction. Always make sure there is sufficient clearance between the engine (or its attachment parts) and the body. |
Align cross member 00 0 200 such that the spindle 00 0 202 is positioned correctly over the lifting eye.
Secure suitable chain to spindle 00 0 200 and attach to lifting eye (1).
Scheme 475
| WARNING | Risk of injury! Tighten all adjusting screws, knurled screws and nuts on cross member 00 0 200 and on special tool 00 0 490 . |
Scheme 476
| IMPORTANT | Bolts must be slackened to prevent elongation of rubber mounts in bracket (1)! |
Slacken bolts (2, 3).
Installation
Low engine first onto engine or transmission mounts and then tighten down bolts (2, 3).
Tightening torque: See ENGINE - TIGHTENING TORQUES .
Scheme 477
Left side only
Remove transmission support bracket
Right side only
Unscrew nut (1).
Installation
Replace self-locking nut.
Tightening torque: See ENGINE - TIGHTENING TORQUES .
Scheme 478
Raise engine approx. 10 mm with crossmember.
