Cylinder Head: Removal & Installation Honda Pilot II

Timing Belt Installation

Note. The following procedure is for installing a used timing belt. If you are installing a new belt, refer to the timing belt replacement procedure (see TIMING BELT REPLACEMENT ).

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

1. Clean the timing belt pulleys, the timing belt guide plate, and the upper and lower covers.
2. Set the timing belt drive pulley to top dead center (TDC) by aligning the TDC mark (A) on the tooth of the timing belt drive pulley with the pointer (B) on the oil pump.
3. Set the camshaft pulleys to TDC by aligning the TDC marks (A) on the camshaft pulleys with the pointers (B) on the back covers. FRONT REAR
4. Loosely install the idler pulley using a new idler pulley bolt so the pulley can move but does not come off.
5. If the auto-tensioner has extended and the timing belt cannot be installed, do the timing belt replacement procedure (see «TIMING BELT REPLACEMENT»(ref-333551-S06614527922009072100000) ).
6. Install the timing belt in a counterclockwise sequence starting with the drive pulley. Take care not to damage the timing belt during installation. Drive pulley (A) Idler pulley (B) Front camshaft pulley (C) Water pump pulley (D) Rear camshaft pulley (E) Adjusting pulley (F)
7. Tighten the idler pulley bolt.
8. Remove the battery clamp bolt from the back cover.
9. Install the lower half of the side engine mount bracket.
10. Install the timing belt guide plate as shown below.
11. Install the lower cover.
12. Install the front upper cover (A) and the rear upper cover (B).
13. Install the crankshaft pulley (see «CRANKSHAFT PULLEY REMOVAL AND INSTALLATION»(ref-333551-S21806405492009072100000) ).
14. Rotate the crankshaft pulley about six turns clockwise so the tinning belt positions itself on the pulleys.
15. Turn the crankshaft pulley so its white mark (A) lines up with the pointer (B). NOTE: The other pointer (C) is not used.
16. Check the camshaft pulley marks. NOTE: If the marks are not aligned, rotate the crankshaft 360 degrees, and recheck the camshaft pulley mark. If the camshaft pulley marks are at TDC, go to step 17 . If the camshaft pulley marks are not at TDC, remove the timing belt (see «TIMING BELT REMOVAL»(ref-333551-S34987126892009072100000) ) and repeat steps 2 through 16 . FRONT REAR
17. Install the upper half of the side engine mount bracket (A), and tighten the new mounting bolts (B), then tighten the mass damper mounting bolt (C).
18. Install the ground cable (D).
19. Install the drive belt auto-tensioner (see «DRIVE BELT AUTO-TENSIONER REPLACEMENT»(ref-333547-S24150286392009072100000) ).
20. Install the splash shield (see «SPLASH SHIELD REPLACEMENT»(ref-333594-S31882515052009072100000) ).
21. Install the right front wheel.
22. Do the crankshaft position (CKP) pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-333557-S25100768752009072100000) ).

Timing Belt Replacement

Note. The following procedure is for the installation of a new timing belt. If you are installing a used belt, refer to the timing belt installation procedure (see TIMING BELT INSTALLATION ).

