MODULE/PROGRAMMING ORDER REPLACEMENT GUIDE

Match the module row with the condition that applies, after module replacement follow the chart down and program the modules in the chart order.

INSTALLATION

Note. LHD shown in illustration, RHD similar.

Note. If the Antilock Brake System (ABS) module is replaced it must be initialized using the scan tool.

1. With the ABS module (3) forward of the brake lines (4), move the module (3) toward the outside of the vehicle and around the brake lines (4) in order to align it with the HCU (1).
2. Align the ABS module contact tower (2) and the tower receiving hole of the Hydraulic Control Unit (1) and put ABS module (3) and the HCU (1) together without touching the tower terminals to any solenoids. NOTE: For ease of installation, place the RH bottom ABS Module retaining screw in position in the module prior to installing the module on the HCU. NOTE: Tighten the ABS module screws (2) in a crisscross pattern.
3. Install the four ABS module screws (2) securing the module (1) to the HCU and tighten to 2.9 N.m (25.5 in. lbs.).
4. Reconnect the HCU electrical connector (3).
5. Install negative battery cable to the battery.
6. Install the air cleaner body, refer to «BODY, AIR CLEANER»(ref-465933-S12281486612012042300000) or «BODY, AIR CLEANER»(ref-465934-S05869443912012042300000) .
7. Connect the scan tool and initialize the ABS module by performing the ABS VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465938-S29477186702012042300000) .

Scheme 21

Blind Spot Module (1) - Vehicles equipped with the blind spot monitor system include a module which is secured to a mounting bracket by two integrated latches and mounted in the electronic module tub (2), located beneath the left front seat assembly where it is concealed beneath a cover panel.

Hardwired circuitry connects the various blind spot monitor system components to each other through the electrical system of the vehicle. These hardwired circuits are integral to several wire harnesses, which are routed throughout the vehicle and retained by many different methods. These circuits may be connected to each other and to the vehicle electrical system through the use of a combination of soldered splices, splice block connectors, and many different types of wire harness terminal connectors and insulators. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, further details on wire harness routing and retention, as well as pin-out and location views for the various wire harness connectors, splices and grounds.

The blind spot monitor system components cannot be adjusted or repaired. If any of the BSM system components are damaged or inoperative, that component must be replaced. For more information on the blind spot monitor system and its components. Refer to DESCRIPTION .

REMOVAL

1. Position the left front seat to its full forward position.
2. Disconnect and isolate the negative battery cable, for battery location and disconnect procedure. Refer to «CABLES, BATTERY, REMOVAL»(ref-465932-S24943704712012042300000) .
3. Remove the cover panel from the electronic module tub (2) to access the blind spot module (1).
4. Disconnect the body wire harness connector (3) from the module connector receptacle (4).
5. Release integral latches that secures the module to the mounting bracket and slide the module upward.
6. Remove the module from the vehicle.

1. Position the blind spot module (1) in the mounting bracket.
2. Slide the module into place until the locking tabs are secure.
3. Connect the body wire harness connector (3) to the module connector receptacle (4).
4. Install the cover panel onto the electronic module tub.
5. Connect the negative battery cable., for battery location and cable connection procedure. Refer to «CABLES, BATTERY, INSTALLATION»(ref-465932-S15625009942012042300000) .

Scheme 22

The Remote Compass Module (RCM) (2) is a separate stand alone module mounted to the top side of the headliner (1) at the left rear of the vehicle. The RCM can be accessed by removing both quarter trim panels and the headliner molding, then carefully lowering the rear of the headliner at the D-pillar area.

If the compass position sensor (Remote Compass Module) is inoperative and requires replacement. Refer to MODULE, COMPASS, REMOVAL .

Scheme 23

1. Disconnect and isolate the negative battery cable.
2. Partially remove the headliner (1) to gain access to the Remote Compass Module (RCM) (2). Refer to «HEADLINER, REMOVAL»(ref-465921-S32112500962012042300000) .
3. Disconnect the RCM electrical connector (3).
4. Remove the RCM fasteners (4).
5. Remove the RCM (2) from the vehicle.

