Driver Door Module (Ddm) (Dmfl) - Electrical Diagnostics: Diagnosis Dodge Durango III

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Scheme 207

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

DIAGNOSTIC TEST

1. TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase the DTCs. Operate the Driver Window/Door Lock Switch in lock and unlock positions several times. Cycle the ignition from on to off. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display; B1800-2A-DRIVER DOOR LOCK/UNLOCK SWITCH - SIGNAL STUCK IN RANGE? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. DOOR LOCK SWITCH Check the switch for any objects that could cause a sticking condition. Was anything found that could cause a sticking condition? Yes Clean or remove the object as necessary. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Replace the Driver Window/Door Lock Switch. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

Scheme 208

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase the DTCs. Operate the Front Left Window up and down several times. Wait 30 seconds. With the scan tool, read the active DTCs. Does the scan tool display: B18B5-00-MASTER SWITCH-FRONT LEFT WINDOW SWITCH as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Operate the switch several more times. If the switch ever sticks, replace it. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. MASTER POWER WINDOW/DOOR LOCK SWITCH NOTE: Anytime this code is active, the switch must be replaced. Repair Replace the Driver Window/Door Lock Switch in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase the DTCs. Operate the Front Right Window from the master switch up and down several times. Wait 30 seconds. With the scan tool, read the active DTCs. Does the scan tool display: B18B6-00-MASTER SWITCH-FRONT RIGHT WINDOW SWITCH as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Operate the switch several more times. If the switch ever sticks, replace it. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. MASTER POWER WINDOW/DOOR LOCK SWITCH NOTE: Anytime this code is active, the switch must be replaced. Repair Replace the Driver Window/Door Lock Switch in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase the DTCs. Operate the Rear Left Window, from the master switch, up and down several times. Wait 30 seconds. With the scan tool, read the active DTCs. Does the scan tool display: B18B7-00-MASTER SWITCH-REAR LEFT WINDOW SWITCH as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Operate the switch several more times. If the switch ever sticks, replace it. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. MASTER POWER WINDOW/DOOR LOCK SWITCH NOTE: Anytime this code is active, the switch must be replaced. Repair Replace the Driver Window/Door Lock Switch in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase the DTCs. Operate the Front Left Window up and down several times. Wait 30 seconds. With the scan tool, read the active DTCs. Does the scan tool display B18B8-00-MASTER SWITCH-REAR RIGHT WINDOW SWITCH as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Operate the switch several more times. If the switch ever sticks, replace it. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. MASTER POWER WINDOW/DOOR LOCK SWITCH NOTE: Anytime this code is active, the switch must be replaced. Repair Replace the Driver Window/Door Lock Switch in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. VERIFY IF DTC B1D00-2A MIRROR FOLD SWITCH INPUT STUCK IS ACTIVE Turn the ignition on. With the scan tool, erase the DTCs. Press the Mirror Fold Switch in both directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display active: B1D00-2A MIRROR FOLD SWITCH INPUT STUCK? Yes Replace the Drivers Window/Door Lock Switch in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. INSPECT DRIVER DOOR SWITCH ASSEMBLY FOR DAMAGE NOTE: Diagnose and repair all LIN Bus related Diagnostic Trouble Codes (DTCs) before performing this test procedure. Turn the ignition off. Inspect the Driver Power Window /Door Lock Switch assembly for damage. Is the switch assembly damaged? Yes Replace the Driver Power Window/Door Lock switch in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 2 .
2. INSPECT FOR OBJECT OR SUBSTANCE CAUSING MIRROR ADJUST SWITCH TO STAY OR STICK IN A PUSHED POSITION Inspect the Mirror Adjust switch for anything that would cause it to stay or stick in a pushed position. Is anything present that would cause the Mirror Adjust switch to stay or stick in a pushed position? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 3 .
3. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Using a scan tool, record and erase DTCs. Press and release the Mirror Select switch in all positions. Operate the Mirror Adjust switch in all positions several times and then wait 30 seconds. Using a scan tool, read the active DTCs. Does the scan tool display; B1D04-2A-MIRROR ADJUST SWITCH INPUT - SIGNAL STUCK IN RANGE as active? Yes Replace the Driver Power Window/Door Lock Switch in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. INSPECT DRIVER DOOR SWITCH ASSEMBLY FOR DAMAGE NOTE: Diagnose and repair all LIN Bus related Diagnostic Trouble Codes (DTCs) before performing this test procedure. Turn the ignition off. Inspect the Driver Door switch assembly for damage. Is the switch assembly damaged? Yes Replace the Driver Window/Door Lock Switch assembly in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 2 .
2. INSPECT FOR OBJECT OR SUBSTANCE CAUSING LEFT MIRROR SELECT SWITCH TO STAY OR STICK IN A PUSHED POSITION Inspect the Left Mirror Select switch for anything that would cause it to stay or stick in a pushed position. Is anything present that would cause the Left Mirror Select switch to stay or stick in a pushed position? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 3 .
3. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Using a scan tool, record and erase DTCs. Press and release the Left Mirror Select switch several times and then wait 30 seconds. Using a scan tool, read DTCs. Is the same DTC active? Yes Replace the Driver Window/Door Lock Switch assembly in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. INSPECT DRIVER DOOR SWITCH ASSEMBLY FOR DAMAGE NOTE: Diagnose and repair all LIN Bus related Diagnostic Trouble Codes (DTCs) before performing this test procedure. Turn the ignition off. Inspect the Driver Window/Door Lock Switch assembly for damage. Is the switch assembly damaged? Yes Replace the Driver Window/Door Lock Switch assembly in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 2 .
2. INSPECT FOR OBJECT OR SUBSTANCE CAUSING RIGHT MIRROR SELECT SWITCH TO STAY OR STICK IN A PUSHED POSITION Inspect the Right Mirror Select switch for anything that would cause it to stay or stick in a pushed position. Is anything present that would cause the Right Mirror Select switch to stay or stick in a pushed position? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 3 .
3. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Using a scan tool, record and erase DTCs. Press and release the Right Mirror Select switch several times and then wait 30 seconds. Using a scan tool, read the DTCs. Does the scan tool display; B1E65-00-RIGHT MIRROR SELECT SWITCH STUCK as active? Yes Replace the Driver Window/Door Lock Switch assembly in accordance with the Service Information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK ENGINE DTCs With the scan tool, read Powertrain Control Module DTCs. Are there any active Charging or Battery DTCs present? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the appropriate charging system or battery DTC diagnostic procedure . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase the DTCs. Start the engine and run for two minutes. With the scan tool, read the active door module DTCs. Does the scan tool display: B210C-17-BATTERY VOLTAGE INPUT - CIRCUIT VOLTAGE ABOVE THRESHOLD? Yes Replace the Driver Door Module in accordance with the Service Information. Refer to «MODULE, DOOR , REMOVAL»(ref-465939-S21196325252012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

