WHEN THE ON BOARD SELF-DIAGNOSIS DOES NOT START
If the on board self-diagnosis does not start, check the following items.
| Assumed abnormal part | Inspection item | |
|---|---|---|
| Information display | Combination meter malfunction | Check that the self-diagnosis function of the combination meter operates. Refer to " ON BOARD DIAGNOSIS FUNCTION ". |
| ICC steering switch malfunction | Perform the inspection for DTC "C1A06". Refer to " DTC LOGIC ". | |
| Harness malfunction between ICC steering switch and ECM | ||
| ECM malfunction | ||
| ADAS control unit malfunction | Check power supply and ground circuit of ADAS control unit. Refer to " DIAGNOSIS PROCEDURE ". Perform SELF-DIAGNOSIS for "ICC/ADAS" with CONSULT, and then check the malfunctioning parts. Refer to " DTC INDEX ". | |
Scheme 30
- Turn the ignition switch OFF.
- Start the engine, and then start the on board self-diagnosis.
- Press the CANCEL switch 5 times, and then press the DISTANCE switch 5 times under the condition that the on board self-diagnosis starts. NOTE: Complete the operation within 10 seconds after pressing the CANCEL switch first. If the operation is not completed within 10 seconds, repeat the procedure from step 1 .
- DTC 55 is displayed after erasing. NOTE: DTCs for existing malfunction can not be erased.
- Turn ignition switch OFF, and finish the diagnosis.
SELF DIAGNOSTIC RESULT
Refer to " DTC INDEX ".
Scheme 31
Scheme 32
Scheme 33
ACTIVE TEST
| CAUTION | Never perform "Active Test" while driving the vehicle. The "Active Test" cannot be performed when the following systems warning lamp is illuminated. ICC system warning lamp Lane departure warning lamp BSW/BSI warning lamp IBA OFF indicator lamp (IBA system ON) Shift the selector lever to "P" position, and then perform the test. |
| Test item | Description |
|---|---|
| METER LAMP | The ICC system warning lamp, MAIN switch indicator and IBA OFF indicator lamp can be illuminated by ON/OFF operations as necessary |
| STOP LAMP | The ICC brake hold relay can be operated by ON/OFF operations as necessary, and the stop lamp can be illuminated |
| ICC BUZZER | Sounds a buzzer used for following systems by arbitrarily operating ON/OFF Intelligent Cruise Control (ICC) Distance Control Assist (DCA) Forward Collision Warning (FCW) Intelligent Brake Assist (IBA) |
| BRAKE ACTUATOR | Activates the brake by an arbitrary operation |
| Active Pedal | The accelerator pedal actuator can be operated as necessary |
| DCA INDICATOR | The DCA system switch indicator can be illuminated by ON/OFF operations as necessary |
| LDP BUZZER | Sounds a buzzer used for following systems by arbitrarily operating ON/OFF Lane Departure Warning (LDW) Lane Departure Prevention (LDP) Blind Spot Warning (BSW) Blind Spot Intervention (BSI) |
| WARNING SYSTEM IND | The warning systems ON indicator (on warning systems switch) can be illuminated by ON/OFF operations as necessary |
| LDP ON IND | The LDP ON indicator lamp can be illuminated by ON/OFF operations as necessary |
| LANE DEPARTURE W/L | The Lane departure warning lamp can be illuminated by ON/OFF operations as necessary |
| BSW/BSI WARNING LAMP | The BSW/BSI warning lamp can be illuminated by ON/OFF operations as necessary |
| BSI ON INDICATOR | The BSI ON indicator can be illuminated by ON/OFF operations as necessary |
Refer to " DTC INDEX ".
Refer to " DTC INDEX ".
| CAUTION | Never perform ACTIVE TEST while driving the vehicle. |
Note. The active test cannot be performed when the ICC system warning lamp is illuminated.
| Active test item | Description |
|---|---|
| ACCELERATOR PEDAL ACTUATOR TEST1 | Drive the accelerator pedal actuator and generate the constant accelerator pedal actuation force |
| ACCELERATOR PEDAL ACTUATOR TEST2 | Drive the accelerator pedal actuator and generate the vibration |
ACTIVE TEST ITEM LIST
ACCELERATOR PEDAL ACTUATOR TEST 1
Note. Check the accelerator pedal by depressing when performing the test.
| Active test item | Operation | Description |
|---|---|---|
| ACCELERATOR PEDAL ACTUATOR TEST1 | STOP | Finish the test |
| START | Generate the constant accelerator pedal actuation force for accelerator pedal |
ACCELERATOR PEDAL ACTUATOR TEST 2
Note. Check the accelerator pedal by depressing when performing the test.
| Active test item | Operation | Description |
|---|---|---|
| ACCELERATOR PEDAL ACTUATOR TEST 2 | STOP | Finish the test |
| START | Generate the vibration for accelerator pedal |
VALUES ON THE DIAGNOSIS TOOL
| Monitor item | Condition | Value/Status | |
|---|---|---|---|
| MAIN SW | Ignition switch ON | When MAIN switch is pressed | On |
| When MAIN switch is not pressed | Off | ||
| SET/COAST SW | Ignition switch ON | When SET/COAST switch is pressed | On |
| When SET/COAST switch is not pressed | Off | ||
| CANCEL SW | Ignition switch ON | When CANCEL switch is pressed | On |
| When CANCEL switch is not pressed | Off | ||
| RESUME/ACC SW | Ignition switch ON | When RESUME/ACCELERATE switch is pressed | On |
| When RESUME/ACCELERATE switch is not pressed | Off | ||
| DISTANCE SW | Ignition switch ON | When DISTANCE switch is pressed | On |
| When DISTANCE switch is not pressed | Off | ||
| CRUISE OPE | Drive the vehicle and activate the vehicle-to-vehicle distance control mode | When ICC system is controlling | On |
| When ICC system is not controlling | Off | ||
| BRAKE SW | Ignition switch ON | When brake pedal is depressed | Off |
| When brake pedal is not depressed | On | ||
| STOP LAMP SW | Ignition switch ON | When brake pedal is depressed | On |
| When brake pedal is not depressed | Off | ||
| IDLE SW | Engine running | Idling | On |
| Except idling (depress accelerator pedal) | Off | ||
| SET DISTANCE | Start the engine and turn the ICC system ON Press the DISTANCE switch to change the vehicle-to-vehicle distance setting | When set to "long" | Long |
| When set to "middle" | Mid | ||
| When set to "short" | Short | ||
| CRUISE LAMP | Start the engine and press MAIN switch | ICC system ON (MAIN switch indicator ON) | On |
| ICC system OFF (MAIN switch indicator OFF) | Off | ||
| OWN VHCL | Start the engine and press MAIN switch | ICC system ON (Own vehicle indicator ON) | On |
| ICC system OFF (Own vehicle indicator OFF) | Off | ||
| VHCL AHEAD | Drive the vehicle and activate the vehicle-to-vehicle distance control mode | When a vehicle ahead is detected (vehicle ahead detection indicator ON) | On |
| When a vehicle ahead is not detected (vehicle ahead detection indicator OFF) | Off | ||
| ICC WARNING | Start the engine and press MAIN switch | When ICC system is malfunctioning (ICC system warning lamp ON) | On |
| When ICC system is normal (ICC system warning lamp OFF) | Off | ||
| VHCL SPEED SE | While driving | Displays the vehicle speed calculated by ADAS control unit | |
| SET VHCL SPD | While driving | When vehicle speed is set | Displays the set vehicle speed |
| BUZZER O/P | Engine running | When the buzzer of the following system operates Vehicle-to-vehicle distance control mode DCA system FCW system IBA system | On |
| When the buzzer of the following system not operates Vehicle-to-vehicle distance control mode DCA system FCW system IBA system | Off | ||
| THRTL SENSOR | NOTE: The item is indicated, but not monitored | 0.0 | |
| ENGINE RPM | Engine running | Equivalent to tachometer reading | |
| WIPER SW | Ignition switch ON | Wiper not operating | Off |
| Wiper LO operation | Low | ||
| Wiper HI operation | High | ||
| YAW RATE | NOTE: The item is indicated, but not monitored | 0.0 | |
| BA WARNING | Engine running | IBA OFF indicator lamp ON When IBA system is malfunctioning When IBA system is turned to OFF | On |
| IBA OFF indicator lamp OFF When IBA system is normal When IBA system is turned to ON | Off | ||
| STP LMP DRIVE | Drive the vehicle and activate the vehicle-to-vehicle distance control mode | When ICC brake hold relay is activated | On |
| When ICC brake hold relay is not activated | Off | ||
| D RANGE SW | Engine running | When the selector lever is in "D" position or manual mode | On |
| When the selector lever is in any position other than "D" or manual mode | Off | ||
| NP RANGE SW | Engine running | When the selector lever is in "N", "P" position | On |
| When the selector lever is in any position other than "N", "P" | Off | ||
| PKB SW | Ignition switch ON | When the parking brake is applied | On |
| When the parking brake is released | Off | ||
| PWR SUP MONI | Engine running | Power supply voltage value of ADAS control unit | |
| VHCL SPD AT | While driving | Value of A/T vehicle speed sensor signal | |
| THRTL OPENING | Engine running | Depress accelerator pedal | Displays the throttle position |
| GEAR | While driving | Displays the gear position | |
| MODE SIG | Start the engine and press MAIN switch | When ICC system is deactivated | Off |
| When vehicle-to-vehicle distance control mode is activated | ICC | ||
| When conventional (fixed speed) cruise control mode is activated | ASCD | ||
| SET DISP IND | Drive the vehicle and activate the conventional (fixed speed) cruise control mode Press SET/COAST switch | SET switch indicator ON | On |
| SET switch indicator OFF | Off | ||
| DISTANCE | Drive the vehicle and activate the vehicle-to-vehicle distance control mode | When a vehicle ahead is detected | Displays the distance from the preceding vehicle |
| When a vehicle ahead is not detected | 0.0 | ||
| RELATIVE SPD | Drive the vehicle and activate the vehicle-to-vehicle distance control mode | When a vehicle ahead is detected | Displays the relative speed. |
| When a vehicle ahead is not detected | 0.0 | ||
| DYNA ASIST SW | Ignition switch ON | When dynamic driver assistance switch is pressed | On |
| When dynamic driver assistance switch is not pressed | Off | ||
| DCA ON IND | Start the engine and press dynamic driver assistance switch (When DCA setting is ON) | DCA system OFF (DCA system switch indicator OFF) | Off |
| DCA system ON (DCA system switch indicator ON) | On | ||
| DCA VHL AHED | Drive the vehicle and activate the DCA system | When a vehicle ahead is not detected (vehicle ahead detection indicator OFF) | Off |
| When a vehicle ahead is detected (vehicle ahead detection indicator ON) | On | ||
| IBA SW | Ignition switch ON | When the IBA OFF switch is pressed | On |
| When the IBA OFF switch is not pressed | Off | ||
| FCW SYSTEM ON | Ignition switch ON | When the FCW system is ON (Warning systems ON indicator ON) | On |
| When the FCW system is OFF (Warning systems ON indicator OFF) | Off | ||
| APA TEMP | Engine running | Display the accelerator pedal actuator integrated motor temperature | |
| APA PWR | Ignition switch ON | Power supply voltage value of accelerator pedal actuator | |
| LDW SYSTEM ON | Ignition switch ON | When the LDW system is ON (Warning systems ON indicator ON) | On |
| When the LDW system is OFF (Warning systems ON indicator OFF) | Off | ||
| LDW ON LAMP | Ignition switch ON | Warning systems ON indicator ON | On |
| Warning systems ON indicator OFF | Off | ||
| LDP ON IND | Start the engine and press dynamic driver assistance switch (When LDP system setting is ON) | LDP ON indicator lamp ON | On |
| LDP ON indicator lamp OFF | Off | ||
| LANE DPRT W/L | Drive the vehicle and activate the LDW system or LDP system | Lane departure warning lamp ON | On |
| Lane departure warning lamp OFF | Off | ||
| LDW BUZER OUTPUT | Drive the vehicle and activate the LDW/LDP system or BSW/BSI system | When the buzzer of the following system operates LDW/LDP system BSW/BSI system | On |
| When the buzzer of the following system does not operate LDW/LDP system BSW/BSI system | Off | ||
