C220 Chevrolet Silverado 3500

C220 I/P Harness to Infotainment Jumper Harness Terminal Identification (UQ7 w/o Y91) Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRY) Connector Part Information 15305213 24-Way M Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 ORN 1044 Class 2 Serial Data A1 ORN 1044 Class 2 Serial Data A2-A7 - - Not Used A2-A7 - - Not Used A8 TAN 201 Left Front Speaker Output (+) A8 TAN 201 Left Front Speaker Output (+) A9 GRY 118 Left Front Speaker Output (-) A9 GRY 118 Left Front Speaker Output (-) A10 LT BLU 115 Right Rear Speaker Output (-) A10 LT BLU 115 Right Rear Speaker Output (-) A11 DK BLU 46 Right Rear Speaker Output (+) A11 DK BLU 46 Right Rear Speaker Output (+) A12 BLK/WHT 1851 Ground A12 BLK/WHT 1851 Ground B1 ORN 340 Battery Positive Voltage B1 ORN 340 Battery Positive Voltage B2-B7 - - Not Used B2-B7 - - Not Used B8 BRN 199 Left Rear Speaker Output (+) B8 BRN 199 Left Rear Speaker Output (+) B9 YEL 116 Left Rear Speaker Output (-) B9 YEL 116 Left Rear Speaker Output (-) B10 DK GRN 117 Right Front Speaker Output (-) B10 DK GRN 117 Right Front Speaker Output (-) B11 LT GRN 200 Right Front Speaker Output (+) B11 LT GRN 200 Right Front Speaker Output (+) B12 - - Not Used B12 - - Not Used

Scheme 152
