Seat Frames (Cabriolet): Overview Audi S5 I facelift

SEAT VERSIONS OVERVIEW

Note. The illustration shows manual standard front seats.

Scheme 518

1. Front Passenger Seat Standard seat (manual) Assembly overview, refer to «STANDARD MANUAL FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S41336104562013011400000) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(ref-522379-S29082603452013011400000) Optional equipment: Seat and backrest heating Four-way lumbar support Storage compartment LATCH child seat anchor Power Standard Seat Assembly overview, refer to «POWER STANDARD FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S05169178602013011400000) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Memory function Seat and backrest heating Storage compartment LATCH child seat anchor Comfort Seats (power) Assembly overview, refer to «COMFORT FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S41653456402013011400000) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Memory function Storage compartment LATCH child seat anchor Manual Sport Seat with Seat Depth Adjuster Assembly overview, refer to «MANUAL SPORT FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S40371542512013011400000) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(ref-522379-S29082603452013011400000) Optional equipment: Seat and backrest heating Seat angle adjustment Cabin heater Storage compartment LATCH child seat anchor Power Sport Seat with Seat Depth Adjuster Assembly overview, refer to «POWER SPORT FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S21784417112013011400000) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Memory function Seat and backrest heating Cabin heater Storage compartment LATCH child seat anchor Super Sport Seats (power) Assembly overview, refer to «SUPER SPORT FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S26422294722013011400000) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Memory function Seat and backrest heating Storage compartment LATCH child seat anchor
2. Right Side Airbag Assembly overview, refer to «FRONT SIDE AIRBAG ASSEMBLY OVERVIEW»(ref-522301-S34741944562013011400000) Removing and installing, refer to «THORAX (SIDE) AIRBAG IGNITERS -N199- / -N200»(ref-522301-S02286298112013011400000)
3. Rear Seat Backrest Divided Assembly overview, refer to «REAR SEAT BACKREST ASSEMBLY OVERVIEW»(ref-522379-S22641538532013011400000) Removing and installing, refer to «REAR BACKREST»(ref-522379-S28247886592013011400000) Optional equipment: Rear seat backrest heating
4. Bench Seat One piece Assembly overview, refer to «BENCH SEAT ASSEMBLY OVERVIEW»(ref-522379-S22500886722013011400000) Removing and installing, refer to «BENCH SEAT»(ref-522379-S10250447682013011400000) Optional equipment: Seat bench heating Center storage compartment
5. Left Side Airbag Assembly overview, refer to «FRONT SIDE AIRBAG ASSEMBLY OVERVIEW»(ref-522301-S34741944562013011400000) Removing and installing, refer to «THORAX (SIDE) AIRBAG IGNITERS -N199- / -N200»(ref-522301-S02286298112013011400000)
6. Driver Seat Standard Seat (manual) Assembly overview, refer to «STANDARD MANUAL FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S41336104562013011400000) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(ref-522379-S29082603452013011400000) Optional equipment: Seat and backrest heating Four-way lumbar support Storage compartment Power Standard Seat Assembly overview, refer to «POWER STANDARD FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S05169178602013011400000) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Memory function Seat and backrest heating Storage compartment Comfort Seats (power) Assembly overview, refer to «COMFORT FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S41653456402013011400000) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Memory function Storage compartment Manual Sport Seat with Seat Depth Adjuster Assembly overview, refer to «MANUAL SPORT FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S40371542512013011400000) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(ref-522379-S29082603452013011400000) Optional equipment: Seat and backrest heating Seat angle adjustment Cabin heater Storage compartment Power Sport Seat with Seat Depth Adjuster Assembly overview, refer to «POWER SPORT FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S21784417112013011400000) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Memory function Seat and backrest heating Cabin heater Storage compartment Super Sport Seats (power) Assembly overview, refer to «SUPER SPORT FRONT SEAT ASSEMBLY OVERVIEW»(ref-522379-S26422294722013011400000) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Memory function Seat and backrest heating Storage compartment

STANDARD MANUAL FRONT SEAT ASSEMBLY OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering.

Scheme 519

1. Connector Station Connector routing «CONNECTOR STATION CONNECTORS»(ref-522379-S25641912442013011400000)
2. Cover For coupling station Removing and installing, refer to «HARNESS CONNECTORS, DISCONNECTING AND CONNECTING»(ref-522379-S23154178062013011400000)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview «MODULAR WIRE ROUTING ASSEMBLY OVERVIEW»(ref-522379-S28775488642013011400000) Modular wiring with corrugated tube on front seat «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(ref-522379-S10181520102013011400000)
4. Storage Compartment Removing and installing, refer to «STORAGE COMPARTMENT»(ref-522379-S26026523662013011400000)
5. Seat Forward/Back Adjuster Seat forward/back adjustment handle, removing and installing, refer to «SEAT FORWARD/BACK ADJUSTMENT HANDLE»(ref-522379-S20558046132013011400000) Seat forward/back adjuster release cable, removing and installing, refer to «SEAT FORWARD/BACK ADJUSTER RELEASE CABLE»(ref-522379-S08588068242013011400000)
6. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(ref-522379-S33078796162013011400000)
7. LATCH Child Seat Anchor Vehicles with For the front passenger seat only Removing and installing, refer to «LATCH CHILD SEAT ANCHOR»(ref-522301-S17217829862013011400000) check after accident «CHILD SEAT ANCHORAGES, CHECKING AFTER AN ACCIDENT»(ref-522301-S22331909022013011400000)
8. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(ref-522301-S19185847502013011400000)
9. Tunnel Side Trim Removing and installing, refer to «TUNNEL SIDE TRIM»(ref-522379-S35879487442013011400000)
10. Standard Front Seat (manual) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(ref-522379-S29082603452013011400000) Optional equipment: Seat and backrest heating
11. Headrest Manual Removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(ref-522379-S22064421432013011400000)
12. Entry Assistance Backrest Release Assembly overview, refer to «ENTRY ASSISTANCE, SEATBACK RELEASE ASSEMBLY OVERVIEW»(ref-522379-S21126829622013011400000) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
13. Backrest Adjusting Wheel Removing and installing, refer to «BACKREST ADJUSTING WHEEL»(ref-522379-S39738560142013011400000)
14. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(ref-522379-S30106986192013011400000)
15. Bolts 50 Nm Quantity: 4
16. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(ref-522379-S33536482512013011400000)
17. Seat Height Adjuster Removing and installing, refer to «SEAT HEIGHT ADJUSTER»(ref-522379-S01930725772013011400000)
18. Actuator For the lumbar support Lumbar Support Adjustment Switch, Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000) Four-way lumbar support, removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)
19. Sill-Side Trim Removing and installing, refer to «SILL SIDE TRIM»(ref-522379-S02615420852013011400000)

BACKREST COVER ASSEMBLY OVERVIEW

Note. The assembly overview shows a standard front seat. The backrest cover of the other seat versions is identical. The illustration shows a backrest cover without a storage net.

Scheme 520

1. Front Seat
2. Upper Hook Quantity: 2
3. Backrest Cover Removing and installing, refer to «BACKREST COVER»(ref-522379-S00281298622013011400000)
4. Lower Hook Quantity: 2
5. Hook, Bottom Side Quantity: 2
6. Tab, Upper Side Quantity: 2

Scheme 521

1. Spring Mat Removing and installing, refer to «SPRING MAT»(ref-522379-S38498023672013011400000) Can be removed and installed with and without the pull-springs
2. Backrest Frame
3. Release Cable With entry assist
4. Upper Pull-Spring Not available separately
5. Center Pull-Spring Not available separately
6. Bottom Spring Not available separately

HEADREST ASSEMBLY OVERVIEW

Note. The assembly overview is based on a standard front seat. The headrest on the manual front sport seat is similar. The illustration does not show the backrest cover and upholstery.

Scheme 522

1. Backrest Frame
2. Headrest Guide Without release button Always installed on right side of backrest Removing and installing, refer to «HEADREST GUIDE»(ref-522379-S03304763972013011400000)
3. Headrest Removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(ref-522379-S22064421432013011400000)
4. Headrest Guide With release button Always installed on left side of backrest Removing and installing, refer to «HEADREST GUIDE»(ref-522379-S03304763972013011400000)

STORAGE COMPARTMENT ASSEMBLY OVERVIEW

The assembly overview is based on a power standard front seat. The storage compartment on the manual standard front seat is similar.

