Engine Block: Other Honda Pilot II

Connecting Rod Bearing Selection

Each connecting rod falls into one of four tolerance ranges (from 0 to 0.024 mm (0.0009 in.), 0.006 mm (0.0002 in.) increments) depending on the size of its big end bore.

It's then stamped with a number or bar (1, 2, 3, or 4/I, II, III or IIII) indicating the range. You may find any combination of 1, 2, 3, or 4/I, II, III, or MM in any engine.

Big End Bore Size: 58.0 mm (2.283 in)

Inspect the connecting rod for cracks and heat damage.

Big End Bore Code Locations

Numbers or bars have been stamped on the side of each connecting rod as a code for the size of the big end. Use them, and the letters or bars stamped on the crank (codes for rod journal size) to choose the correct bearings. If the codes are indecipherable because of an accumulation of dirt and dust, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent.

Scheme 336

Scheme 337

Connecting Red Journal Code Locations (Letters or Bars)

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

1. If the engine is already out of the vehicle, go to step 6 .
2. Raise the vehicle on the lift.
3. Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-333553-S35525073332009072100000) ).
4. Remove the front subframe stiffener (see step 31 on «ENGINE REMOVAL»(ref-333550-S08423022402009072100000) ).
5. Remove exhaust pipe A (see step 32 on «ENGINE REMOVAL»(ref-333550-S08423022402009072100000) ).
6. Remove the rear warm up three way catalytic converter (rear WU-TWC) bracket.
7. Remove the crankshaft position (CKP) sensor cover (A) and the bolt (B), then disconnect the CKP sensor connector (C).
8. Remove the torque converter cover (A) and the four bolts (B) securing the transmission.
9. Remove the bolts securing the oil pan.
10. Using a flat blade screwdriver, separate the oil pan from the engine block in the places shown.
11. Remove the oil pan.

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

1. Remove the engine/transmission (see «ENGINE REMOVAL»(ref-333550-S08423022402009072100000) ).
2. Remove the transmission (see «TRANSMISSION REMOVAL»(ref-333568-S17228229162009072100000) ).
3. Remove the drive plate (see «DRIVE PLATE REMOVAL AND INSTALLATION»(ref-333568-S33913666202009072100000) ).
4. Remove the cylinder heads (see «CYLINDER HEAD REMOVAL»(ref-333551-S41411568312009072100000) ).
5. Remove the timing belt drive pulley from the crankshaft (see «TIMING BELT DRIVE PULLEY REPLACEMENT»(ref-333551-S37642158972009072100000) ).
6. Remove the oil pan (see «OIL PAN REMOVAL»(ref-333552-S07031113582009072100000) ).
7. Remove the engine block end cover.
8. Remove the rocker arm oil pressure sensor cover (A), then remove the oil filter base/oil filter assembly (B).
9. Remove the oil screen (A), the baffle plate (B), and the oil pump (C).
10. If you can feel a ridge of metal or hard carbon around the top of any cylinder, remove it with a ridge reamer (A). Follow the reamer manufacturer's instructions. If the ridge is not removed, it may damage the piston as it's pushed out.
11. Remove the connecting rod caps after setting the connecting rod at bottom dead center (BDC) for each cylinder. Remove the piston/connecting rod assembly by pushing on the connecting rod. Take care not to damage the oil jets, connecting rod journal, or the cylinder with the connecting rod.
12. Remove the bearing from the cap. Keep all caps/bearings in order.
13. Remove the upper bearing halves from the connecting rods, and set them aside with their respective caps.
14. After removing a piston/connecting rod assembly, reinstall the cap on the rod.
15. To avoid confusion during reassembly, mark each piston/connecting rod assembly with its cylinder number.
16. Loosen the bearing cap bolts and the bearing cap side bolts in sequence 1/3 turn at a time; repeat the sequence until all bolts are loosened.
17. Remove the bearing cap bolts (A) and the bearing cap side bolts (B), then remove the bearing caps (C).
18. Lift the crankshaft (A) out of the engine block, being careful not to damage the journals and the CKP pulse plate.
19. Remove the CKP pulse plate from the crankshaft (see «CKP PULSE PLATE REPLACEMENT»(ref-333552-S10261555712009072100000) ).
20. Reinstall the main caps and the bearings on the engine block in the proper order.

