ADAS CONTROL UNIT INPUT/OUTPUT SIGNAL ITEM
| Transmit unit | Signal name | Description | ||
|---|---|---|---|---|
| ECM | CAN communication | Closed throttle position signal | Receives idle position state (ON/OFF) | |
| Accelerator pedal position signal | Receives accelerator pedal position (angle) | |||
| ICC prohibition signal | Receives an operable/inoperable state of the ICC system | |||
| ICC steering switch signal | Main switch signal | Receives the operational state of the ICC steering switch | ||
| SET/COAST switch signal | ||||
| CANCEL switch signal | ||||
| RESUME/ACCELERATE switch signal | ||||
| DISTANCE switch signal | ||||
| Dynamic driver assistance switch signal | ||||
| Engine speed signal | Receives engine speed | |||
| ECO pedal reaction force control signal | Receives a reaction force limiting value of the accelerator pedal during ECO mode (ECO pedal ON) selected by operating the drive mode select switch | |||
| Stop lamp switch signal | Receives an operational state of the brake pedal | |||
| ICC brake switch signal | Receives an operational state of the brake pedal | |||
| Snow mode switch signal | Receives an operational state of the snow mode | |||
| TCM | CAN communication | Input speed signal | Receives the number of revolutions of input shaft | |
| Current gear position signal | Receives a current gear position | |||
| Shift position signal | Receives a select lever position | |||
| Output shaft revolution signal | Receives the number of revolutions of output shaft | |||
| Drive mode select signal | Receives a drive mode state of ECM and TCM | |||
| ABS actuator and electric unit (control unit) | CAN communication | ABS malfunction signal | Receives a malfunction state of ABS | |
| ABS operation signal | Receives an operational state of ABS | |||
| ABS warning lamp signal | Receives an ON/OFF state of ABS warning lamp | |||
| TCS malfunction signal | Receives a malfunction state of TCS | |||
| TCS operation signal | Receives an operational state of TCS | |||
| VDC OFF switch signal | Receives an ON/OFF state of VDC | |||
| VDC malfunction signal | Receives a malfunction state of VDC | |||
| VDC operation signal | Receives an operational state of VDC | |||
| Vehicle speed signal (ABS) | Receives wheel speeds of four wheels | |||
| Stop lamp switch signal | Receives an operational state of the brake pedal | |||
| Yaw rate signal | Receives yaw rate acting on the vehicle | |||
| Side G sensor signal | Receives lateral G acting on the vehicle | |||
| Combination meter | CAN communication | Parking brake switch signal | Receives an operational state of the parking brake | |
| BCM | CAN communication | Front wiper request signal | Receives an operational state of front wiper(s) | |
| Turn indicator signal | Receives an operational state of the turn signal lamp and the hazard lamp | |||
| Dimmer signal | Receives ON/OFF state of dimmer signal | |||
| Steering angle sensor | CAN communication | Steering angle sensor malfunction signal | Receives a malfunction state of steering angle sensor | |
| Steering angle sensor signal | Receives the number of revolutions, turning direction of the steering wheel | |||
| Steering angle speed signal | Receives the turning angle speed of the steering wheel | |||
| AV control unit | CAN communication | System selection signal | Receives a selection state of each item in "Driver Assistance" selected with the navigation system | |
| A/C auto amp. | CAN communication | ECO mode signal | Receives a mode selection state of the drive mode select switch | |
| SNOW mode signal | ||||
| SPORT mode signal | ||||
| STANDARD mode signal | ||||
| ICC sensor | ITS communication | ICC sensor signal | Receives detection results, such as the presence or absence of a leading vehicle and distance from the vehicle | |
| Lane camera unit | ITS communication | Detected lane condition signal | Receives detection results of lane marker | |
| Accelerator pedal actuator | ITS communication | Accelerator pedal actuator operation status signal | Receives an operational state of accelerator pedal actuator | |
| Side radar LH, RH | ITS communication | Vehicle detection signal | Receives vehicle detection condition of detection zone | |
| IBA OFF switch | IBA OFF switch signal | Receives an ON/OFF state of the IBA OFF switch | ||
| Warning systems switch | Warning systems switch signal | Receives an ON/OFF state of the warning systems switch | ||
INPUT SIGNAL ITEM DESCRIPTION
| Reception unit | Signal name | Description | ||
|---|---|---|---|---|
| ECM | CAN communication | ICC operation signal | Transmits an ICC operation signal necessary for intelligent cruise control | |
| TCM | CAN communication | ICC operation signal | Transmits an ICC operation signal necessary for intelligent cruise control via ECM | |