| LDP SYSTEM ON | Start the engine and press dynamic driver assistance switch (When LDP system setting is ON) | When the LDP system is ON | On |
| When the LDP system is OFF | Off | ||
| READY signal | Start the engine and press dynamic driver assistance switch (When LDP system setting is ON) | When the LDP system is ON | On |
| When the LDP system is OFF | Off | ||
| Camera lost | Drive the vehicle and activate the LDW system, LDP system or BSI system | Both side lane markers are detected | Detect |
| Deviate side lane marker is lost | Deviate | ||
| Both side lane markers are lost | Both | ||
| Shift position | Engine running While driving | Displays the shift position | |
| Turn signal | Turn signal lamps OFF | Off | |
| Turn signal lamp LH blinking | LH | ||
| Turn signal lamp RH blinking | RH | ||
| Turn signal lamp LH and RH blinking | LH&RH | ||
| SIDE G | While driving | Vehicle turning right | Negative value |
| Vehicle turning left | Positive value | ||
| WARN REQ | Drive the vehicle and activate the LDP system | Lane departure warning is operating | On |
| Lane departure warning is not operating | Off | ||
| STATUS signal | Drive the vehicle and activate the LDP system | When the LDP system is ON | Stnby |
| When the LDP system is operating | Warn | ||
| When the LDP system is canceled | Cancl | ||
| When the LDP system is OFF | Off | ||
| Lane unclear | While driving | Lane marker is unclear | On |
| Lane marker is clear | Off | ||
| FUNC ITEM | Ignition switch ON | FUNC3 | |
| FUNC ITEM (NV-ICC) | NOTE: The item is indicated, but not monitored | Off | |
| FUNC ITEM (NVDCA) | NOTE: The item is indicated, but not monitored | Off | |
| DCA SELECT | Ignition switch ON | "Distance Control Assist" set with the navigation system is ON | On |
| "Distance Control Assist" set with the navigation system is OFF | Off | ||
| LDP SELECT | Ignition switch ON | "Lane Departure Prevention" set with the navigation system is ON | On |
| "Lane Departure Prevention" set with the navigation system is OFF | Off | ||
| BSI SELECT | Ignition switch ON | "Blind Spot Intervention" set with the navigation system is ON | On |
| "Blind Spot Intervention" set with the navigation system is OFF | Off | ||
| NAVI ICC SELECT | NOTE: The item is indicated, but not monitored | Off | |
| NAVI DCA SELECT | NOTE: The item is indicated, but not monitored | Off | |
| SYS SELECTABILITY | Ignition switch ON | Items set with the navigation system can be switched normally | On |
| Items set with the navigation system cannot be switched normally | Off | ||
| DRIVE MODE STATS | Ignition switch ON | When drive mode select switch position is STANDARD | STD |
| When drive mode select switch position is in SPORT | SPORT | ||
| When drive mode select switch position is in ECO | ECO | ||
| When drive mode select switch position is in SNOW | SNOW | ||
| When position of drive mode select switch is in following states In the middle of SNOW-ECO In the middle of ECO-STANDARD In the middle of STANDARD-SPORTS | Mid | ||
| A signal other than those above is input | ERROR | ||
| WARN SYS SW | Ignition switch ON | When warning systems switch is pressed | On |
| When warning systems switch is not pressed | Off | ||
| BSW/BSI WARN LMP | Ignition switch ON | BSW/BSI warning lamp ON | On |
| BSW/BSI warning lamp OFF | Off | ||
| BSI ON IND | Ignition switch ON | BSI ON indicator ON | On |
| BSI ON indicator OFF | Off | ||
| BSW SYSTEM ON | Ignition switch ON | When the BSW system is ON (Warning systems ON indicator ON) | On |
| When the BSW system is OFF (Warning systems ON indicator OFF) | Off | ||
| BSI SYSTEM ON | Start the engine and press dynamic driver assistance switch (When BSI system setting is ON) | When the BSI system is ON | On |
| When the BSI system is OFF | Off | ||
| NOTE |
|---|
| The item is indicated, but not monitored |
| NOTE |
|---|
| The item is indicated, but not monitored |
| NOTE |
|---|
| The item is indicated, but not monitored |
| NOTE |
|---|
| The item is indicated, but not monitored |
| NOTE |
|---|
| The item is indicated, but not monitored |
| NOTE |
|---|
| The item is indicated, but not monitored |
Scheme 34
| Terminal No. (Wire color) | Description | Condition | Value (Approx.) | |||
|---|---|---|---|---|---|---|
| + | Signal name | Input/Output | ||||
| 1 (Y) | Ground | Warning systems switch | Input | Ignition switch ON | When warning systems switch is not pressed | 12 V |
| When warning systems switch is pressed | 0 V | |||||
| 3 (BR) | IBA OFF switch | Input | Ignition switch ON | When IBA OFF switch is not pressed | 12 V | |
| When IBA OFF switch is pressed | 0 V | |||||
| 4 (O) | Warning systems ON indicator | Output | Ignition switch ON | Warning systems ON indicator ON | 0 V | |
| Warning systems ON indicator OFF | 12 V | |||||
| 5 (SB) | ICC brake hold relay drive signal | Output | Ignition switch ON | 12 V | ||
| At "STOP LAMP" test of "Active test" | 0 V | |||||
| 6 (B/R) | Ground | Ignition switch ON | 0 V | |||
| 7 (L) | ITS communication-H | |||||
| 8 (P) | ITS communication-L | |||||
| 12 (W) | Warning buzzer signal | Output | Ignition switch ON | Warning buzzer operation | 0 V | |
| Warning buzzer not operating | 12 V | |||||
| 14 (L) | CAN-H | |||||
| 15 (R) | CAN-L | |||||
| 16 (GR) | Ignition power supply | Input | Ignition switch ON | Battery voltage | ||
DTC Inspection Priority Chart
If multiple DTCs are detected simultaneously, check them one by one depending on the following DTC inspection priority chart.
| Priority | Detected items (DTC) |
|---|---|
| 1 | U1507: LOST COMM (SIDE RDR R) U1508: LOST COMM (SIDE RDR L) |
| 2 | U1000: CAN COMM CIRCUIT U1010: CONTROL UNIT (CAN) |
| 3 | C1B00: CAMERA UNIT MALF C1F02: APA C/U MALF C1A17: ICC SENSOR MALF C1B53: SIDE RDR R MALF C1B54: SIDE RDR L MALF |
| 4 | C1A01: POWER SUPPLY CIR C1A02: POWER SUPPLY CIR 2 C1A04: ABS/TCS/VDC CIRC C1A05: BRAKE SW/STOP L SW C1A06: OPERATION SW CIRC C1A12: LASER BEAM OFFCNTR C1A13: STOP LAMP RLY FIX C1A14: ECM CIRCUIT C1A16: RADAR STAIN C1A18: LASER AIMING INCMP C1A2A: ICC SEN PWR SUP CIR C1A21: ICC SENSOR HIGH TEMP C1A24: NP RANGE C1A26: ECD MODE MALF C1A27: ECD PWR SUPLY CIR C1A33: CAN TRANSMISSION ERR C1A34: COMMAND ERROR C1A35: APA CIR C1A36: APA CAN COMM CIR C1A37: APA CAN CIR 2 C1A38: APA CAN CIR 1 C1A39: STRG SEN CIR C1A40: SYSTEM SW CIRC C1B01: CAM AIMING INCMP C1B03: CAM ABNRML TMP DETCT C1F01: APA MOTOR MALF C1F05: APA PWR SUPLY CIR U0121: VDC CAN CIR 2 U0126: STRG SEN CAN CIR 1 U0235: ICC SENSOR CAN CIRC 1 U0401: ECM CAN CIR 1 U0402: TCM CAN CIR 1 U0415: VDC CAN CIR 1 U0424: HVAC CAN CIR 1 U0428: STRG SEN CAN CIR 2 U1500: CAM CAN CIR 2 U1501: CAM CAN CIR 1 U1502: ICC SEN CAN COMM CIR U1503: SIDE RDR L CAN CIR 2 U1504: SIDE RDR L CAN CIR 1 U1505: SIDE RDR R CAN CIR 2 U1506: SIDE RDR R CAN CIR 1 U150B: ECM CAN CIRC 3 U150C: VDC CAN CIRC 3 U150D: TCM CAN CIRC 3 U150E: BCM CAN CIRC 3 U150F: AV CAN CIRC 3 U1512: HVAC CAN CIRC3 U1513: METER CAN CIRC 3 U1514: STRG SEN CAN CIRC 3 U1515: ICC SENSOR CAN CIRC 3 U1516: CAM CAN CIRC 3 U1517: APA CAN CIRC 3 U1518: SIDE RDR L CAN CIRC 3 U1519: SIDE RDR R CAN CIRC 3 |
| 5 | C1A03: VHCL SPEED SE CIRC |
| 6 | C1A15: GEAR POSITION |
| 7 | C1A00: CONTROL UNIT |
DTC Index
Note. The details of time display are as per the following. CRNT: A malfunction is detected now PAST: A malfunction was detected in the past IGN counter is displayed on FFD (Freeze Frame Data). 0: The malfunctions that are detected now CAN communication system (U1000, U1010) 1 - 39: It increases like 0 --> 1 --> 2... 38 --> 39 after returning to the normal condition whenever the ignition switch OFF --> ON. It returns to 0 when a malfunction is detected again in the process. If it is over 39, it is fixed to 39 until the self-diagnosis results are erased. Other than CAN communication system (Other than U1000, U1010) 1 - 49: It increases like 0 --> 1 --> 2... 38 --> 49 after returning to the normal condition whenever the ignition switch OFF --> ON. It returns to 0 when a malfunction is detected again in the process. If it is over 49, it is fixed to 49 until the self-diagnosis results are erased.
Systems for fail-safe
Scheme 35
- A: Vehicle-to-vehicle distance control mode
- B: Conventional (fixed speed) cruise control mode
- C: Intelligent Brake Assist (IBA)
- D: Forward Collision Warning (FCW)
- E: Distance Control Assist (DCA)
- F: Lane Departure Warning (LDW)/Lane Departure Prevention (LDP)
- G: Blind Spot Warning (BSW)/Blind Spot Intervention (BSI)
- H: Active trace control function
Systems for fail-safe
Scheme 36
- A: Vehicle-to-vehicle distance control mode
- B: Conventional (fixed speed) cruise control mode
- C: Intelligent Brake Assist (IBA)
- D: Forward Collision Warning (FCW)
- E: Distance Control Assist (DCA)
- F: Lane Departure Warning (LDW)/Lane Departure Prevention (LDP)
- G: Blind Spot Warning (BSW)/Blind Spot Intervention (BSI)
- H: Active trace control function
Systems for fail-safe
Scheme 37
- A: Vehicle-to-vehicle distance control mode
- B: Conventional (fixed speed) cruise control mode
- C: Intelligent Brake Assist (IBA)
- D: Forward Collision Warning (FCW)
- E: Distance Control Assist (DCA)
- F: Lane Departure Warning (LDW)/Lane Departure Prevention (LDP)
- G: Blind Spot Warning (BSW)/Blind Spot Intervention (BSI)
- H: Active trace control function
Systems for fail-safe
Scheme 38
- A: Vehicle-to-vehicle distance control mode
- B: Conventional (fixed speed) cruise control mode
- C: Intelligent Brake Assist (IBA)
- D: Forward Collision Warning (FCW)
- E: Distance Control Assist (DCA)
- F: Lane Departure Warning (LDW)/Lane Departure Prevention (LDP)
- G: Blind Spot Warning (BSW)/Blind Spot Intervention (BSI)
- H: Active trace control function
Note. With the detection of "U1000" some systems do not perform the fail-safe operation. A system controlling based on a signal received from the control unit performs fail-safe operation when the communication with the ADAS control unit becomes inoperable.
| Monitor item | Condition | Value/Status | |
|---|---|---|---|
| VHCL SPEED SE | While driving | Value of vehicle speed signal (wheel speed) | |
| YAW RATE | While driving | Vehicle stopped | 0.0 |
| Vehicle turning right | Positive value | ||
| Vehicle turning left | Negative value | ||
| PWR SUP MONI | Ignition switch ON | Power supply voltage value of ICC sensor | |
| DISTANCE | Drive the vehicle and activate the vehicle-to-vehicle distance control mode | When a vehicle ahead is detected | Displays the distance from the preceding vehicle |
| When a vehicle ahead is not detected | 0.0 | ||
| RELATIVE SPD | Drive the vehicle and activate the vehicle-to-vehicle distance control mode | When a vehicle ahead is detected | Displays the relative speed |
| When a vehicle ahead is not detected | 0.0 | ||
| LASER OFFSET | NOTE: The item is indicated, but not used | ||
| LASER HEIGHT | NOTE: The item is indicated, but not used | ||
| STEERING ANGLE | Ignition switch ON | When setting the steering wheel in straight-ahead position | 0.0 |
| When turning the steering wheel 90° rightward | +90 | ||
| When turning the steering wheel 90° leftward | 90 | ||
| STRG ANGLE SPEED | Ignition switch ON | At the time of turning the steering wheel | Steering wheel turning speed is displayed |
| L/R ADJUST | Ignition switch ON | At the completion of laser beam adjustment | Horizontal correction value is displayed |
| U/D ADJUST | Ignition switch ON | At the completion of laser beam adjustment | Vertical correction value is displayed |
| NOTE |
|---|
| The item is indicated, but not used |
| NOTE |
|---|
| The item is indicated, but not used |
Scheme 39
If multiple DTCs are detected simultaneously, check them one by one depending on the following DTC inspection priority chart.