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

1. Remove the timing belt.
2. Clean the timing belt pulleys, timing belt guide plate, and the upper and lower covers.
3. Set the timing belt drive pulley to top dead center (TDC) by aligning the TDC mark (A) on the tooth of the timing belt drive pulley with the pointer (B) on the oil pump.
4. Set the camshaft pulleys to TDC by aligning the TDC marks (A) on the camshaft pulleys with the pointers (B) on the back covers. FRONT REAR
5. Remove the battery clamp bolt from the back cover.
6. Remove the auto-tensioner.
7. Align the holes on the rod and the housing of the auto-tensioner.
8. Use a hydraulic press to slowly compress the auto-tensioner. Insert a 2.0 mm (0.08 in.) pin through the housing and the rod. NOTE: The compression pressure should not exceed 9,800 N (1,000 kgf, 2,200 lbf).
9. Install the auto-tensioner. NOTE: Make sure the pin stays in place.
10. Thread in the battery clamp bolt as shown below to hold the timing belt adjuster. Tighten it by hand; do not use a wrench.
11. Loosely install the idler pulley with a new idler pulley bolt so the pulley can move but does not come off.
12. Install the timing belt in a counterclockwise sequence starting with the drive pulley. Drive pulley (A) Idler pulley (B) Front camshaft pulley (C) Water pump pulley (D) Rear camshaft pulley (E) Adjusting pulley (F)
13. Tighten the idler pulley bolt.
14. Remove the pin from the auto-tensioner.
15. Remove the battery clamp bolt from the back cover.
16. Install the lower half of the side engine mount bracket.
17. Install the timing belt guide plate as shown below.
18. Install the lower cover.
19. Install the front upper cover (A) and the rear upper cover (B).
20. Install the crankshaft pulley (see «CRANKSHAFT PULLEY REMOVAL AND INSTALLATION»(ref-333551-S21806405492009072100000) ).
21. Rotate the crankshaft pulley about six turns clockwise so the timing belt positions itself on the pulleys.
22. Turn the crankshaft pulley so its white mark (A) lines up with the pointer (B). NOTE: The other pointer (C) is not used.
23. Check the camshaft pulley marks. NOTE: If the marks are not aligned, rotate the crankshaft 360 degrees, and recheck the camshaft pulley mark. If the camshaft pulley marks are at TDC, go to step 24 . If the camshaft pulley marks are not at TDC, remove the timing belt (see «TIMING BELT REMOVAL»(ref-333551-S34987126892009072100000) ) and repeat steps 3 through 22 . FRONT REAR
24. Install the upper half of the side engine mount bracket (A), and tighten the new mounting bolts (B), then tighten the mass damper mounting bolt (C).
25. Install the ground cable (D).
26. Install the drive belt auto-tensioner (see «DRIVE BELT AUTO-TENSIONER REPLACEMENT»(ref-333547-S24150286392009072100000) ).
27. Install the splash shield (see «SPLASH SHIELD REPLACEMENT»(ref-333594-S31882515052009072100000) ).
28. Install the right front wheel.
29. Do the crankshaft position (CKP) pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-333557-S25100768752009072100000) ).

Scheme 167

1. Remove the timing belt (see «TIMING BELT REMOVAL»(ref-333551-S34987126892009072100000) ).
2. Remove the battery clamp bolt from the back cover.
3. Remove the auto-tensioner (see step 6 ).
4. Remove the bolt (A), then remove the timing belt adjuster (B) and the collar (C).
5. Install the timing belt adjuster in the reverse order of removal.
6. Install the timing belt (see «TIMING BELT INSTALLATION»(ref-333551-S12213281632009072100000) ).

Scheme 168

1. Remove the timing belt (see «TIMING BELT REMOVAL»(ref-333551-S34987126892009072100000) ).
2. Remove the timing belt stopper (A), then remove the timing belt drive pulley (B) and the key (C).
3. Inspect the timing belt drive pulley and the key for damage. If it is cracked or damaged, replace the timing belt drive pulley and the key.
4. Install the new timing belt drive pulley and the key, then install the timing belt stopper.
5. Install the timing belt (see «TIMING BELT INSTALLATION»(ref-333551-S12213281632009072100000) ).
6. Do the crankshaft position (CKP) pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-333557-S25100768752009072100000) ).

Scheme 169

Scheme 170

1. Remove the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(ref-333554-S11195159552009072100000) ).
2. Remove the three ignition coils (see «IGNITION COIL REMOVAL/INSTALLATION»(ref-333546-S38274197062009072100000) ) from the front cylinder head.
3. Disconnect the engine coolant temperature (ECT) sensor 1 connector (A), the exhaust gas recirculation (EGR) valve connector (B), the front secondary heated oxygen (sensor 2) (secondary HO2S) connector (C), the front air fuel ratio (A/F) (sensor 1) connector (D), the rocker arm oil control solenoid A (BANK 2) connector (E), the front rocker arm oil pressure switch connector (F) the harness clamp (G) securing the harness holder, and remove the dipstick (H).
4. Remove the bolt (I) securing the harness holder.
5. Remove front cylinder head cover.

