DCA System Service
| CAUTION | Never look straight into the laser beam discharger when adjusting laser beam aiming. Turn the DCA system OFF in conditions similar to driving, such as free rollers or a chassis dynamometer. Never use the ICC sensor removed from vehicle. Never disassemble or remodel. Erase DTC when replacing parts of DCA system, then check the operation of DCA system after adjusting laser beam aiming if necessary. |
Scheme 51
Scheme 51: Component Parts Location
ADAS CONTROL UNIT INPUT/OUTPUT SIGNAL ITEM
| Transmit unit | Signal name | Description |
| ECM | CAN communication | Closed throttle position signal | Receives idle position state (ON/OFF) |
| Accelerator pedal position signal | Receives accelerator pedal position (angle) |
| ICC steering switch signal | Dynamic driver assistance switch signal | Receives the operational state of the ICC steering switch |
| Engine speed signal | Receives engine speed |
| Stop lamp switch signal | Receives an operational state of the brake pedal |
| Snow mode switch signal | Receives an operational state of the snow mode |
| TCM | CAN communication | Input speed signal | Receives the number of revolutions of input shaft |
| Current gear position signal | Receives a current gear position |
| Shift position signal | Receives a selector lever position |
| Output shaft revolution signal | Receives the number of revolutions of output shaft |
| ABS actuator and electric unit (control unit) | CAN communication | ABS malfunction signal | Receives a malfunction state of ABS |
| ABS operation signal | Receives an operational state of ABS |
| ABS warning lamp signal | Receives an ON/OFF state of ABS warning lamp |
| TCS malfunction signal | Receives a malfunction state of TCS |
| TCS operation signal | Receives an operational state of TCS |
| VDC OFF switch signal | Receives an ON/OFF state of VDC |
| VDC malfunction signal | Receives a malfunction state of VDC |
| VDC operation signal | Receives an operational state of VDC |
| Vehicle speed signal (ABS) | Receives wheel speeds of four wheels |
| Stop lamp switch signal | Receives an operational state of the brake pedal |
| Yaw rate signal | Receives yaw rate acting on the vehicle |
| Steering angle sensor | CAN communication | Steering angle sensor malfunction signal | Receives a malfunction state of steering angle sensor |
| Steering angle sensor signal | Receives the number of revolutions, turning direction of the steering wheel |
| Steering angle speed signal | Receives the turning angle speed of the steering wheel |
| AV control unit | CAN communication | System selection signal | Receives a selection state of each item in "Driver Assistance" selected with the navigation system |
| ICC sensor | ITS communication | ICC sensor signal | Receives detection results, such as the presence or absence of a leading vehicle and distance from the vehicle |
| Accelerator pedal actuator | ITS communication | Accelerator pedal actuator operation status signal | Receives an operational state of accelerator pedal actuator |
INPUT SIGNAL ITEM DESCRIPTION
| Reception unit | Signal name | Description |
| ABS actuator and electric unit (control unit) | CAN communication | Brake fluid pressure control signal | Transmits a brake fluid pressure control signal to activates the brake |
| Combination meter | CAN communication | Meter display signal | Vehicle ahead detection indicator signal | Transmits a signal to display a state of the system on the information display |
| DCA system switch indicator signal |
| ICC warning lamp signal | Transmits an ICC warning lamp signal to turn ON the ICC system warning lamp |
| Buzzer output signal | Transmits a buzzer output signal to activate the buzzer |
| ICC sensor | ITS communication | Vehicle speed signal | Transmits a vehicle speed calculated by the ADAS control unit |
| Steering angle sensor signal | Transmits a steering angle sensor signal received from the steering angle sensor |
| Accelerator pedal actuator | ITS communication | Accelerator pedal position signal | Transmits an accelerator pedal angle calculated by the ADAS control unit |
| Accelerator pedal feedback force control signal | Transmits a target actuation force value calculated by the ADAS control unit |
| ICC brake hold relay | ICC brake hold relay drive signal | Activates the brake hold relay and turns ON the stop lamp |
OUTPUT SIGNAL ITEM DESCRIPTION
Fail-safe (ADAS Control Unit)
If a malfunction occurs in each system, ADAS control unit cancels each control, sounds a beep, and turns ON the warning lamp or indicator lamp.
| System | Buzzer | Warning lamp/Indicator lamp | Description |
| Vehicle-to-vehicle distance control mode | High-pitched tone | ICC system warning lamp | Cancel |
| Conventional (fixed speed) cruise control mode | High-pitched tone | ICC system warning lamp | Cancel |
| Intelligent Brake Assist (IBA) | High-pitched tone | IBA OFF indicator lamp | Cancel |
| Forward Collision Warning (FCW) | High-pitched tone | IBA OFF indicator lamp | Cancel |
| Distance Control Assist (DCA) | High-pitched tone | ICC system warning lamp | Cancel |
| Lane Departure Warning (LDW) | | Lane departure warning lamp | Cancel |
| Lane Departure Prevention (LDP) | Low-pitched tone | Lane departure warning lamp | Cancel |
| Blind Spot Warning (BSW) | | BSW/BSI warning lamp | Cancel |
| Blind Spot Intervention (BSI) | Low-pitched tone | BSW/BSI warning lamp | Cancel |
| Active trace control function | | IBA OFF indicator lamp | Cancel If a communication error occurs between the A/C auto amp. and CAN communication line, a mode at the instant of error occurrence is maintained until the mode is fixed to STANDARD after turning the ignition switch from OFF to ON |
Fail-safe (ICC Sensor)
If a malfunction occurs in the ICC sensor, ADAS control unit cancels control, sounds a beep, and turns ON the ICC system warning lamp in the combination meter.