| Priority | Detected items (DTC) |
|---|---|
| 1 | U1000: CAN COMM CIRCUIT U1010: CONTROL UNIT (CAN) |
| 2 | C1A50: ADAS MALFUNCTION |
| 3 | C1A01: POWER SUPPLY CIR C1A02: POWER SUPPLY CIR 2 C1A12: LASER BEAM OFFCNTR C1A16: RADAR STAIN C1A18: LASER AIMING INCMP C1A21: UNIT HIGH TEMP C1A39: STRG SEN CIR U0104: ADAS CAN CIR1 U0121: VDC CAN CIR2 U0126: STRG SEN CAN CIR1 U0405: ADAS CAN CIR2 U0415: VDC CAN CIR1 U0428: STRG SEN CAN CIR2 |
| 4 | C1A00: CONTROL UNIT |
Note. The details of time display are as per the following. 0: The malfunctions that are detected now CAN communication system (U1000, U1010) 1 - 39: It increases like 0 --> 1 --> 2... 38 --> 39 after returning to the normal condition whenever the ignition switch OFF --> ON. It returns to 0 when a malfunction is detected again in the process. If it is over 39, it is fixed to 39 until the self-diagnosis results are erased. Other than CAN communication system (Other than U1000, U1010) 1 - 49: It increases like 0 --> 1 --> 2... 38 --> 49 after returning to the normal condition whenever the ignition switch OFF --> ON. It returns to 0 when a malfunction is detected again in the process. If it is over 49, it is fixed to 49 until the self-diagnosis results are erased.
Scheme 40
| Monitor item | Condition | Value/Status | |
|---|---|---|---|
| TGT FBK FRC | Drive the vehicle and operate the DCA system | When the ADAS control unit is controlling the accelerator pedal actuator | It changes with the demand from the ADAS control unit |
| TGT MOT POSI | NOTE: The item is indicated, but not used. | ||
| ACT MOT POSI | Engine running | Depress accelerator pedal | It changes according to the depressed amount of accelerator pedal |
| AP OPEN | Engine running | Depress accelerator pedal | It changes according to the depressed amount of accelerator pedal |
| APA TEMP | Engine running | Display the accelerator pedal actuator integrated motor temperature | |
| APA CURRENT | Drive the vehicle and operate the DCA system | When the ADAS control unit is controlling the accelerator pedal actuator | Display the accelerator pedal actuator motor operation consumption current |
| APA PWR | Ignition switch ON | Battery voltage | |
| APA OPE STATS | Engine running | When the accelerator pedal actuator control is permitted | On |
| When the accelerator pedal actuator control is invalid | Off | ||
| APA STATS | Engine running | When the accelerator pedal actuator is normal | Ready |
| When the accelerator pedal actuator is temporarily malfunctioning | TP NG | ||
| When the accelerator pedal actuator is malfunctioning | NG | ||
| During the accelerator pedal actuator operation preparations | Init | ||
| NOTE |
|---|
| The item is indicated, but not used. |
Scheme 41
If multiple DTCs are detected simultaneously, check them one by one depending on the following DTC inspection priority chart.
| Priority | Detected items (DTC) |
|---|---|
| 1 | U1000: CAN COMM CIRCUIT U1010: CONTROL UNIT (CAN) |
| 2 | C1F02: APA C/U MALF |
| 3 | C1F01: APA MOTOR MALF C1F03: APA HI TEMP C1F05: APA PWR SUPLY CIR C1F06: CAN CIR2 C1F07: CAN CIR1 |
Note. The details of time display are as per the following. CRNT: A malfunction is detected now PAST: A malfunction was detected in the past IGN counter is displayed in FFD (Freeze Frame Data). 0: The malfunctions that are detected now 1 - 39: It increases like 0 --> 1 --> 2... 38 --> 39 after returning to the normal condition whenever the ignition switch OFF --> ON. It returns to 0 when a malfunction is detected again in the process. If it is over 39, it is fixed to 39 until the self-diagnosis results are erased.
| X: Applicable | ||
|---|---|---|
| CONSULT display | ICC system warning lamp | Fail-safe function |
| C1F01 ACCELERATOR PEDAL ACTUATOR | ON | X |
| C1F02 ACCELERATOR PEDAL ACTUATOR | ON | X |
| C1F03 ACCELERATOR PEDAL ACTUATOR | ||
| C1F05 ACCELERATOR PEDAL ACTUATOR POWER SUPPLY CIRCUIT | ON | X |
| C1F06 CAN CIRCUIT2 | ON | X |
| C1F07 CAN CIRCUIT1 | ON | X |
| U1000 CAN COMM CIRCUIT | ON | X |
| U1010 CONTROL UNIT (CAN) | ON | X |
| DTC | Description |
|---|---|
| DTC C1A00 | CONTROL UNIT |
| DTC C1A01 | POWER SUPPLY CIRCUIT 1, DTC C1A02: POWER SUPPLY CIRCUIT 2 |
| DTC C1A03 | VEHICLE SPEED SENSOR |
| DTC C1A04 | ABS/TCS/VDC SYSTEM |
| DTC C1A05 | BRAKE SW/STOP LAMP SW |
| DTC C1A06 | OPERATION SW |
| DTC C1A12 | LASER BEAM OFF CENTER |
| DTC C1A13 | STOP LAMP RELAY |
| DTC C1A14 | ECM |
| DTC C1A15 | GEAR POSITION |
| DTC C1A16 | RADAR STAIN |
| DTC C1A17 | ICC SENSOR |
| DTC C1A18 | LASER AIMING INCMP |
| DTC C1A21 | UNIT HIGH TEMP |
| DTC C1A24 | NP RANGE |
| DTC C1A26 | ECD MODE MALFUNCTION |
| DTC C1A27 | ECD POWER SUPPLY CIRCUIT |
| DTC C1A2A | ICC SENSOR POWER SUPPLY CIRCUIT |
| DTC C1A33 | CAN TRANSMISSION ERROR |
| DTC C1A34 | COMMAND ERROR |
| DTC C1A35 | ACCELERATOR PEDAL ACTUATOR |
| DTC C1A36 | ACCELERATOR PEDAL ACTUATOR CAN COMM |
| DTC C1A37 | ACCELERATOR PEDAL ACTUATOR CAN 2 |
| DTC C1A38 | ACCELERATOR PEDAL ACTUATOR CAN 1 |
| DTC C1A39 | STEERING ANGLE SENSOR |
| DTC C1F01 | ACCELERATOR PEDAL ACTUATOR |
| DTC C1F02 | ACCELERATOR PEDAL ACTUATOR |
| DTC C1F03 | ACCELERATOR PEDAL ACTUATOR |
| DTC C1F05 | ACCELERATOR PEDAL ACTUATOR POWER SUPPLY CIRCUIT |
| DTC C1F06 | CAN CIRCUIT2 |
| DTC C1F07 | CAN CIRCUIT1 |
| DTC U0121 | VDC CAN 2 |
| DTC U0126 | STRG SEN CAN 1 |
| DTC U0235 | ICC SENSOR CAN 1 |
| DTC U0401 | ECM CAN 1 |
| DTC U0402 | TCM CAN 1 |
| DTC U0415 | VDC CAN 1 |
| DTC U0428 | STRG SEN CAN 2 |
| DTC U1000 | CAN COMM CIRCUIT |
| DTC U1010 | CONTROL UNIT (CAN) |
| DTC U150B | ECM CAN 3 |
| DTC U150C | VDC CAN 3 |
| DTC U150D | TCM CAN 3 |
| DTC U150E | BCM CAN 3 |
| DTC U1502 | ICC SENSOR CAN COMM CIRC |
| DTC U1513 | METER CAN 3 |
| DTC U1514 | STRG SEN CAN 3 |
| DTC U1515 | ICC SENSOR CAN 3 |
| DTC U1517 | ACCELERATOR PEDAL ACTUATOR CAN 3 |
DTC INDEX
DTC DETECTION LOGIC
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A00 (0) | CONTROL UNIT | ADAS control unit internal malfunction | ADAS control unit |
DTC CONFIRMATION PROCEDURE
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Perform "All DTC Reading" with CONSULT. Check if the "C1A00" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A00" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S39390324802013082200000) ". NO: INSPECTION END
Diagnosis Procedure
- CHECK SELF-DIAGNOSIS RESULTS Check if any DTC other than "C1A00" is detected in "Self Diagnostic Result" of "ICC/ADAS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A01 (1) | POWER SUPPLY CIR | The battery voltage sent to ADAS control unit remains less than 7.9 V for 5 seconds | Connector, harness, fuse ADAS control unit |
| C1A02 (2) | POWER SUPPLY CIR 2 | The battery voltage sent to ADAS control unit remains more than 19.3 V for 5 seconds |
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A01" or "C1A02" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A01" or "C1A02" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S13594147302013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK ADAS CONTROL UNIT POWER SUPPLY AND GROUND CIRCUIT Check power supply and ground circuit of ADAS control unit. Refer to " «ADAS CONTROL UNIT: DIAGNOSIS PROCEDURE»(ref-573618-S19740678512013082200000) ". Is the inspection result normal? YES: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: Repair or replace the malfunctioning parts.
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A03 (3) | VHCL SPEED SE CIRC | If the vehicle speed signal (wheel speed) from ABS actuator and electric unit (control unit) and the A/T vehicle speed sensor signal (output shaft revolution signal) from TCM, received by the ADAS control unit via CAN communication, are inconsistent | Wheel speed sensor ABS actuator and electric unit (control unit) Vehicle speed sensor A/T (output speed sensor) TCM ADAS control unit |
Note. If DTC "C1A03" is detected along with DTC "U1000" or "C1A04", first diagnose the DTC "U1000" or "C1A04". Refer to " ADAS CONTROL UNIT: DTC LOGIC " for DTC "U1000". Refer to " DTC LOGIC " for DTC "C1A04".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Drive the vehicle at 30 km/h (19 MPH) or more. CAUTION: Always drive safely. Stop the vehicle. Perform "All DTC Reading" with CONSULT. Check if the "C1A03" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A03" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S18567034482013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "C1A04" or "U1000" is detected other than "C1A03" in "Self Diagnostic Result" of "ICC/ADAS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S39553697082013082200000) ". NO: GO TO 2.
- CHECK DATA MONITOR Start the engine. Drive the vehicle. Check that the value of "VHCL SPD AT" is almost the same as the value of "VHCL SPEED SE" in "DATA MONITOR" of "ICC/ADAS". CAUTION: Be careful of the vehicle speed. Is the inspection result normal? YES: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: GO TO 3.
- CHECK TCM SELF-DIAGNOSIS RESULTS Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "TRANSMISSION". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573584-S14505563512013082200000) ". NO: GO TO 4.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A04 (4) | ABS/TCS/VDC CIRC | If a malfunction occurs in the VDC/TCS/ABS system | ABS actuator and electric unit (control unit) |
Note. If DTC "C1A04" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- CHECK SELF-DIAGNOSIS RESULTS Perform "All DTC Reading" with CONSULT. Check if the "U1000" is detected other than "C1A04" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A05 (5) | BRAKE SW/STOP L SW | A mismatch between a stop lamp switch signal and a ICC brake switch signal received from ECM and a stop lamp signal received from the ABS actuator and electric unit (control unit) continues for 10 seconds or more with vehicle speeds at approximately 40 km/h or more | Stop lamp switch circuit ICC brake switch circuit Stop lamp switch ICC brake switch Incorrect stop lamp switch installation Incorrect ICC brake switch installation ECM ABS actuator and electric unit (control unit) |
Note. If DTC "C1A05" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- CHECK SELF-DIAGNOSIS RESULTS Perform "All DTC Reading" with CONSULT. Check if the "U1000" is detected other than "C1A05" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK STOP LAMP SWITCH AND ICC BRAKE SWITCH Check that "STOP LAMP SW" and "BRAKE SW" operate normally in "DATA MONITOR" of "ICC/ADAS". Is the inspection result normal? YES: GO TO 3. NO-1: When "BRAKE SW" operation is malfunctioning: GO TO 4 . NO-2: When "STOP LAMP SW" operation is malfunctioning: GO TO 9 .