SEAT FORWARD/BACK ADJUSTER ASSEMBLY OVERVIEW

Note. The lower section of the seat with the seat forward/back adjuster cannot be separated from the upper section (seat pan) on manual standard front seats.

Scheme 523

1. Front Seat
2. Seat Forward/Back Adjuster Part of the lower seat section assembly Not replaced separately
3. Seat Forward/Back Adjuster Release Cable Removing and installing, refer to «SEAT FORWARD/BACK ADJUSTER RELEASE CABLE»(ref-522379-S08588068242013011400000) It is not possible to adjust the release cable
4. Clip or Cable Tie
5. Handle For seat forward/back adjustment Removing and installing, refer to «SEAT FORWARD/BACK ADJUSTMENT HANDLE»(ref-522379-S20558046132013011400000)
6. Retaining Clip Replace the seat forward/back adjustment handle each time it is removed Note location «SEAT FORWARD/BACK ADJUSTMENT HANDLE»(ref-522379-S20558046132013011400000)
7. Actuator For seat forward/back adjustment
8. Spring For lever for seat forward/back adjuster release cable retainer Different components for driver and front passenger side Removing and installing, refer to «RELEASE CABLE MOUNT LEVER AND SEAT FORWARD/BACK ADJUSTMENT SPRING»(ref-522379-S16659086932013011400000)
9. Lever For seat forward/back adjuster release cable retainer Same part for driver and front passenger seat Removing and installing, refer to «RELEASE CABLE MOUNT LEVER AND SEAT FORWARD/BACK ADJUSTMENT SPRING»(ref-522379-S16659086932013011400000)

LUMBAR SUPPORT ADJUSTMENT SWITCH ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power standard front seat. The lumbar support adjustment switch are similar to the standard seat (manual).

FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The four-way lumbar support of the manual standard front seat is similar.

SEAT POSITION SENSOR ASSEMBLY OVERVIEW

The seat position sensor is the same in all seat versions.

POWER STANDARD FRONT SEAT ASSEMBLY OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering and the four-way lumbar support.

Scheme 524

1. Connector Station Connector routing «CONNECTOR STATION CONNECTORS»(ref-522379-S25641912442013011400000)
2. Cover For coupling station Removing and installing, refer to «HARNESS CONNECTORS, DISCONNECTING AND CONNECTING»(ref-522379-S23154178062013011400000)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview «MODULAR WIRE ROUTING ASSEMBLY OVERVIEW»(ref-522379-S28775488642013011400000) Modular wiring with corrugated tube on front seat «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(ref-522379-S10181520102013011400000)
4. Storage Compartment Vehicles with Removing and installing, refer to «STORAGE COMPARTMENT»(ref-522379-S26026523662013011400000)
5. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(ref-522379-S33078796162013011400000)
6. LATCH Child Seat Anchor Vehicles with for the front passenger seat only Removing and installing, refer to «LATCH CHILD SEAT ANCHOR»(ref-522301-S17217829862013011400000) Check after accident «CHILD SEAT ANCHORAGES, CHECKING AFTER AN ACCIDENT»(ref-522301-S22331909022013011400000)
7. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(ref-522301-S19185847502013011400000)
8. Tunnel Side Trim Removing and installing, refer to «TUNNEL SIDE TRIM»(ref-522379-S35879487442013011400000)
9. Power Standard Front Seat Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Seat and backrest heating
10. Headrest Power Removing and installing, refer to «POWER HEADRESTS»(ref-522379-S08086614552013011400000)
11. Entry Assistance Backrest Release Assembly overview, refer to «ENTRY ASSISTANCE, SEATBACK RELEASE ASSEMBLY OVERVIEW»(ref-522379-S21126829622013011400000) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
12. Button With entry assist Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)
13. Sill-Side Trim Removing and installing, refer to «SILL SIDE TRIM»(ref-522379-S39429621502013011400000)
14. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(ref-522379-S30106986192013011400000)
15. Bolts 50 Nm Quantity: 4
16. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(ref-522379-S33536482512013011400000)
17. Actuator For backrest and headrest adjustment Actuator, removing and installing, refer to «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(ref-522379-S41605726682013011400000) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
18. Actuator For seat adjustment Actuator, removing and installing «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S16921393772013011400000) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
19. Actuator For the lumbar support Lumbar support adjustment switch, removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000) Four-way lumbar support, removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)

MODULAR WIRE ROUTING ASSEMBLY OVERVIEW

The assembly overview relates to the manual standard front seat. The modular wiring for the power standard front seat is similar. Refer to MODULAR WIRE ROUTING ASSEMBLY OVERVIEW

TORSION BAR ASSEMBLY OVERVIEW

The assembly overview relates to the manual standard front seat. The torsion bar on the power standard front seat is similar. Refer to TORSION BAR ASSEMBLY OVERVIEW

Scheme 525

1. Seat Pan
2. Screws Self-locking Always replace if removed Threaded holes for screws must be cleaned, for example, with thread cutter 33 Nm
3. Backrest Removing and installing, refer to «BACKREST»(ref-522379-S11273622302013011400000)
4. Headrest Power Removing and installing, refer to «POWER HEADRESTS»(ref-522379-S08086614552013011400000)
5. Entry Assist Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(ref-522379-S05337448952013011400000)
6. Handle With bracket (entry assistance) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
7. Button With entry assist Assembly overview, refer to «ENTRY ASSISTANCE BUTTON ASSEMBLY OVERVIEW»(ref-522379-S12327702102013011400000) Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)
8. Wiring Harness From the side airbag to the coupling station Depending on optional equipment, there may be more wiring harnesses, such as for backrest heating, lumbar support

The assembly overview shows a manual Standard front seat. The backrest cover on a power front standard seat is identical. Refer to BACKREST COVER ASSEMBLY OVERVIEW

ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW

Part 1

Scheme 526

1. Angle Adjustment Motor Driver side: driver seat angle adjustment motor -V243- Front passenger side: front passenger seat angle adjustment motor -V244- Assembly overview, refer to «SEAT ANGLE ADJUSTMENT MOTOR ASSEMBLY OVERVIEW»(ref-522379-S29287606522013011400000) Removing and installing, refer to «SEAT ANGLE ADJUSTMENT MOTOR»(ref-522379-S36021620562013011400000)
2. Memory Seat/Steering Column Adjustment and Seat Heating Control Module Driver side: memory seat/steering column adjustment control module -J136- Front passenger side: passenger memory seat control module -J521- Comfort seat: Driver side left front seat ventilation control module -J800- Driver side: left cabin heater control module -J846- Comfort seat: Front passenger side: right front seat ventilation control module -J799- Front passenger side: right cabin heater control module -J847- Vehicles with Sport seat: Driver side: left cabin heater control module -J846- Front passenger side: right cabin heater control module -J847- Assembly overview, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT AND SEAT HEATING CONTROL MODULE ASSEMBLY OVERVIEW»(ref-522379-S09888592982013011400000) Removing and installing, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE»(ref-522379-S36149855032013011400000)
3. Seat Position Sensor Diver side: driver seat position sensor -G553- Front passenger side: front passenger seat position sensor -G554- Assembly overview, refer to «SEAT POSITION SENSOR ASSEMBLY OVERVIEW»(ref-522301-S35519759572013011400000) Versions with seat occupied sensor for belt fastening detection, removing and installing, refer to «SEAT POSITION SENSOR WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION»(ref-522301-S35129441862013011400000) Versions with seat occupied sensor for passenger airbag deactivation, removing and installing, refer to «SEAT POSITION SENSOR WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION»(ref-522301-S02323114342013011400000)
4. Seat Forward/Back Adjustment Motor Driver side: driver seat forward/back adjustment motor -V28- Front passenger side: front passenger seat forward/back adjustment motor -V31- Assembly overview, refer to «FORWARD/BACK ADJUSTMENT MOTOR ASSEMBLY OVERVIEW»(ref-522379-S38334775302013011400000) Removing and installing, refer to «FORWARD/BACK ADJUSTMENT MOTOR»(ref-522379-S19224634822013011400000)
5. Heating Element Vehicles with Removing and installing, refer to «SEAT HEATING ELEMENT, STANDARD SEAT»(ref-522405-S15597020012013011400000)
6. Backrest Adjustment Motor Driver side: driver backrest adjustment motor -V45- Front passenger side: front passenger backrest adjustment motor -V46- Assembly overview, refer to «BACKREST ADJUSTMENT MOTOR ASSEMBLY OVERVIEW»(ref-522379-S13602555132013011400000) Removing and installing, refer to «BACKREST ADJUSTMENT MOTOR»(ref-522379-S27125586332013011400000)
7. Footwell Light Vehicles with Removing and installing, refer to «Removal and Installation»(ref-522299-S27854082502013011400000)
8. Four-Way Lumbar Support Cannot be disassembled; available only as a complete unit, Driver side: Driver seat lumbar support curvature adjustment motor -V125- Driver seat lumbar support height adjustment motor -V129- Passenger side: Front passenger seat lumbar support curvature adjustment motor -V126- Front passenger seat lumbar support height adjustment motor -V130- Assembly overview, refer to «FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW»(ref-522379-S00776984162013011400000) Removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)
9. Headrest Adjustment Motor Driver side: Driver headrest adjustment motor -V103- Front passenger side: Front passenger headrest adjustment motor -V104- Fixed component of the headrest base plate and cannot be replaced. If the headrest adjustment motor is faulty, replace the entire headrest base plate. Refer to «HEADREST COVER AND UPHOLSTERY WITH LOCKING MECHANISM»(ref-522405-S12902601082013011400000) .
10. Entry Assistance Button Driver side: driver entry assistance button -E358- Front passenger side: front passenger entry assistance button -E359- Assembly overview, refer to «ENTRY ASSISTANCE BUTTON ASSEMBLY OVERVIEW»(ref-522379-S12327702102013011400000) Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)
11. Front Side Airbag Driver side: with the driver side airbag igniter -N199- Front passenger side: with front passenger side airbag igniter -N200- WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS»(ref-522301-S31745711692013011400000) . Assembly overview, refer to «FRONT SIDE AIRBAG ASSEMBLY OVERVIEW»(ref-522301-S34741944562013011400000) Removing and installing, refer to «THORAX (SIDE) AIRBAG IGNITERS -N199- / -N200»(ref-522301-S02286298112013011400000)
12. Selector Unit (microswitch for backrest adjustment wheel) The backrest lock switch and the backrest forward stop switch are installed on the same bracket Driver side: Driver backrest lock switch -F211- Driver seat backrest forward stop switch -F381- Passenger side: Front passenger backrest lock switch -F212- Front passenger seat backrest forward stop switch -F383- Checking, refer to «SWITCH UNIT MICRO SWITCH, CHECKING»(ref-522379-S11897527322013011400000) Adjusting, refer to «SWITCH UNIT MICRO SWITCH, ADJUSTING»(ref-522379-S01789893062013011400000)
13. Front Passenger Seat Occupied Sensor -G128- Vehicles with For the front passenger seat only Removing and installing, refer to «SEAT OCCUPIED SENSOR»(ref-522301-S04654090742013011400000)
14. Seat Adjustment Control Head Driver side: driver seat adjustment control head -E470- Front passenger side: front passenger seat adjustment control head -E471- Assembly overview, refer to «SEAT ADJUSTMENT CONTROL HEAD ASSEMBLY OVERVIEW»(ref-522379-S32567070082013011400000) Removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
15. Height Adjustment Motor Driver side: driver seat height adjustment motor -V245- Front passenger side: front passenger seat height adjustment motor -V246- Assembly overview, refer to «HEIGHT ADJUSTMENT MOTOR ASSEMBLY OVERVIEW»(ref-522379-S02260232402013011400000) Removing and installing, refer to «HEIGHT ADJUSTMENT MOTOR»(ref-522379-S33648553522013011400000)
16. Lumbar Support Adjustment Switch Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Assembly overview, refer to «ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW»(ref-522379-S24349334842013011400000) Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000)

Part 2

Scheme 527

1. Seat Ventilation Control Module (integrated in the seat heating) Versions with driver side seat heating: left front seat ventilation control module -J800- Versions with passenger side seat heating: right front seat ventilation control module -J799- Assembly overview, refer to «SEAT VENTILATION CONTROL MODULE ASSEMBLY OVERVIEW»(ref-522379-S25998671282013011400000) Removing and installing, refer to «RIGHT FRONT SEAT VENTILATION CONTROL MODULE (SEAT HEATER FUNCTION INTEGRATED)»(ref-522379-S11397153202013011400000)
2. Seat Position Sensor Diver side: driver seat position sensor -G553- Front passenger side: front passenger seat position sensor -G554- Assembly overview, refer to «SEAT POSITION SENSOR ASSEMBLY OVERVIEW»(ref-522301-S35519759572013011400000) Versions with seat occupied sensor for belt fastening detection, removing and installing «SEAT POSITION SENSOR WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION»(ref-522301-S35129441862013011400000) Versions with seat occupied sensor for passenger airbag deactivation, removing and installing «SEAT POSITION SENSOR WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION»(ref-522301-S02323114342013011400000)
3. Heating Element Vehicles with Removing and installing, refer to «SEAT HEATING ELEMENT, STANDARD SEAT»(ref-522405-S15597020012013011400000)
4. Footwell Light Vehicles with Removing and installing, refer to «Removal and Installation»(ref-522299-S27854082502013011400000)
5. Four-Way Lumbar Support Cannot be disassembled; available only as a complete unit, Driver side: Driver seat lumbar support curvature adjustment motor -V125- Driver seat lumbar support height adjustment motor -V129- Passenger side: Passenger seat lumbar support curvature adjustment motor -V126- Passenger seat lumbar support height adjustment motor -V130- Assembly overview, refer to «FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW»(ref-522379-S00776984162013011400000) Removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)
6. Front Side Airbag Driver side: with the driver side airbag igniter -N199- Front passenger side: with front passenger side airbag igniter -N200- WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS»(ref-522301-S31745711692013011400000) . Assembly overview, refer to «FRONT SIDE AIRBAG ASSEMBLY OVERVIEW»(ref-522301-S34741944562013011400000) Removing and installing, refer to «THORAX (SIDE) AIRBAG IGNITERS -N199- / -N200»(ref-522301-S02286298112013011400000)
7. Front Passenger Seat Occupant Sensor -G128- Vehicles with For the front passenger seat only Removing and installing, refer to «SEAT OCCUPIED SENSOR»(ref-522301-S04654090742013011400000)
8. Lumbar Support Adjustment Switch Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Assembly overview, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH ASSEMBLY OVERVIEW»(ref-522379-S22995735512013011400000) Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000)

Scheme 528

1. Sill-Side Trim Removing and installing, refer to «SILL SIDE TRIM»(ref-522379-S39429621502013011400000)
2. Actuator for backrest and headrest adjustment clipped to the control head Removing and installing, refer to «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(ref-522379-S41605726682013011400000)
3. Actuator for seat adjustment clipped to the control head Removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S16921393772013011400000)
4. Screws Quantity: 3 0.4 Nm
5. Seat Adjustment Control Head Driver side: driver seat adjustment control head -E470- with: Driver backrest adjustment switch -E96- Driver headrest adjustment switch -E155- Driver seat angle adjustment switch -E222- Driver seat forward/back adjustment switch -E363- Driver height adjustment switch -E364- Front passenger side: front passenger seat adjustment control head -E471- with: Front passenger seat forward/back adjustment switch -E64- Front passenger backrest adjustment switch -E98- Front passenger headrest adjustment switch -E170- Front passenger seat angle adjustment motor -E334- Front passenger seat height adjustment switch -E365- Removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)

FORWARD/BACK ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

Note. If motor is faulty, lower seat pan frame must be replaced. The seat pan is shown without the upholstery and cover.

