Automatic Transaxle: Other Ford Grand C-MAX II

Differential Bearing Preload Shim Selection Chart

Transfer Gear Bearing Preload Shim Selection Chart

Scheme 51

Scheme 52

Scheme 53

The TCM is also referred to as the SOBDMC . The TCM is a DC to AC inverter that supplies current to the electric motor and generator/starter and converts AC from the motor and generator/starter to DC to charge the high voltage batteries.

Scheme 54

Scheme 55

TCM

The TCM is also referred to as the Secondary On Board Diagnostics Module C (SOBDMC). The TCM is a DC to AC inverter that supplies current to the electric motor and generator/starter and converts AC from the motor and generator/starter to DC to charge the high voltage batteries. For additional information, Refer to ENGINE CONTROLS - INTRODUCTION (HYBRID) .

Network Message Chart

Scheme 56

The TFT sensor is a thermistor located on the internal transmission harness. It sends a voltage signal to the TCM . The voltage signal varies with TFT . The TFT sensor can not be serviced in vehicle, the transmission must be removed and disassembled.

The TR sensor assembly is an internally mounted sensor that includes the detent bracket. The components of the TR sensor are factory adjusted and installed as a calibrated assembly. The TR sensor contains electronic circuitry that provides the PCM a fixed frequency duty cycle for each of the various positions of the manual lever (PARK, REVERSE, NEUTRAL, DRIVE and LOW). The TR sensor cannot be serviced in vehicle, the transmission must be removed and disassembled. The PCM uses the TR sensor signal for range selection, torque calculation and reverse lamp operation.

Scheme 57

Scheme 58

In electric mode, torque flows from the electric motor to the transfer shaft and to the final drive ring gear. When the engine is off, the planetary carrier is held and the planetary ring gear is driven by the transfer shaft. This action causes the sun gear and the generator/starter to rotate. Under certain conditions, the SOBDMC will command the generator/starter to produce electricity for the electric motor and to charge the batteries.

Scheme 59

To start the engine, the final drive works as a holding element to the ring gear in the planetary assembly. The generator/starter turns the sun gear to start the engine.

Scheme 60

To charge the batteries, the final drive works as a holding element to the ring gear in the planetary assembly. The engine turns the carrier. This actions allows the generator/starter to produce current to charge the batteries and power the electric motor.

Regenerative Braking

When additional torque is needed to propel the vehicle, the generator/starter works as a holding element to the planetary sun gear. The flow of torque from the transfer shaft to the planetary ring gear is reversed and torque from the engine combines with the electric motor torque at the transfer shaft.

Scheme 61

Scheme 62

The transmission fluid pump is an internal pump bolted to the transmission case. The transmission fluid pump is turned by the input shaft and circulates transmission fluid through the transmission for lubrication and through an oil-to-air cooler mounted in the front of the radiator for transmission cooling. The transmission fluid pump only operates when the engine is running.

Scheme 63

The transmission fluid pump is an internal pump bolted to the transmission case. The transmission fluid pump is turned by the input shaft and circulates transmission fluid through the transmission for lubrication and through an oil-to-air cooler mounted in the front of the radiator for transmission cooling. The transmission fluid pump only operates when the engine is running. PHEV also have an electric auxiliary transmission fluid pump to circulate the transmission fluid during extended drive times without engine charging. The auxiliary transmission fluid pump is controlled by the TCM .

Scheme 64

This transmission has one simple planetary gear set. The planetary gear set is used to match the vehicle speed to the desired engine speed for maximum efficiency.

The ring gear is connected to the transmission final drive though the middle gear on the transfer shaft. The ring gear rotates when the vehicle is moving.

The planetary carrier is splined to the transmission input shaft and is connected to the engine. The carrier rotates with the engine crankshaft. The planetary carrier is also used to drive the hydraulic fluid pump.

The sun gear is splined to the generator/starter.

Scheme 65

The final drive gear is meshed with the transfer shaft and bolted to the differential case. The ring gear bolts are one time use bolts. Use new bolts when installing the ring gear.

