C125 Chevrolet Silverado 3500

C125 Snowplow Harness to Forward Lamp Harness Terminal Identification (VYU) Connector Part Information 12047938 7-Way F Metri-Pack 150 Series Sealed (LT GRY) Connector Part Information 12047933 7-Way M Metri-Pack 150 Series Sealed (LT GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BRN 2309 Front Park Lamps Supply Voltage A BRN 2309 Front Park Lamps Supply Voltage B BRN 2309 Front Park Lamps Supply Voltage B BRN 2309 Front Park Lamps Supply Voltage C LT BLU 2114 Left Turn Signal Lamps Supply Voltage C LT BLU 2114 Left Turn Signal Lamps Supply Voltage D - - Not Available D - - Not Available E LT BLU 2114 Left Turn Signal Lamps Supply Voltage E LT BLU 2114 Left Turn Signal Lamps Supply Voltage F BLK 150 Ground F BLK 150 Ground G DK BLU 545 DRL Supply Voltage G DK BLU 545 DRL Supply Voltage H BLK 150 Ground H BLK 150 Ground

Scheme 142

Scheme 143
