DIAGNOSIS AND TESTING

The hard wired circuits between components related to the electronic front door control modules (also known as a Driver Door Module/DDM, a Passenger Door Module/PDM or Front Door Multiplex/MUX Modules) may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the front door control modules or the electronic controls and communication between modules and other devices that provide some features of the door modules. The most reliable, efficient, and accurate means to diagnose the front door control modules or the electronic controls and communication related to module operation requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

START-UP DIAGNOSTICS

When the DTCM is activated, the internal circuitry will undergo a diagnostic procedure. The controller will examine all inputs and outputs for short circuits to ground, short circuits to battery and open circuits and will also verify proper CPU and memory operation. If a fault is detected, a message will be sent out over the CAN C bus to the Cluster based Electronic Vehicle Information Center EVIC indicating that service is recommended.

After passing all diagnostic tests, the controller will receive and process inputs and produce the appropriate outputs. Proper monitoring of the controller inputs and outputs performance will continue.

The hard wired circuits between components related to the headlamp leveling system and the Automatic Headlamp Leveling Module (AHLM) (also known as the Headlamp Leveling Module/HLM) may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the AHLM or the electronic controls and communication between modules and other devices that provide some features of the headlamp leveling system or the AHLM. The most reliable, efficient, and accurate means to diagnose the headlamp leveling system, the AHLM or the electronic controls and communication related to headlamp leveling or AHLM operation requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

The hard wired circuits between components related to the passive entry system and the Passive Entry Module (PEM) may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the PEM or the electronic controls and communication between modules and other devices that provide some features of the passive entry system or the PEM. The most reliable, efficient, and accurate means to diagnose the passive entry system, the PEM or the electronic controls and communication related to passive entry or PEM operation requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

The hard wired circuits between components related to the power liftgate system and the Power LiftGate Module (PLGM) (also known as the Power LiftGate/PLG control module) may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the PLGM or the electronic controls and communication between modules and other devices that provide some features of the power liftgate system or the PLGM. The most reliable, efficient, and accurate means to diagnose the power liftgate system, the PLGM or the electronic controls and communication related to power liftgate or PLGM operation requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

The hard wired circuits between components related to the Steering Column Control Module (SCCM) and the Steering Control Module (SCM) may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the SCCM, the SCM or the electronic controls and communication between modules and other devices that provide some features of the SCCM or SCM. The most reliable, efficient, and accurate means to diagnose the SCCM, the SCM or the electronic controls and communication related to SCCM or SCM operation requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

Scheme 16

Scheme 17

1. Place the front wheels in the straight ahead position.
2. Disconnect and isolate the battery negative cable.
3. Remove the driver airbag from the steering wheel. Refer to «AIR BAG, DRIVER, REMOVAL»(ref-465918-S42918776142012042300000) .
4. Disconnect the steering wheel wire harness connectors from the upper Steering Column Control Module (SCCM) connector receptacles.
5. Remove the steering wheel from the upper steering column shaft. Refer to «WHEEL, STEERING, REMOVAL»(ref-465942-S24027396162012042300000) .
6. Using a trim stick or another suitable wide flat-bladed tool, disengage the snap clips that secure the molded hard plastic outer edges of the steering column gap hider bezel to the instrument panel.
7. Pull the gap hider bezel up and away from the instrument panel far enough to access and disengage the retainer clip (2) of the service length of the instrument panel wire harness SCCM take out that secures it to the instrument panel base trim (1) on the right side of the steering column opening.
8. Firmly grasp each side of the SCCM shroud (2) on the edges nearest the instrument panel. Use a short, firm tug rearward on the shroud to disengage the spring-loaded upper and lower keystones (6) from the slots (4) in the top and bottom of the steering column jacket (3).
9. Pull the SCCM away from the top of the steering column far enough to reach through the back of the gap hider and shroud to access and disconnect the instrument panel wire harness connector from the lower SCCM connector receptacle.
10. Remove the SCCM from the vehicle.

DIAGNOSIS AND TESTING - FOBIK TRAPPED IN WIN

For more information. Refer to TRANSMITTER, INTEGRATED KEY FOB, DIAGNOSIS AND TESTING .

Scheme 18

Scheme 19

Scheme 20

1. Disconnect and isolate the negative battery cable. NOTE: Passenger side shown in illustration, drivers side similar.
2. Remove the drivers scuff plate. Refer to «PLATE, SCUFF, DOOR, REMOVAL»(ref-465921-S01157018472012042300000) or «PLATE, SCUFF, LIFTGATE, REMOVAL»(ref-465921-S22802627772012042300000) .
3. Remove the drivers cowl trim panel. Refer to «PANEL, COWL TRIM, SIDE, REMOVAL»(ref-465921-S36276791172012042300000) .
4. Remove the drivers side silencer pad.
5. Remove the steering column opening cover. Refer to «COVER, STEERING COLUMN OPENING, REMOVAL»(ref-465921-S13011093802012042300000) .
6. Remove the right side knee blocker support bracket.
7. Remove the instrument cluster. Refer to «REMOVAL»(ref-465951-S00141159402012042300000) .
8. Through instrument cluster opening, remove the upper Wireless Ignition Node (WIN) bracket retainer.
9. From the steering column opening remove the two lower WIN bracket retainers one on the bottom and one on the side (1).
10. Pull the WIN (2) and bracket down through the steering column opening.
11. Disconnect the antenna and electrical connector.

DIAGNOSIS AND TESTING - ACC SYSTEM

The hard wired circuits to the adaptive speed control sensor (also known as the Adaptive Cruise Control/ACC sensor or module, or the radar sensor or module) may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the ACC sensor or the electronic controls and communication between modules and other devices that provide some features of the adaptive speed control and Forward Collision Warning (FCW) systems. The most reliable, efficient, and accurate means to diagnose the ACC sensor or the electronic controls and communication related to adaptive speed control or FCW system operation requires the use of a diagnostic scan tool. Refer to DIAGNOSIS AND TESTING .
