Cylinder Head: Adjustments Honda Pilot II

Valve Clearance Adjustment

Note. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see step 2 on HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM) , and monitor the engine coolant temperature (ECT) sensor 1 with the HDS. Adjust the valve clearance only when the engine coolant temperature is less than 100°F (38°C).

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

1. Remove the cylinder head covers (see «CYLINDER HEAD COVER REMOVAL»(ref-333551-S34784543322009072100000) ).
2. Set the No. 1 piston at top dead center (TDC). Align the pointer (A) on the front upper cover with the No. 1 piston TDC mark (B) on the front camshaft pulley.
3. Select the correct feeler gauge for the valve clearance you are going to check. Valve Clearance Intake: 0.20-0.24 mm (0.008-0.009 in) Exhaust: 0.28-0.32 mm (0.011-0.013 in) REAR FRONT
4. Insert the feeler gauge (A) between the adjusting screw and the end of the valve stem on the No. 1 cylinder and slide it back and forth; you should feel a slight amount of drag. INTAKE EXHAUST
5. If you feel too much or too little drag, loosen the locknut, and turn the adjusting screw until the drag on the feeler gauge is correct. INTAKE EXHAUST
6. While holding the adjusting screw with the screw driver, tighten the locknut, then recheck the clearance. Repeat the adjustment, if necessary. Specified Torque No. 1, No. 2, No. 3, and No. 4 cylinders: 20 N.m (2.0 kgf.m, 14 lbf.ft) Apply new engine oil to the nut threads. No. 5 and No. 6 cylinders: 14 N.m (1.4 kgf.m, 10 lbf.ft) Apply new engine oil to the nut threads.
7. Rotate the crankshaft clockwise. Align the pointer (A) on the front upper cover with the No. 4 piston TDC mark (B) on the front camshaft pulley.
8. Check and, if necessary, adjust the valve clearance on No. 4 cylinder.
9. Rotate the crankshaft clockwise. Align the pointer (A) on the front upper cover with the No. 2 piston TDC mark (B) on the front camshaft pulley.
10. Check and, if necessary, adjust the valve clearance on the No. 2 cylinder.
11. Rotate the crankshaft clockwise. Align the pointer (A) on the front upper cover with the No. 5 piston TDC mark (B) on the front camshaft pulley.
12. Check and, if necessary, adjust the valve clearance on No. 5 cylinder.
13. Rotate the crankshaft clockwise. Align the pointer (A) on the front upper cover with the No. 3 piston TDC mark (B) on the front camshaft pulley.
14. Check and, if necessary, adjust the valve clearance on No. 3 cylinder.
15. Rotate the crankshaft clockwise. Align the pointer (A) on the front upper cover with the No. 6 piston TDC mark (B) on the front camshaft pulley.
16. Check and, if necessary, adjust the valve clearance on the No. 6 cylinder.
17. Install the cylinder head covers (see «CYLINDER HEAD COVER INSTALLATION»(ref-333551-S21087979762009072100000) ).