Scheme 24

1. Position the Remote Compass Module (RCM) (2) into the bracket on the upper side of the headliner (1).
2. Install the RCM fasteners (4).
3. Connect the electrical connector (3).
4. Install the headliner assembly. Refer to «HEADLINER, INSTALLATION»(ref-465921-S00140682502012042300000) .
5. Connect the negative battery cable.
6. Perform the Compass Variance Adjustment. Refer to «MODULE, COMPASS, STANDARD PROCEDURE»(ref-465952-S29964811602012042300000) .
7. Perform the Manual Compass Calibration. Refer to «MODULE, COMPASS, STANDARD PROCEDURE»(ref-465952-S29964811602012042300000) .
8. Verify proper compass operation.

Scheme 25

This vehicle is equipped with two electronic front door control modules (1) (also known as a Driver Door Module/DDM, a Passenger Door Module/PDM or Front Door Multiplex/MUX Modules), one each on both the driver and passenger front doors. Each door control module is concealed behind the front door trim panel where it is secured through two integral mounting tabs (2) to the door hardware module carrier by two screws. The front door control modules are located in the upper front corner of the front door hardware carriers, just below the mirror flag area of the front door.

Each door control module contains a microprocessor and is connected to the various switches on that door. In the case of the driver side module, it communicates with some switches over a Local Interface Network (LIN) data bus. Both the driver and passenger side module also receive various hard wired switch inputs and provide numerous hard wired outputs to various devices located on their respective doors. In addition, both front door control modules communicate with each other and with other electronic modules in the vehicle over the Controller Area Network (CAN) Interior High Speed (IHS) data bus system.

Concealed and protected within the molded plastic door control module housing is the printed circuit board and the other electronic circuitry of the module. The front door control modules are connected to the vehicle electrical system through up to eight connector receptacles that are integral to the module housing.

A door control module cannot be adjusted or repaired and, if damaged or ineffective, it must be replaced. The door control module software is flash programmable.

1. Position the door control module (2) to the front door hardware module carrier (1).
2. Install and tighten the two screws (3) that secure the door control module to the front door hardware module carrier. Tighten the screws securely.
3. Reconnect each of the electrical connectors to the connector receptacles of the door control module.
4. Reinstall the lower trim panel to the inside of the front door. Refer to «PANEL, DOOR TRIM, INSTALLATION»(ref-465921-S39034601642012042300000) .
5. Reconnect the battery negative cable.
6. The Clear/Relearn procedure should be performed following service of a door control module so that the module can learn the correct hard stops of the power window regulator. Refer to «STANDARD PROCEDURE»(ref-465953-S24246852972012042300000) .

Scheme 26

The Drive Train Control Module (DTCM (3) is a microprocessor-based assembly, controlling a 4X4 Transfer Case. Communication is via the CAN serial bus. Inputs include user selectable 4X4 modes that include 4WD Full Time (4HI), 4LO, Neutral. The logic and driver circuitry is contained in aluminum housing base and a stamped steel housing cover with an embedded heat sink

The DTCM is installed inside the passenger compartment underneath the driver seat.

1. Position the left front seat to its full forward position.
2. Disconnect and isolate the negative battery cable, for battery location and disconnect procedure. Refer to «CABLES, BATTERY, REMOVAL»(ref-465932-S24943704712012042300000) .
3. Remove the cover panel from the electronic module tub (4) to access the Drive Train Control Module (DTCM) (3).
4. Disconnect the body wire harness connector from the module connector receptacle.
5. Release integral latches that secures the module to the mounting bracket and slide the module upward.
6. Remove the module from the vehicle.

1. Position the Drive Train Control Module (DTCM) (3) in the mounting bracket.
2. Slide the module into place until the locking tabs are secure.
3. Connect the body wire harness connector to the module connector receptacle.
4. Install the cover panel onto the electronic module tub (4).
5. Connect the negative battery cable., for battery location and cable connection procedure. Refer to «CABLES, BATTERY, INSTALLATION»(ref-465932-S15625009942012042300000) .

Note. There is no internal service of the Electro-Hydraulic Power Steering (EHPS) module. The EHPS module is integral to the EHPS pump. Replace the EHPS module as an assembly, including the brackets, and EHPS pump.

For replacement of the EHPS module. Refer to PUMP, REMOVAL .