Scheme 52
Scheme 52: Switch Name and Function
| No. | Switch name | Description |
| 1 | Dynamic driver assistance switch | Turns DCA system ON/OFF (When the setting of DCA system on the navigation system setting screen is ON) |
| 2 | DCA system setting screen (Navigation system settings screen) | The setting of DCA system can be switched between ON and OFF |
Scheme 53
Scheme 53: SYSTEM DISPLAY
| No. | Switch name | Description |
| 1 | ICC system warning lamp | This indicates that an abnormal condition is present in DCA system |
| 2 | DCA system switch indicator | Indicates that DCA system is ON |
| 3 | Vehicle ahead detection indicator | Indicates whether it detects a vehicle ahead NOTE: The vehicle ahead detection indicator turns OFF when the no operation condition is satisfied |
| NOTE |
| The vehicle ahead detection indicator turns OFF when the no operation condition is satisfied |
System Control Condition Display
The DCA system switch indicator illuminates and the system is turned ON by pressing the dynamic driver assistance switch at the system OFF.
Condition Display on combination meter Operation status Vehicle ahead not detected Vehicle ahead detected
Scheme 54
Scheme 54: System Control Condition Display
Approach Warning Display
- If own vehicle comes closer to the vehicle ahead due to rapid deceleration of that vehicle or if another vehicle cuts in, the system warns the driver with the chime and DCA system display. Decelerate by depressing the brake pedal to maintain a safe vehicle distance if: The chime sounds. The vehicle ahead detection indicator blinks.
- The warning chime may not sound in some cases when there is a short distance between vehicles. Some examples are: When the vehicles are traveling at the same speed and the distance between vehicles is not changing When the vehicle ahead is traveling faster and the distance between vehicles is increasing When a vehicle cuts in near own vehicle
- The warning chime will not sound when own vehicle approaches vehicles that are parked or moving slowly.
Condition Display on combination meter When the system judges that the brake operation by the driver is necessary
WARNING LAMP DISPLAY DESCRIPTION Condition Description Display on combination meter Warning display When the dynamic driver assistance switch is turned ON with settings of DCA system, LDP system and BSI system OFF The DCA system is not activated. The DCA system switch indicator blinks When the VDC or ABS (including the TCS) operates When the VDC is turned OFF When the drive mode select switch is in SNOW position When driving into a strong light (i.e., sunlight) The DCA system is automatically canceled. The chime will sound and the DCA system switch indicator will blink NOTE: The system operates if the dynamic driver assistance switch is turned OFF==>ON after the condition improves When the sensor window is dirty, making it impossible to detect a vehicle ahead The DCA system is automatically canceled. The chime sounds and the ICC system warning lamp will come on and the "CLEAN SENSOR" indicator will appear NOTE: Stop the vehicle in a safe location and turn the ignition switch OFF. Clean the dirty area with soft cloth. The system returns to normal condition when turning the ignition switch ON again When the DCA system is not operating properly The chime sounds and the ICC system warning lamp will come on NOTE: Turn the ignition switch OFF, and then turn the ignition switch ON again. If there is no malfunction, the system returns to the normal condition
Scheme 55
Scheme 56
Scheme 57
Note. When the DCA system is automatically canceled, the cancellation condition can be displayed on "WORK SUPPORT" of CONSULT (ICC/ADAS).
Scheme 58
Scheme 58: Precautions for Distance Control Assist
Scheme 59
- If the vehicle ahead comes to a stop, the vehicle decelerates to a standstill within the limitations of the system. The system will cancel once it judges that the vehicle has come to a standstill with a warning chime. To prevent the vehicle from moving, the driver must depress the brake pedal.
- The DCA system will not apply brake control while the driver is depressing the accelerator pedal.
- This system is only an aid to assist the driver and is not a collision warning or avoidance device. It is the driver's responsibility to stay alert, drive safely and be in control of the vehicle at all times.
- This system will not adapt automatically to road conditions. Do not use the system on roads with sharp curves, or on icy roads, in heavy rain or in fog.
- The distance sensor will not detect under most conditions. Stationary and slow moving vehicles Pedestrians or objects in the roadway Oncoming vehicles in the same lane Motorcycles traveling offset in the travel lane
- As there is a performance limit to the distance control function, never rely solely on the DCA system. This system does not correct careless, inattentive or absent minded driving, or overcome poor visibility in rain, fog, or other bad weather. Decelerate the vehicle speed by depressing the brake pedal, depending on the distance to the vehicle ahead and the surrounding circumstances in order to maintain a safe distance between vehicles.