| ABS actuator and electric unit (control unit) | CAN communication | Active trace control signal | Transmits an active trace control signal necessary to control the active trace control function | |
| Brake fluid pressure control signal | Transmits a brake fluid pressure control signal to activates the brake | |||
| Target yaw moment signal | Transmits a target yaw moment signal to generate yaw moment to the vehicle | |||
| Combination meter | CAN communication | Meter display signal | Own vehicle indicator signal | Transmits a signal to display a state of the system on the information display |
| Vehicle ahead detection indicator signal | ||||
| Set vehicle speed indicator signal | ||||
| Set distance indicator signal | ||||
| SET switch indicator signal | ||||
| MAIN switch indicator signal | ||||
| DCA system switch indicator signal | ||||
| BSW/BSI warning lamp signal | Transmits a BSW/BSI warning lamp signal to turn ON the BSW/BSI warning lamp | |||
| BSI ON indictor lamp signal | Transmits a BSI ON indictor lamp signal to turn ON the BSI ON indictor lamp | |||
| LDP ON indicator lamp signal | Transmits a LDP ON indicator lamp signal to turn ON the LDP ON indicator lamp | |||
| Lane departure warning lamp signal | Transmits a lane departure warning lamp signal to turn ON the lane departure warning lamp | |||
| ICC warning lamp signal | Transmits a ICC warning lamp signal to turn ON the ICC system warning lamp | |||
| IBA OFF indicator lamp signal | Transmits a signal to turn ON the IBA OFF indicator lamp Transmits an ON/OFF state of the intelligent brake assist | |||
| Buzzer output signal | Transmits a buzzer output signal to turn ON the buzzer of the following systems: Intelligent Cruise Control (ICC) Distance Control Assist (DCA) Intelligent Brake Assist (IBA) Forward Collision Warning (FCW) | |||
| ICC sensor | ITS communication | Vehicle speed signal | Transmits a vehicle speed calculated by the ADAS control unit | |
| Steering angle sensor signal | Transmits a steering angle sensor signal received from the steering angle sensor | |||
| Lane camera unit | ITS communication | Vehicle speed signal | Transmits a vehicle speed calculated by the ADAS control unit | |
| Turn indicator signal | Transmits a turn indicator signal received from BCM | |||
| Accelerator pedal actuator | ITS communication | Accelerator pedal position signal | Transmits an accelerator pedal angle calculated by the ADAS control unit | |
| Accelerator pedal feedback force control signal (ECO pedal reaction force control signal) | Transmits a target actuation force value calculated by the ADAS control unit Transfer a signal received from ECM (ECO pedal ON) | |||
| Side radar LH, RH | ITS communication | Vehicle speed signal | Transmits a vehicle speed calculated by the ADAS control unit | |
| BSW/BSI indicator signal | Transmits a BSW/BSI indicator signal to turn ON the BSW/BSI indicator | |||
| BSW/BSI indicator dimmer signal | Transmits a BSW/BSI indicator dimmer signal to dimmer BSW/BSI indicator | |||
| ICC brake hold relay | ICC brake hold relay drive signal | Activates the brake hold relay and turns ON the stop lamp | ||
| Warning buzzer | Warning buzzer signal | Activates the warning buzzer | ||
| Warning systems ON indicator | Warning systems ON indicator signal | Turns ON the warning systems ON indicator | ||
OUTPUT SIGNAL ITEM DESCRIPTION
Fail-safe
If a malfunction occurs in each system, ADAS control unit cancels each control, sounds a beep, and turns ON the warning lamp or indicator lamp.
| System | Buzzer | Warning lamp/Indicator lamp | Description |
|---|---|---|---|
| Vehicle-to-vehicle distance control mode | High-pitched tone | ICC system warning lamp | Cancel |
| Conventional (fixed speed) cruise control mode | High-pitched tone | ICC system warning lamp | Cancel |
| Intelligent Brake Assist (IBA) | High-pitched tone | IBA OFF indicator lamp | Cancel |
| Forward Collision Warning (FCW) | High-pitched tone | IBA OFF indicator lamp | Cancel |
| Distance Control Assist (DCA) | High-pitched tone | ICC system warning lamp | Cancel |
| Lane Departure Warning (LDW) | Lane departure warning lamp | Cancel | |
| Lane Departure Prevention (LDP) | Low-pitched tone | Lane departure warning lamp | Cancel |
| Blind Spot Warning (BSW) | BSW/BSI warning lamp | Cancel | |
| Blind Spot Intervention (BSI) | Low-pitched tone | BSW/BSI warning lamp | Cancel |
| Active trace control function | IBA OFF indicator lamp | Cancel If a communication error occurs between the A/C auto amp. and CAN communication line, a mode at the instant of error occurrence is maintained until the mode is fixed to STANDARD after turning the ignition switch from OFF to ON |
METHOD OF STARTING
| CAUTION | Start condition of on board self-diagnosis ICC system OFF DCA system OFF Vehicle speed 0 km/h (0 MPH) |
Scheme 19
Scheme 20
- Turn the ignition switch OFF.