Note. There is no internal service of the Electro-Hydraulic Power Steering (EHPS) module. The EHPS module is integral to the EHPS pump. Replace the EHPS module as an assembly, including the brackets, and EHPS pump.

For installation of the EHPS module. Refer to PUMP, INSTALLATION .

Scheme 27

Vehicles equipped with the optional High Intensity Discharge (HID) headlamps are also equipped with an Automatic Headlamp Leveling Module (AHLM) (1) (also known as the Headlamp Leveling Module/HLM). The AHLM is located on the underside of the right front lamp unit housing, but serves both the right and left front lamp units. This module works in conjunction with the front and rear axle sensors and the headlamp leveling motors to provide automatic headlamp beam adjustment to compensate for changes in vehicle height caused by changes in vehicle loading, acceleration or deceleration.

The molded black plastic AHLM housing has integral mounting flanges (4) that are secured by a stamped aluminum cover plate and four screws to a receptacle in the bottom of the right front lamp unit housing. Concealed within the housing is the circuitry of the module, which includes a microprocessor. The module is connected through an integral connector receptacle (2) to the vehicle electrical system by a take out and connector of the right front lamp unit wire harness.

The AHLM cannot be adjusted or repaired and, if ineffective or damaged, it must be replaced.

Scheme 28

1. Disconnect and isolate the battery negative cable.
2. Remove the right front lamp unit (1) from the vehicle. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-465935-S27724100512012042300000) .
3. Remove the four screws (2) that secure the cover plate and the Automatic Headlamp Leveling Module (AHLM) (3) (also known as the Headlamp Leveling Module/HLM) to the underside of the right front lamp unit housing.
4. Pull the AHLM away from the receptacle on the bottom of the right front lamp unit housing far enough to access and disconnect the front lamp unit wire harness connector from the connector receptacle on the upward-facing side of the AHLM.
5. Remove the AHLM from the lamp housing.

1. Position the Automatic Headlamp Leveling Module (AHLM) (3) (also known as the Headlamp Leveling Module/HLM) close enough to the receptacle on the bottom of the right front lamp unit housing (1) to reconnect the front lamp unit wire harness connector to the connector receptacle on the upward-facing side of the AHLM.
2. Position the AHLM into the receptacle on the bottom of the lamp housing.
3. Position the cover plate over the AHLM on the bottom of the lamp housing.
4. Install and tighten the four screws (2) that secure the cover plate and the AHLM to the lamp housing. Tighten the screws securely.
5. Reinstall the right front lamp unit into the vehicle. Refer to «UNIT, FRONT LAMP, INSTALLATION»(ref-465935-S17264028992012042300000) .
6. Reconnect the battery negative cable.

Note. On vehicles equipped with the optional High Intensity Discharge (HID) headlamps, when the Automatic Headlamp Leveling Module (AHLM) is replaced with a new unit, a diagnostic scan tool MUST be used to initialize and calibrate the new AHLM before the automatic headlamp leveling system can operate properly. Refer to MODULE, HEADLAMP LEVELING, STANDARD PROCEDURE .

Scheme 29

The Heated Seat Module (HSM) (1) is located under the front passenger seat. The HSM has multiple electrical connector outlets (2) and three retaining tabs (3 and 4) that secure it to a bracket that is mounted to the underside of the seat cushion frame.

The HSM is a microprocessor designed to use the Controller Area Network (CAN) data bus messages from the A/C-heater control to operate the front heated seats. When equipped with rear heated seats, the HSM receives request signals from the rear heated seat switches over hard-wired circuits.

1. Position the Heated Seat Module (HSM) (4) to the bracket (7) and engage the two retaining tabs (6). Make sure the retaining tabs are correctly engaged to the bracket.
2. Engage the HSM retaining tab (3) to the bracket. Make sure the retaining tab is fully engaged to the bracket.
3. Connect the electrical connectors (1, 2 and 5) to the HSM.
4. Position the bracket (2) containing the Heated Seat Module (HSM) (3) to the underside of the seat cushion frame (4) and engage the metal bracket retaining tab (5) to the seat cushion frame.
5. Install the two bolts (1) that secure the bracket to the underside of the seat cushion frame. Tighten the bolts securely.
6. Install the seat. Refer to «SEAT, FRONT, INSTALLATION»(ref-465921-S27937834052012042300000) or «SEAT, SECOND ROW, INSTALLATION»(ref-465921-S32138503162012042300000) or «SEAT, THIRD ROW, INSTALLATION»(ref-465921-S04854288032012042300000) .
7. Reconnect the negative battery cable.
8. Verify proper heated seat system operation.