- CHECK STOP LAMP SWITCH Check that "STOP LAMP SW" operate normally in "DATA MONITOR" of "ABS". Is the inspection result normal? YES: GO TO 14 . NO: GO TO 9 .
- CHECK ICC BRAKE SWITCH INSTALLATION Turn ignition switch OFF. Check ICC brake switch for correct installation. Refer to " «INSPECTION AND ADJUSTMENT»(ref-573611-S24808716902013082200000) ". Is the inspection result normal? YES: GO TO 5. NO: Adjust ICC brake switch installation. Refer to " «INSPECTION AND ADJUSTMENT»(ref-573611-S24808716902013082200000) ".
- ICC BRAKE SWITCH INSPECTION Disconnect ICC brake switch connector. Check ICC brake switch. Refer to " «COMPONENT INSPECTION (ICC BRAKE SWITCH)»(ref-573618-S42892162642013082200000) ". Is the inspection result normal? YES: GO TO 6. NO: Replace ICC brake switch.
- CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT Turn the ignition switch ON. Check voltage between ICC brake switch harness connector and ground. Terminals Voltage (Approx.) (+) (-) ICC brake switch Ground Connector Terminal E114 1 Battery voltage Is the inspection result normal? YES: GO TO 7. NO: Repair the harnesses or connectors.
- CHECK HARNESS BETWEEN ICC BRAKE SWITCH AND ECM Turn ignition switch OFF Disconnect ECM connector. Check for continuity between ICC brake switch harness connector and ECM harness connector. ICC BRAKE SWITCH - VQ37VHR ICC brake switch ECM Continuity Connector Terminal Connector Terminal E114 2 M107 126 Existed ICC BRAKE SWITCH - VK56VD ICC brake switch ECM Continuity Connector Terminal Connector Terminal E114 2 M160 147 Existed Check for continuity between ICC brake switch harness connector and ground. ICC brake switch Ground Continuity Connector Terminal E114 2 Not existed Is the inspection result normal? YES: GO TO 8. NO: Repair the harnesses or connectors.
- PERFORM SELF-DIAGNOSIS OF ECM Connect all connectors again if the connectors are disconnected. Turn ignition switch ON. Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "ENGINE". Refer to " «DTC INDEX»(ref-573577-S32168264542013082200000) " (VQ37VHR) or " «DTC INDEX»(ref-573597-S12084516802013082200000) " (VK56VD for USA and Canada). Is any DTC detected? YES: Repair or replace the malfunctioning parts identified by the self-diagnosis result. NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
- CHECK STOP LAMP SWITCH INSTALLATION Turn ignition switch OFF. Check stop lamp switch for correct installation. Refer to " «INSPECTION AND ADJUSTMENT»(ref-573611-S24808716902013082200000) ". Is the inspection result normal? YES: GO TO 10. NO: Adjust stop lamp switch installation. Refer to " «INSPECTION AND ADJUSTMENT»(ref-573611-S24808716902013082200000) ".
- STOP LAMP SWITCH INSPECTION Disconnect stop lamp switch connector. Check stop lamp switch. Refer to " «COMPONENT INSPECTION (STOP LAMP SWITCH)»(ref-573618-S07628174762013082200000) ". Is the inspection result normal? YES: GO TO 11. NO: Replace stop lamp switch.
- CHECK STOP LAMP SWITCH POWER SUPPLY CIRCUIT Turn the ignition switch ON. Check voltage between stop lamp switch harness connector and ground. Terminals Voltage (Approx.) (+) (-) Stop lamp switch Ground Connector Terminal E110 1 Battery voltage 3 Is the inspection result normal? YES: GO TO 12. NO: Repair the harnesses or connectors.
- CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ECM Turn ignition switch OFF Disconnect ECM, rear combination lamp and high-mounted stop lamp connectors. Check for continuity between stop lamp switch harness connector and ECM harness connector. STOP LAMP SWITCH - VQ37VHR Stop lamp switch ECM Continuity Connector Terminal Connector Terminal E110 2 M107 122 Existed STOP LAMP SWITCH - VK56VD Stop lamp switch ECM Continuity Connector Terminal Connector Terminal E110 2 M160 158 Existed Check for continuity between stop lamp switch harness connector and ground. Stop lamp switch Ground Continuity Connector Terminal E110 2 Not existed Is the inspection result normal? YES: GO TO 13. NO: Repair the harnesses or connectors.
- CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Disconnect ABS actuator and electric unit (control unit) connector. Check for continuity between stop lamp switch harness connector and ABS actuator and electric unit (control unit) harness connector. Stop lamp switch ABS actuator and electric unit (control unit) Continuity Connector Terminal Connector Terminal E110 4 E41 5 Existed Check for continuity between stop lamp switch harness connector and ground. Stop lamp switch Ground Continuity Connector Terminal E110 4 Not existed Is the inspection result normal? YES: GO TO 14. NO: Repair the harnesses or connectors.
- PERFORM SELF-DIAGNOSIS OF ECM Connect all connectors again if the connectors are disconnected. Turn ignition switch ON. Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "ENGINE". Refer to " «DTC INDEX»(ref-573577-S32168264542013082200000) " (VQ37VHR) or " «DTC INDEX»(ref-573597-S12084516802013082200000) " (VK56VD for USA and Canada). Is any DTC detected? YES: Repair or replace the malfunctioning parts identified by the self-diagnosis result. NO: GO TO 15.
- PERFORM SELF-DIAGNOSIS OF ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". Is any DTC detected? YES: Repair or replace the malfunctioning parts identified by the self-diagnosis result. NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
Component Inspection (ICC Brake Switch)
- CHECK ICC BRAKE SWITCH Check for continuity between ICC brake switch terminals. Terminal Condition Continuity 1 2 When brake pedal is depressed Not existed When brake pedal is released Existed Is the inspection result normal? YES: INSPECTION END NO: Replace ICC brake switch.
Component Inspection (Stop Lamp Switch)
- CHECK STOP LAMP SWITCH Check for continuity between stop lamp switch terminals. Terminal Condition Continuity 1 2 When brake pedal is depressed Existed When brake pedal is released Not existed 3 4 When brake pedal is depressed Existed When brake pedal is released Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace stop lamp switch.
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A06 (6) | OPERATION SW CIRC | Any switch of the ICC steering switch is detected as "ON" continuously for 60 seconds An ON/OFF state judgment of the ICC differs between ECM and ADAS control unit, and the state continues for 2 seconds or more | ICC steering switch circuit ICC steering switch ECM |
Note. If DTC "C1A06" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Wait for approximately 10 minutes after turning the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A06" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A06" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S27202542142013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A06" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «DTC LOGIC»(ref-573617-S05987788922013082200000) ". NO: GO TO 2.
- CHECK ICC STEERING SWITCH Turn the ignition switch OFF. Disconnect the ICC steering switch connector. Check the ICC steering switch. Refer to " «COMPONENT INSPECTION»(ref-573618-S40551652822013082200000) ". Is the inspection result normal? YES: GO TO 3. NO: Replace the ICC steering switch.
- CHECK HARNESS BETWEEN SPIRAL CABLE AND ECM Disconnect the ECM connector. Check for continuity between the spiral cable harness connector and ECM harness connector. SPIRAL CABLE - VQ37VHR Spiral cable ECM Continuity Connector Terminal Connector Terminal M36 25 M107 101 Existed 32 108 SPIRAL CABLE - VK56VD Spiral cable ECM Continuity Connector Terminal Connector Terminal M36 25 M160 128 Existed 32 130 Check for continuity between spiral cable harness connector and ground. Spiral cable Ground Continuity Connector Terminal M36 25 Not existed 32 Is the inspection result normal? YES: GO TO 4. NO: Repair the harnesses or connectors.
- CHECK SPIRAL CABLE Check for continuity between spiral cable terminals. Spiral cable Continuity Terminal 13 25 Existed 16 32 Is the inspection result normal? YES: GO TO 5. NO: Replace the spiral cable.
- PERFORM SELF-DIAGNOSIS OF ECM Connect the connectors of ICC steering switch and ECM connector. Turn the ignition switch ON. Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "ENGINE". Is any DTC detected? YES: Perform self-diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573577-S32168264542013082200000) " (VQ37VHR) or " «DTC INDEX»(ref-573597-S12084516802013082200000) " (VK56VD for USA and Canada). NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
Scheme 42
- CHECK ICC STEERING SWITCH Check resistance between ICC steering switch terminals. Terminal Switch operation Resistance [ohms] 13 16 When pressing MAIN switch Approx. 0 When pressing dynamic driver assistance switch Approx. 267 When pressing CANCEL switch Approx. 615 When pressing DISTANCE switch Approx. 1090 When pressing SET/COAST switch Approx. 1805 When pressing RESUME/ACCELERATE switch Approx. 2985 When all switches are not pressed Approx. 5415 Is the inspection result normal? YES: INSPECTION END NO: Replace the ICC steering switch.
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A12 (12) | LASER BEAM OFFCNTR | Laser beam of ICC sensor is off the aiming point | Laser beam is off the aiming point |
- CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS Perform "All DTC Reading" with CONSULT. Check if the "C1A12" is detected as the current malfunction in "Self Diagnostic Result" of "LASER". Is "C1A12" detected? YES: Refer to " «ICC SENSOR: DTC LOGIC»(ref-573604-S38041267872013082200000) ". NO: GO TO 2.
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Check if the "C1A12" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A12" detected? YES: Replace ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: INSPECTION END
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A13 (13) | STOP LAMP RLY FIX | Stop lamp inactive state continues for 0.3 seconds or more despite the outputting of an ICC sensor ICC brake hold relay drive signal The stop lamp remains ON for 60 seconds or more under the following conditions: Driving at 40 km/h or more No stop lamp drive signal output from ICC sensor No brake operation | Stop lamp switch circuit ICC brake switch circuit ICC brake hold relay circuit Stop lamp switch ICC brake switch ICC brake hold relay Incorrect stop lamp switch installation Incorrect ICC brake switch installation ECM ABS actuator and electric unit (control unit) |
Note. If DTC "C1A13" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE (1) Start the engine. Perform the active test item "STOP LAMP" with CONSULT. Perform "All DTC Reading". Check if the "C1A13" is detected as the current malfunction in the "Self Diagnostic Result" of "ICC/ADAS". Is "C1A13" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S24959391662013082200000) ". NO: GO TO 2.
- PERFORM DTC CONFIRMATION PROCEDURE (2) Drive at the vehicle speed of 40 km/h (25 MPH) or more for approximately 20 seconds or more without the brake pedal depressed. CAUTION: Always drive safely. NOTE: If it is outside the above condition, repeat step 1. Perform "All DTC Reading". Check if the "C1A13" is detected as the current malfunction in the "Self Diagnostic Result" of "ICC/ADAS". Is "C1A13" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S24959391662013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A13" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK STOP LAMP SWITCH Check that "STOP LAMP SW" operate normally in "DATA MONITOR" of "ICC/ADAS". Is the inspection result normal? YES: GO TO 10 . NO: GO TO 3.
- CHECK STOP LAMP SWITCH INSTALLATION Turn ignition switch OFF. Check stop lamp switch for correct installation. Refer to " «INSPECTION AND ADJUSTMENT»(ref-573611-S24808716902013082200000) ". Is the inspection result normal? YES: GO TO 4. NO: Adjust stop lamp switch installation. Refer to " «INSPECTION AND ADJUSTMENT»(ref-573611-S24808716902013082200000) ".
- CHECK STOP LAMP SWITCH Disconnect stop lamp switch connector. Check stop lamp switch. Refer to " «COMPONENT INSPECTION (STOP LAMP SWITCH)»(ref-573618-S07628174762013082200000) ". Is the inspection result normal? YES: GO TO 5. NO: Replace stop lamp switch.
- CHECK STOP LAMP FOR ILLUMINATION Connect stop lamp switch connector. Remove ICC brake hold relay. Check that the stop lamp is illuminated by depressing the brake pedal to turn the stop lamp ON. Is the inspection result normal? YES: GO TO 6. NO: Check the stop lamp circuit, and repair or replace the malfunctioning parts.
- CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ECM Turn the ignition switch OFF. Disconnect stop lamp switch, ECM, rear combination lamp, and high-mounted stop lamp connectors. Check for continuity between the stop lamp switch harness connector and the ECM harness connector. STOP LAMP SWITCH - VQ37VHR Stop lamp switch ECM Continuity Connector Terminal Connector Terminal E110 2 M107 122 Existed STOP LAMP SWITCH - VK56VD Stop lamp switch ECM Continuity Connector Terminal Connector Terminal E110 2 M160 158 Existed Check for continuity between stop lamp switch harness connector and ground. Stop lamp switch Ground Continuity Connector Terminal E110 2 Not existed Is the inspection result normal? YES: GO TO 7. NO: Repair the harnesses or connectors.
