C223 Chevrolet Silverado 3500

C223 I/P Harness to Body Harness Terminal Identification (Except NYS and HP2) Connector Part Information 15305133 16-Way F GT 150, 280 Series (BLK) Connector Part Information 15305132 16-Way M GT 150, 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A DK BLU/ WHT 2218 Serial Communications Circuit A DK BLU 1128 SDM Class 2 Serial Data A BRN/WHT 1048 SCM (Seat) Class 2 Serial Data (AG2) B YEL 116 Left Rear Speaker Output (-) B YEL 116 Left Rear Speaker Output (-) C BRN 199 Left Rear Speaker Output (+) C BRN 199 Left Rear Speaker Output (+) D LT BLU 115 Right Rear Speaker Output (-) D LT BLU 115 Right Rear Speaker Output (-) E DK BLU 46 Right Rear Speaker Output (+) E DK BLU 46 Right Rear Speaker Output (+) F - - Not Used F - - Not Used G YEL 354 Discriminating Sensor - Signal G YEL 354 Discriminating Sensor - Signal H GRY 349 Discriminating Sensor - Left - Signal H GRY 349 Discriminating Sensor - Left - Signal J YEL 1834 Forward Discriminating Sensor Signal J YEL 1834 Forward Discriminating Sensor Signal K PNK 353 I/P Module Suppression Indicator Control (C99) L PNK 353 I/P Module Suppression Indicator Control (C99) L TAN/BLK 371 I/P Module Disable Switch - Signal (C99) K TAN/BLK 371 I/P Module Disable Switch - Signal (C99) M DK GRN 1409 Discriminating Sensor - Right - Signal M DK GRN 1409 Discriminating Sensor - Right - Signal N-S - - Not Used N-S - - Not Used

Scheme 154

Scheme 155
