Special Tool(s) / General Equipment
205-153 (T80T-4000-W) Handle 307-626 Installer, Differential Seal TKIT-2008ET-FLM TKIT-2008ET-ROW Puller Punch
Scheme 40
205-153 (T80T-4000-W) Handle 307-626 Installer, Differential Seal TKIT-2008ET-FLM TKIT-2008ET-ROW Puller Punch
307-694 Installer, Manual Lever Seal Punch
Scheme 41
303-290-05A Adapter for 303-290A 303-F072 Support Bar, Engine
Scheme 42
307-694 Installer, Manual Lever Seal
307-586 Differential bearing cup remover TKIT-2006UF-FLM TKIT-2006UF-ROW 308-001 (T58L-101-B) Remover, Pilot Bearing Hydraulic Press Puller Punch
Scheme 43
| WARNING | Before beginning any service procedure, refer to HEALTH AND SAFETY PRECAUTIONS Safety Warnings in information 100-00 General Information. Failure to follow this instruction may result in serious personal injury. |
Pinpoint Test C
- NOTE: Release the clip behind the TFT sensor.
- click to open the image
- click to open the image
- Position the Differential Bearing Cup Remover 307-586 in the transmission case with the tabs on the Differential Bearing Cup Remover 307-586 aligned with the slots in the transmission case. Special Tool(s): 307-586 Differential bearing cup remover
- Expand the Differential Bearing Cup Remover 307-586 by hand.
- While holding the Differential Bearing Cup Remover 307-586 in the expanded position with the tabs in the slots of the transmission case, tighten the nut. click to open the image
- General Equipment: Hydraulic Press
- click to open the image
- click to open the image
- Position the Differential Bearing Cup Remover 307-586 in the damper housing with the tabs on the Differential Bearing Cup Remover 307-586 aligned with the slots in the damper housing. Special Tool(s): 307-586 Differential bearing cup remover
- Expand the Differential Bearing Cup Remover 307-586 by hand.
- While holding the Differential Bearing Cup Remover 307-586 in the expanded position with the tabs in the slots of the damper housing, tighten the nut. click to open the image
- General Equipment : Hydraulic Press
- click to open the image
204-069 (T81P-1104-C) Remover/Installer, Front Wheel Hub 307-587 Differential bearing installer and guide TKIT-2006UF-FLM TKIT-2006UF-ROW Hydraulic Press Puller
204-029 Drawbar 205-153 (T80T-4000-W) Handle 307-435 Installer, Extension Housing Seal TKIT-2002N-F/FM TKIT-2002N-FLM TKIT-2002N-LM 307-541 Installer, Transfer Gear Bearing TKIT-2005D1-F 307-576 Bearing Cup Installer TKIT-2006UF-FLM TKIT-2006UF-ROW 307-591 Shim Gauge, Differential/Transfer Gear Bearing TKIT-2006UF-FLM TKIT-2006UF-ROW 307-626 Installer, Differential Seal TKIT-2008ET-FLM TKIT-2008ET-ROW 307-689 Installer, Bearing Cup 307-692 Tool, Transfer Gear Preload 307-693 Installer, Transfer Gear Bearing Cup Feeler Gauge Hydraulic Press
