Automatic Transaxle External Controls: Removal & Installation Ford Grand C-MAX II

Automatic Trans 14 illustrations ~268 words

Removal

Note. Removal steps in this procedure may contain installation details.

Scheme 80

Scheme 80: Removal
Scheme 80: Removal
  1. Refer to: «FLOOR CONSOLE»(ref-539192-S31928675202013040100000) (501-12 Instrument Panel and Console, Removal and Installation). Torque : 9 Nm Torque : 7 Nm

Installation

  1. To install, reverse the removal procedure.
  2. Adjust the selector lever cable when a new selector lever is installed. Refer to: «SELECTOR LEVER CABLE ADJUSTMENT»(ref-539203-S40933444312013040100000) (307-05 Automatic Transmission External Controls, General Procedures).

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85
  1. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-539167-S37930574612013040100000) (100-02 Jacking and Lifting, Description and Operation).
  2. Refer to: «AIR CLEANER»(ref-539209-S08535137802013040100000) (303-12 Intake Air Distribution and Filtering, Removal and Installation).
  3. Refer to: «FLOOR CONSOLE»(ref-539192-S31928675202013040100000) (501-12 Instrument Panel and Console, Removal and Installation).

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88
  1. Torque : 9 Nm Torque : 10 Nm Torque : 25 Nm
  2. Torque : 7 Nm
  3. Refer to: «FLOOR CONSOLE»(ref-539192-S31928675202013040100000) (501-12 Instrument Panel and Console, Removal and Installation).
  4. Torque : 10 Nm
  5. Torque : 7 Nm
  6. Refer to: «AIR CLEANER»(ref-539209-S08535137802013040100000) (303-12 Intake Air Distribution and Filtering, Removal and Installation).
  7. Rotate the selector shaft lever clockwise until it stops. Rotate the selector shaft lever counterclockwise 3 detents. Move the slide to the left. While holding the slide, position the adjuster lock upward.
  8. Verify that the vehicle only starts in PARK and NEUTRAL and the reverse lamps illuminate in REVERSE.

Note. The grade assist switch is part of the selector lever knob. To install a new grade assist switch, a new selector lever knob must be installed.

Scheme 89

Scheme 89: Removal
Scheme 89: Removal

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93
  1. To install, reverse the removal procedure.