Scheme 529

1. Seat Pan Upper Frame Removing and installing, refer to «UPPER SEAT FRAME»(ref-522379-S20331667592013011400000)
2. Seat Pan Lower Frame with forward/back adjustment motor cannot be disassembled; available only as a complete unit, Removing and installing, refer to «UPPER SEAT FRAME»(ref-522379-S31369469902013011400000)
3. Seat Forward/Back Adjustment Motor With seat pan lower frame Driver side: driver seat forward/back adjustment motor -V28- Front passenger side: front passenger seat forward/back adjustment motor -V31- cannot be disassembled; available only as a complete unit, Removing and installing, refer to «FORWARD/BACK ADJUSTMENT MOTOR»(ref-522379-S19224634822013011400000)

Scheme 530

1. Seat Pan
2. Screws 10 Nm Replace Quantity: 2 Self-locking Threaded holes for screws must always be cleaned, for example, with thread cutter
3. Bracket Bolted with the seat pan
4. Height Adjustment Motor Driver side: driver seat height adjustment motor -V245- Front passenger side: front passenger seat height adjustment motor -V246- Removing and installing, refer to «HEIGHT ADJUSTMENT MOTOR»(ref-522379-S33648553522013011400000)
5. Bolt 18 Nm CAUTION: The bolt has a left-hand thread. Self-locking Replace Follow the information given when removing and installing, refer to «HEIGHT ADJUSTMENT MOTOR»(ref-522379-S33648553522013011400000) Threaded holes for screws must always be cleaned, for example, with thread cutter
6. Adjusting Spindle Pre-adjusted by the manufacturer Component of the height adjustment motor
7. Screws 28 Nm Quantity: 2 Self-locking Replace Threaded holes for screws must always be cleaned, for example, with thread cutter

Scheme 531

1. Angle Adjustment Motor Driver side: driver seat angle adjustment motor -V243- Front passenger side: front passenger seat angle adjustment motor -V244- Removing and installing, refer to «SEAT ANGLE ADJUSTMENT MOTOR»(ref-522379-S36021620562013011400000)
2. Screws 10 Nm Replace Quantity: 2 Self-locking Threaded holes for screws must always be cleaned, for example, with thread cutter
3. Bolt 20 Nm Replace Self-locking Threaded screw holes must always be cleaned (for example, with thread cutter)
4. Connector

BACKREST ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

Note. The backrest is shown without the upholstery, cover and seat pan.

Scheme 532

1. Backrest Frame
2. Nut Replace 6 Nm
3. Window
4. Shaft The threads must be cleaned before installing the nut -item 2- (for example, using a thread tap). Coat the threads on the shaft with locking fluid before installing the nut.
5. Bolt Replace Use locking fluid when installing the bolt. 7.5 Nm
6. Backrest Adjustment Motor Driver side: driver backrest adjustment motor -V45- Front passenger side: front passenger backrest adjustment motor -V46- Removing and installing, refer to «BACKREST ADJUSTMENT MOTOR»(ref-522379-S27125586332013011400000)

SELECTOR UNIT (BACKREST ADJUSTMENT WHEEL MICROSWITCH) ASSEMBLY OVERVIEW

Note. The 6-pin connector with backrest lock switch and backrest forward stop switch are not separate from the bracket. They are delivered as a microswitch with bracket switch unit -7-. The locking bushing -6- and screws for mounting the switch unit -2- are supplied as replacement parts. The backrest is shown without the upholstery, cover and seat pan.

Scheme 533

1. Backrest Frame
2. Bolt 1.5 Nm Quantity: 2
3. Window
4. Nut Tightening specification, item 2 2 Replace
5. Shaft The threads must always be cleaned before installing the nut -4-, for example, using a thread tap. Coat the threads on the shaft with locking fluid before installing the nut.
6. Locking bushing clipped to the spindle Clip to the spindle after adjusting the switch unit
7. Switch Unit (micro switch with bracket) Removing and installing, refer to «BACKREST ADJUSTMENT MOTOR»(ref-522379-S27125586332013011400000) Adjusting, refer to «SWITCH UNIT MICRO SWITCH, ADJUSTING»(ref-522379-S01789893062013011400000) Checking, refer to «SWITCH UNIT MICRO SWITCH, CHECKING»(ref-522379-S11897527322013011400000)

Scheme 534

1. 6-Pin Connector Clipped with the bracket
2. Backrest Lock Switch Driver side: driver backrest lock switch -F211- Front passenger side: front passenger backrest lock switch -F212- Also called a micro switch Adjusting, refer to «SWITCH UNIT MICRO SWITCH, ADJUSTING»(ref-522379-S01789893062013011400000) Checking, refer to «SWITCH UNIT MICRO SWITCH, CHECKING»(ref-522379-S11897527322013011400000)
3. Slide Moveable mount for the river backrest lock switch -F211- or front passenger backrest lock switch -F212
4. Slide Retainer Unclip to adjust the backrest lock switch
5. Bracket
6. Locking Bushing Clipped to the spindle
7. Spindle
8. Spindle Nut
9. Stop Switch for Backrest Toward the Front Driver side: driver seat backrest forward stop switch -F381- Front passenger side: front passenger backrest forward stop switch -F383- Adjusting, refer to «SWITCH UNIT MICRO SWITCH, ADJUSTING»(ref-522379-S01789893062013011400000) Checking, refer to «SWITCH UNIT MICRO SWITCH, CHECKING»(ref-522379-S11897527322013011400000)

POWER HEADRESTS ASSEMBLY OVERVIEW

Note. The illustration does not show the backrest cover and upholstery.

Scheme 535

1. Backrest
2. Headrest Guide Without release button Removing and installing, refer to «HEADREST GUIDE»(ref-522379-S03304763972013011400000) Always installed on right side of backrest
3. Wiring With connector Connected firmly to the headrest
4. Headrest Driver side: Driver head restraint height adjustment sensor -G217- Driver headrest adjustment motor -V103- Passenger side: Front passenger head restraint height adjustment sensor -G282- Front passenger headrest adjustment motor -V104- Removing and installing, refer to «POWER HEADRESTS»(ref-522379-S08086614552013011400000) With the headrest, the cover and upholstery can only be replaced with the entire base plate (including the adjuster). It is not possible to disassemble the base plate or replace the electrical and electronic components installed inside.
5. Headrest Guide With release button Removing and installing, refer to «HEADREST GUIDE»(ref-522379-S03304763972013011400000) Always installed on left side of backrest

The assembly overview is based on a manual standard front seat. The lumbar support adjustment switches for the power standard front seat are similar. Refer to. Refer to ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The four-way lumbar support on a power standard front seat (electrically adjustable) is identical. Refer to FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW

Scheme 536

1. Entry Assist Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(ref-522379-S05337448952013011400000)
2. Connector Entry assistance button
3. Entry Assistance Button Driver side: driver entry assistance button -E358- Front passenger side: front passenger entry assistance button -E359- Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)

Scheme 537

1. Front Seat
2. Pin For securing the bracket to the seat pan
3. Bracket Engaged and clipped in the seat pan Removing and installing, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE BRACKET»(ref-522379-S33563269562013011400000)
4. Memory Seat/Steering Column Adjustment and Seat Heating Control Module Driver side: memory seat/steering column adjustment control module -J136- Front passenger side: passenger memory seat control module -J521- Comfort seat: Driver side left front seat ventilation control module -J800- Driver side: left cabin heater control module -J846- Comfort seat: Front passenger side: right front seat ventilation control module -J799- Front passenger side: right cabin heater control module -J847- Vehicles with Sport seat: Driver side: left cabin heater control module -J846- Front passenger side: right cabin heater control module -J847- clipped with the bracket Removing and installing, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE»(ref-522379-S36149855032013011400000)

The seat position sensor is the same in all seat versions. Refer to SEAT POSITION SENSOR ASSEMBLY OVERVIEW

The assembly overview relates to the manual standard front seat. It is similar for the comfort front seat. Refer to MODULAR WIRE ROUTING ASSEMBLY OVERVIEW

SILL AND TUNNEL SIDE TRIM ASSEMBLY OVERVIEW

The assembly overview relates to the power standard front seat. The trims on the sill and tunnel side of the comfort front seat are similar. Refer to SILL AND TUNNEL SIDE TRIM ASSEMBLY OVERVIEW

SILL SIDE TRIM RETAINING BRACKET ASSEMBLY OVERVIEW

The assembly overview relates to the power standard front seat. The trim retaining bracket on the sill side of the comfort front seat is similar. Refer to SILL SIDE TRIM RETAINING BRACKET ASSEMBLY OVERVIEW

The assembly overview relates to the manual standard front seat. The torsion bar is similar for the comfort front seat. Refer to TORSION BAR ASSEMBLY OVERVIEW

BACKREST ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The backrest on the front seat - comfort seat is similar. Refer to BACKREST ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The backrest cover on the Comfort front seat is identical. Refer to BACKREST COVER ASSEMBLY OVERVIEW

SEAT FRAME ASSEMBLY OVERVIEW

The assembly overview relates to the power standard front seat. The seat pan is similar for the comfort front seat. Refer to SEAT FRAME ASSEMBLY OVERVIEW

The assembly overview relates to the power standard front seat. The storage compartment is similar for the comfort front seat. Refer to STORAGE COMPARTMENT ASSEMBLY OVERVIEW

COMFORT FRONT SEAT ASSEMBLY OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering and the four-way lumbar support.