- The system may not detect the vehicle in front of own vehicle in certain road or weather conditions. To avoid accidents, never use the DCA system under the following conditions. On roads with sharp curves On slippery road surfaces such as on ice or snow, etc. During bad weather (rain, fog, snow, etc.) When strong light (for example, at sunrise or sunset) is directly shining on the front of the vehicle When rain, snow or dirt cover the system sensor On steep downhill roads (frequent braking may result in overheating the brakes) On repeated uphill and downhill roads
- Do not use the DCA system if own vehicle are towing a trailer. The system may not detect a vehicle ahead.
- In some road or traffic conditions, a vehicle or object can unexpectedly come into the sensor detection zone and cause automatic braking. Driver may need to control the distance from other vehicles using the accelerator pedal. Always stay alert and avoid using the DCA system when it is not recommended in this Service Information.
- The following are some conditions in which the sensor cannot detect the signals. When the reflector of the vehicle ahead is positioned high on the vehicle (trailer, etc.) When the reflector on the vehicle ahead is missing, damaged or covered When the reflector of the vehicle ahead is covered with dirt, snow and road spray When the snow or road spray from traveling vehicles reduces the sensor's visibility When dense exhaust or other smoke (black smoke) from vehicles reduces the sensor's visibility When excessively heavy baggage is loaded in the rear seat or the luggage room of own vehicle
- The DCA system is designed to automatically check the sensor's operation. When the sensor is covered with dirt or is obstructed, the system will automatically be canceled. If the sensor is covered with ice, a transparent or translucent vinyl bag, etc., the DCA system may not detect them. In these instances, the DCA system may not be able to decelerate the vehicle properly. Be sure to check and clean the sensor regularly.
- The DCA system is designed to help assist the driver to maintain a following distance from the vehicle ahead. The system will decelerate as necessary and if the vehicle ahead comes to a stop, the vehicle decelerates to standstill. However, the DCA system can only apply up to 25% of the vehicles total braking power. If a vehicle moves into the traveling lane ahead or if a vehicle traveling ahead rapidly decelerates, the distance between vehicles may become closer because the DCA system cannot decelerate the vehicle quickly enough. If this occurs, the DCA system will sound a warning chime and blink the system display to notify the driver to take necessary action.
- The DCA system does not control vehicle speed or warn when driver approach stationary and slow moving vehicles. Driver must pay attention to vehicle operation to maintain proper distance from vehicles ahead.
- The detection zone of the sensor is limited. A vehicle ahead must be in the detection zone for the system to operate. A vehicle ahead may move outside of the detection zone due to its position within the same lane of travel. Motorcycles may not be detected in the same lane ahead if they are traveling offset from the center line of the lane. A vehicle that is entering the lane ahead may not be detected until the vehicle has completely moved into the lane. If this occurs, the system may warn driver by blinking the system indicator and sounding the chime. The driver may have to manually control the proper distance away from vehicle traveling ahead. When driving on some roads, such as winding, hilly, curved, narrow roads, or roads which are under construction, the sensor may detect vehicles in a different lane, or may temporarily not detect a vehicle traveling ahead. This may cause the system to work inappropriately. The detection of vehicles may also be affected by vehicle operation (steering maneuver or traveling position in the lane, etc.) or vehicle condition. If this occurs, the system may warn driver by blinking the system indicator and sounding the chime unexpectedly. The driver will have to manually control the proper distance away from the vehicle traveling ahead.
- The approach warning chime may sound and the system display may blink when the sensor detects some reflectors which are fitted on vehicles in other lanes or on the side of the road. This may cause the DCA system to operate inappropriately. The sensor may detect these reflectors when the vehicle is driven on winding roads, hilly roads or when entering or exiting a curve. The sensor may also detect reflectors on narrow roads or in road construction zones. In these cases driver will have to manually control the proper distance ahead of own vehicle. Also, the sensor sensitivity can be affected by vehicle operation (steering maneuver or driving position in the lane) or traffic or vehicle condition (for example, if a vehicle is being driven with some damage).
- The DCA system automatically decelerates own vehicle to help assist the driver to maintain a following distance from the vehicle ahead. Manually brake when deceleration is required to maintain a safe distance upon sudden braking by the vehicle ahead or when a vehicle suddenly appears in front of own vehicle. Always stay alert when using the DCA system.
- When the vehicle ahead detection indicator lamp is not illuminated, system will not control or warn the driver.
- Never place a foot under the brake pedal. A foot may be caught when the system controls the brake.
- Depending on the position of the accelerator pedal, the system may not be able to assist the driver to release the accelerator pedal appropriately.
- If the vehicle ahead comes to a standstill, the vehicle decelerates to a standstill within the limitations of the system. The system will release brake control with a warning chime once it judges the vehicle is at a standstill. To prevent the vehicle from moving, the driver must depress the brake pedal. [The system will resume control automatically once the system reaches 5 km/h (3 MPH)].
METHOD OF STARTING
| CAUTION | Start condition of on board self-diagnosis ICC system OFF DCA system OFF Vehicle speed 0 km/h (0 MPH) |
Scheme 60
Scheme 61
- Turn the ignition switch OFF.
- Start the engine.
