Seat Frames (Coupe): Wiring Audi S5 I facelift

Seats 1 illustration ~311 words

HARNESS CONNECTORS, DISCONNECTING AND CONNECTING

Note. The connector coupling station is located in the vehicle floor under the front seat area.

Disconnecting and connecting the connectors on the manual standard front seat is described here. The procedure is similar for the bucket front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Scheme 132

Scheme 132: LOWER SEAT FRAME AND FRONT BACKREST OVERVIEW
Scheme 132: LOWER SEAT FRAME AND FRONT BACKREST OVERVIEW
  1. Screws 24 Nm Insert with locking compound. For locking compound.
  2. Bolt 4 Nm
  3. Handle For seat forward/back adjustment Removing and installing, refer to «SEAT FORWARD/BACK ADJUSTER RELEASE CABLE»(ref-520146-S18758372782012123100000)
  4. Bolt 24 Nm Insert with locking compound. For locking compound.
  5. Seat Pan Removing and Installing, refer to «SEAT PAN»(ref-520146-S20775121682012123100000)
  6. Bolt 20 Nm Insert with locking compound. For locking compound.
  7. Front Backrest Removing and installing, refer to «FRONT BACKREST»(ref-520146-S41449298762012123100000)
  8. Bolt 20 Nm Insert with locking compound. For locking compound.
  9. Pneumatic Hose From the module carrier with air cushions for lumbar support
  10. Electrical Wiring Harness
  11. Bolt 24 Nm Insert with locking compound. For locking compound.
  12. Seat Frame

Disconnecting and connecting the connectors on the manual standard front seat is described here. The procedure is similar for the manual sport front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

The following describes disconnecting and connecting the connectors for the manual standard front seat. The procedure is similar for the comfort front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING

The following describes disconnecting and connecting the connectors for the manual standard front seat. The procedure is similar for the power standard front seat.

Disconnecting and connecting the connectors on the manual standard front seat is described here. The procedure is similar for the manual sport front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Disconnecting and connecting the connectors on the manual standard front seat is described here. The procedure is similar for the super sport front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .
