C310 Chevrolet Silverado 3500

C310 Body Harness to Left Rear Door Harness Terminal Identification (Crew Cab) Connector Part Information 12177260 and 12177259 7-Way F GT 150 280 (BLK) and 10-Way F GT 150 280 (BLK) Connector Part Information 12177258 17-Way M Metri-Pack 150 280 (NAT) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A WHT 1185 Power Window Relay Left Rear Up Control (YE9) A WHT 1185 Power Window Relay Left Rear Up Control (YE9) B YEL 1187 Power Window Relay Left Rear Down Control (YE9) B YEL 1187 Power Window Relay Left Rear Down Control (YE9) C LT BLU 2265 Power Window Lockout Left Rear Control (YE9) C LT BLU 2265 Power Window Lockout Left Rear Control (YE9) D - - Not Used D - - Not Used E BRN/WHT 230 Instrument Panel Lamps Dimming Control (YE9) E BRN/WHT 230 Instrument Panel Lamps Dimming Control (YE9) F BLK 1150 Ground (YE9) F BLK 1150 Ground (YE9) G ORN 1240 Battery Positive Voltage (YE9) G ORN 1240 Battery Positive Voltage (YE9) H LT BLU/ BLK 747 Left Rear Door Ajar Switch Signal H LT BLU/ BLK 747 Left Rear Door Ajar Switch Signal J - - Not Used J - - Not Used K YEL 116 Left Rear Speaker Output (-) K YEL 116 Left Rear Speaker Output (-) L BRN 199 Left Rear Speaker Output (+) L BRN 199 Left Rear Speaker Output (+) M BLK 1150 Ground M BLK 1150 Ground N TAN 294 Door Lock Actuator Unlock Control N TAN 294 Door Lock Actuator Unlock Control P GRY 295 Door Lock Actuator Lock Control P GRY 295 Door Lock Actuator Lock Control R-T - - Not Used R-T - - Not Used

Scheme 158