- CHECK ICC BRAKE HOLD RELAY CIRCUIT Connect ICC brake hold relay, ECM, rear combination lamp, and high-mounted stop lamp connectors. Check that the stop lamp does not illuminate when brake pedal is not depressed. Is the inspection result normal? YES: GO TO 9 . NO: GO TO 8.
- CHECK ICC BRAKE HOLD RELAY Remove ICC brake hold relay. Check ICC brake hold relay. Refer to " «COMPONENT INSPECTION»(ref-573618-S14183966002013082200000) ". Is the inspection result normal? YES: GO TO 9. NO: Replace ICC brake hold relay.
- PERFORM SELF-DIAGNOSIS OF ECM Connect all connectors again if the connectors are disconnected. Turn ignition switch ON. Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "ENGINE". Refer to " «DTC INDEX»(ref-573577-S32168264542013082200000) " (VQ37VHR) or " «DTC INDEX»(ref-573597-S12084516802013082200000) " (VK56VD for USA and Canada). Is any DTC detected? YES: Repair or replace the malfunctioning parts identified by the self-diagnosis result. NO: Replace ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
- CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT Turn ignition switch OFF. Remove ICC brake hold relay. Check the voltage between ICC brake hold relay harness connector and ground. Terminal Voltage (Approx.) (+) (-) ICC brake hold relay Ground Connector Terminal E92 2 Battery voltage Is the inspection result normal? YES: GO TO 11. NO: Repair or replace ICC brake hold relay power supply circuit.
- CHECK HARNESS BETWEEN AND ICC BRAKE HOLD RELAY AND ADAS CONTROL UNIT Disconnect ADAS control unit connectors. Check for continuity between ICC brake hold relay harness connector and ADAS control unit harness connector. ICC brake hold relay ADAS control unit Continuity Connector Terminal Connector Terminal E92 1 B50 5 Existed Check for continuity between ADAS control unit harness connector and ground. ICC brake hold relay Ground Continuity Connector Terminal E92 1 Not existed Is the inspection result normal? YES: GO TO 12. NO: Repair the harnesses or connectors.
- CHECK ADAS CONTROL UNIT STANDARD VOLTAGE Connect all connectors again if the connectors are disconnected. Turn ignition switch ON. Perform "STOP LAMP" on "Active Test" of "ICC/ADAS", and then check the voltage between ADAS control unit harness connector and ground. Terminal Condition Voltage (Approx.) (+) (-) ADAS control unit Ground Active Test item "STOP LAMP" Connector Terminal B50 5 Off Battery voltage On 0 V Is the inspection result normal? YES: GO TO 13. NO: Replace ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
- CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT Turn ignition switch OFF. Check the voltage between ICC brake hold relay harness connector and ground. Terminal Voltage (Approx.) (+) (-) ICC brake hold relay Ground Connector Terminal E92 5 Battery voltage Is the inspection result normal? YES: GO TO 14. NO: Repair or replace ICC brake hold relay power supply circuit.
- CHECK HARNESS BETWEEN ICC BRAKE HOLD RELAY AND ECM Disconnect ECM, rear combination lamp, and high-mounted stop lamp connectors and remove ICC brake hold relay. Check for continuity between ICC brake hold relay harness connector and ECM harness connector. ICC BRAKE HOLD RELAY - VQ37VHR ICC brake hold relay ECM Continuity Connector Terminal Connector Terminal E92 3 M107 122 Existed ICC BRAKE HOLD RELAY - VK56VD ICC brake hold relay ECM Continuity Connector Terminal Connector Terminal E92 3 M160 158 Existed Check for continuity between ICC brake hold relay harness connector and ground. ICC brake hold relay Ground Continuity Connector Terminal E92 3 Not existed Is the inspection result normal? YES: GO TO 15. NO: Repair the harnesses or connectors.
- CHECK ICC BRAKE HOLD RELAY Remove ICC brake hold relay. Check ICC brake hold relay. Refer to " «COMPONENT INSPECTION»(ref-573618-S14183966002013082200000) ". Is the inspection result normal? YES: GO TO 16. NO: Replace ICC brake hold relay.
- CHECK STOP LAMP SWITCH Check that "STOP LAMP SW" operate normally in "DATA MONITOR" of "ABS". Is the inspection result normal? YES: GO TO 21 . NO: GO TO 17.
- CHECK STOP LAMP SWITCH INSTALLATION Turn ignition switch OFF. Check stop lamp switch for correct installation. Refer to " «INSPECTION AND ADJUSTMENT»(ref-573611-S24808716902013082200000) ". Is the inspection result normal? YES: GO TO 18. NO: Adjust stop lamp switch installation. Refer to " «INSPECTION AND ADJUSTMENT»(ref-573611-S24808716902013082200000) ".
- CHECK STOP LAMP SWITCH Disconnect stop lamp switch connector. Check stop lamp switch. Refer to " «COMPONENT INSPECTION (STOP LAMP SWITCH)»(ref-573618-S07628174762013082200000) ". Is the inspection result normal? YES: GO TO 19. NO: Replace stop lamp switch.
- CHECK STOP LAMP SWITCH POWER SUPPLY CIRCUIT Connect stop lamp switch connector. Check the voltage between stop lamp switch harness connector and ground. Terminal Voltage (Approx.) (+) (-) Stop lamp switch Ground Connector Terminal E110 3 Battery voltage Is the inspection result normal? YES: GO TO 20. NO: Repair or replace stop lamp switch power supply circuit.
- CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Turn the ignition switch OFF. Disconnect stop lamp switch, ABS actuator and electric unit (control unit) connectors. Check for continuity between the stop lamp switch harness connector and the ABS actuator and electric unit (control unit) harness connector. Stop lamp switch ABS actuator and electric unit (control unit) Continuity Connector Terminal Connector Terminal E110 4 E41 5 Existed Check for continuity between stop lamp switch harness connector and ground. Stop lamp switch Ground Continuity Connector Terminal E110 4 Not existed Is the inspection result normal? YES: GO TO 21. NO: Repair the harnesses or connectors.
- PERFORM SELF-DIAGNOSIS OF ECM Connect all connectors again if the connectors are disconnected. Turn ignition switch ON. Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "ENGINE". Refer to " «DTC INDEX»(ref-573577-S32168264542013082200000) " (VQ37VHR) or " «DTC INDEX»(ref-573597-S12084516802013082200000) " (VK56VD for USA and Canada). Is any DTC detected? YES: Repair or replace the malfunctioning parts identified by the self-diagnosis result. NO: GO TO 22.
- PERFORM SELF-DIAGNOSIS OF ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Connect all connectors again if the connectors are disconnected. Turn ignition switch ON. Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". Is any DTC detected? YES: Repair or replace the malfunctioning parts identified by the self-diagnosis result. NO: Replace ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
Scheme 43
- CHECK ICC BRAKE HOLD RELAY Apply battery voltage to ICC brake hold relay terminals 1 and 2, and then check for continuity under the following conditions. Terminal Condition Continuity 3 5 When the battery voltage is applied Existed When the battery voltage is not applied Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace ICC brake hold relay.
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A14 (14) | ECM CIRCUIT | If ECM is malfunctioning | Accelerator pedal position sensor ECM ADAS control unit |
Note. If DTC "C1A14" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Operate the ICC system and drive. CAUTION: Always drive safely. Stop the vehicle. Perform "All DTC Reading" with CONSULT. Check if the "C1A14" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A14" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S31940662052013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A14" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- PERFORM SELF-DIAGNOSIS OF ECM Check if any DTC is detected in "Self Diagnostic Result" of "ENGINE". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573577-S32168264542013082200000) " (VQ37VHR) or " «DTC INDEX»(ref-573597-S12084516802013082200000) " or (VK56VD for USA and Canada). NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A15 (15) | GEAR POSITION | A mismatch between an current gear position signal transmitted from TCM via CAN communication and a gear position calculated by the ADAS control unit continues for approximately 11 minutes or more | Input speed sensor Vehicle speed sensor A/T (output speed sensor) TCM |
Note. If DTC "C1A15" is detected along with DTC "U1000", "C1A03", or "C1A04", first diagnose the DTC "U1000", "C1A03", or "C1A04".
- Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) " for DTC "U1000".
- Refer to " «DTC LOGIC»(ref-573618-S24346124202013082200000) " for DTC "C1A03".
- Refer to " «DTC LOGIC»(ref-573618-S04353491582013082200000) " for DTC "C1A04".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Drive the vehicle at 10 km/h (6 MPH) or faster for approximately 15 minutes or more. CAUTION: Always drive safely. Stop the vehicle. Perform "All DTC Reading" with CONSULT. Check if "C1A15" is detected as the current malfunction in the "Self Diagnostic Result" of "ICC/ADAS". Is "C1A15" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S26508735972013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "C1A03", "C1A04", or "U1000" is detected other than "C1A15" in "Self Diagnostic Result" of "ICC/ADAS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S39553697082013082200000) ". NO: GO TO 2.
- CHECK VEHICLE SPEED SIGNAL Check that "VHCL SPEED SE" operates normally in "DATA MONITOR" of "ICC/ADAS". CAUTION: Be careful of the vehicle speed. Is the inspection result normal? YES: GO TO 3. NO: GO TO 7 .
- CHECK GEAR POSITION Check that "GEAR" operates normally in "DATA MONITOR" of "ICC/ADAS". CAUTION: Be careful of the vehicle speed. Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
- CHECK GEAR POSITION SIGNAL Check that "GEAR" operates normally in "DATA MONITOR" of "TRANSMISSION". Is the inspection result normal? YES: GO TO 5. NO: GO TO 6 .
- CHECK INPUT SPEED SENSOR SIGNAL Check that "INPUT SPEED" operates normally in "DATA MONITOR" of "TRANSMISSION". Is the inspection result normal? YES: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: GO TO 6.
- CHECK TCM SELF-DIAGNOSIS RESULTS Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "TRANSMISSION". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573584-S14505563512013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A16 (16) | RADAR STAIN | If any stain occurs to ICC sensor body window | Stain or foreign materials is deposited Cracks or scratches exist |
Note. DTC "C1A16" may be detected under the following conditions. (Explain to the customer about the difference between the contamination detection function and the indication when the malfunction is detected and tell them "This is not malfunction".)
- When contamination or foreign materials cover the ICC sensor body window
- When driving while it is snowing or when frost forms on the ICC sensor body window
- When ICC sensor body window is temporarily fogged
- CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS Perform "All DTC Reading" with CONSULT. Check if the "C1A16" is detected as the current malfunction in "Self Diagnostic Result" of "LASER". Is "C1A16" detected? YES: Refer to " «ICC SENSOR: DTC LOGIC»(ref-573604-S01676535192013082200000) ". NO: GO TO 2.
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Erase All self-diagnosis results with CONSULT. Perform "All DTC Reading" Check if the "C1A16" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A16" detected? YES: Replace ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: INSPECTION END
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A17 (17) | ICC SENSOR MALF | If ICC sensor is malfunctioning | ICC sensor |
Note. If DTC "C1A17" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Perform "All DTC Reading" with CONSULT. Check if "U1000" is detected other than "C1A17" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "LASER". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S19364115382013082200000) ". NO: Replace ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A18 (18) | LASER AIMING INCMP | Laser beam aiming of ICC sensor is not adjusted | No laser beam aiming adjustment is performed Laser beam aiming adjustment has been interrupted |
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A18" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A18" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S39964452162013082200000) ". NO: INSPECTION END
- ADJUST LASER BEAM AIMING Check if the "C1A18" is detected in "Self Diagnostic Result" of "LASER". Is "C1A18" detected? YES: Refer to " «ICC SENSOR: DTC LOGIC»(ref-573604-S39951164302013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A21 (21) | ICC SENSOR HIGH TEMP | ICC sensor judges high temperature abnormality | Temperature around the ICC sensor becomes high |
- PERFORM DTC CONFIRMATION PROCEDURE Turn the ignition switch OFF. Wait for 10 minutes or more to cool the ICC sensor. Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A21" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A21" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S12596832072013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "C1A21" is detected in "Self Diagnostic Result" of "LASER". Is "C1A21" detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S19364115382013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A24 (24) | NP RANGE | A mismatch between a shift position signal transmitted from TCM via CAN communication and an current gear position signal continues for 60 seconds or more | TCM Transmission range switch |
Note. If DTC "C1A24" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- CHECK DTC REPRODUCE (1) Start the engine. Turn the DCA system ON. Wait for approximately 5 minutes or more after shifting the selector lever to "P" position. Perform "All DTC Reading" with CONSULT. Check if the "C1A24" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A24" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S06353567422013082200000) ". NO: GO TO 2.