Scheme 30

When equipped, the Memory Seat Module (MSM) (1) is located underneath the driver seat. It is used in conjunction with the other modules in the memory system to recall the driver seat to two different driver preset seat position preferences. The memory seat module is able to store and recall all driver side power seat positions (fore/aft, up/down, tilt and recline), outside mirror position, power steering column position and up to twelve radio station presets (six AM and six FM), on vehicles with a factory installed radio connected to the Controller Area Network (CAN) data bus network. The memory system will also store and recall the last radio station listened to for each driver, even if it is not one of the twelve preset stations.

The memory seat system will automatically recall the settings when a button of the memory switch located in the driver door trim panel is pressed, or when the doors are unlocked using the Remote Keyless Entry (RKE) transmitter (if the "RKE Linked to Memory" feature is enabled). If the vehicle has more than two drivers the RKE transmitter recall of memory features can be disabled. This is a customer programmable feature.

Note. The scan tool standardization process must be performed on the Memory Seat Module (MSM) any time a new MSM is installed or the existing MSM is reflashed.

Scheme 31

Note. Depending on how equipped, more memory seat module electrical connectors may be present than shown in the illustration.

1. Disconnect and isolate the negative battery cable.
2. Remove the fasteners that secure the driver seat to the body and tip the seat rearward to gain access to the underneath of the seat. Refer to «SEAT, FRONT, REMOVAL»(ref-465921-S04451249182012042300000) .
3. Disconnect the electrical connectors (3 and 6) from the Memory Seat Module (MSM) (1).
4. Disengage the two rear MSM retaining tabs (5 and 7) from the bracket (8) by carefully pushing the rear of the MSM upward.
5. Disengage the two front MSM retaining tabs (2 and 4) from the bracket by pulling the MSM rearward.
6. Remove the MSM from underneath the driver seat.

Note. Depending on how equipped, more memory seat module electrical connectors may be present than shown in the illustration.

1. Position the Memory Seat Module (MSM) (1) to the driver seat and engage the two front retaining tabs (2 and 4) to the bracket (8). CAUTION: Properly align the rear Memory Seat Module (MSM) retaining tabs to the bracket, prior to engagement. Failure to follow these instructions may result damage to the MSM rear retaining tabs.
2. Align the two rear MSM retaining tabs (5 and 7) to the bracket and carefully pull downward down on the MSM to engage the tabs. Make sure the retaining tabs are fully engaged to the bracket.
3. Connect the electrical connectors (3 and 6) to the MSM.
4. Install the driver seat. Refer to «SEAT, FRONT, INSTALLATION»(ref-465921-S27937834052012042300000) .
5. Reconnect the negative battery cable. NOTE: Anytime a new Memory Seat Module (MSM) is replaced, the MSM must be cleared of all learned parameters using a scan tool and the Power Seat System Verification test must be performed.
6. Using a scan tool, select Clear All MSM Learned Parameters, found under the Memory Seat Module, Miscellaneous Functions tab.
7. Perform the Power Seat System Verification test. Refer to «STANDARD PROCEDURE»(ref-465956-S41384634012012042300000) .
8. Verify proper memory seat system operation.

1. Position the park assist module (1) to the right inner quarter panel (2) and install the fasteners.
2. Connect the body wire harness connector (3) to the module connector receptacle (4). Vehicles with the front park assist option will have a second connection to the module at this location, which must also be reconnected.
3. Install the right quarter interior trim panel. Refer to «PANEL, QUARTER TRIM, INSTALLATION»(ref-465921-S22832939962012042300000) .
4. Connect the negative battery cable.