- Start the engine.
- Wait for 5 seconds after starting the engine. Push up the RESUME/ACCELERATE switch 5 times and push down the SET/COAST switch 5 times within 10 seconds. NOTE: If the above operation cannot be performed within 10 seconds after waiting for 5 seconds after starting the engine, repeat the procedure from step 1 .
- The DTC is displayed on the set vehicle speed indicator (1) on the ICC system display on the information display when the on board self-diagnosis starts. Refer to " «DTC INDEX»(ref-573617-S03818570942013082200000) ". NOTE: It displays for up to 5 minutes and then stops. If multiple malfunctions exist, up to 6 DTCs can be stored in memory at the most, and the most recent one is displayed first.
WORK SUPPORT
| Work support items | Description |
|---|---|
| CAUSE OF AUTO-CANCEL 1 | Displays causes of automatic system cancellation occurred during control of the following systems Vehicle-to-vehicle control mode Conventional (fixed speed) control mode Distance Control Assist (DCA) |
| CAUSE OF AUTO-CANCEL 2 | Displays causes of automatic system cancellation occurred during control of the following systems Lane Departure Prevention (LDP) Blind Spot Intervention (BSI) |
Note. Causes of the maximum five cancellations (system cancel) are displayed. The displayed cancellation causes display the number of the ignition switch ON/OFF up to 254. It is fixed to 254 if it is over 254. It returns to 0 when the same cancellation cause is detected again.
Display Items for The Cause of Automatic Cancellation 1
Scheme 21
Display Items for The Cause of Automatic Cancellation 2
Scheme 22
Scheme 23
METER LAMP
Note. The test can be performed only when the engine is running.
| Test item | Operation | Description | MAIN switch indicator ICC system warning lamp IBA OFF indicator lamp |
|---|---|---|---|
| METER LAMP | Off | Stops sending the following signals to exit from the test Meter display signal ICC warning lamp signal IBA OFF indicator lamp signal | OFF |
| On | Transmits the following signals to the combination meter via CAN communication Meter display signal ICC warning lamp signal IBA OFF indicator lamp signal | ON |
STOP LAMP
| Test item | Operation | Description | Stop lamp |
|---|---|---|---|
| STOP LAMP | Off | Stops transmitting the ICC brake hold relay drive signal below to end the test | OFF |
| On | Transmits the ICC brake hold relay drive signal | ON |
ICC BUZZER
| Test item | Operation | Description | ICC warning chime operation sound |
|---|---|---|---|
| ICC BUZZER | MODE1 | Transmits the buzzer output signals to the combination meter via CAN communication | Intermittent beep sound |
| Test start | Starts the tests of "MODE1" | ||
| Reset | Stops transmitting the buzzer output signal below to end the test | ||
| End | Returns to the "SELECT TEST ITEM" screen |
BRAKE ACTUATOR
Note. The test can be performed only when the engine is running.
| Test item | Operation | Description | "PRESS SENS" value |
|---|---|---|---|
| BRAKE ACTUATOR | MODE1 | Transmits the brake fluid pressure control signal to the ABS actuator and electric unit (control unit) via CAN communication | 10 bar |
| MODE2 | 20 bar | ||
| MODE3 | 30 bar | ||
| Test start | Starts the tests of "MODE1", "MODE2" and "MODE3" | ||
| Reset | Stops transmitting the brake fluid pressure control signal below to end the test | ||
| End | Returns to the "SELECT TEST ITEM" screen |
Note. The test is finished in 10 seconds after starting
Scheme 24
Active Pedal
| CAUTION | Shift the selector lever to "P" position, and then perform the test. Never depress the accelerator pedal excessively. (The engine speed may rise unexpectedly when finishing the test.) |
Note. Depress the accelerator pedal to check when performing the test. The test can be performed only when the engine is running.