Scheme 171

Scheme 172

Scheme 173

1. Remove the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(ref-333554-S11195159552009072100000) ).
2. Remove the three ignition coils (see «IGNITION COIL REMOVAL/INSTALLATION»(ref-333546-S38274197062009072100000) ) from the rear cylinder head.
3. Remove the drive belt (see «DRIVE BELT REPLACEMENT»(ref-333547-S39082279042009072100000) )
4. Remove the power steering (P/S) pump and the P/S hose bracket (see step 6 ) with its hoses connected.
5. Remove the harness holder mounting bolts (A) and the engine ground cable bolt (B).
6. Disconnect the three injector connectors (C) and the two harness clips (D).
7. Disconnect the breather hose (E).
8. Remove the harness (F) from the upper cover.
9. Disconnect the rear rocker arm oil pressure switch connector (A), the rocker arm oil control solenoid B (BANK 1) connector (B), the rocker arm oil control solenoid A (BANK 1) connector (C), the rear air fuel ratio (A/F) sensor 1 connector (D), the rear secondary heated oxygen sensor 2 (secondary HO2S) connector (E), and the harness clamps (F), then remove the harness holder (G).
10. Disconnect the breather hose (H).
11. Remove the rear cylinder head cover.

Scheme 174

Scheme 175

Scheme 176

Scheme 177

1. Check the spark plug seals for damage. If any seal is damaged, replace it.
2. Thoroughly clean the head cover gasket and the groove of the cylinder head cover. NOTE: Check and if necessary, replace the head cover gasket.
3. Install the head cover gasket (A) in the groove of the cylinder head cover (B). Make sure the head cover gasket is seated securely.
4. Remove all of the old liquid gasket from the rocker shaft holder and the cylinder head.
5. Clean the head cover contacting surfaces with a shop towel.
6. Apply liquid gasket, P/N 08717-0004,08718-0001, 08718-0003, or 08718-0009, evenly to the rocker shaft holder mating surface (A). Install the component within 5 minutes of applying the liquid gasket. NOTE: If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply the new liquid gasket.
7. Set the spark plug seals (A) on the spark plug tubes, and install the front cylinder head cover (B). NOTE: Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the cylinder head cover.
8. Inspect the spark plug seals for damage.
9. Inspect the cover washers (C). Replace any washer that is damaged or deteriorated.
10. Tighten the bolts in three steps. In the final step torque all bolts, in sequence, 12 N.m (1.2 kgf.m, 8.7 lbf.ft).
11. Install bolt (A) securing the harness holder.
12. Connect the engine coolant temperature (ECT) sensor 1 connector (A), the exhaust gas recirculation (EGR) valve connector (B), the front secondary heated oxygen (sensor 2) (secondary HO2S) connector (C), the front air fuel ratio (A/F) (sensor 1) connector (D), the rocker arm oil control solenoid A (BANK 2) connector (E), the front rocker arm oil pressure switch connector (F) and the harness clamp (G) securing the harness holder, and install the dipstick (H).
13. Install three ignition coils to the front cylinder head (see «IGNITION COIL REMOVAL/INSTALLATION»(ref-333546-S38274197062009072100000) .)
14. Install the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(ref-333554-S11195159552009072100000) ).

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

1. Check the spark plug seals for damage. If any seal is damaged, replace it.
2. Thoroughly clean the head cover gasket and the groove.
3. Install the head cover gasket (A) in the groove of the cylinder head cover (B). Make sure the head cover gasket is seated securely.
4. Remove all of the old liquid gasket from the rocker shaft holder and the cylinder head.
5. Clean the head cover contacting surfaces with a shop towel.
6. Apply liquid gasket, P/N 08717-0004,08718-0001, 08718-0003, or 08718-0009, evenly to the rocker shaft holder mating surface (A). Install the component within 5 minutes of applying the liquid gasket. NOTE: If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes. If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply the new liquid gasket.
7. Set the spark plug seals (A) on the spark plug tubes, and install the rear cylinder head cover (B). NOTE: Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the cylinder head cover.
8. Inspect the spark plug seals for damage.
9. Inspect the cover washers (C). Replace any washer that is damaged or deteriorated.
10. Tighten the bolts in three steps. In the final step torque all bolts, in sequence, 12 N.m (1.2 kgf.m, 8.7 lbf.ft).
11. Connect the rear rocker arm oil pressure switch connector (A), the rocker arm oil control solenoid B (BANK 1) connector (B), the rocker arm oil control solenoid A (BANK 1) connector (C), the rear air fuel ratio (A/F) (sensor 1) connector (D), the rear secondary heated oxygen (sensor 2) (secondary HO2S) connector (E), and the harness clamps (F), then install the harness holder (G).
12. Connect the breather hose (H).
13. Tighten the harness holder mounting bolt (A).
14. Install the engine ground cable (B) and connect the breather hose (C), then install the harness (D) to the upper cover.
15. Reconnect the three injector connectors (E) and the two harness clips (F).
16. Install the power steering (P/S) pump and the P/S hose bracket (see step 6 ).
17. Install the drive belt (see «DRIVE BELT REPLACEMENT»(ref-333547-S39082279042009072100000) ).
18. Install the three ignition coils (see «IGNITION COIL REMOVAL/INSTALLATION»(ref-333546-S38274197062009072100000) ) to the rear cylinder head.
19. Install the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(ref-333554-S11195159552009072100000) ).