Scheme 32

The Passive Entry Module (PEM) (1) is the primary component of the Passive Entry (PE) and Keyless Go (KG) systems. The PEM contains both the Central Processor Unit (CPU) and Controller Area Network (CAN) data bus transceiver of the PE and KG systems, and is sometimes alternately referred to as the PEKG module or receiver. Concealed within the molded black plastic PEM housing is the printed circuit board and the other electronic circuitry of the module.

The PEM is secured by three screws to three tabs equipped with plastic nuts located on the outboard end of the air conditioning and heater unit blower housing beneath the passenger side end of the instrument panel. The PEM includes three integral mounting stanchions (2) and two connector receptacles (3) integral to the PEM housing. The connector receptacles contain all of the terminal pins that connect the PEM to the vehicle electrical system through two dedicated take outs and connectors of the instrument panel wire harness.

There are at least two unique hardware versions of the PEM. These versions are required in order to accommodate the unique data bus systems possibly found in Chrysler vehicles. The PEM used for this platform must be able to communicate with other electronic modules in the vehicle using the CAN-C data bus network. Refer to COMMUNICATION, DESCRIPTION .

The PEM cannot be adjusted or repaired and, if damaged or ineffective, it must be replaced. The PEM software is flash programmable.

Scheme 33

1. Disconnect and isolate the battery negative cable.
2. If the vehicle is so equipped, remove the closeout (hush) panel from under the passenger side end of the instrument panel.
3. From the passenger side of the vehicle, reach around the outboard end of the heater and air conditioner blower housing (1) to access and disconnect the two instrument panel wire harness connectors from the two Passive Entry Module (PEM) (2) connector receptacles (3).
4. Remove the three screws (4) that secure the PEM to the tabs on the blower housing.
5. Remove the PEM from the vehicle.

1. From the passenger side of the vehicle, position the Passive Entry Module (PEM) (2) to the outboard end of the heater and air conditioner blower housing (1).
2. Install and tighten the three screws (4) that secure the PEM to the tabs on the blower housing. Tighten the screws securely.
3. Reconnect the two instrument panel wire harness connectors to the two PEM connector receptacles (3).
4. If the vehicle is so equipped, reinstall the closeout (hush) panel under the passenger side end of the instrument panel.
5. Reconnect the battery negative cable.

Note. If the PEM is being replaced with a new unit, a diagnostic scan tool MUST be used to initialize and configure the new PEM. Follow the programming steps outlined in the diagnostic scan tool for Replace found under Miscellaneous Functions for the PEM/Passive Entry Module menu item.

Scheme 34

Vehicles equipped with an optional power-operated liftgate are equipped with a Power LiftGate Module (PLGM) (2) (also known as the Power LiftGate/PLG control module). The PLGM is concealed behind the trim on the inside of the left D-pillar below the belt line, where it is secured by two integral mounting tabs (4) and an integral latch tab (1) to slots in the inner D-pillar sheet metal.

Concealed and protected within the molded plastic housing of the PLGM is the printed circuit board and the other electronic circuitry of the module. The module contains a microprocessor and communicates with other electronic modules in the vehicle over the Controller Area Network (CAN) Interior High Speed (IHS) data bus system. Two connector receptacles (3) integral to the PLGM housing are connected to the vehicle electrical system through two dedicated take outs and connectors of the body wire harness.

A PLGM cannot be adjusted or repaired and, if damaged or ineffective, it must be replaced. The PLGM software is flash programmable.

1. Position the Power LiftGate Module (PLGM) (2) to the left lower inner D-pillar (1) in the vehicle.
2. Engage the two tabs integral to the lower end of the PLGM housing into the slots in the lower left inner D-pillar.
3. Press the top of the PLGM housing against the lower left inner D-pillar far enough for the latch feature integral to the upper end of the PLGM housing to engage the clearance hole in the inner D-pillar.
4. Reconnect the two body wire harness (3) connectors to the PLGM connector receptacles.
5. Reinstall the quarter trim panel to the lower left inner D-pillar. Refer to «PANEL, QUARTER TRIM, INSTALLATION»(ref-465921-S22832939962012042300000) .
6. Reconnect the battery negative cable.

