C206 Chevrolet Silverado 3500

C206 I/P Harness to Body Harness Terminal Identification (Y91/HP2) Connector Part Information 15317325 22-Way F Metri-Pack 150, 280 Series (LT GRY) Connector Part Information 15317322 22-Way M Metri-Pack 150, 280 Series (LT GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 - - Not Used A1 - - Not Used A2 YEL 354 Discriminating Sensor - Signal A2 YEL 354 Discriminating Sensor - Signal A3 GRY 349 Discriminating Sensor - Left - Signal A3 GRY 349 Discriminating Sensor - Left - Signal A4 LT BLU 115 Right Rear Speaker Output (-) A4 LT BLU 115 Right Rear Speaker Output (-) A5 DK BLU 46 Right Rear Speaker Output (+) A5 DK BLU 46 Right Rear Speaker Output (+) A6 TAN/WHT 2500 High Speed GMLAN Serial Data Bus+ (HP2) A6 TAN/WHT 2500 High Speed GMLAN Serial Data Bus+ (HP2) TAN/WHT 2500 High Speed GMLAN Serial Data Bus+ (HP2) A7 YEL 116 Left Rear Speaker Output (-) A7 YEL 116 Left Rear Speaker Output (-) A8 BRN 199 Left Rear Speaker Output (+) A8 BRN 199 Left Rear Speaker Output (+) A9 YEL 1834 Forward Discriminating Sensor Signal A9 YEL 1834 Forward Discriminating Sensor Signal A10 TAN/BLK 371 I/P Module Disable Switch - Signal (C99) A10 TAN/BLK 371 I/P Module Disable Switch - Signal (C99) A11 PNK 353 I/P Module Suppression Indicator Control (C99) A11 PNK 353 I/P Module Suppression Indicator Control (C99) B1 DK GRN 1409 Discriminating Sensor - Right - Signal B1 DK GRN 1409 Discriminating Sensor - Right - Signal B2 DK GRN 2164 Side Impact Sensor - Right - Signal (HP2) B2 DK GRN 2164 Side Impact Sensor - Right - Signal (HP2) B3 TAN 2163 Side Impact Sensor - Right - Voltage (HP2) B3 TAN 2163 Side Impact Sensor - Right - Voltage (HP2) B4 TAN 2501 High Speed GMLAN Serial Data Bus - (HP2) B4 TAN 2501 High Speed GMLAN Serial Data Bus - (HP2) TAN 2501 High Speed GMLAN Serial Data Bus - (HP2) B5 DK BLU/ WHT 2218 Serial Communications Circuit B5 DK BLU/ WHT 2218 Serial Communications Circuit B6 PNK 1020 Ignition 0 Voltage (HP2) B6 PNK 1020 Ignition 0 Voltage (HP2) B7 PNK 1939 Ignition 1 Voltage (HP2) B7 PNK 1939 Ignition 1 Voltage (HP2) B8 - - Not Used B8 - - Not Used B9 ORN 2740 Battery Positive Voltage (HP2) B9 ORN 2740 Battery Positive Voltage (HP2) B10-B11 - - Not Used B10-B11 - - Not Used

Scheme 149