- CHECK DTC REPRODUCE (2) Wait for approximately 5 minutes or more after shifting the selector lever to "N" position. Perform "All DTC Reading". Check if the "C1A24" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A24" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S06353567422013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A24" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK NP POSITION SWITCH SIGNAL Check that "NP RANGE SW" operates normally in "DATA MONITOR" of "ICC/ADAS". Is the inspection result normal? YES: GO TO 3. NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
- CHECK TCM DATA MONITOR Check that "SLCT LVR POSI" operates normally in "DATA MONITOR" of "TRANSMISSION". Is the inspection result normal? YES: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: GO TO 4.
- PERFORM TCM SELF-DIAGNOSIS Perform "All DTC Reading". Check if any DTC is detected in "Self Diagnostic Result" of "TRANSMISSION". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573584-S14505563512013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible cause |
|---|---|---|---|
| C1A26 (26) | ECD MODE MALF | If an abnormal condition occurs with ECD system | ABS actuator and electric unit (control unit) |
Note. If DTC "C1A26" is detected along with DTC "U1000", "U0415" or "U0121" first diagnose the DTC "U1000", "U0415", or "U0121".
- DTC "U1000": Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ".
- DTC "U0415": Refer to " «DTC LOGIC»(ref-573618-S31000183502013082200000) ".
- DTC "U0121": Refer to " «DTC LOGIC»(ref-573618-S26574476592013082200000) ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Wait for approximately 1 minute after turning the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A26" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A26" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S14002257702013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000", "U0415", or "U0121" is detected other than "C1A26" in "Self Diagnostic Result" of "ICC/ADAS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S39553697082013082200000) ". NO: GO TO 2.
- PERFORM SELF-DIAGNOSIS OF ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible cause |
|---|---|---|---|
| C1A27 (27) | ECD PWR SUPLY CIR | ECD system power supply voltage is excessively low | ABS actuator and electric unit (control unit) power supply circuit ABS actuator and electric unit (control unit) |
Note. If DTC "C1A27" is detected along with DTC "U1000", "U0415", or "U0121" first diagnose the DTC "U1000", "U0415", or "U0121".
- DTC "U1000": Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ".
- DTC "U0415": Refer to " «DTC LOGIC»(ref-573618-S31000183502013082200000) ".
- DTC "U0121": Refer to " «DTC LOGIC»(ref-573618-S26574476592013082200000) ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Wait for approximately 1 minute after turning the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A27" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A27" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S27571101042013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000", "U0415" or "U0121" is detected other than "C1A27" in "Self Diagnostic Result" of "ICC/ADAS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S39553697082013082200000) ". NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT OF ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Check power supply circuit of ABS actuator and electric unit (control unit). Refer to " «DIAGNOSIS PROCEDURE»(ref-573602-S37224577822013082200000) ". Is the inspection result normal? YES: Perform self-diagnosis of ABS actuator and electric unit (control unit). Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Repair the harnesses or connectors.
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible cause |
|---|---|---|---|
| C1A2A (80) | ICC SEN PWR SUP CIR | ICC sensor power supply voltage is malfunction | Harness, connector, fuse ICC sensor |
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A2A" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A2A" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S29497789052013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A2A" in "Self Diagnostic Result" of "ICC/ADAS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ICC SENSOR SELF-DIAGNOSIS Check if any DTC is detected in "Self Diagnostic Result" of "LASER". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S19364115382013082200000) ". NO: Replace ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A33 (33) | CAN TRANSMISSION ERR | If an error occurs in the CAN communication signal that ADAS control unit transmits to ECM | ADAS control unit |
Note. If DTC "C1A33" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A33" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A33" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S02488626672013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A33" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A34 (34) | COMMAND ERROR | If an error occurs in the command signal that ADAS control unit transmits to ECM via CAN communication | ADAS control unit |
Note. If DTC "C1A34" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Operate the ICC system and drive. CAUTION: Always drive safely. Stop the vehicle. Perform "All DTC Reading" with CONSULT. Check if the "C1A34" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "C1A34" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S01930504772013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A34" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A35 (35) | APA CIR | If the accelerator pedal actuator is malfunctioning | Accelerator pedal actuator |
Note. If DTC "C1A35" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A35" is detected as the current malfunction in self-diagnosis results of "ICC/ADAS". Is "C1A35" detected as the current malfunction? YES: GO TO 2. NO: INSPECTION END
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A35" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 3.
- CHECK ACCELERATOR PEDAL ACTUATOR SELF-DIAGNOSIS RESULTS Check if the DTC is detected in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S00764776022013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A36 (36) | APA CAN COMM CIR | If an error occurs in the signal that the accelerator pedal actuator transmits via ITS communication | ADAS control unit Accelerator pedal actuator ITS communication system |
Note. If DTC "C1A36" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A36" is detected as the current malfunction in self-diagnosis results of "ICC/ADAS". Is "C1A36" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S35964308192013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A36" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ACCELERATOR PEDAL ACTUATOR SELF-DIAGNOSIS RESULTS Check if the DTC is detected in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S00764776022013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A37 (133) | APA CAN CIR2 | If ADAS control unit detects an error signal that is received from accelerator pedal actuator via ITS communication | Accelerator pedal actuator malfunction |
Note. If DTC "C1A37" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A37" is detected as the current malfunction in self-diagnosis results of "ICC/ADAS". Is "C1A37" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S15999518152013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A37" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- REPLACE ACCELERATOR PEDAL ASSEMBLY Turn the ignition switch OFF. Replace the accelerator pedal assembly. Turn the ignition switch ON. Erases All self-diagnosis results. Perform "All DTC Reading" again. Check if the DTC "C1A37" is detected in self-diagnosis results of "ICC/ADAS". Is "C1A37" detected? YES: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: INSPECTION END
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A38 (132) | APA CAN CIR1 | If ADAS control unit detects an error signal that is received from accelerator pedal actuator via ITS communication | Accelerator pedal actuator malfunction |
Note. If DTC "C1A38" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A38" is detected as the current malfunction in self-diagnosis results of "ICC/ADAS". Is "C1A38" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S04967895882013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK CONTROL UNIT SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A38" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- REPLACE ACCELERATOR PEDAL ASSEMBLY Turn the ignition switch OFF. Replace the accelerator pedal assembly. Erases All self-diagnosis results. Perform "All DTC Reading" again. Check if the "C1A38" is detected in self-diagnosis results of "ICC/ADAS". Is "C1A38" detected? YES: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: INSPECTION END
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1A39 (39) | STRG SEN CIR | If the steering angle sensor is malfunction | Steering angle sensor |
Note. If DTC "C1A39" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1A39" is detected as the current malfunction in self-diagnosis results of "ICC/ADAS". Is "C1A39" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S21221888562013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1A39" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F01 (91) | APA MOTOR MALF | If the accelerator pedal actuator motor error is detected | Accelerator pedal actuator integrated motor malfunction |
- PERFORM DTC CONFIRMATION PROCEDURE Turn the ignition switch OFF. Turn the ignition switch ON. Slowly depress the accelerator pedal completely, and then release it. Repeat step 3 several times. Perform "All DTC Reading" with CONSULT. Check if the DTC "C1F01" is detected as the current malfunction on the self-diagnosis results of "ICC/ADAS". Is "C1F01" detected as the current malfunction? YES: Refer to " «ADAS CONTROL UNIT: DIAGNOSIS PROCEDURE»(ref-573618-S26726876042013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
ADAS CONTROL UNIT: Diagnosis Procedure
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1F01" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ACCELERATOR PEDAL ACTUATOR SELF-DIAGNOSIS RESULTS Check if "C1F01" is detected in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "C1F01" detected? YES: Refer to " «DTC INDEX»(ref-573618-S00764776022013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F01 | APA MOTOR MALF | If the accelerator pedal actuator motor error is detected | Accelerator pedal actuator integrated motor malfunction |
- PERFORM DTC CONFIRMATION PROCEDURE Turn the ignition switch OFF. Turn the ignition switch ON. Slowly depress the accelerator pedal completely, and then release it. Repeat step 3 several times. Perform "All DTC Reading" with CONSULT. Check if the DTC "C1F01" is detected as the current malfunction on the self-diagnosis results of "ICC/ADAS" or "ACCELE PEDAL ACT". Is "C1F01" detected as the current malfunction? YES: Refer to " «ACCELERATOR PEDAL ACTUATOR: DIAGNOSIS PROCEDURE»(ref-573618-S04194521952013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
ACCELERATOR PEDAL ACTUATOR: Diagnosis Procedure
- REPLACE ACCELERATOR PEDAL ASSEMBLY Perform DTC confirmation procedure. If "C1F01" is detected, replace the accelerator pedal assembly. Refer to " «EXPLODED VIEW»(ref-573618-S18037321042013082200000) ". : INSPECTION END
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F02 (92) | APA C/U MALF | If the accelerator pedal actuator integrated control unit error is detected | Accelerator pedal actuator integrated control unit malfunction |
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1F02" is detected as the current malfunction on the self-diagnosis results of "ICC/ADAS". Is "C1F02" detected as the current malfunction? YES: Refer to " «ADAS CONTROL UNIT: DIAGNOSIS PROCEDURE»(ref-573618-S00196410522013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1F02" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ACCELERATOR PEDAL ACTUATOR SELF-DIAGNOSIS RESULTS Check if "C1F02" is detected in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "C1F02" detected? YES: Refer to " «DTC INDEX»(ref-573618-S00764776022013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F02 | APA C/U MALF | If the accelerator pedal actuator integrated control unit error is detected | Accelerator pedal actuator integrated control unit malfunction |
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1F02" is detected as the current malfunction on the self-diagnosis results of "ACCELE PEDAL ACT" or "ICC/ADAS". Is "C1F02" detected as the current malfunction? YES: Replace the accelerator pedal assembly. Refer to " «EXPLODED VIEW»(ref-573618-S18037321042013082200000) ". NO: INSPECTION END
| DTC | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F03 | APA HI TEMP | The temperature of the motor integrated in the accelerator pedal actuator remains 100°C (212°F) or more for 0.4 seconds or more. The temperature of the motor drive circuit integrated in the accelerator pedal actuator remains 120°C (248°F) or more for 0.4 seconds or more. | Accelerator pedal actuator integrated motor malfunction |
Note. When the accelerator pedal actuator operates excessively, "C1F03" may be detected temporarily.
- PERFORM DTC CONFIRMATION PROCEDURE Turn the ignition switch OFF. Wait for 10 minutes or more and cool the accelerator pedal actuator integrated motor. Drive the vehicle with DCA system ON and operate the system. CAUTION: Always drive safely. Stop the vehicle. Perform "All DTC Reading" with CONSULT. Check if the DTC "C1F03" is detected as the current malfunction in self-diagnosis results of "ACCELE PEDAL ACT". Is "C1F03" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S21472644112013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- REPLACE ACCELERATOR PEDAL ASSEMBLY Perform DTC confirmation procedure. If "C1F03" is detected, replace the accelerator pedal assembly. Refer to " «EXPLODED VIEW»(ref-573618-S18037321042013082200000) ". : INSPECTION END
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F05 (95) | APA PWR SUPLY CIR | The battery voltage sent to accelerator pedal actuator remains less than 7.9 V or more than 19.3 V for 5 seconds | Harness, connector, or fuse Accelerator pedal actuator |
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1F05" is detected as the current malfunction on the self-diagnosis results of "ICC/ADAS". Is "C1F05" detected as the current malfunction? YES: Refer to " «ADAS CONTROL UNIT: DIAGNOSIS PROCEDURE»(ref-573618-S08357337192013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1F05" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ACCELERATOR PEDAL ACTUATOR SELF-DIAGNOSIS RESULTS Check if "C1F05" is detected in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "C1F05" detected? YES: Refer to " «ACCELERATOR PEDAL ACTUATOR: DTC LOGIC»(ref-573618-S00756078012013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F05 | APA PWR SUPLY CIR | The battery voltage sent to accelerator pedal actuator remains less than 7.9 V or more than 19.3 V for 5 seconds | Harness, connector, or fuse Accelerator pedal actuator |
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1F05" is detected as the current malfunction on the self-diagnosis results of "ACCELE PEDAL ACT". Is "C1F05" detected as the current malfunction? YES: Refer to " «ACCELERATOR PEDAL ACTUATOR: DIAGNOSIS PROCEDURE»(ref-573618-S18217113122013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK POWER SUPPLY CIRCUIT Check the accelerator pedal actuator power supply circuit. Refer to " «ACCELERATOR PEDAL ACTUATOR: DIAGNOSIS PROCEDURE»(ref-573618-S26021993012013082200000) ". Is the inspection result normal? YES: Replace the accelerator pedal assembly. Refer to " «EXPLODED VIEW»(ref-573618-S18037321042013082200000) ". NO: Repair or replace the malfunctioning parts.
| DTC | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F06 | CAN CIR 2 | If accelerator pedal actuator detects an error signal that is received from ADAS control unit via ITS communication | ADAS control unit |
Note. If DTC "C1F06" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ACCELERATOR PEDAL ACTUATOR: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1F06" is detected as the current malfunction in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "C1F06" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S10216223062013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1F06" in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ACCELERATOR PEDAL ACTUATOR: DTC LOGIC»(ref-573618-S00756078012013082200000) ". NO: GO TO 2.