Note. If a replacement power liftgate system component is installed or a mechanical liftgate adjustment is made, the PLGM must learn or relearn the effort and time required to open or close the liftgate. This learn/relearn cycle can be initiated using the power liftgate switches, using the Remote Keyless Entry (RKE) FOB with Integrated Key (FOBIK) or with a diagnostic scan tool connected to the Data Link Connector (DLC). Refer to MODULE, POWER LIFTGATE CONTROL, STANDARD PROCEDURE .

Scheme 35

The Powertrain Control Module (PCM) (1) is located in the engine compartment on the front of the Total Integrated Power Module (TIPM).

Labor Operations Table

Scheme 36

Scheme 37

1. Disconnect and isolate the negative battery cable.
2. Carefully unplug the 38-way connectors (2) from the PCM (1).
3. Remove the PCM retaining bolts (3).
4. Position the ground strap (2) aside.
5. Remove the PCM (1) from the mounting bracket located on the TIPM.

Labor Operations Table

Scheme 38

1. Position the PCM (1) onto the mounting bracket located on the TIPM.
2. Position the ground strap (2), install the retaining bolts (3) and tightened to 9 N.m (80 in. lbs.).
3. Check the pin connectors in the PCM. Also check the 38-way connectors (2) for corrosion or damage. Repair as necessary.
4. Carefully plug the 38-way connectors (2) into the PCM (1).
5. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.). NOTE: If the original Vehicle Identification Number (VIN) and original vehicle mileage is not programed into the PCM, a Diagnostic Trouble Code (DTC) may be set.
6. If installing a new PCM, use a diagnostic scan tool to reprogram the new PCM with the vehicles original VIN and mileage.

Scheme 39

The Steering Control Module (SCM) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud (1), the Steering Angle Sensor (SAS) (2), the clockspring (3), the multi-function switch (6), a steering column power tilt and telescope switch (5) for vehicles so equipped and a trim cover (4).

The SCCM is secured to the steering column by a unique mounting system using no external fasteners. The SCCM has two key stone features that snap into slots in the upper column jacket to secure the SCCM. In addition, a mechanical red indicator on the lower surface of the column shroud will be flush with the shroud surface when the SCCM is properly installed, but will stand proud of the shroud surface if the key stones are incompletely or improperly seated in the slots of the column jacket.

There are also unique lugs cast into the outer circumference of the steering wheel hub that must be engaged into slots within the inner circumference of the clockspring rotor hub to unlock and drive both the clockspring and the SAS, and the steering wheel must be tightened to specification to ensure proper clockspring and SAS function.

The SCCM includes an integral connector receptacle that faces toward the instrument panel and is connected to the vehicle electrical system through a single take out and connector of the instrument panel wire harness. The instrument panel wire harness take out has been intentionally provided with additional length to facilitate service removal and installation of the SCCM. However, following SCCM installation, this additional length must be pulled back and secured to the instrument panel structure to prevent the potential for undesirable rattling and buzzing noises while driving.

The SCM cannot be adjusted or repaired. If ineffective or damaged the entire SCCM unit must be replaced.