Scheme 538

1. Connector Station Connector routing «CONNECTOR STATION CONNECTORS»(ref-522379-S25641912442013011400000)
2. Cover For coupling station Removing and installing, refer to «HARNESS CONNECTORS, DISCONNECTING AND CONNECTING»(ref-522379-S23154178062013011400000)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview «MODULAR WIRE ROUTING ASSEMBLY OVERVIEW»(ref-522379-S28775488642013011400000) Modular wiring with corrugated tube on front seat «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(ref-522379-S10181520102013011400000)
4. Storage Compartment Vehicles with Removing and installing, refer to «STORAGE COMPARTMENT»(ref-522379-S26026523662013011400000)
5. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(ref-522379-S33078796162013011400000)
6. LATCH Child Seat Anchor Vehicles with For the front passenger seat only Removing and installing, refer to «LATCH CHILD SEAT ANCHOR»(ref-522301-S17217829862013011400000) Check after accident «CHILD SEAT ANCHORAGES, CHECKING AFTER AN ACCIDENT»(ref-522301-S22331909022013011400000)
7. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(ref-522301-S19185847502013011400000)
8. Tunnel Side Trim Removing and installing, refer to «TUNNEL SIDE TRIM»(ref-522379-S35879487442013011400000)
9. Front Seat - Comfort Seat (electrically adjustable) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Seat and backrest heating
10. Cabin Heater Driver side: left cabin heater fan -V450- Front passenger side: right cabin heater fan -V451- Removing and installing, refer to «LEFT AND RIGHT CABIN HEATER FAN»(ref-522379-S27343050242013011400000)
11. Headrest Power Removing and installing, refer to «POWER HEADRESTS»(ref-522379-S08086614552013011400000)
12. Entry Assistance Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
13. Button With entry assist Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)
14. Sill-Side Trim Removing and installing, refer to «SILL SIDE TRIM»(ref-522379-S39429621502013011400000)
15. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(ref-522379-S30106986192013011400000)
16. Screws Quantity: 4 50 Nm
17. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(ref-522379-S33536482512013011400000)
18. Actuator For backrest and headrest adjustment Actuator, removing and installing «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(ref-522379-S41605726682013011400000) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
19. Actuator For seat adjustment Actuator, removing and installing «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S16921393772013011400000) control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
20. Actuator For the lumbar support Lumbar Support Adjustment Switch, Removing and Installing «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000) Four-way lumbar support, removing and installing «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)
21. Cabin Heater Switch Driver side: left cabin heater switch -E678- Front passenger side: right cabin heater switch -E679- Removing and installing, refer to «LEFT AND RIGHT CABIN HEATER SWITCHES»(ref-522379-S40971306112013011400000)

The assembly overview relates to the power standard front seat. The electrical and electronic components of the comfort front seat are similar. Refer to ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW

Scheme 539

1. Cabin Heater Switch Driver side: left cabin heater switch -E678- Front passenger side: right cabin heater switch -E679- Removing and installing, refer to «LEFT AND RIGHT CABIN HEATER SWITCHES»(ref-522379-S40971306112013011400000)
2. Seat Cushion Fan Driver side: driver seat cushion blower fan -V390- Front passenger side: front passenger seat cushion blower fan -V391- Removing and installing, refer to «SEAT CUSHION FAN»(ref-522379-S33481111292013011400000)
3. Seat Cushion Fan 2 Driver side: driver seat cushion blower fan 2 -V419- Front passenger side: front passenger seat cushion blower fan 2 -V420- Removing and installing, refer to «SEAT CUSHION FAN»(ref-522379-S33481111292013011400000)
4. Backrest Fan Driver side: driver seat backrest blower fan -V388- Front passenger side: front passenger seat backrest blower fan -V389- Removing and installing, refer to «BACKREST FAN»(ref-522379-S18212520142013011400000)
5. Cabin Heater Blower Driver side: left cabin heater fan -V450- Front passenger side: right cabin heater fan -V451- Removing and installing, refer to «LEFT AND RIGHT CABIN HEATER FAN»(ref-522379-S27343050242013011400000)

Scheme 540

1. Bolt - 1.5 Nm
2. Cover grille
3. Seal
4. Seat cushion fan

Scheme 541

1. Bracket For cabin heater blower Removing and installing, refer to «CABIN HEATER BLOWER BRACKET»(ref-522379-S42592348472013011400000)
2. Cabin Heater Blower Driver side: left cabin heater fan -V450- Front passenger side: right cabin heater fan -V451- Removing and installing, refer to «LEFT AND RIGHT CABIN HEATER FAN»(ref-522379-S27343050242013011400000)
3. Connection
4. Cabin Heater Vent Removing and installing, refer to «CABIN HEATER VENTS»(ref-522379-S07748928962013011400000)
5. Bolt Quantity: 2 3.5 Nm
6. Rubber Bushing With a washer and a threaded nut Quantity: 2
7. Backrest Frame

Scheme 542

1. Cabin Heater Switch Driver side: left cabin heater switch -E678- Front passenger side: right cabin heater switch -E679- Removing and installing, refer to «LEFT AND RIGHT CABIN HEATER SWITCHES»(ref-522379-S40971306112013011400000)
2. Sill-Side Trim Removing and installing, refer to «SILL SIDE TRIM»(ref-522379-S39429621502013011400000)
3. Mount For the cabin heater switch
4. Bolt 0.4 Nm Quantity: 2

SEAT ADJUSTMENT CONTROL HEAD ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The control head on the front seat - comfort seat is similar. Refer to SEAT ADJUSTMENT CONTROL HEAD ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat backward and foreward adjustment motor is similar on the comfort front seat. Refer to FORWARD/BACK ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

HEIGHT ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat height adjustment motor is similar on the comfort front seat. Refer to HEIGHT ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

SEAT ANGLE ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat angle adjustment motor is similar on the comfort front seat.

The assembly overview shows the four-way lumbar support on a power Standard front seat. The comfort front seat is similar. Refer to BACKREST ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

SELECTOR UNIT (MICROSWITCH FOR BACKREST ADJUSTMENT WHEEL) ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The comfort front seat is similar. Refer to SELECTOR UNIT (BACKREST ADJUSTMENT WHEEL MICROSWITCH) ASSEMBLY OVERVIEW

SWITCH UNIT MICRO SWITCH ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The comfort front seat is similar. Refer to SWITCH UNIT MICRO SWITCH ASSEMBLY OVERVIEW

The assembly overview relates to the power standard front seat. The electrically adjustable headrest is similar for the comfort front seat. Refer to POWER HEADRESTS ASSEMBLY OVERVIEW

Scheme 543

1. Sill-Side Trim
2. Screws Quantity: 2 0.5 Nm
3. Lumbar Support Adjustment Switch Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000) Switch and operating knob cannot be separated

Scheme 544

1. Plastic Washer Insert in front of the four-way lumber support riveted connection between the lumbar support bracket and the backrest frame
2. Four-Way Lumbar Support Cannot be disassembled; available only as a complete unit, Driver side: Driver seat lumbar support curvature adjustment motor -V125- Driver seat lumbar support height adjustment motor -V129- Passenger side: Front passenger seat lumbar support curvature adjustment motor -V126- Front passenger seat lumbar support height adjustment motor -V130- Removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)
3. Backrest Frame
4. Rivet

ENTRY ASSISTANCE BUTTON ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The entry assistance button is similar on the comfort front seat. Refer to ENTRY ASSISTANCE BUTTON ASSEMBLY OVERVIEW

Scheme 545

1. Seat Ventilation Control Module (integrated in the seat heating) Driver side left front seat ventilation control module -J800- Front passenger side: right front seat ventilation control module -J799- Clipped with the bracket Removing and installing, refer to «RIGHT FRONT SEAT VENTILATION CONTROL MODULE (SEAT HEATER FUNCTION INTEGRATED)»(ref-522379-S11397153202013011400000)
2. Bracket Removing and installing, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE BRACKET»(ref-522379-S33563269562013011400000)
3. Front Seat
4. Pin For securing the bracket to the seat pan

MEMORY SEAT/STEERING COLUMN ADJUSTMENT AND SEAT HEATING WITH INTEGRATED SEAT VENTILATION CONTROL MODULE ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The memory seat/steering column adjustment and seat heating control module is similar on the front seat - comfort seat. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT AND SEAT HEATING CONTROL MODULE ASSEMBLY OVERVIEW

The seat position sensor is the same in all seat versions. Refer to SEAT POSITION SENSOR ASSEMBLY OVERVIEW

MANUAL SPORT FRONT SEAT ASSEMBLY OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering.