Note. Use fender covers to avoid damaging painted surfaces. To avoid damaging the wiring and terminals, unplug the wiring connectors carefully while holding the connector portion. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC), and monitor the engine coolant temperature (ECT) sensor 1. To avoid damaging the cylinder head, wait until the engine coolant temperature drops below 100°F (38°C) before loosening the cylinder head bolts. Mark all wiring and hoses to avoid misconnection. Also, be sure that they do not contact other wiring or hoses, or interfere with other parts.

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

1. Relieve the fuel pressure (see «FUEL PRESSURE RELIEVING»(ref-333562-S16159631292009072100000) ).
2. Remove the air intake duct (see step 1 on «FRONT BULKHEAD COVER REPLACEMENT»(ref-333593-S12466888562009072100000) ).
3. Do the battery removal procedure (see «BATTERY REMOVAL AND INSTALLATION»(ref-333608-S42868124562009072100000) ).
4. Drain the engine coolant (see «COOLANT CHECK»(ref-333555-S24547779662009072100000) ).
5. Remove the drive belt (see «DRIVE BELT REPLACEMENT»(ref-333547-S39082279042009072100000) ).
6. Remove the power steering (P/S) pump (A) and the bolt (B) securing the P/S hose bracket (C).
7. Remove the alternator (see «REMOVAL»(ref-333547-S22404527682009072100000) ).
8. Remove the timing belt (see «TIMING BELT REMOVAL»(ref-333551-S34987126892009072100000) ).
9. Remove the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(ref-333554-S11195159552009072100000) ).
10. Remove the six ignition coils (see «IGNITION COIL REMOVAL/INSTALLATION»(ref-333546-S38274197062009072100000) ).
11. Disconnect the following engine wire harness connectors and wire harness clamps from the cylinder head: Six injector connectors Engine coolant temperature (ECT) sensor 1 connector Front rocker arm oil pressure switch connector Rear rocker arm oil pressure switch connector Camshaft position (CMP) sensor connector Front air fuel ratio (A/F) (sensor 1) connector Rear air fuel ratio (A/F) (sensor 1) connector Front secondary heated oxygen (sensor 2) (secondary HO2S) connector Rear secondary heated oxygen (sensor 2) (secondary HO2S) connector Rocker arm oil control solenoid A (BANK 1) connector Rocker arm oil control solenoid A (BANK 2) connector Rocker arm oil control solenoid B (BANK 1) connector Knock sensor connector
12. Remove the front warm up three way catalytic converter (front WU-TWC) (see «FRONT»(ref-333564-S10602104362009072100000) ) and the rear warm up three way catalytic converter (rear WU-TWC) (see «REAR»(ref-333564-S31137591282009072100000) )
13. Remove the quick-connect fitting cover (A), then disconnect the fuel feed hose (B) (see «FUEL LINE/QUICK-CONNECT FITTING REMOVAL»(ref-333562-S35569173912009072100000) ).
14. Remove the connector bracket (A) from the front cylinder head.
15. Remove the harness clamp bracket (A) from the rear cylinder head.
16. Remove the injector bases (see «INJECTOR BASE REMOVAL AND INSTALLATION»(ref-333554-S03885112412009072100000) ).
17. Remove the water passage (see «WATER PASSAGE REPLACEMENT»(ref-333555-S13744526962009072100000) ).
18. Remove the camshaft pulleys (A) and the back covers (B). FRONT REAR
19. Remove the cylinder head cover (see «TIMING BELT DRIVE PULLEY REPLACEMENT»(ref-333551-S37642158972009072100000) ).
20. Remove the cylinder head bolts. To prevent warpage, loosen the bolts in sequence 1/3 turn at a time; repeat the sequence until all the bolts are loosened. FRONT REAR
21. Remove the cylinder head.