Scheme 351

Scheme 352

1. Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-333552-S30813783042009072100000) ).
2. Remove the crankshaft position (CKP) pulse plate from the crankshaft (see «CKP PULSE PLATE REPLACEMENT»(ref-333552-S10261555712009072100000) ).
3. Clean the crankshaft oil passages with pipe cleaners or a suitable brush.
4. Check the keyway slot and the threaded holes for damage.
5. Measure the out-of-round at the middle of each rod and main journal in two places. The difference between measurements on each journal must not be more than the service limit. Journal Out-of-Round Standard (New): 0.005 mm (0.0002 in) max. Service Limit: 0.010 mm (0.0004 in)
6. Measure the taper at the edges of each rod and main journal. The difference between measurements on each journal must not be more than the service limit. Journal Taper Standard (New): 0.005 mm (0.0002 in) max. Service Limit: 0.010 mm (0.0004 in) Straightness
7. Place the V-blocks on a flat surface.
8. Check the total runout with the crankshaft supported on V-blocks.
9. Measure the runout on all of the main journals. Rotate the crankshaft two complete revolutions. The difference between measurements on each journal must not be more than the service limit. Crankshaft Total Runout Standard (New): 0.025 mm (0.0010 in) max. Service Limit: 0.03 mm (0.001 in)

Scheme 353

Scheme 354

Scheme 355

Scheme 356

1. Remove the pistons (see «CRANKSHAFT AND PISTON REMOVAL»(ref-333552-S30813783042009072100000) ) from the engine block.
2. Check the pistons for distortion or cracks.
3. Measure the piston skirt diameter at a point 16.0 mm (0.63 in.) from the bottom of the skirt. Piston Skirt Diameter Standard (New): 88.975-88.985 mm (3.5029-3.5033 in) Service Limit: 88.965 mm (3.5026 in) Oversize Piston Skirt Diameter 0.25: 89.225-89.235 mm (3.5128-3.5132 in.)
4. Measure the wear and taper in direction X and Y at three levels in each cylinder as shown below. If measurements in any cylinder are beyond the oversize bore service limit, replace the engine block. If the engine block has to be rebored, refer to step 7 after reboring. Cylinder Bore Size Standard (New): 89.000-89.015 mm (3.5039-3.5045 in) Service Limit: 89.065 mm (3.5065 in) Oversize 0.25: 89.250-89.265 mm (3.5138-3.5144 in.) Reboring Limit: 0.25 mm (0.010 in) Bore Taper Limit: (Difference between first and third measurement) 0.05 mm (0.002 in)
5. Hone any scored or scratched cylinder bores (see «CYLINDER BORE HONING»(ref-333552-S02562750712009072100000) ).
6. Check the top of the engine block for warpage. Measure along the edges and across the center as shown below. Engine Block Warpage Standard (New): 0.07 mm (0.0028 in) max. Service Limit: 0.10 mm (0.0039 in)
7. Calculate the difference between the cylinder bore diameter and the piston diameter. If the clearance is near or exceeds the service limit, inspect the piston and the cylinder bore for excessive wear. Piston-to-Cylinder Bore Clearance Standard (New): 0.015-0.040 mm (0.00059-0.00157 in) Service Limit: 0.08 mm (0.0031 in)

Scheme 357

1. Measure the cylinder bores (see step 4 ). If the engine block is to be reused, hone the cylinders and remeasure the bores. Only scored or scratched cylinder bores must be honed.
2. Remove the oil jets (see «OIL JET REPLACEMENT»(ref-333553-S12487435472009072100000) ).
3. Hone the cylinder bores with honing oil and a fine (400 grit) stone in a 60 degree Crosshatch pattern. NOTE: Use only a rigid hone with 400 grit or finer stone, such as Sunnen, Ammco, or equivalent. Do not use stones that are worn or broken.
4. When honing is complete, thoroughly clean the engine block of all metal particles. Wash the cylinder bores with hot soapy water, then dry and oil them immediately to prevent rusting. NOTE: Never use solvent, it will only redistribute the grit on the cylinder walls.
5. If scoring or scratches are still present in the cylinder bores after honing to the service limit, rebore the engine block. Some light vertical scoring and scratching is acceptable if it is not deep enough to catch your fingernail and does not run the full length of the bore.
6. Install the oil jets (see «OIL JET REPLACEMENT»(ref-333553-S12487435472009072100000) ).

Scheme 358

Scheme 359

Scheme 360

1. Remove the pistons from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-333552-S30813783042009072100000) ).
2. Apply new engine oil to the piston pin snap rings (A) and turn them in the ring grooves until the end gaps are lined up with the cutouts in the piston pin bores (B). NOTE: Take care not to damage the ring grooves.
3. Remove the snap rings (A) from both sides of each piston. Start at the cutout in the piston pin bore. Remove the snap rings carefully so they do not go flying or get lost. Wear eye protection.
4. Separately heat each piston and connecting rod assembly to about 158°F (70°C), then remove the piston pin.