Scheme 546

1. Connector Station Connector routing, refer to «CONNECTOR STATION CONNECTORS»(ref-522379-S25641912442013011400000)
2. Cover For coupling station Removing and installing, refer to «HARNESS CONNECTORS, DISCONNECTING AND CONNECTING»(ref-522379-S23154178062013011400000)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview «MODULAR WIRE ROUTING ASSEMBLY OVERVIEW»(ref-522379-S28775488642013011400000) Modular wiring with corrugated tube on front seat «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(ref-522379-S10181520102013011400000)
4. Seat Angle Adjustment Removing and installing, refer to «SEAT ANGLE ADJUSTER»(ref-522379-S05808491712013011400000)
5. Storage Compartment Vehicles with Removing and installing, refer to «STORAGE COMPARTMENT»(ref-522379-S26026523662013011400000)
6. Seat Forward/Back Adjuster Seat forward/back adjustment handle, removing and installing, refer to «SEAT FORWARD/BACK ADJUSTMENT HANDLE»(ref-522379-S20558046132013011400000) Seat forward/back adjuster release cable, removing and installing, refer to «SEAT FORWARD/BACK ADJUSTER RELEASE CABLE»(ref-522379-S08588068242013011400000)
7. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(ref-522379-S33078796162013011400000)
8. Seat Depth Adjuster Removing and installing, refer to «SEAT DEPTH ADJUSTER»(ref-522379-S26594049032013011400000)
9. LATCH Child Seat Anchor Vehicles with For the front passenger seat only Removing and installing, refer to «LATCH CHILD SEAT ANCHOR»(ref-522301-S17217829862013011400000) Check after accident «CHILD SEAT ANCHORAGES, CHECKING AFTER AN ACCIDENT»(ref-522301-S22331909022013011400000)
10. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(ref-522301-S19185847502013011400000)
11. Tunnel Side Trim Removing and installing, refer to «TUNNEL SIDE TRIM»(ref-522379-S35879487442013011400000)
12. Manual Sport Front Seat There is no separation between the upper and lower seat pan frame on the manual sport front seat Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(ref-522379-S29082603452013011400000) Optional equipment: Seat and backrest heating Cabin heater
13. Headrest Manual Removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(ref-522379-S22064421432013011400000)
14. Entry Assistance Assembly overview, refer to «ENTRY ASSISTANCE, SEATBACK RELEASE ASSEMBLY OVERVIEW»(ref-522379-S21126829622013011400000) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
15. Backrest Adjusting Wheel Removing and installing, refer to «BACKREST ADJUSTING WHEEL»(ref-522379-S39738560142013011400000)
16. Sill-Side Trim Removing and installing, refer to «SILL SIDE TRIM»(ref-522379-S02615420852013011400000)
17. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(ref-522379-S30106986192013011400000)
18. Bolt Quantity: 4 50 Nm
19. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(ref-522379-S33536482512013011400000)
20. Seat Height Adjustment and Seat Height Adjustment Handle Removing and installing, refer to «SEAT HEIGHT ADJUSTER»(ref-522379-S01930725772013011400000)
21. Actuator For the lumbar support Lumbar Support Adjustment Switch, Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000) Four-way lumbar support, removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)

The assembly overview shows a manual Standard front seat. The modular wiring for the manual sport front seat is similar. Refer to MODULAR WIRE ROUTING ASSEMBLY OVERVIEW .

The assembly overview shows a manual Standard front seat. The trims on the sill and tunnel side of the manual sport front seat are similar. Refer to SILL AND TUNNEL SIDE TRIM ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The trim retaining bracket on the sill side of the manual sport front seat is similar. Refer to SILL SIDE TRIM RETAINING BRACKET ASSEMBLY OVERVIEW

Scheme 547

1. Handle For seat inclination adjustment Removing and installing, refer to «SEAT ANGLE ADJUSTMENT HANDLE»(ref-522379-S05922259842013011400000)
2. Retaining Clip Replace the seat angle adjustment handle each time it is removed Installation position «SEAT ANGLE ADJUSTMENT HANDLE»(ref-522379-S05922259842013011400000)
3. Bolt 6.5 Nm Self-locking Always replace if removed Threaded hole for screws must be cleaned, for example, with thread cutter
4. Shoulder Pin 6 Nm Self-locking Always replace if removed Threaded hole for shoulder pin must be cleaned, for example, with thread cutter
5. Seat Angle Adjustment Removing and installing, refer to «SEAT ANGLE ADJUSTER»(ref-522379-S05808491712013011400000)

The assembly overview shows a manual Standard front seat. The torsion bar is similar for the manual sport front seat. Refer to TORSION BAR ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The backrest is similar on the manual front seat - sport seat. Refer to BACKREST ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The procedure is similar for the manual Sport front seat. Refer to BACKREST COVER ASSEMBLY OVERVIEW

ENTRY ASSISTANCE, SEATBACK RELEASE ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The entry assistance is similar for the manual sport front seat. Refer to ENTRY ASSISTANCE, SEATBACK RELEASE ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The seat forward/back adjuster is similar for the manual sport front seat. Refer to SEAT FORWARD/BACK ADJUSTER ASSEMBLY OVERVIEW

HEADRESTS ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The headrests are similar for the manual Sport front seat. Refer to HEADREST ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The storage compartment is similar for the manual sport front seat. Refer to STORAGE COMPARTMENT ASSEMBLY OVERVIEW

Scheme 548

1. Nut Quantity: 4 Replacing
2. Sport Seat With a seat depth adjuster
3. Trim For seat depth adjustment Removing and installing, refer to «SEAT DEPTH ADJUSTOR TRIM»(ref-522379-S04154279112013011400000) Press on until it engages audibly
4. Seat Depth Adjuster Removing and installing, refer to «SEAT DEPTH ADJUSTER»(ref-522379-S26594049032013011400000)
5. Bushing
6. Bolt Replacing Use locking fluid when installing the bolt. 4 Nm
7. Screws Replacing Use locking fluid when installing the bolt. 4 Nm
8. Bolt Replacing Use locking fluid when installing the bolt. 4 Nm
9. Bushing

The assembly overview shows a power Standard front seat. The electrical and electronic components of the manual sport front seat are similar. Refer to ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW

CABIN HEATER ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The cabin heater on the manual sport front seat is identical. Refer to CABIN HEATER ASSEMBLY OVERVIEW

CABIN HEATER SWITCH ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The cabin heater switch is similar on the manual sport front seat. Refer to CABIN HEATER SWITCH ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The lumbar support adjustment switches of the manual sport front seat are similar.

The assembly overview shows the four-way lumbar support on a power Standard front seat. The four-way lumbar support of the manual sport front seat is similar. Refer to FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW

The seat position sensor is the same in all seat versions. Refer to SEAT POSITION SENSOR ASSEMBLY OVERVIEW

POWER SPORT FRONT SEAT ASSEMBLY OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering and the four-way lumbar support.

