C202 Chevrolet Silverado 3500

C202 I/P Harness to Brake/Clutch Harness Terminal Identification Connector Part Information 15336209 12-Way F GT Mixed (BLK) Connector Part Information 15336205 12-Way M GT Mixed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PPL 420 TCC Brake Switch /Cruise Control Release Signal A PPL 420 TCC Brake Switch /Cruise Control Release Signal B DK GRN 1433 Clutch Start Switch Signal (Man Trans) B DK GRN 1433 Clutch Start Switch Signal (Man Trans) GRY/BLK 5689 Low Reference (HP2) GRY/BLK 5689 Low Reference (HP2) C PNK 639 Ignition 1 Voltage (w/o HP2) C PNK 639 Ignition 1 Voltage (w/o HP2) YEL 5066 Brake Pedal Position Sensor Signal (HP2) YEL 5066 Brake Pedal Position Sensor Signal (HP2) D DK GRN /WHT 1135 A/T Shift Lock Control Solenoid Supply Voltage D DK GRN /WHT 1135 A/T Shift Lock Control Solenoid Supply Voltage E LT GRN/ BLK 584 A/T Shift Lock Control Switch Supply Voltage E LT GRN/ BLK 584 A/T Shift Lock Control Switch Supply Voltage F BRN 441 Ignition 3 Voltage F BRN 441 Ignition 3 Voltage G ORN 1540 Battery Positive Voltage G ORN 1540 Battery Positive Voltage H WHT 17 Stop Lamp Switch Signal H WHT 17 Stop Lamp Switch Signal J LT BLU 1134 Park Brake Switch Signal J LT BLU 1134 Park Brake Switch Signal K GRY 48 CPP Switch Signal (Man Trans) K GRY 48 CPP Switch Signal (Man Trans) ORN 5688 5 Volt Reference (HP2) ORN 5688 5 Volt Reference (HP2) L-M - - Not Used L-M - - Not Used

Scheme 148