- Wait for 5 seconds after starting the engine. Push up the RESUME/ACCELERATE switch 5 times and push down the SET/COAST switch 5 times within 10 seconds. NOTE: If the above operation cannot be performed within 10 seconds after waiting for 5 seconds after starting the engine, repeat the procedure from step 1 .
- The DTC is displayed on the set vehicle speed indicator (1) on the ICC system display on the information display when the on board self-diagnosis starts. Refer to " «DTC INDEX»(ref-573617-S03818570942013082200000) ". NOTE: It displays for up to 5 minutes and then stops. If multiple malfunctions exist, up to 6 DTCs can be stored in memory at the most, and the most recent one is displayed first.
WORK SUPPORT
| Work support items | Description |
| CAUSE OF AUTO-CANCEL 1 | Displays causes of automatic system cancellation occurred during control of the following systems Vehicle-to-vehicle control mode Conventional (fixed speed) control mode Distance Control Assist (DCA) |
| CAUSE OF AUTO-CANCEL 2 | Displays causes of automatic system cancellation occurred during control of the following systems Lane Departure Prevention (LDP) Blind Spot Intervention (BSI) |
Note. Causes of the maximum five cancellations (system cancel) are displayed. The displayed cancellation causes display the number of the ignition switch ON/OFF up to 254. It is fixed to 254 if it is over 254. It returns to 0 when the same cancellation cause is detected again.
Scheme 62
Scheme 62: Display Items for The Cause of Automatic Cancellation 1
Scheme 63
Scheme 63: Display Items for The Cause of Automatic Cancellation 2
Scheme 64
METER LAMP
Note. The test can be performed only when the engine is running.
| Test item | Operation | Description | MAIN switch indicator ICC system warning lamp IBA OFF indicator lamp |
| METER LAMP | Off | Stops sending the following signals to exit from the test Meter display signal ICC warning lamp signal IBA OFF indicator lamp signal | OFF |
| On | Transmits the following signals to the combination meter via CAN communication Meter display signal ICC warning lamp signal IBA OFF indicator lamp signal | ON |
STOP LAMP
| Test item | Operation | Description | Stop lamp |
| STOP LAMP | Off | Stops transmitting the ICC brake hold relay drive signal below to end the test | OFF |
| On | Transmits the ICC brake hold relay drive signal | ON |
ICC BUZZER
| Test item | Operation | Description | ICC warning chime operation sound |
| ICC BUZZER | MODE1 | Transmits the buzzer output signals to the combination meter via CAN communication | Intermittent beep sound |
| Test start | Starts the tests of "MODE1" | |
| Reset | Stops transmitting the buzzer output signal below to end the test | |
| End | Returns to the "SELECT TEST ITEM" screen | |
BRAKE ACTUATOR
Note. The test can be performed only when the engine is running.
| Test item | Operation | Description | "PRESS SENS" value |
| BRAKE ACTUATOR | MODE1 | Transmits the brake fluid pressure control signal to the ABS actuator and electric unit (control unit) via CAN communication | 10 bar |
| MODE2 | 20 bar |
| MODE3 | 30 bar |
| Test start | Starts the tests of "MODE1", "MODE2" and "MODE3" | |
| Reset | Stops transmitting the brake fluid pressure control signal below to end the test | |
| End | Returns to the "SELECT TEST ITEM" screen | |
Note. The test is finished in 10 seconds after starting
Scheme 65
Active Pedal
| CAUTION | Shift the selector lever to "P" position, and then perform the test. Never depress the accelerator pedal excessively. (The engine speed may rise unexpectedly when finishing the test.) |
Note. Depress the accelerator pedal to check when performing the test. The test can be performed only when the engine is running.
| Test item | Operation | Description | Accelerator pedal operation |
| Active Pedal | MODE1 | Transmit the accelerator pedal feedback force control signal to the accelerator pedal actuator via ITS communication. | Constant with a force of 25 N for 8 seconds |
| MODE2 | Constant with a force of 15 N for 8 seconds |
| MODE3 | Change up to a force of 25 N for 8 seconds |
| MODE4 | Change up to a force of 15 N for 8 seconds |
| Test start | Starts the tests of "MODE1", "MODE2", "MODE3" and "MODE4" | |
| Reset | Stops transmitting the accelerator pedal feedback force control signal below to end the test. | |
| End | Returns to the "SELECT TEST ITEM" screen | |
Note. The test is finished in 10 seconds after starting
Scheme 66
DCA INDICATOR
Note. The test can be performed only when the engine is running.
