C214 (U42) Chevrolet Silverado 3500

C214 I/P Harness to Headliner Harness Terminal Identification (U42) Connector Part Information 15332177 16-Way F GT 150 Series (BLK) Connector Part Information 15332182 16-Way M GT 150 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YEL/BLK 2516 Keypad Green LED Signal (UE1) A YEL/BLK 2516 Keypad Green LED Signal (UE1) B BRN/WHT 2517 Keypad Red LED Signal (UE1) B BRN/WHT 2517 Keypad Red LED Signal (UE1) C LT GRN/ BLK 2515 Keypad Supply Voltage (UE1) C LT GRN/ BLK 2515 Keypad Supply Voltage (UE1) D DK GRN /WHT 2514 Keypad Signal (UE1) D DK GRN /WHT 2514 Keypad Signal (UE1) E-G - - Not Used E-G - - Not Used H DK GRN /WHT 368 Remote Playback Device Right Audio Signal (U42) H DK GRN /WHT 368 Remote Playback Device Right Audio Signal (U42) J BRN/WHT 367 Remote Playback Device Left Audio Signal (U42) J BRN/WHT 367 Remote Playback Device Left Audio Signal (U42) K BLK/WHT 372 Radio On Signal (U42) K BLK/WHT 372 Radio On Signal (U42) L BARE 1573 Drain Wire (U42) L BARE 1573 Drain Wire (U42) M LT GRN/ BLK 1098 Class 2 Serial Data (U42) M LT GRN/ BLK 1098 Class 2 Serial Data (U42) N ORN 3240 Battery Positive Voltage (U42) N ORN 3240 Battery Positive Voltage (U42) P BLK/WHT 1851 Ground (U42) P BLK/WHT 1851 Ground (U42) R-S - - Not Used R-S - - Not Used

Scheme 150