- REPLACE ADAS CONTROL UNIT Turn the ignition switch OFF. Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". Erases All self-diagnosis results. Perform "All DTC Reading" again. Check if the "C1F06" is detected in self-diagnosis results of "ACCELE PEDAL ACT". Is "C1F06" detected? YES: Replace the accelerator pedal assembly. Refer to " «EXPLODED VIEW»(ref-573618-S18037321042013082200000) ". NO: INSPECTION END
| DTC | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| C1F07 | CAN CIR 1 | If accelerator pedal actuator detects an error signal that is received from ADAS control unit via ITS communication | ADAS control unit |
Note. If DTC "C1F07" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ACCELERATOR PEDAL ACTUATOR: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "C1F07" is detected as the current malfunction in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "C1F07" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S10216223062013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "C1F07" in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ACCELERATOR PEDAL ACTUATOR: DTC LOGIC»(ref-573618-S00756078012013082200000) ". NO: GO TO 2.
- REPLACE ADAS CONTROL UNIT Turn the ignition switch OFF. Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". Erases All self-diagnosis results. Perform "All DTC Reading" again. Check if the "C1F07" is detected in self-diagnosis results of "ACCELE PEDAL ACT". Is "C1F07" detected? YES: Replace the accelerator pedal assembly. Refer to " «EXPLODED VIEW»(ref-573618-S18037321042013082200000) ". NO: INSPECTION END
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U0121 (127) | VDC CAN CIR2 | If ADAS control unit detects an error signal that is received from ABS actuator and electric unit (control unit) via CAN communication | ABS actuator and electric unit (control unit) |
Note. If DTC "U0121" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U0121" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U0121" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S39828581742013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U0121" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U0126 (130) | STRG SEN CAN CIR1 | If ADAS control unit detects an error signal that is received from steering angle sensor via CAN communication | Steering angle sensor |
Note. If DTC "U0126" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U0126" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U0126" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S18864155712013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U0126" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U0235 (144) | ICC SENSOR CAN CIR1 | If ADAS control unit detects an error signal that is received from ICC sensor via ITS communication | ICC sensor |
Note. If DTC "U0235" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U0235" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U0235" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S09941567432013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U0235" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «DTC LOGIC»(ref-573618-S09280082352013082200000) ". NO: GO TO 2.
- CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "LASER". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S19364115382013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U0401 (120) | ECM CAN CIR1 | If ADAS control unit detects an error signal that is received from ECM via CAN communication | ECM |
Note. If DTC "U0401" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U0401" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U0401" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S25818338832013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U0401" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ECM SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ENGINE". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573577-S32168264542013082200000) " (VQ37VHR) or " «DTC INDEX»(ref-573597-S12084516802013082200000) " or (VK56VD for USA and Canada). NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U0402 (122) | TCM CAN CIRC1 | If ADAS control unit detects an error signal that is received from TCM via CAN communication | TCM |
Note. If DTC "U0402" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U0402" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U0402" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S16965907792013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U0402" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK TCM SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "TRANSMISSION". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573584-S14505563512013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U0415 (126) | VDC CAN CIR1 | If ADAS control unit detects an error signal that is received from ABS actuator and electric unit (control unit) via CAN communication | ABS actuator and electric unit (control unit) |
Note. If DTC "U0415" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U0415" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U0415" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S26712521332013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U0415" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U0428 (131) | STRG SEN CAN CIR2 | If ADAS control unit detects an error signal that is received from steering angle sensor via CAN communication | Steering angle sensor |
Note. If DTC "U0428" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U0428" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U0428" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S16326145042013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U0428" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1000 (100) | CAN COMM CIRCUIT | If ADAS control unit is not transmitting or receiving CAN communication signal or ITS communication signal for 2 seconds or more | CAN communication system ITS communication system |
Note. If "U1000" is detected, first diagnose the CAN communication system.
- PERFORM THE SELF-DIAGNOSIS Turn the ignition switch ON. Turn the DCA system ON, and then wait for 30 seconds or more. Perform "All DTC Reading" with CONSULT. Check if the "U1000" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected as the current malfunction? YES: Refer to " «TROUBLE DIAGNOSIS FLOW CHART»(ref-573573-S04258406552013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
| DTC | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1000 | CAN COMM CIRCUIT | If accelerator pedal actuator is not transmitting or receiving ITS communication signal for 2 seconds or more | ITS communication system |
- PERFORM THE SELF-DIAGNOSIS Turn the ignition switch ON. Turn the DCA system ON, and then wait for 2 seconds or more. Perform "All DTC Reading" with CONSULT. Check if the "U1000" is detected as the current malfunction in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "U1000" detected as the current malfunction? YES: Refer to " «TROUBLE DIAGNOSIS FLOW CHART»(ref-573573-S04258406552013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1010 (110) | CONTROL UNIT (CAN) | If ADAS control unit detects malfunction by CAN controller initial diagnosis | ADAS control unit |
- PERFORM DTC CONFIRMATION PROCEDURE Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U1010" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U1010" detected as the current malfunction? YES: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: INSPECTION END
| DTC | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1010 | CONTROL UNIT (CAN) | If accelerator pedal actuator detects malfunction by CAN controller initial diagnosis | Accelerator pedal actuator |
- PERFORM DTC CONFIRMATION PROCEDURE Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U1010" is detected as the current malfunction in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is "U1010" detected as the current malfunction? YES: Replace the accelerator pedal actuator. Refer to " «EXPLODED VIEW»(ref-573618-S18037321042013082200000) ". NO: INSPECTION END
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U150B (157) | ECM CAN CIRC 3 | ADAS control unit detects an error signal that is received from ECM via CAN communication | ECM |
Note. If DTC "U150B" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the MAIN switch of ICC system ON. Perform "All DTC Reading" with CONSULT. Check if the "U150B" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U150B" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S29583527322013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U150B" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ECM SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ENGINE". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573577-S32168264542013082200000) " (VQ37VHR) or " «DTC INDEX»(ref-573597-S12084516802013082200000) " or (VK56VD for USA and Canada). NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U150C (158) | VDC CAN CIRC 3 | ADAS control unit detects an error signal that is received from ABS actuator and electric unit (control unit) via CAN communication | ABS actuator and electric unit (control unit) |
Note. If DTC "U150C" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U150C" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U150C" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S06884103532013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U150C" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U150D (159) | TCM CAN CIRC 3 | ADAS control unit detects an error signal that is received from TCM via CAN communication | TCM |
Note. If DTC "U150D" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U150D" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U150D" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S06691469082013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U150D" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK TCM SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "TRANSMISSION". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573584-S14505563512013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U150E (160) | BCM CAN CIRC 3 | ADAS control unit detects an error signal that is received from BCM via CAN communication | BCM |
Note. If DTC "U150E" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U150E" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U150E" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S23518542232013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U150E" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK BCM SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "BCM". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573610-S36653255012013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1502 (147) | ICC SEN CAN COMM CIR | ADAS control unit detects an error signal that is received from ICC sensor via ITS communication | ICC sensor |
Note. If DTC "U1502" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U1502" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U1502" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S19561364162013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U1502" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "LASER". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S19364115382013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1513 (163) | METER CAN CIRC 3 | ADAS control unit detects an error signal that is received from combination meter via CAN communication | Combination meter |
Note. If DTC "U1513" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U1513" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U1513" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S37079582982013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U1513" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK COMBINATION METER SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "METER/M&A". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573605-S33376959532013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1514 (164) | STRG SEN CAN CIRC 3 | ADAS control unit detects an error signal that is received from steering angle sensor via CAN communication | Steering angle sensor |
Note. If DTC "U1514" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U1514" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U1514" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S15307087242013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U1514" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ABS". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573602-S37917943772013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1515 (165) | ICC SENSOR CAN CIRC 3 | ADAS control unit detects an error signal that is received from ICC sensor via ITS communication | ICC sensor |
Note. If DTC "U1515" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U1515" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U1515" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S05294243732013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U1515" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". NO: GO TO 2.
- CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "LASER". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S19364115382013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
| DTC (On board display) | Trouble diagnosis name | DTC detecting condition | Possible causes |
|---|---|---|---|
| U1517 (167) | APA CAN CIRC 3 | ADAS control unit detects an error signal that is received from accelerator pedal actuator via ITS communication | Accelerator pedal actuator |
Note. If DTC "U1517" is detected along with DTC "U1000", first diagnose the DTC "U1000". Refer to " ADAS CONTROL UNIT: DTC LOGIC ".
- PERFORM DTC CONFIRMATION PROCEDURE Start the engine. Turn the DCA system ON. Perform "All DTC Reading" with CONSULT. Check if the "U1517" is detected as the current malfunction in "Self Diagnostic Result" of "ICC/ADAS". Is "U1517" detected as the current malfunction? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S40423622012013082200000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-573569-S01363100422013082200000) ".
- CHECK SELF-DIAGNOSIS RESULTS Check if "U1000" is detected other than "U1517" in "Self Diagnostic Result" of "ICC/ADAS". Is "U1000" detected? YES: Perform the CAN communication system inspection. Repair or replace the malfunctioning parts. Refer to " «DTC LOGIC»(ref-573617-S05987788922013082200000) ". NO: GO TO 2.
- CHECK ACCELERATOR PEDAL ACTUATOR SELF-DIAGNOSIS RESULTS Check if any DTC is detected in "Self Diagnostic Result" of "ACCELE PEDAL ACT". Is any DTC detected? YES: Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S00764776022013082200000) ". NO: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ".
- CHECK FUSES Check if any of the following fuses are blown: Signal name Fuse No. Ignition power supply 46 Is the inspection result normal? YES: GO TO 2. NO: Replace the blown fuse after repairing the affected circuit if a fuse is blown.
- CHECK ADAS CONTROL UNIT POWER SUPPLY CIRCUIT Check voltage between ADAS control unit harness connector and ground. Terminal Condition Voltage (Approx.) (+) (-) ADAS control unit Ground Ignition switch Connector Terminal B50 16 OFF 0 V ON Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair the ADAS control unit power supply circuit.
- CHECK ADAS CONTROL UNIT GROUND CIRCUIT Turn the ignition switch OFF. Disconnect the ADAS control unit connector. Check for continuity between ADAS control unit harness connector and ground. ADAS control unit Ground Continuity Connector Terminal B50 6 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair the ADAS control unit ground circuit.
- CHECK FUSES Check if any of the following fuses are blown: Signal name Fuse No. Battery power supply 63 Ignition power supply 46 Is the inspection result normal? YES: GO TO 2. NO: Replace the blown fuse after repairing the affected circuit if a fuse is blown.
- CHECK ACCELERATOR PEDAL ACTUATOR POWER SUPPLY CIRCUIT Check voltage between accelerator pedal actuator harness connector and ground. Terminal Condition Voltage (Approx.) (+) (-) Accelerator pedal actuator Ground Ignition switch Connector Terminal M152 1 OFF Battery voltage 3 ON Is the inspection result normal? YES: GO TO 3. NO: Repair the accelerator pedal actuator power supply circuit.
- CHECK ACCELERATOR PEDAL ACTUATOR GROUND CIRCUIT Turn the ignition switch OFF. Disconnect the accelerator pedal actuator connector. Check for continuity between accelerator pedal actuator harness connector and ground. Accelerator pedal actuator Ground Continuity Connector Terminal M152 2 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair the accelerator pedal actuator ground circuit.
Symptom Table
| Symptoms | Refer to | |
|---|---|---|
| Operation | Switch does not turn ON | Refer to " DESCRIPTION ". |
| Switch does not turn OFF | ||
| DCA system setting cannot be turned ON on the navigation screen | Refer to " DESCRIPTION ". | |
| DCA system setting cannot be turned OFF on the navigation screen | ||
| DCA system not activated (switch is ON) | Refer to " DESCRIPTION ". | |
| Display/Chime | Information display is not illuminated (vehicle ahead indicator) | Refer to " ON BOARD DIAGNOSIS FUNCTION ". |
| Chime does not sound | Refer to " DESCRIPTION ". | |
| Control | No force generated for putting back the accelerator pedal | Refer to " DESCRIPTION ". |
| Detection of lead vehicle | Frequently cannot detect the vehicle ahead | Refer to " DESCRIPTION ". |
| Detection zone is short | ||
| System misidentifies a vehicle even though there is no vehicle ahead | Adjust laser beam aiming: Refer to " DESCRIPTION ". Perform action test. Refer to " DESCRIPTION ". | |
| System misidentifies a vehicle in the next lane | ||
| System does not detect the vehicle ahead at all | Refer to " DESCRIPTION ". | |
- CHECK DCA SYSTEM SETTING Start the engine. After starting the engine wait for 5 seconds or more. Check that DCA system setting on the navigation screen is ON. Is DCA system setting ON? YES: GO TO 2. NO: Enable the DCA system setting.