| Test item | Operation | Description | DCA system switch indicator |
| DCA INDICATOR | Off | Stops transmitting the DCA system switch indicator signal below to end the test | |
| On | Transmits the DCA system switch indicator signal to the combination meter via CAN communication | ON |
LDP BUZZER
| Test item | Operation | Description | Warning buzzer |
| LDP BUZZER | Off | Stops transmitting the warning buzzer signal below to end the test | |
| On | Transmits the warning buzzer signal to the warning buzzer | ON |
WARNING SYSTEM IND
| Test item | Operation | Description | Warning systems ON indicator |
| WARNING SYSTEM IND | Off | Stops transmitting the warning systems ON indicator signal below to end the test | |
| On | Transmits the warning systems ON indicator signal to the warning systems ON indicator. | ON |
LDP ON IND
| Test item | Operation | Description | LDP ON indicator lamp (Green) |
| LDP ON IND | Off | Stops transmitting the LDP ON indicator lamp signal below to end the test | |
| On | Transmits the LDP ON indicator lamp signal to the combination meter via CAN communication | ON |
LANE DEPARTURE W/L
| Test item | Operation | Description | Lane departure warning lamp (Yellow) |
| LANE DEPARTURE W/L | Off | Stops transmitting the lane departure warning lamp signal below to end the test | |
| On | Transmits the lane departure warning lamp signal to the combination meter via CAN communication | ON |
BSW/BSI WARNING LAMP
| Test item | Operation | Description | BSW/BSI warning lamp (Yellow) |
| BSW/BSI WARNING LAMP | Off | Stops transmitting the BSW/BSI warning lamp signal below to end the test | |
| On | Transmits the BSW/BSI warning lamp signal to the combination meter via CAN communication | ON |
BSI ON INDICATOR
| Test item | Operation | Description | BSI ON indicator lamp (Green) |
| BSI ON INDICATOR | Off | Stops transmitting the BSI ON indicator signal below to end the test | |
| On | Transmits the BSI ON indicator signal to the combination meter via CAN communication | ON |
| Work support items | Description |
| LASER BEAM ADJUST | Outputs laser beam, calculates dislocation of the beam, and indicates adjustment direction |
DATA MONITOR
| Monitored item [Unit] | Description |
| VHCL SPEED SE [km/h] or [mph] | Vehicle speed judged from a vehicle speed signal read by the ICC sensor via ITS communication is displayed [ADAS control unit receives a vehicle speed signal from ABS actuator and electric unit (control unit) via CAN communication and transmits the calculated vehicle speed to ICC sensor via ITS communication] |
| YAW RATE [deg/s] | Yaw rate judged from a yaw rate signal read by ICC sensor via ITS communication is displayed [ADAS control unit receives a yaw rate signal from ABS actuator and electric unit (control unit) via CAN communication and transmits the calculated yaw rate to ICC sensor via ITS communication] |
| PWR SUP MONI [V] | Indicates IGN voltage input by ICC sensor |
| DISTANCE [m] | Indicates the distance from the vehicle ahead |
| RELATIVE SPD [m/s] | Indicates the relative speed of the vehicle ahead |
| LASER OFFSET [m] | NOTE: The item is indicated, but not used |
| LASER HEIGHT [m] | NOTE: The item is indicated, but not used |
| STEERING ANGLE [deg] | The steering angle is displayed |
| STRG ANGLE SPEED [deg/s] | The steering angle speed is displayed |
| L/R ADJUST | The horizontal correction value of the laser beam is displayed |
| U/D ADJUST | The vertical correction value of the laser beam is displayed |
| NOTE |
| The item is indicated, but not used |
| NOTE |
| The item is indicated, but not used |
FFD (Freeze Frame Data)
The accelerator pedal actuator records the following data when the malfunction is detected.
| Freeze Frame Data item [Unit] | Description |
| TGT FBK FRC [N] | It displays the target accelerator pedal actuation force that the accelerator pedal actuator read out from the accelerator pedal feedback force control signal received via ITS communication at the time when the malfunction is detected |
| TGT MOT POSI [%] | It displays the target motor position that the accelerator pedal actuator read out from the accelerator pedal feedback force control signal received via ITS communication at the time when the malfunction is detected |
| ACT MOT POSI [%] | It displays the integrated motor position that the accelerator pedal actuator read out at the time when the malfunction is detected |
| AP OPEN [%] | It displays the accelerator pedal position signal that the accelerator pedal actuator read out via ITS communication at the time when the malfunction is detected |
| APA TEMP [°C] | It displays the integrated motor temperature that the accelerator pedal actuator read out at the time when the malfunction is detected |
| APA CURRENT [A] | It displays the integrated motor consumption current that the accelerator pedal actuator read out at the time when the malfunction is detected |
| APA PWR [V] | It displays the power supply voltage that the accelerator pedal actuator read out at the time when the malfunction is detected |
| APA OPE STATS [On/Off] | It displays the activation permission status of accelerator pedal actuator at the time when the malfunction is detected |
| APA STATS [READY/NG/TP NG/INIT] | It displays the condition of accelerator pedal actuator at the time when the malfunction is detected |
| IGN Counter (1) | It displays number of ignition switch OFF --> ON after the malfunction is detected |
| NOTE: (1) The number is 0 when is detected now. The number increases like 1 --> 2... 38 --> 39 after returning to the normal condition whenever IGN OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39. |
| NOTE |
| (1) The number is 0 when is detected now. The number increases like 1 --> 2... 38 --> 39 after returning to the normal condition whenever IGN OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39. |
| (1) | The number is 0 when is detected now. |
| Monitor item [Unit] | FUNCTION DESCRIPTION |
| TGT FBK FRC [N] | It displays the target accelerator pedal actuation force that the accelerator pedal actuator read out from the accelerator pedal feedback force control signal received via ITS communication (The ADAS control unit transmits the accelerator pedal feedback force control signal via ITS communication) |
| TGT MOT POSI [%] | It displays the target motor position that the accelerator pedal actuator read out from the accelerator pedal feedback force control signal received via ITS communication (The ADAS control unit transmits the accelerator pedal feedback force control signal via ITS communication) |
| ACT MOT POSI [%] | It displays the integrated motor position that the accelerator pedal actuator read out |
| AP OPEN [%] | It displays the accelerator pedal position signal that the accelerator pedal actuator read out via ITS communication (The ADAS control unit transmits with ITS communication the accelerator pedal position signal that is received from ECM via CAN communication) |
| APA TEMP [°C] | It displays the accelerator pedal actuator integrated motor temperature |
| APA CURRENT [A] | It displays the accelerator pedal actuator integrated motor consumption current |
| APA PWR [V] | It displays the power supply voltage that the accelerator pedal actuator read out |
| APA OPE STATS [On/Off] | It displays the activation permission status of accelerator pedal actuator |
| APA STATS [READY/NG/TP NG/INIT] | It displays the condition of accelerator pedal actuator |
Fail-safe
If a malfunction occurs in each system, ADAS control unit cancels each control, sounds a beep, and turns ON the warning lamp or indicator lamp.