Scheme 549

1. Connector Station Connector routing, refer to «CONNECTOR STATION CONNECTORS»(ref-522379-S25641912442013011400000)
2. Cover For coupling station Removing and installing, refer to «HARNESS CONNECTORS, DISCONNECTING AND CONNECTING»(ref-522379-S23154178062013011400000)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview, refer to «MODULAR WIRE ROUTING ASSEMBLY OVERVIEW»(ref-522379-S28775488642013011400000) Modular wiring with corrugated tube on front seat, refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(ref-522379-S10181520102013011400000)
4. Storage Compartment Vehicles with Removing and installing, refer to «STORAGE COMPARTMENT»(ref-522379-S26026523662013011400000)
5. Seat Depth Adjuster Removing and installing, refer to «SEAT DEPTH ADJUSTER»(ref-522379-S26594049032013011400000)
6. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(ref-522379-S33078796162013011400000)
7. LATCH Child Seat Anchor Vehicles with For the front passenger seat only Removing and installing, refer to «LATCH CHILD SEAT ANCHOR»(ref-522301-S17217829862013011400000) Check after accident, refer to «CHILD SEAT ANCHORAGES, CHECKING AFTER AN ACCIDENT»(ref-522301-S22331909022013011400000)
8. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(ref-522301-S19185847502013011400000)
9. Tunnel Side Trim Removing and installing, refer to «TUNNEL SIDE TRIM»(ref-522379-S35879487442013011400000)
10. Power Sport Front Seat Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000) Optional equipment: Seat and backrest heating Cabin heater
11. Headrest Power Removing and installing, refer to «POWER HEADRESTS»(ref-522379-S08086614552013011400000)
12. Entry Assistance Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
13. Button With entry assist Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)
14. Sill-Side Trim Removing and installing, refer to «SILL SIDE TRIM»(ref-522379-S39429621502013011400000)
15. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(ref-522379-S30106986192013011400000)
16. Bolt Quantity: 4 50 Nm
17. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(ref-522379-S33536482512013011400000)
18. Actuator For backrest and headrest adjustment Actuator, removing and installing, refer to «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(ref-522379-S41605726682013011400000) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
19. Actuator For seat adjustment Actuator, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S16921393772013011400000) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
20. Actuator For the lumbar support Lumbar support adjustment switch, removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000) Four-way lumbar support, removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)

The assembly overview shows a manual Standard front seat. The modular wiring on a power Sport front seat is identical. Refer to MODULAR WIRE ROUTING ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The trims on the sill and tunnel side of the power sport front seat are similar. Refer to SILL AND TUNNEL SIDE TRIM ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The trim retaining bracket on the sill side of the power sport front seat is similar. Refer to SILL SIDE TRIM RETAINING BRACKET ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The torsion bar is similar for the power sport front seat. Refer to TORSION BAR ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The backrest cover on the power Sport front seat is identical. Refer to BACKREST COVER ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat frame on the power Sport front seat is identical. Refer to SEAT FRAME ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The storage compartment on a power Sport front seat is identical. Refer to STORAGE COMPARTMENT ASSEMBLY OVERVIEW

SEAT DEPTH ADJUSTER ASSEMBLY OVERVIEW

The assembly overview shows a manual Sport front seat. The seat depth adjustment on a power Sport front seat is identical. Refer to SEAT DEPTH ADJUSTER ASSEMBLY OVERVIEW

ELECTRICAL AND ELECTRONIC COMPONENTS ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The electrical and electronic components in a power Sport front seat are identical. Refer to ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The cabin heater is similar on the power front seat - sport seat. Refer to CABIN HEATER ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The cabin heater switch is similar on the power sport front seat. Refer to CABIN HEATER SWITCH ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The backward and forward adjustment motor is similar for the front sport seat (electrically adjustable). Refer to FORWARD/BACK ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat height adjustment motor on a power sport front seat is identical. Refer to HEIGHT ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat forward/back adjustment motor on a power sport front seat is identical. Refer to SEAT ANGLE ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The backrest adjustment motor on a power Sport front seat is identical. Refer to BACKREST ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The backrest adjustment motor on a power Sport front seat is identical. Refer to SELECTOR UNIT (BACKREST ADJUSTMENT WHEEL MICROSWITCH) ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The backrest adjustment motor on a power Sport front seat is identical. Refer to SWITCH UNIT MICRO SWITCH ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The power headrest of the power sport front seat is similar. Refer to POWER HEADRESTS ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The lumbar support adjustment switches of the power sport front seat are similar. Refer to ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The four-way lumbar support on a power Sport front seat is identical. Refer to FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The entry assistance button is similar on the power sport front seat. Refer to ENTRY ASSISTANCE BUTTON ASSEMBLY OVERVIEW

MEMORY SEAT/STEERING COLUMN ADJUSTMENT AND SEAT HEATING CONTROL MODULE ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The memory seat/steering column adjustment and seat heating control module is similar on the power front sport seat. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT AND SEAT HEATING CONTROL MODULE ASSEMBLY OVERVIEW

The seat position sensor is the same in all seat versions. Refer to SEAT POSITION SENSOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The control head on a power sport front seat is identical. Refer to SEAT ADJUSTMENT CONTROL HEAD ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The backrest is similar on the power front sport seat. Refer to BACKREST ASSEMBLY OVERVIEW

SUPER SPORT FRONT SEAT ASSEMBLY OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering and the four-way lumbar support.

Scheme 550

1. Connector Station Connector routing, refer to «CONNECTOR STATION CONNECTORS»(ref-522379-S25641912442013011400000)
2. Cover For coupling station Removing and installing, refer to «HARNESS CONNECTORS, DISCONNECTING AND CONNECTING»(ref-522379-S23154178062013011400000)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview «MODULAR WIRE ROUTING ASSEMBLY OVERVIEW»(ref-522379-S28775488642013011400000) Modular wiring with corrugated tube on front seat «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(ref-522379-S10181520102013011400000)
4. Seat Depth Adjuster Removing and installing, refer to «SEAT DEPTH ADJUSTER»(ref-522379-S26594049032013011400000)
5. Spindle Cover Quantity: 2 clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(ref-522379-S33078796162013011400000)
6. LATCH Child Seat Anchor Vehicles with For the front passenger seat only Removing and installing, refer to «LATCH CHILD SEAT ANCHOR»(ref-522301-S17217829862013011400000) Check after accident «CHILD SEAT ANCHORAGES, CHECKING AFTER AN ACCIDENT»(ref-522301-S22331909022013011400000)
7. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(ref-522301-S19185847502013011400000)
8. Tunnel Side Trim Removing and installing, refer to «TUNNEL SIDE TRIM»(ref-522379-S35879487442013011400000)
9. Super Sport Front Seat Removing and installing, refer to «POWER STANDARD FRONT SEAT»(ref-522379-S23432344862013011400000)
10. Button With entry assist Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)
11. Entry Assistance Assembly overview, refer to «ENTRY ASSISTANCE, SEATBACK RELEASE ASSEMBLY OVERVIEW»(ref-522379-S32519725012013011400000) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
12. Sill-Side Trim Removing and installing, refer to «SILL SIDE TRIM»(ref-522379-S39429621502013011400000)
13. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(ref-522379-S30106986192013011400000)
14. Screws 50 Nm Quantity: 4
15. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(ref-522379-S33536482512013011400000)
16. Actuator For backrest adjustment Actuator, removing and installing «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(ref-522379-S41605726682013011400000) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
17. Actuator For seat adjustment Actuator, removing and installing «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S16921393772013011400000) control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(ref-522379-S12303451622013011400000)
18. Actuator For the lumbar support Vehicles with Lumbar Support Adjustment Switch, Removing and Installing «LUMBAR SUPPORT ADJUSTMENT SWITCH»(ref-522379-S16403440182013011400000) Four-way lumbar support, removing and installing «FOUR-WAY LUMBAR SUPPORT»(ref-522379-S32993319982013011400000)

The assembly overview shows a manual Standard front seat. The modular wiring for the super sport front seat is similar. Refer to MODULAR WIRE ROUTING ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The trims on the sill and tunnel side of the super sport front seat are similar. Refer to SILL AND TUNNEL SIDE TRIM ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The trim retaining bracket on the sill side of the super sport front seat is similar. Refer to SILL SIDE TRIM RETAINING BRACKET ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The torsion bar is similar for the super sport front seat. Refer to TORSION BAR ASSEMBLY OVERVIEW

Scheme 551

1. Seat Pan
2. Bolt 33 Nm Self-locking Always replace if removed Threaded holes for screws must be cleaned, for example, with thread cutter
3. Backrest Removing and installing, refer to «BACKREST»(ref-522379-S11273622302013011400000)
4. Driver Entry Assistance Button -E358- Front passenger side: front passenger entry assistance button -E359- Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)
5. Handle With bracket (entry assistance) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
6. Entry Assist Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(ref-522379-S05337448952013011400000)
7. Wiring Harness From the side airbag to the coupling station Depending on optional equipment, there may be more wiring harnesses, such as for seat heating, lumbar support

The assembly overview shows a manual Standard front seat. The procedure is similar for the super sport front seat. Refer to BACKREST COVER ASSEMBLY OVERVIEW

Note. The headrest is a fixed component of the backrest upholstery and can only be removed together with the backrest upholstery. It is not possible to separate the headrest from the backrest upholstery. The backrest cover was not shown in the illustration for clarity purposes.

