Automatic Transaxle Cooling: Removal & Installation Ford Grand C-MAX II

Automatic Trans 12 illustrations ~472 words

Removal

WARNINGBefore beginning any service procedure in this section, refer to HEALTH AND SAFETY PRECAUTIONS Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

Scheme 95

Scheme 95

Scheme 96

Scheme 96
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-539149-S05516616262013040100000) (100-00 General Information, Description and Operation).
  2. Refer to: «ACTIVE GRILLE SHUTTER»(ref-539194-S34547364872013040100000) (501-02 Front End Body Panels, Removal and Installation).
  3. NOTE: Use a Jiffy-tite quick disconnect tool, close the tool around the tube, press the tool into the fitting and rotate until the tool is fully seated into the fitting.

Scheme 97

Scheme 97: Installation

Scheme 98

Scheme 98

Scheme 99

Scheme 99
  1. Backing ring (7J324)
  2. Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid / XT-10-QLVC (WSS-M2C938-A) (MERCON® LV)
  3. Torque: 25 Nm
  4. NOTE: Make sure that the transmission fluid cooler tubes are secure. Push, pull then push the transmission cooler tubes on the transmission fluid cooler.
  5. Refer to: «ACTIVE GRILLE SHUTTER»(ref-539194-S34547364872013040100000) (501-02 Front End Body Panels, Removal and Installation).
  6. Refer to: «TRANSMISSION FLUID LEVEL CHECK»(ref-539174-S20195020062013040100000) (307-01 Automatic Transmission - Vehicles With: Automatic Transmission - HF35, General Procedures).
WARNINGBefore beginning any service procedure in this section, refer to HEALTH AND SAFETY PRECAUTIONS Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

Scheme 100

Scheme 100

Scheme 101

Scheme 101

Scheme 102

Scheme 102
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-539149-S05516616262013040100000) (100-00 General Information, Description and Operation).
  2. Refer to: «ACTIVE GRILLE SHUTTER»(ref-539194-S34547364872013040100000) (501-02 Front End Body Panels, Removal and Installation).
  3. NOTE: Use a Jiffy-tite quick disconnect tool, close the tool around the tube, press the tool into the fitting and rotate until the tool is fully seated into the fitting.

Scheme 103

Scheme 103: Installation
  1. Backing ring (7J324)
  2. Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid / XT-10-QLVC (WSS-M2C938-A) (MERCON® LV)
  3. Torque: 9 Nm
  4. Backing ring (7J324)
  5. Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid / XT-10-QLVC (WSS-M2C938-A) (MERCON® LV)
  6. Torque: 9 Nm
  7. Backing ring (7J324)
  8. Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid / XT-10-QLVC (WSS-M2C938-A) (MERCON® LV)
  9. Torque: 9 Nm Backing ring (7J324) Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid / XT-10-QLVC (WSS-M2C938-A) (MERCON® LV)
  10. Torque: 9 Nm
  11. NOTE: To ensure the transmission fluid cooler tubes are secure, push, pull then push the transmission cooler tubes on the transmission fluid cooler.
  12. Backing ring (7J324)
  13. Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid / XT-10-QLVC (WSS-M2C938-A) (MERCON® LV)
  14. Torque: 25 Nm
  15. Refer to: «ACTIVE GRILLE SHUTTER»(ref-539194-S34547364872013040100000) (501-02 Front End Body Panels, Removal and Installation).
  16. Refer to: «TRANSMISSION FLUID LEVEL CHECK»(ref-539174-S20195020062013040100000) (307-01 Automatic Transmission - Vehicles With: Automatic Transmission - HF35, General Procedures).

Removal and Installation

  1. NOTE: The transmission fluid cooler is part of an assembly. If installation of a new transmission fluid cooler is required, Refer to: «RADIATOR»(ref-539175-S17604134622013040100000) (303-03B Electric Powertrain Cooling, Removal and Installation).
WARNINGBefore beginning any service procedure in this section, refer to HEALTH AND SAFETY PRECAUTIONS Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

Scheme 104

Scheme 104

Scheme 105

Scheme 105

Scheme 106

Scheme 106
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-539149-S05516616262013040100000) (100-00 General Information, Description and Operation).
  2. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-539167-S37930574612013040100000) (100-02 Jacking and Lifting, Description and Operation).

Installation

  1. Backing ring (7J342)
  2. Seal (7D258)
  3. Torque: 25 Nm
  4. Backing ring (7J342)
  5. Seal (7D258)
  6. Torque: 9 Nm
  7. Backing ring (7J342)
  8. Seal (7D258)
  9. Torque: 25 Nm
  10. Refer to: «TRANSMISSION FLUID LEVEL CHECK»(ref-539174-S20195020062013040100000) (307-01 Automatic Transmission - Vehicles With: Automatic Transmission - HF35, General Procedures).
