Active Control Engine Mount (Acm) System: Maintenance Honda Pilot II

Mechanical 2 illustrations ~166 words

ACM Reset

  1. Reset the ACM with the HDS while the engine is stopped.
  2. Turn the ignition switch to LOCK (0).
  3. Turn the ignition switch to ON (II), and wait 30 seconds.
  4. Turn the ignition switch to LOCK (0), and disconnect the HDS from the DLC.

Scheme 42

Scheme 42: Special Tools Required
Scheme 42: Special Tools Required

Scheme 43

Scheme 43
Scheme 43
  1. Connect the backprobe adapters (A) to the stacking patch codes (B), and connect the codes to a digital multimeter (C).
  2. Using the wire insulation as a guide for the contoured tip of the backprobe adapter, gently slide the tip into the connector from the wire side until it touches the end of the wire terminal.
  3. If you cannot get to the wire side of the connector or the wire side is sealed (A), disconnect the connector, and probe the terminals (B) from the terminal side. Do not force the probe into the connector. NOTE: Do not puncture the insulation on a wire. Punctures can cause poor or intermittent electrical connections.