Scheme 40

1. Before reinstalling a Steering Column Control Module (SCCM) onto a steering column, clockspring centering must be confirmed by viewing the inspection window (3) on the clockspring rotor (1). If the black squares (2) on the clockspring tape are not visible through the inspection window, clockspring centering has been compromised and the SCCM MUST be replaced with a new unit.
2. Be certain that the front wheels are still in the straight ahead position.
3. If a new SCCM is being installed, disengage the steering column gap hider from the lower edge of the used SCCM shroud and transfer it to the new one.
4. Position the SCCM close enough to the top of the steering column to reach through the back of the gap hider and shroud to reconnect the instrument panel wire harness connector SCCM take out to the lower SCCM connector receptacle.
5. Align the hub of the SCCM with the upper steering column shaft (5) and jacket (3).
6. Slide the SCCM over the top of the steering column jacket far enough for the spring-loaded upper and lower keystones (6) to engage the slots (4) in the top and bottom of the steering column jacket.
7. Confirm that the keystones are fully engaged in the column jacket slots by inspecting the round red indicator (7) visible on the lower surface of the SCCM shroud. The indicator should be flush with the shroud. If the indicator stands proud of the shroud, the keystones are NOT fully engaged. Carefully slide the SCCM slightly up and down, or rotate it slightly right and left as necessary for the keystones to snap into their slots and the indicator to become flush with the shroud. NOTE: The service length of the instrument panel wire harness take out for the SCCM MUST be pulled back out of the SCCM shroud and secured to the instrument panel base trim. Failure to properly accomplish this task will result in unsatisfactory buzzes, squeaks or rattles during vehicle operation.
8. Pull the gap hider bezel up and away from the instrument panel far enough to access and engage the retainer clip (2) of the service length of the instrument panel wire harness SCCM take out to the instrument panel base trim (1) on the right side of the steering column opening.
9. Align and engage the snap clips that secure the molded hard plastic steering column gap hider bezel to the instrument panel.
10. If a new SCCM is being installed, remove (break off) the red locking tab that secures the clockspring rotor to the clockspring case.
11. Reinstall the steering wheel onto the upper steering column shaft. Be certain to align and insert the rotational lugs on the steering wheel hub into the slots in the hub of the clockspring. Also, the steering wheel fastener MUST be tightened to the proper torque specification to ensure proper clockspring and Steering Angle Sensor (SAS) operation. Refer to «WHEEL, STEERING, INSTALLATION»(ref-465942-S00017040732012042300000) .
12. Reconnect the steering wheel wire harness connectors to the upper SCCM connector receptacles.
13. Reinstall the driver airbag onto the steering wheel. Refer to «AIR BAG, DRIVER, INSTALLATION»(ref-465918-S09084676772012042300000) .
14. Reconnect the battery negative cable.

1. Connect the electrical connectors to the TIPM.
2. Align the tabs with the TIPM and push the TIPM down until it is fully seated.
3. Install the B+ cable (2) the TIPM.
4. Install and tighten the B+ retainer (1).
5. Close the TIPM cover.
6. Connect the negative battery cable.

Scheme 41

The transmission control module (TCM) (2) and mounting bracket (1) is mounted under the center dash panel, on the transmission hump.

The electronic control system consists of various components providing inputs to the TCM. The TCM monitors transmission sensors, shifter assembly, and bus messages to determine transmission shift strategy. After shift strategies are determined, the TCM controls the actuation of transmission solenoids, which controls the routing of hydraulic fluid within the transmission, by moving a sequence of four valves to make a shift occur.

The system performs its functions based on continuous real-time sensor feedback information. In addition the TCM receives information from the rest of the vehicle over the CAN C bus. The CAN C bus is a high-speed communication bus that allows real time control capability between various controllers. Most messages are sent every 20 milliseconds. This means critical information can be shared between the transmission, engine, and ABS controllers. The CAN C bus is a two wire bus with a CAN C Bus (+) circuit and a CAN C Bus (-) circuit. These circuits are twisted pairs in the harness to reduce the potential of radio and noise interference.

The transmission control system automatically adapts to changes in engine performance, vehicle speed, and transmission temperature variations to provide consistent shift quality. The control system ensures that clutch operation during up-shifting and downshifting is more responsive without increased harshness. The TCM activates the solenoid valves and moves valves in the valve body to achieve the necessary gear changes. The required pressure level is calculated from the load condition, engine speed. Vehicle speed (from ABS module) and transmission oil temperature, matched to the torque to be transmitted. Power for the transmission system is supplied through the shifter mechanism (no transmission control relay).

Scheme 42

The Transmission Control Module (TCM) is a sub-module within the Powertrain Control Module (PCM) (1). The PCM is located on the right side in front of the TIPM.

1. Insert the WIN and bracket up through the steering column opening.
2. From the steering column opening install the two lower WIN bracket retainers one on the bottom and one on the side (1).
3. Through instrument cluster opening, install the upper Wireless Ignition Node (WIN) bracket retainer.
4. Install the instrument cluster. Refer to «INSTALLATION»(ref-465951-S21963868172012042300000) .
5. Install the right side knee blocker support bracket.
6. Install the steering column opening cover. Refer to «COVER, STEERING COLUMN OPENING, INSTALLATION»(ref-465921-S38359398272012042300000) .
7. Install the drivers side silencer pad. NOTE: Passenger side shown in illustration, drivers side similar.
8. Install the drivers cowl trim panel. Refer to «PANEL, COWL TRIM, SIDE, INSTALLATION»(ref-465921-S00121233912012042300000) .
9. Install the drivers scuff plate. Refer to «PLATE, SCUFF, DOOR, INSTALLATION»(ref-465921-S01892873462012042300000) or «PLATE, SCUFF, LIFTGATE, INSTALLATION»(ref-465921-S19089732772012042300000) .
10. Connect the battery negative cable.