Scheme 66

The differential allows the halfshafts and wheels to rotate at different speeds during cornering. The differential assembly consists of the following components

1. Differential carrier
2. Two pinion gears
3. Two side gears

When driving in a straight line, both front wheels rotate at relatively the same speed. This means both side gears are rotating at the same speed as well, while both pinion gears revolve (but do not spin) with the side gears in the differential carrier. During cornering, the wheel on the outside of the turn is forced to rotate faster than the wheel on the inside of the turn. Since the side gears must now rotate at different speeds, the pinion gears rotate on the pinion shaft allowing the drive axles to rotate at different speeds while still transferring output torque.

Transmission Range Sensor

Using the diagnostic scan tool, the TR sensor Diagnostic Trouble Codes (DTCs) are located within the SOBDMC/ TCM.

Possible Sources

1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
2. TR sensor
3. PCM

1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
2. TFT sensor
3. SOBDMC / TCM

Using the diagnostic scan tool, the TR sensor Diagnostic Trouble Codes (DTCs) are located within the SOBDMC / TCM .

1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
2. TR sensor
3. PCM

1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
2. TFT sensor
3. SOBDMC / TCM

1. Connectors damaged or pushed-out terminals, corrosion, loose wires and missing or damaged seals
2. BJB fuse 17 (20A)
3. BJB fuse 19 (5A)
4. Transmission fluid auxiliary pump
5. SOBDMC / TCM

Materials

Scheme 67

Scheme 68

1. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-539167-S37930574612013040100000) (100-02 Jacking and Lifting, Description and Operation).
2. Torque: 8 Nm

Scheme 69

Scheme 70

1. Remove the following items: Refer to: «AIR CLEANER»(ref-539209-S08535137802013040100000) (303-12 Intake Air Distribution and Filtering, Removal and Installation). Refer to: «AIR CLEANER OUTLET PIPE»(ref-539209-S33663050852013040100000) (303-12 Intake Air Distribution and Filtering, Removal and Installation). Refer to: «COWL PANEL»(ref-539194-S19601587112013040100000) (501-02 Front End Body Panels, Removal and Installation).
2. Material: Motorcraft® MERCON® LV Automatic Transmission Fluid / XT-10-QLVC (WSS-M2C938-A) (MERCON® LV) Torque: 35 Nm
3. Refer to: «AIR CLEANER»(ref-539209-S08535137802013040100000) (303-12 Intake Air Distribution and Filtering, Removal and Installation). Refer to: «AIR CLEANER OUTLET PIPE»(ref-539209-S33663050852013040100000) (303-12 Intake Air Distribution and Filtering, Removal and Installation). Start the engine and allow to run for 1 minute. Turn engine off and wait 5 minutes. Allow the excess fluid to drain. The fluid should be even with the bottom of the oil leveling plug hole. Torque: 8 Nm
4. Refer to: «COWL PANEL»(ref-539194-S19601587112013040100000) (501-02 Front End Body Panels, Removal and Installation).

Check

Scheme 71

Scheme 72

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-539149-S05516616262013040100000) (100-00 General Information).
2. Start the engine and allow to run for 1 minute. Turn engine off and wait 5 minutes.
3. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-539167-S37930574612013040100000) (100-02 Jacking and Lifting).
4. The transmission fluid should be even with the bottom of the oil leveling plug hole. If the transmission fluid is not even with the oil leveling plug hole, add clean transmission fluid. Material: Motorcraft® MERCON® LV Automatic Transmission Fluid / XT-10-QLVC (WSS-M2C938-A) (MERCON® LV) Torque: 8 Nm

Configuration

Transmission

Note. The transmission cannot be removed from the vehicle separate from the engine. Refer to REMOVAL engine removal to remove the transmission. Separate the transmission from the engine following the additional steps in this procedure.

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-539149-S05516616262013040100000) (100-00 General Information, Description and Operation).
2. Refer to: «TRANSMISSION»(ref-539174-S04554186622013040100000) (307-01 Automatic Transmission - Vehicles With: Automatic Transmission - HF35, Removal and Installation).

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-539149-S05516616262013040100000) (100-00 General Information, Description and Operation).
2. Refer to: «TRANSMISSION»(ref-539174-S04554186622013040100000) (307-01 Automatic Transmission - Vehicles With: Automatic Transmission - HF35, Removal and Installation).
