C113 Engine Jumper Harness to Engine Harness Terminal Identification (LB7/LLY) Connector Part Information FW-C-6F-B 6-Way F (BLK) Connector Part Information FW-C-6M-B 6-Way M (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PNK/YEL - Ground A PNK/YEL - Ground B TAN/WHT 332 Oil Pressure Sensor Signal B TAN/WHT 332 Oil Pressure Sensor Signal C BRN 1174 Oil Level Switch Signal C BRN 1174 Oil Level Switch Signal D GRY 2705 5-Volt Reference D GRY 2705 5-Volt Reference E BLK 2755 Low Reference E BLK 2755 Low Reference F - - Not Used F - - Not Used