| System | Buzzer | Warning lamp/Indicator lamp | Description |
| Vehicle-to-vehicle distance control mode | High-pitched tone | ICC system warning lamp | Cancel |
| Conventional (fixed speed) cruise control mode | High-pitched tone | ICC system warning lamp | Cancel |
| Intelligent Brake Assist (IBA) | High-pitched tone | IBA OFF indicator lamp | Cancel |
| Forward Collision Warning (FCW) | High-pitched tone | IBA OFF indicator lamp | Cancel |
| Distance Control Assist (DCA) | High-pitched tone | ICC system warning lamp | Cancel |
| Lane Departure Warning (LDW) | | Lane departure warning lamp | Cancel |
| Lane Departure Prevention (LDP) | Low-pitched tone | Lane departure warning lamp | Cancel |
| Blind Spot Warning (BSW) | | BSW/BSI warning lamp | Cancel |
| Blind Spot Intervention (BSI) | Low-pitched tone | BSW/BSI warning lamp | Cancel |
| Active trace control function | | IBA OFF indicator lamp | Cancel If a communication error occurs between the A/C auto amp. and CAN communication line, a mode at the instant of error occurrence is maintained until the mode is fixed to STANDARD after turning the ignition switch from OFF to ON |
PHYSICAL VALUES
| Terminal No. (Wire color) | Description | Condition | Value (Approx.) |
| + | | Signal name | Input/Output |
| 1 (LG) | Ground | Ignition power supply | Input | Ignition switch ON | Battery voltage |
| 3 (L) | ITS communication-H | | | |
| 4 (B/Y) | Ground | | Ignition switch ON | 0 V |
| 6 (Y) | ITS communication-L | | | |
If a malfunction occurs in the ICC sensor, ADAS control unit cancels control, sounds a beep, and turns ON the ICC system warning lamp in the combination meter.
| Terminal No. (Wire color) | Description | Condition | Value (Approx.) |
| + | | Signal name | Input/Output |
| 1 (O) | Ground | Battery power supply | Input | Ignition switch OFF | Battery voltage |
| 2 (B) | Ground | | Ignition switch ON | 0 V |
| 3 (R) | Ignition power supply | Input | Ignition switch ON | Battery voltage |
| 4 (Y) | ITS communication-L | | | |
| 5 (L) | ITS communication-H | | | |
DETAILED FLOW
- INTERVIEW FOR MALFUNCTION It is also important to clarify the customer concerns before starting the inspection. Interview the customer about the concerns carefully and understand the symptoms fully. NOTE: The customers are not professionals. Never assume that "maybe the customer means..." or "maybe the customer mentioned this symptom". : GO TO 2.
- SELF-DIAGNOSIS WITH CONSULT Perform "All DTC Reading" with CONSULT. Check if the DTC is detected on the self-diagnosis results of "ICC/ADAS" and/or "ACCELE PEDAL ACT". Is any DTC detected? YES: GO TO 5 . NO: GO TO 3.
- ACTION TEST Perform DCA system action test to check the operation status. Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) ". Check if any other malfunctions occur. : GO TO 4.
- SYMPTOM DIAGNOSIS Perform the applicable diagnosis according to the diagnosis chart by symptom. Refer to " «SYMPTOM TABLE»(ref-573618-S38066937322013082200000) ". : GO TO 6 .
- TROUBLE DIAGNOSIS BY DTC Check the DTC in the self-diagnosis results. Perform trouble diagnosis for the detected DTC. Refer to " «DTC INDEX»(ref-573618-S39553697082013082200000) " (ICC/ADAS) and/or " «DTC INDEX»(ref-573618-S00764776022013082200000) " (ACCELE PEDAL ACT). NOTE: If "DTC: U1000" is detected, first diagnose the CAN communication system or ITS communication system. : GO TO 6.
- MALFUNCTIONING PART REPAIR Repair or replace the identified malfunctioning parts. : GO TO 7.
- REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT) Erases self-diagnosis results. Perform "All DTC Reading" again after repairing or replacing the specific items. Check if any DTC is detected in self-diagnosis results of "ICC/ADAS" and "ACCELE PEDAL ACT". Is any DTC detected? YES: GO TO 5 . NO: GO TO 8.
- REPAIR CHECK (ACTION TEST) Perform the DCA system action test. Check that the malfunction symptom is solved or no other symptoms occur. Is there a malfunction symptom? YES: GO TO 4 . NO: INSPECTION END
Work Procedure
- LASER BEAM AIMING ADJUSTMENT Adjust the laser beam aiming. Refer to " «DESCRIPTION»(ref-573604-S40117573552013082200000) ". : GO TO 2.
- DCA SYSTEM ACTION TEST Perform the DCA system action test. Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) ". Check that the DCA system operates normally. : INSPECTION END
- ACCELERATOR PEDAL RELEASED POSITION LEARNING Perform accelerator pedal released position learning. Refer to " «DESCRIPTION»(ref-573577-S33966080532013082200000) " (VQ37VHR) or " «DESCRIPTION»(ref-573597-S07466647142013082200000) " (VK56VD for USA and Canada). : GO TO 2.
- DCA SYSTEM ACTION TEST Perform the DCA system action test. Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) ". Check that the DCA system operates normally. : INSPECTION END
Note. When the ICC system is set, the information display changes to the ICC system display.
Scheme 67
Scheme 67: Work Procedure
- ICC SYSTEM ACTION TEST Perform the ICC system action test. Refer to " «DESCRIPTION»(ref-573604-S13863895562013082200000) ". : GO TO 2.
- CHECK DCA SYSTEM SETTING Start the engine. After starting the engine wait for 30 seconds or more. Check that the DCA system setting can be enabled/disabled on the navigation screen. Turn OFF the ignition switch and wait for 5 seconds or more. Check that the previous setting is saved when the engine starts again. : GO TO 3.
- CHECK DRIVER ASSISTANCE SYSTEMS SWITCH Start the engine. After starting the engine wait for 30 seconds or more. Enable the setting of the DCA system on the navigation screen. Press the dynamic driver assistance switch (1). Check that the DCA system switch indicator (2) on the information display illuminates. Check that the DCA system switch indicator turns OFF when the system is turned OFF by pressing the dynamic driver assistance switch. Check that the DCA system switch indicator turns OFF when the engine starts again. NOTE: The DCA system switch indicator does not illuminate even when the dynamic driver assistance switch is turned ON within approximately 5 seconds after starting the engine. If the accelerator pedal assembly is not replaced: INSPECTION END If the accelerator pedal assembly is replaced: GO TO 4.
- CHECK DCA SYSTEM OPERATION Check that the accelerator pedal actuator operates by the "Active Test" items "ACCELERATOR PEDAL ACTUATOR TEST1" and "ACCELERATOR PEDAL ACTUATOR TEST2" of "ACCELE PEDAL ACT" with CONSULT. : INSPECTION END
CAN COMMUNICATION
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Modern vehicle is equipped with many electronic control units, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H, CAN-L) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads the required data only.
CAN communication signal chart. Refer to " CAN COMMUNICATION SYSTEM: CAN COMMUNICATION SIGNAL CHART ".
ITS COMMUNICATION
- ITS communication is a multiplex communication system. This enables the system to transmit and receive large quantities of data at high speed by connecting control units with 2 communication lines.
- ITS communication lines adopt twisted-pair line style (two lines twisted) for noise immunity.
- ITS communication is a multiplex communication system. This enables the system to transmit and receive large quantities of data at high speed by connecting control units with 2 communication lines.
- ITS communication lines adopt twisted-pair line style (two lines twisted) for noise immunity.
PRECAUTIONS FOR DISTANCE CONTROL ASSIST (DCA) SYSTEM
- If the vehicle ahead comes to a stop, the vehicle decelerates to a standstill within the limitations of the system. The system will cancel once it judges that the vehicle has come to a standstill with a warning chime. To prevent the vehicle from moving, the driver must depress the brake pedal.
- The DCA system will not apply brake control while the driver is depressing the accelerator pedal.
- This system is only an aid to assist the driver and is not a collision warning or avoidance device. It is the driver's responsibility to stay alert, drive safely and be in control of the vehicle at all times.
- This system will not adapt automatically to road conditions. Do not use the system on roads with sharp curves, or on icy roads, in heavy rain or in fog.
- The distance sensor will not detect under most conditions. Stationary and slow moving vehicles Pedestrians or objects in the roadway Oncoming vehicles in the same lane Motorcycles traveling offset in the travel lane
- As there is a performance limit to the distance control function, never rely solely on the DCA system. This system does not correct careless, inattentive or absent minded driving, or overcome poor visibility in rain, fog, or other bad weather. Decelerate the vehicle speed by depressing the brake pedal, depending on the distance to the vehicle ahead and the surrounding circumstances in order to maintain a safe distance between vehicles.
- The system may not detect the vehicle in front of own vehicle in certain road or weather conditions. To avoid accidents, never use the DCA system under the following conditions. On roads with sharp curves On slippery road surfaces such as on ice or snow, etc. During bad weather (rain, fog, snow, etc.) When strong light (for example, at sunrise or sunset) is directly shining on the front of the vehicle When rain, snow or dirt covers the system sensor On steep downhill roads (frequent braking may result in overheating the brakes) On repeated uphill and downhill roads
- Do not use the DCA system if own vehicle are towing a trailer. The system may not detect a vehicle ahead.