Note. On vehicles equipped with the Sentry Key Immobilizer System (SKIS), when the Wireless Ignition Node (WIN) is replaced with a new unit, a diagnostic scan tool MUST be used to initialize the new WIN and to program at least two Sentry Key FOBIK transponders before the vehicle can be operated. Refer to STANDARD PROCEDURE .

Note. Vehicles equipped with PEM: If the WIN is being replaced, a diagnostic scan tool MUST be used to initialize and configure the new PEM. Follow the programming steps outlined in the diagnostic scan tool for Replace found under Miscellaneous Functions for the PEM/Passive Entry Module menu item.

Note. On vehicles equipped with a premium Tire Pressure Monitoring (TPM) system, when the Wireless Ignition Node (WIN) or the spare tire pressure sensor is replaced with a new unit, a diagnostic scan tool MUST be used to run a routine that allows the WIN to be programmed with the ID number and location of the spare tire pressure sensor mounted in the wheel of the spare tire. This may be done using a TPM-RKE Analyzer special tool by following the programming steps outlined in the diagnostic scan tool for Program Tire Sensor ID w/TPM Tool under Miscellaneous Functions for the WIN menu item. If a TPM-RKE Analyzer special tool is not available, the spare tire must be dismounted from its wheel to access and note the ID number on the spare tire pressure sensor so that the ID code for that sensor can be programmed into the new WIN. Follow the programming steps outlined in the diagnostic scan tool for Learn Spare Tire Sensor ID under Miscellaneous Functions for the WIN menu item as appropriate. Refer to SENSOR, TIRE PRESSURE MONITORING (TPM), INSTALLATION .

Note. On vehicles equipped with a shaft lock module the WIN initialization procedure is required whenever the WIN or shaft lock module is replaced. Refer to STANDARD PROCEDURE .

Scheme 43

The adaptive speed control sensor (1) (also known as the Adaptive Cruise Control/ACC sensor or module, or the radar sensor or module) is located on a bracket secured near the center of the underside of the front bumper support member of the Front End Module (FEM) behind the front fascia. The stamped steel ACC sensor mounting bracket is secured by two screws to a bracket on the bumper support member. This sensor is also the primary component of the Forward Collision Warning (FCW) feature of the Electronic Vehicle Information Center (EVIC).

One fixed ball stud (4) and two adjustable ball studs (3) secure the sensor housing through a snap fit into three molded plastic ball socket clips installed in the mounting bracket. The sensor pivots on the fixed ball stud while the two adjustable ball studs allow the sensor to be vertically aligned after installation using an ACC vertical alignment special tool and a 3.5 millimeter hex nut driver special tool. Horizontal alignment is performed electronically using a diagnostic scan tool during a ten minute drive at a steady, predetermined speed following completion of the vertical alignment.

The ACC sensor electronic circuitry is sealed and protected within a die cast aluminum housing. A molded plastic cover and a lens or radar dome (5) faces forward through an opening in the center of the front fascia lower airflow grille texture that is trimmed with a bezel snapped into the texture opening. A molded plastic sensor bezel or mirror cover with a center clearance hole for the sensor lens snaps over the sensor and conceals a small square mirror in one corner of the sensor cover that is used for calibration purposes during the sensor manufacturing process.

The ACC sensor includes an applied connector receptacle (2) that is sealed and secured to the sensor housing with screws and faces downward when installed on the mounting bracket. The ACC sensor is connected to the vehicle electrical system through a single dedicated takeout and connector of the FEM wire harness.

The adjustable ball studs and the ACC sensor cannot be repaired. If ineffective or damaged the entire sensor unit must be replaced. The three plastic ball socket clips in the sensor mounting bracket must also be replaced each time the ACC sensor is removed from and reinstalled onto the mounting bracket.