This DTC is for information only. At some time the module was re-flashed or was reset during a power on operation. No repair is necessary.

1. CHECK ENGINE DTCs With the scan tool, read Powertrain Control Module DTCs. Are there any Charging or Battery DTCs present? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the active charging system or battery DTC diagnostic procedure . No This code is for information only. At some time there was a low battery system voltage. Check the battery and charging system in accordance with the Service Information.

1. CHECK ENGINE DTCs With the scan tool, read Powertrain Control Module DTCs. Are there any Charging or Battery DTCs present? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) and perform the active charging system or battery DTC diagnostic procedure . No This code is a CAN system message for information only. Check the charging system in accordance with the Service Information.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Operate the Driver Window switch up and down several times. Wait 30 seconds. With the scan tool, read the active DTCs. Does the scan tool display B2598-54-DOOR MODULE FRONT LEFT - MISSING CALIBRATION? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. WINDOW MODULE NOT CALIBRATED Activate the window to the full up position and continue to hold the switch for an additional two seconds. Activate the window to the full down position and continue to hold the switch for an additional two seconds. Again activate the window to the full up position and continue to hold the switch for an additional two seconds. Lower the window all the way down then press and release the switch to the express up position. Did the window move to the full up position? Yes Test complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 3 .
3. EXPRESS WINDOW SWITCH Turn the ignition off. Move the Driver Express Window Switch from the idle position to the up position and then to the express up position. Is there two definite detent positions felt? Yes Replace the Driver Door Module in accordance with the service information. Refer to «MODULE, DOOR , REMOVAL»(ref-465939-S21196325252012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Replace the Driver Express Window Switch in accordance with the service information. Refer to «SWITCH, POWER WINDOW , REMOVAL»(ref-465953-S23881180922012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase the DTCs. Operate the Driver Window up and down several times. Wait 30 seconds. With the scan tool, read the active DTCs. Does the scan tool display: B2598-96-DOOR MODULE FRONT LEFT - COMPONENT INTERNAL FAILURE? Yes Replace the Door Module in accordance with the Service Information. Refer to «MODULE, DOOR , REMOVAL»(ref-465939-S21196325252012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No The conditions that caused this code to set are not present at this time. If this code ever repeats, replace the door module in accordance with the Service Information. Refer to «MODULE, DOOR , REMOVAL»(ref-465939-S21196325252012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display; U0010-00-CAN INTERIOR BUS as active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0010-CAN Interior Bus diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

Scheme 209

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0164-Lost Communication with HVAC Control Module. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Does the scan tool display: U0203-00-LOST COMMUNICATION WITH DOOR MODULE FRONT LEFT as active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0203-Lost Communication with Door Module Front Left diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Does the scan tool display; U0204-00-LOST COMMUNICATION WITH DOOR MODULE FRONT RIGHT as active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0204-Lost Communication with Door Module Front Right diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Does the scan tool display; U0209-00-LOST COMMUNICATION WITH MEMORY SEAT CONTROL MODULE as active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0209-Lost Communication with Memory Seat Control Module diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display: U0232-00-LOST COMMUNICATION WITH BLIND SPOT DETECTION MODULE as active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0232-00 Lost Communication with Blind Spot Detection Module diagnostic procedure. No . Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.