- In some road or traffic conditions, a vehicle or object can unexpectedly come into the sensor detection zone and cause automatic braking. Driver may need to control the distance from other vehicles using the accelerator pedal. Always stay alert and avoid using the DCA system when it is not recommended in this Service Information.
- The following are some conditions in which the sensor cannot detect the signals. When the reflector of the vehicle ahead is positioned high on the vehicle (trailer, etc.) When the reflector on the vehicle ahead is missing, damaged or covered When the reflector of the vehicle ahead is covered with dirt, snow and road spray When the snow or road spray from traveling vehicles reduces the sensor's visibility When dense exhaust or other smoke (black smoke) from vehicles reduces the sensor's visibility When excessively heavy baggage is loaded in the rear seat or the luggage room of own vehicle
- The DCA system is designed to automatically check the sensor's operation. When the sensor is covered with dirt or is obstructed, the system will automatically be canceled. If the sensor is covered with ice, a transparent or translucent vinyl bag, etc., the DCA system may not detect them. In these instances, the DCA system may not be able to decelerate the vehicle properly. Be sure to check and clean the sensor regularly.
- The DCA system is designed to help assist the driver to maintain a following distance from the vehicle ahead. The system will decelerate as necessary and if the vehicle ahead comes to a stop, the vehicle decelerates to standstill. However, the DCA system can only apply up to 25% of the vehicles total braking power. If a vehicle moves into the traveling lane ahead or if a vehicle traveling ahead rapidly decelerates, the distance between vehicles may become closer because the DCA system cannot decelerate the vehicle quickly enough. If this occurs, the DCA system will sound a warning chime and blink the system display to notify the driver to take necessary action.
- The DCA system does not control vehicle speed or warn when driver approach stationary and slow moving vehicles. Driver must pay attention to vehicle operation to maintain proper distance from vehicles ahead.
- The detection zone of the sensor is limited. A vehicle ahead must be in the detection zone for the system to operate. A vehicle ahead may move outside of the detection zone due to its position within the same lane of travel. Motorcycles may not be detected in the same lane ahead if they are traveling offset from the center line of the lane. A vehicle that is entering the lane ahead may not be detected until the vehicle has completely moved into the lane. If this occurs, the system may warn driver by blinking the system indicator and sounding the chime. The driver may have to manually control the proper distance away from vehicle traveling ahead. When driving on some roads, such as winding, hilly, curved, narrow roads, or roads which are under construction, the sensor may detect vehicles in a different lane, or may temporarily not detect a vehicle traveling ahead. This may cause the system to work inappropriately. The detection of vehicles may also be affected by vehicle operation (steering maneuver or traveling position in the lane, etc.) or vehicle condition. If this occurs, the system may warn driver by blinking the system indicator and sounding the chime unexpectedly. The driver will have to manually control the proper distance away from the vehicle traveling ahead.
- The approach warning chime may sound and the system display may blink when the sensor detects some reflectors which are fitted on vehicles in other lanes or on the side of the road. This may cause the DCA system to operate inappropriately. The sensor may detect these reflectors when the vehicle is driven on winding roads, hilly roads or when entering or exiting a curve. The sensor may also detect reflectors on narrow roads or in road construction zones. In these cases driver will have to manually control the proper distance ahead of own vehicle. Also, the sensor sensitivity can be affected by vehicle operation (steering maneuver or driving position in the lane) or traffic or vehicle condition (for example, if a vehicle is being driven with some damage).
- The DCA system automatically decelerates own vehicle to help assist the driver to maintain a following distance from the vehicle ahead. Manually brake when deceleration is required to maintain a safe distance upon sudden braking by the vehicle ahead or when a vehicle suddenly appears in front of own vehicle. Always stay alert when using the DCA system.
- When the vehicle ahead detection indicator lamp is not illuminated, system will not control or warn the driver.
- Never place a foot under the brake pedal. A foot may be caught when the system controls the brake.
- Depending on the position of the accelerator pedal, the system may not be able to assist the driver to release the accelerator pedal appropriately.
- If the vehicle ahead comes to a standstill, the vehicle decelerates to a standstill within the limitations of the system. The system will release brake control with a warning chime once it judges the vehicle is at a standstill. To prevent the vehicle from moving, the driver must depress the brake pedal. [The system will resume control automatically once the system reaches 5 km/h (3 MPH)].
Exploded View
| CAUTION | Always perform the laser beam aiming adjustment and check the operation after the replacement, removal and installation of ICC sensor. |
Scheme 68
Refer to " MODELS WITH DISTANCE CONTROL ASSIST SYSTEM: EXPLODED VIEW ".
| CAUTION | Always perform accelerator pedal released position learning after replacement, removal, or installation of accelerator pedal assembly, and then check the DCA system operation. Refer to " DESCRIPTION ". |
Dynamic driver assistance switch is integrated in the ICC steering switch. Refer to " EXPLODED VIEW ".