Scheme 192

Scheme 193

Scheme 194

1. Remove the air intake duct (see step 1 on «FRONT BULKHEAD COVER REPLACEMENT»(ref-333593-S12466888562009072100000) ).
2. Do the battery removal procedure (see «BATTERY REMOVAL AND INSTALLATION»(ref-333608-S42868124562009072100000) ).
3. Remove the battery base (see step 9 on «ENGINE REMOVAL»(ref-333550-S08423022402009072100000) ).
4. Drain the engine coolant (see step 11 on «COOLANT REPLACEMENT»(ref-333555-S19429433502009072100000) ).
5. Disconnect the radiator hoses (A).
6. Remove the exhaust gas recirculation (EGR) valve (see «EGR VALVE REPLACEMENT»(ref-333565-S28763655732009072100000) ).
7. Remove the EGR valve stud bolts (A).
8. Remove the timing belt (see «TIMING BELT REMOVAL»(ref-333551-S34987126892009072100000) ).
9. Remove the rocker arm assembly (see «FRONT»(ref-333551-S31376790022009072100000) ).
10. Remove the front camshaft pulley (see «CYLINDER HEAD REMOVAL»(ref-333551-S41411568312009072100000) ).
11. Remove the thrust cover (A), then remove the camshaft (B).
12. Install the camshaft in the reverse order of removal using a new O-ring (C). Apply new engine oil to the journals and cam lobes.
13. Apply new engine oil to the threads of the camshaft pulley mounting bolt, then install the front camshaft pulley (see step 12 on «REAR»(ref-333551-S22914830052009072100000) ).
14. Install the rocker arm assembly (see step 10 on «CAMSHAFT, ROCKER ARM ASSEMBLY, CAMSHAFT SEAL, AND PULLEY INSTALLATION»(ref-333551-S20923989242009072100000) ), then tighten the mounting bolts.
15. Install the timing belt (see «TIMING BELT INSTALLATION»(ref-333551-S12213281632009072100000) ).
16. Adjust the valve clearance (see «VALVE CLEARANCE ADJUSTMENT»(ref-333551-S26574303442009072100000) ).
17. Install the EGR valve stud bolts then install the EGR valve (see «EGR VALVE REPLACEMENT»(ref-333565-S28763655732009072100000) ).
18. Connect radiator hoses.
19. Install the battery base (see step 56 on «ENGINE INSTALLATION»(ref-333550-S05584759992009072100000) ).
20. Do the battery installation procedure (see «BATTERY REMOVAL AND INSTALLATION»(ref-333608-S42868124562009072100000) ).
21. Install the air intake duct (see «FRONT BULKHEAD COVER REPLACEMENT»(ref-333593-S12466888562009072100000) ).
22. Fill the radiator with engine coolant (see step 11 on «COOLANT REPLACEMENT»(ref-333555-S19429433502009072100000) ) and bleed the air from the cooling system with the heater valve open.
23. Do the crankshaft position (CKP) pattern clear/CKP pattern lean procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-333557-S25100768752009072100000) ).