- DYNAMIC DRIVER ASSISTANCE SWITCH INSPECTION Start the engine. Check that "DYNA ASIST SW" operates normally in "DATA MONITOR" of "ICC/ADAS" with CONSULT. Is the inspection result normal? YES: GO TO 3. NO: GO TO 5 .
- CHECK DCA SYSTEM SWITCH INDICATOR CIRCUIT Start the engine. Select the active test item "DCA INDICATOR" of "ICC/ADAS" with CONSULT. Check if the DCA system switch indicator illuminates when the test item is operated. Is the inspection result normal? YES: GO TO 6 . NO: GO TO 4.
- PERFORM THE SELF-DIAGNOSIS OF COMBINATION METER Perform "All DTC Reading" with CONSULT. Check if the DTC is detected in self-diagnosis results of "METER/M&A". Refer to " «DTC INDEX»(ref-573605-S33376959532013082200000) ". Is any DTC detected? YES: GO TO 7 . NO: GO TO 6 .
- CHECK STEERING SWITCH CIRCUIT Check the steering switch circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-573618-S27202542142013082200000) ". Is the inspection result normal? YES: GO TO 6. NO: GO TO 7 .
- PERFORM THE SELF-DIAGNOSIS Perform "All DTC Reading" with CONSULT. Check if the DTC is detected in self-diagnosis results of "ICC/ADAS". Refer to " «DTC INDEX»(ref-573618-S39553697082013082200000) ". Is any DTC detected? YES: GO TO 7. NO: GO TO 8 .
- REPAIR OR REPLACE MALFUNCTIONING PARTS. Repair or replace malfunctioning parts. : GO TO 8.
- CHECK DCA SYSTEM Erase "self-diagnosis result", and then perform "All DTC Reading" again after performing the action test. (Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) " for action test.) Check that the DCA system is normal. : INSPECTION END
- CHECK DCA SYSTEM SETTING Start the engine. Check that the DCA system settings is selectable on the navigation screen. Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
- PERFORM THE SELF-DIAGNOSIS Perform "All DTC Reading" with CONSULT. Check if the DTC is detected in self-diagnosis results of "ICC/ADAS", "MULTI AV" and "METER/M&A". Refer to the following. ICC/ADAS: " «DTC INDEX»(ref-573618-S39553697082013082200000) " MULTI AV: " «DTC INDEX»(ref-573616-S07963851042013082200000) " METER/M&A: " «DTC INDEX»(ref-573605-S33376959532013082200000) " Is any DTC detected? YES: Repair or replace malfunctioning parts. NO: INSPECTION END
- CHECK DATA MONITOR OF ADAS CONTROL UNIT Check that "DCA SELECT" operates normally in "DATA MONITOR" of "ICC/ADAS" with CONSULT. Is the inspection result normal? YES: Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-573616-S09614470392013082200000) ". NO: GO TO 4.
- CHECK MULTIFUNCTION SWITCH Operate the multifunction switch to check that the audio, navigation system, and air conditioner operate properly. Is the inspection result normal? YES: Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". NO: Repair or replace malfunctioning parts.
- CHECK CAUSE OF AUTOMATIC CANCELLATION Check if there is any cancellation cause in the "CAUSE OF AUTO-CANCEL" on "WORK SUPPORT" of "ICC/ADAS" with CONSULT. Is it displayed? Not displayed: GO TO 2. "OPE SW VOLT CIRC": Refer to " «DTC LOGIC»(ref-573618-S12655636832013082200000) ". "VHCL SPD UNMATCH": Refer to " «DTC LOGIC»(ref-573618-S24346124202013082200000) ". "IGN LOW VOLT": Refer to " «DTC LOGIC»(ref-573618-S22991796752013082200000) ". "CAN COMM ERROR": Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". "ICC SENSOR CAN COMM ERR": Refer to " «DTC LOGIC»(ref-573618-S09280082352013082200000) ". "ABS/TCS/VDC CIRC": Refer to " «DTC LOGIC»(ref-573618-S04353491582013082200000) ". "APA HI TEMP": Refer to " «DTC LOGIC»(ref-573618-S02266668532013082200000) ". "ECD CIRCUIT": Refer to " «DTC LOGIC»(ref-573618-S13575726732013082200000) ".
- PERFORM ALL OF THE SELF-DIAGNOSIS Perform "All DTC Reading". Check if any DTC is detected in self-diagnosis results of "ICC/ADAS". Refer to " «DTC INDEX»(ref-573618-S39553697082013082200000) ". Is any DTC detected? YES: GO TO 3. NO: GO TO 4 .
- REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace malfunctioning parts identified by the self-diagnosis result. : GO TO 6 .
- CHECK EACH SWITCH AND VEHICLE SPEED SIGNAL Start the engine. Check that the following items operate normally in "DATA MONITOR" of "ICC/ADAS". "VHCL SPEED SE" "BRAKE SW" "DYNA ASIST SW" Is there a malfunctioning item? All items are normal: GO TO 5. "VHCL SPEED SE": Refer to " «DTC LOGIC»(ref-573618-S24346124202013082200000) ". "BRAKE SW": Refer to " «DTC LOGIC»(ref-573618-S22128086292013082200000) ". "DYNA ASIST SW": Refer to " «DTC LOGIC»(ref-573618-S12655636832013082200000) ".
- REPLACE ADAS CONTROL UNIT Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". : GO TO 6.
- CHECK DCA SYSTEM Erase "self-diagnosis result", and then perform "All DTC Reading" again after performing the action test. (Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) " for action test.) Check that the DCA system is normal. : INSPECTION END
- PERFORM ACTIVE TEST Check if the warning chime sounds on the active test item "ICC BUZZER" of "ICC/ADAS" with CONSULT. Does the warning chime sound? YES: GO TO 2. NO: GO TO 3 .
- CHECK THE MALFUNCTION SYMPTOM DURING WARNING CHIME OPERATION Understand the vehicle ahead detection condition when the malfunction occurred. If the warning chime should have sounded, replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". : GO TO 9 .
- PERFORM THE SELF-DIAGNOSIS Perform "All DTC Reading" with CONSULT. Check if the "U1000" is detected in self-diagnosis results of "ICC/ADAS". Is "U1000" detected? YES: GO TO 4. NO: GO TO 5 .
- CAN COMMUNICATIONS INSPECTION Check the CAN communication and repair or replace malfunctioning parts. Refer to " «ADAS CONTROL UNIT: DTC LOGIC»(ref-573618-S08665209032013082200000) ". : GO TO 9 .
- PERFORM THE SELF-DIAGNOSIS OF COMBINATION METER Perform "All DTC Reading" with CONSULT. Check if any DTC is detected in self-diagnosis results of "METER/M&A". Is any DTC detected? YES: Repair or replace malfunctioning parts. Refer to " «DTC INDEX»(ref-573605-S33376959532013082200000) ". NO: GO TO 6.
- CHECK ICC WARNING CHIME CIRCUIT Check meter buzzer. Refer to " «COMPONENT FUNCTION CHECK»(ref-573643-S31490331642013082200000) ". Is the inspection result normal? YES: GO TO 8 . NO: GO TO 7.
- REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace malfunctioning parts. : GO TO 9 .
- REPLACE ADAS CONTROL UNIT Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". : GO TO 9.
- CHECK DCA SYSTEM Erase "self-diagnosis result", and then perform "All DTC Reading" again after performing the action test. (Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) " for action test.) Check if the DCA system is normal. : INSPECTION END
- PERFORM THE SELF-DIAGNOSIS Perform "All DTC Reading" with CONSULT. Check if any DTC is detected in self-diagnosis results of "ICC/ADAS" or "ACCELE PEDAL ACT". Is any DTC detected? YES: GO TO 2. NO: GO TO 3 .
- REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace malfunctioning parts. Refer to " «DTC INDEX»(ref-573618-S39553697082013082200000) " (ICC/ADAS) or " «DTC INDEX»(ref-573618-S00764776022013082200000) " (ACCELE PEDAL ACT). : GO TO 5 .
- PERFORM ACTIVE TEST Check if the accelerator pedal actuator operates by the active test items "ACCELERATOR PEDAL ACTUATOR TEST1" and "ACCELERATOR PEDAL ACTUATOR TEST2" of "ACCELE PEDAL ACT" with CONSULT. Does it operate? YES: GO TO 4. NO: Replace the accelerator pedal assembly.
- CHECK VEHICLE AHEAD DETECTION PERFORMANCE Understand the vehicle ahead detection condition when the malfunction occurred. If the detecting function is malfunctioning, check according to " «DESCRIPTION»(ref-573618-S23184933632013082200000) ". : INSPECTION END
- CHECK DCA SYSTEM Erase "self-diagnosis result", and then perform "All DTC Reading" again after performing the action test. (Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) " for action test.) Check if the DCA system is normal. : INSPECTION END
- VISUAL CHECK (1) Check ICC sensor body window for contamination and foreign materials. Is Body Sensor Window Blocked? YES: GO TO 2. NO: GO TO 3 .
- WIPE OUT DIRT AND FOREIGN OBJECTS Wipe out the contamination and/or foreign materials from the ICC sensor body window. : GO TO 7 .
- VISUAL CHECK (2) Check ICC sensor body window for cracks and/or scratches. Are there cracks? YES: GO TO 5 . NO: GO TO 4.
- LASER BEAM AIMING ADJUSTMENT Adjust the laser beam aiming. Refer to " «DESCRIPTION»(ref-573604-S40117573552013082200000) ". Perform action test. Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) ". Check that the vehicle ahead detection performance improves. Does it improve? YES: INSPECTION END NO: GO TO 5.
- REPLACE ICC SENSOR Replace the ICC sensor. Refer to " «REMOVAL AND INSTALLATION»(ref-573618-S35881135952013082200000) ". Adjust the laser beam aiming. Refer to " «DESCRIPTION»(ref-573604-S40117573552013082200000) ". Perform action test. Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) ". Check that the vehicle ahead detection performance improves. Does it improve? YES: INSPECTION END NO: GO TO 6.
- REPLACE ADAS CONTROL UNIT Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". : GO TO 7.
- CHECK DCA SYSTEM Erase "self-diagnosis result", and then perform "All DTC Reading" again after performing the action test. (Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) " for action test.) Check that the DCA system is normal. : INSPECTION END
- CHECK INFORMATION DISPLAY Start the self-diagnosis mode of combination meter. Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-573605-S17622562892013082200000) ". Check that the segment of information display is displayed normally. Is the inspection result normal? YES: GO TO 2. NO: Replace the combination meter.
- VISUAL CHECK (1) Check ICC sensor body window for contamination and/or foreign materials. Is sensor body window blocked? YES: GO TO 3. NO: GO TO 4 .
- WIPE OUT DIRT AND FOREIGN MATERIALS Wipe out the contamination and/or foreign materials from the ICC sensor body window. : GO TO 8 .
- VISUAL CHECK (2) Check ICC sensor body window for cracks and/or scratches. Are there cracks? YES: GO TO 6 . NO: GO TO 5.
- LASER BEAM AIMING ADJUSTMENT Adjust the laser beam aiming. Refer to " «DESCRIPTION»(ref-573604-S40117573552013082200000) ". Perform action test. Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) ". Check that the vehicle ahead detection performance improves. Does it improve? YES: INSPECTION END NO: GO TO 6.
- REPLACE ICC SENSOR Replace the ICC sensor. Refer to " «REMOVAL AND INSTALLATION»(ref-573618-S35881135952013082200000) ". Adjust the laser beam aiming. Refer to " «DESCRIPTION»(ref-573604-S40117573552013082200000) ". Perform action test. Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) ". Check that the vehicle ahead detection performance improves. Does it improve? YES: INSPECTION END NO: GO TO 7.
- REPLACE ADAS CONTROL UNIT Replace the ADAS control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-573617-S32428842472013082200000) ". : GO TO 8.
- CHECK DCA SYSTEM Erase "self-diagnosis result", and then perform "All DTC Reading" again after performing the action test. (Refer to " «DESCRIPTION»(ref-573618-S15598773542013082200000) " for action test.) Check that the DCA system is normal. : INSPECTION END