| Test item | Operation | Description | Accelerator pedal operation |
|---|---|---|---|
| Active Pedal | MODE1 | Transmit the accelerator pedal feedback force control signal to the accelerator pedal actuator via ITS communication. | Constant with a force of 25 N for 8 seconds |
| MODE2 | Constant with a force of 15 N for 8 seconds | ||
| MODE3 | Change up to a force of 25 N for 8 seconds | ||
| MODE4 | Change up to a force of 15 N for 8 seconds | ||
| Test start | Starts the tests of "MODE1", "MODE2", "MODE3" and "MODE4" | ||
| Reset | Stops transmitting the accelerator pedal feedback force control signal below to end the test. | ||
| End | Returns to the "SELECT TEST ITEM" screen |
Note. The test is finished in 10 seconds after starting
Scheme 25
DCA INDICATOR
Note. The test can be performed only when the engine is running.
| Test item | Operation | Description | DCA system switch indicator |
|---|---|---|---|
| DCA INDICATOR | Off | Stops transmitting the DCA system switch indicator signal below to end the test | |
| On | Transmits the DCA system switch indicator signal to the combination meter via CAN communication | ON |
LDP BUZZER
| Test item | Operation | Description | Warning buzzer |
|---|---|---|---|
| LDP BUZZER | Off | Stops transmitting the warning buzzer signal below to end the test | |
| On | Transmits the warning buzzer signal to the warning buzzer | ON |
WARNING SYSTEM IND
| Test item | Operation | Description | Warning systems ON indicator |
|---|---|---|---|
| WARNING SYSTEM IND | Off | Stops transmitting the warning systems ON indicator signal below to end the test | |
| On | Transmits the warning systems ON indicator signal to the warning systems ON indicator. | ON |
LDP ON IND
| Test item | Operation | Description | LDP ON indicator lamp (Green) |
|---|---|---|---|
| LDP ON IND | Off | Stops transmitting the LDP ON indicator lamp signal below to end the test | |
| On | Transmits the LDP ON indicator lamp signal to the combination meter via CAN communication | ON |
LANE DEPARTURE W/L
| Test item | Operation | Description | Lane departure warning lamp (Yellow) |
|---|---|---|---|
| LANE DEPARTURE W/L | Off | Stops transmitting the lane departure warning lamp signal below to end the test | |
| On | Transmits the lane departure warning lamp signal to the combination meter via CAN communication | ON |
BSW/BSI WARNING LAMP
| Test item | Operation | Description | BSW/BSI warning lamp (Yellow) |
|---|---|---|---|
| BSW/BSI WARNING LAMP | Off | Stops transmitting the BSW/BSI warning lamp signal below to end the test | |
| On | Transmits the BSW/BSI warning lamp signal to the combination meter via CAN communication | ON |
BSI ON INDICATOR
| Test item | Operation | Description | BSI ON indicator lamp (Green) |
|---|---|---|---|
| BSI ON INDICATOR | Off | Stops transmitting the BSI ON indicator signal below to end the test | |
| On | Transmits the BSI ON indicator signal to the combination meter via CAN communication | ON |
If a malfunction occurs in each system, ADAS control unit cancels each control, sounds a beep, and turns ON the warning lamp or indicator lamp.
| System | Buzzer | Warning lamp/Indicator lamp | Description |
|---|---|---|---|
| Vehicle-to-vehicle distance control mode | High-pitched tone | ICC system warning lamp | Cancel |
| Conventional (fixed speed) cruise control mode | High-pitched tone | ICC system warning lamp | Cancel |
| Intelligent Brake Assist (IBA) | High-pitched tone | IBA OFF indicator lamp | Cancel |
| Forward Collision Warning (FCW) | High-pitched tone | IBA OFF indicator lamp | Cancel |
| Distance Control Assist (DCA) | High-pitched tone | ICC system warning lamp | Cancel |
| Lane Departure Warning (LDW) | Lane departure warning lamp | Cancel | |
| Lane Departure Prevention (LDP) | Low-pitched tone | Lane departure warning lamp | Cancel |
| Blind Spot Warning (BSW) | BSW/BSI warning lamp | Cancel | |
| Blind Spot Intervention (BSI) | Low-pitched tone | BSW/BSI warning lamp | Cancel |
| Active trace control function | IBA OFF indicator lamp | Cancel If a communication error occurs between the A/C auto amp. and CAN communication line, a mode at the instant of error occurrence is maintained until the mode is fixed to STANDARD after turning the ignition switch from OFF to ON |
CAN COMMUNICATION
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Modern vehicle is equipped with many electronic control units, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H, CAN-L) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads the required data only.
CAN communication signal chart. Refer to " CAN COMMUNICATION SYSTEM: CAN COMMUNICATION SIGNAL CHART ".
ITS COMMUNICATION
- ITS communication is a multiplex communication system. This enables the system to transmit and receive large quantities of data at high speed by connecting control units with 2 communication lines.
- ITS communication lines adopt twisted-pair line style (two lines twisted) for noise immunity.