Scheme 195

Scheme 196

Scheme 197

1. Relieve the fuel pressure (see «FUEL PRESSURE RELIEVING»(ref-333562-S16159631292009072100000) ).
2. Drain the engine coolant (see «COOLANT CHECK»(ref-333555-S24547779662009072100000) ).
3. Remove the intake air duct (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(ref-333563-S38299951722009072100000) ).
4. Remove the air cleaner assembly (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-333563-S41422864462009072100000) ).
5. Remove the quick-connect fitting cover (A), then disconnect the fuel feed hose (B) (see «FUEL LINE/QUICK-CONNECT FITTING REMOVAL»(ref-333562-S35569173912009072100000) ).
6. Disconnect the heater hoses (A) and the evaporative emission (EVAP) canister hose (B), then remove the purge joint bracket (C).
7. Remove the timing belt (see «TIMING BELT REMOVAL»(ref-333551-S34987126892009072100000) ).
8. Remove the rocker arm assembly (see «REAR»(ref-333551-S39943037612009072100000) ).
9. Remove the rear camshaft pulley (see «CYLINDER HEAD REMOVAL»(ref-333551-S41411568312009072100000) ).
10. Remove the thrust cover (A), then remove the rear camshaft (B).
11. Install the rear camshaft in the reverse order of removal using a new O-ring (C). Apply new engine oil to the journals and the cam lobes.
12. Apply new engine oil to the threads of the camshaft pulley mounting bolt, then install the rear camshaft pulley (see step 12 on «REAR»(ref-333551-S22914830052009072100000) ).
13. Install the rocker arm assembly (see step 10 on «CAMSHAFT, ROCKER ARM ASSEMBLY, CAMSHAFT SEAL, AND PULLEY INSTALLATION»(ref-333551-S20923989242009072100000) ), then tighten the mounting bolts.
14. Install the timing belt (see «TIMING BELT INSTALLATION»(ref-333551-S12213281632009072100000) ).
15. Adjust the valve clearance (see «VALVE CLEARANCE ADJUSTMENT»(ref-333551-S26574303442009072100000) ).
16. Install the heater hoses and the purge joint bracket.
17. Connect the fuel feed hose (see «FUEL LINE/QUICK-CONNECT FITTING INSTALLATION»(ref-333562-S07004954342009072100000) ), then install the quick-connect fitting cover.
18. Install the air cleaner assembly (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-333563-S41422864462009072100000) ).
19. Install the intake air duct (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(ref-333563-S38299951722009072100000) ).
20. Inspect for fuel leaks. Turn the ignition switch to ON (II) (do not operate the starter) so the fuel pump runs for about 2 seconds and pressurizes the fuel line. Repeat this operation three times, then check for fuel leakage at any point in the fuel line.
21. Fill the radiator with engine coolant (see step 11 on «COOLANT REPLACEMENT»(ref-333555-S19429433502009072100000) ), and bleed the air from the cooling system with the heater valve open.
22. Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-333557-S25100768752009072100000) ).

Scheme 198

1. Remove the cylinder head (see «CYLINDER HEAD REMOVAL»(ref-333551-S41411568312009072100000) ).
2. Inspect the camshaft (see «CAMSHAFT INSPECTION»(ref-333551-S06940188432009072100000) ).
3. Check the cylinder head for warpage. Measure along the edges, and three ways across the center. If warpage is less than 0.05 mm (0.002 in.), cylinder head resurfacing is not required. If warpage is between 0.05 mm (0.002 in.) and 0.2 mm (0.008 in.), resurface the cylinder head. Maximum resurface limit is 0.2 mm (0.008 in.) based on a height of 121 mm (4.76 in.). Cylinder Head Height Standard (New): 120.95-121.05 mm (4.762-4.766 in)

Scheme 199

Scheme 200

1. Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(ref-333551-S34784543322009072100000) ).
2. Loosen the locknuts and adjusting screws (A).
3. Remove the rocker shaft bridge mounting bolts, the rocker shaft holder mounting bolts, and the rocker arm assembly. Loosen the rocker shaft bridge mounting bolts and the rocker shaft holder mounting bolts in sequence two turns at a time, to prevent damaging the valves or the rocker arm assembly. When removing the rocker arm assembly, do not remove the rocker shaft bridge mounting bolts and the rocker shaft holder mounting bolts. The bolts will keep the rocker arms on the shafts.

Scheme 201

Scheme 202

1. Remove the cylinder head cover (see «REAR»(ref-333551-S35723280702009072100000) ).
2. Loosen the locknuts and the adjusting screws (A).
3. Remove the rocker shaft bridge mounting bolts, the rocker shaft holder mounting bolts, and the rocker arm assembly. Loosen the rocker shaft bridge mounting bolts and the rocker shaft holder mounting bolts in sequence two turns at a time, to prevent damaging the valves or the rocker arm assembly. When removing the rocker arm assembly, do not remove the rocker shaft bridge mounting bolts and the rocker shaft holder mounting bolts. The bolts will keep the rocker arms on the shafts.

Sealing Bolt Installation

Note. When installing the sealing bolt (A), use a new washer (B).

FRONT

Scheme 203

REAR

Scheme 204

Scheme 205

1. Remove the front rocker arm assembly (see «FRONT»(ref-333551-S31376790022009072100000) ).
2. Remove the front rocker arm oil control valve (A).
3. Install the front rocker arm oil control valve in the reverse order of removal.

Scheme 206

1. Remove the rear rocker arm assembly (see «REAR»(ref-333551-S39943037612009072100000) ).
2. Remove the rocker arm oil control valve (A).
3. Install the rear rocker arm oil control valve in the reverse order of removal.