Scheme 552

1. Backrest frame with bracket The bracket cannot be removed
2. Headrest guide without release button always installed on right side of backrest Removing and installing, refer to «HEADREST GUIDE»(ref-522379-S33290784782013011400000)
3. Headrest with padding Headrest laid in foam in upholstery Removing and installing, refer to «BACKREST COVER AND CUSHION, SUPER SPORT SEAT»(ref-522405-S21554523092013011400000)
4. Headrest guide With release button Removing and installing, refer to «HEADREST GUIDE»(ref-522379-S33290784782013011400000) always installed on left side of backrest
5. Backrest frame with support plate Support plate riveted to the backrest frame Support Plate, Removing and Installing «SUPPORT PLATE»(ref-522379-S01390510962013011400000)

The assembly overview shows the four-way lumbar support on a power Standard front seat. The lower seat frame is similar for the super sport front seat. Refer to SEAT FRAME ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The storage compartment is similar for the super sport front seat. Refer to STORAGE COMPARTMENT ASSEMBLY OVERVIEW

The assembly overview shows a manual Sport front seat. The seat depth adjuster is similar for the super sport front seat. Refer to SEAT DEPTH ADJUSTER ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The electrical and electronic components of the super sport front seat are similar. Refer to ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The control head is similar on the super sport front seat. Refer to SEAT ADJUSTMENT CONTROL HEAD ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat forward/back adjustment motor is similar for the super sport front seat. Refer to FORWARD/BACK ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat height adjustment motor is similar for the super sport front seat. Refer to HEIGHT ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The seat angle adjustment motor is similar for the super sport front seat. Refer to SEAT ANGLE ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The super sport front seat is similar. Refer to BACKREST ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The super sport front seat is similar. Refer to SELECTOR UNIT (BACKREST ADJUSTMENT WHEEL MICROSWITCH) ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The super sport front seat is similar. Refer to SWITCH UNIT MICRO SWITCH ASSEMBLY OVERVIEW

The assembly overview shows a manual Standard front seat. The lumbar support adjustment switches of the super sport front seat are similar. Refer to. Refer to ELECTRICAL COMPONENTS ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The four-way lumbar support is similar on the front super sport seat. Refer to FOUR-WAY LUMBAR SUPPORT ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The entry assistance button is similar for the super sport front seat. Refer to ENTRY ASSISTANCE BUTTON ASSEMBLY OVERVIEW

MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE ASSEMBLY OVERVIEW

The assembly overview shows the four-way lumbar support on a power Standard front seat. The memory seat/steering column adjustment control module is similar on the front super sport seat. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT AND SEAT HEATING CONTROL MODULE ASSEMBLY OVERVIEW

The seat position sensor is the same in all seat versions. Refer to SEAT POSITION SENSOR ASSEMBLY OVERVIEW

Two different versions of the backrest may be installed.

1. Backrest frame with bracket
2. Backrest frame with support plate
3. Note the allocation of the handle with bracket and the entry assistance trim.

Note. The four-way lumbar support and seat frame are not shown in the illustration.

Scheme 553

1. Backrest frame With bracket The bracket cannot be removed
2. Release cable For the backrest release One piece Removing and installing, refer to «BACKREST RELEASE CABLE»(ref-522379-S33993708712013011400000) Adjusting, refer to «BACKREST RELEASE CABLE, ADJUSTING»(ref-522379-S17440046342013011400000)
3. Mount For the backrest release cable Component of the release cable clipped to the backrest frame
4. Rivet Quantity: 2
5. Support plate Riveted to backrest frame Different versions, Removing and installing, refer to «SUPPORT PLATE»(ref-522379-S01390510962013011400000)
6. Backrest frame For versions with the support plate
7. Button With entry assist Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(ref-522379-S38312506322013011400000)
8. Entry assist trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(ref-522379-S05337448952013011400000)
9. Bolt Quantity: 2 3.5 Nm
10. Bolt 3.5 Nm
11. Connecting cable For the backrest release Between the handle and bracket Engaged in the handle and bracket Removing and installing, refer to «CONNECTING CABLE»(ref-522379-S24121537412013011400000)
12. Handle With bracket (entry assistance) For the backrest release Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
13. Bracket For the backrest release cable Riveted to backrest frame Removing and installing, refer to «BACKREST RELEASE BRACKET»(ref-522379-S29331563522013011400000)
14. Bracket For the backrest release cable Quantity: 2 Component of the release cable Riveted to backrest frame
15. Bolts For the backrest release Both sides Component of the backrest hinge

Scheme 554

1. Bench Seat Assembly overview, refer to «BENCH SEAT ASSEMBLY OVERVIEW»(ref-522379-S22500886722013011400000) Removing and installing, refer to «BENCH SEAT»(ref-522379-S10250447682013011400000) Optional equipment: Seat heater Center storage compartment
2. Side Upholstery Assembly overview, refer to «REAR SEAT BACKREST ASSEMBLY OVERVIEW»(ref-522379-S22641538532013011400000) Removing and installing, refer to «SIDE UPHOLSTERY»(ref-522379-S33749679072013011400000)
3. Headrest Assembly overview, refer to «REAR HEAD RESTRAINTS ASSEMBLY OVERVIEW»(ref-522379-S37005055582013011400000) Removing and installing, refer to «REAR HEADREST»(ref-522379-S22421018692013011400000)
4. Rear Seat Backrest Lock Assembly overview, refer to «BACKREST LOCK ASSEMBLY OVERVIEW»(ref-522379-S05546611632013011400000) Removing and installing, refer to «REAR SEAT BACKREST RELEASE LEVER»(ref-522379-S16977037892013011400000)
5. Rear Seat Backrest Assembly overview, refer to «REAR SEAT BACKREST ASSEMBLY OVERVIEW»(ref-522379-S22641538532013011400000) Removing and installing, refer to «REAR BACKREST»(ref-522379-S28247886592013011400000) Optional equipment: Backrest heater

Scheme 555

1. Bolt Quantity: 2 2.8 Nm
2. Bench Seat With center storage compartment Vehicles with Removing and installing, refer to «BENCH SEAT»(ref-522379-S10250447682013011400000)
3. Center Storage Compartment Vehicles with Removing and installing, refer to «CENTER STORAGE COMPARTMENT»(ref-522379-S31089421582013011400000)
4. Bench Seat Without a center storage compartment Removing and installing, refer to «BENCH SEAT»(ref-522379-S10250447682013011400000)

Scheme 556

1. Expanding Rivet
2. Release Lever For the rear seat backrest Removing and installing, refer to «REAR SEAT BACKREST RELEASE LEVER»(ref-522379-S16977037892013011400000)
3. Bracket For the release
4. Clips For the release
5. Bolt Quantity: 4 20 Nm
6. Lock For the rear seat backrest Removing and installing, refer to «REAR SEAT BACKREST LOCK»(ref-522379-S06893498452013011400000)
7. Release Cable For the rear seat backrest lock Removing and installing, refer to «RELEASE»(ref-522379-S24211630172013011400000)
8. Luggage Compartment Side Trim Removing and installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM»(ref-522378-S07747626042013011400000)

Scheme 557

1. Headrest Removing and installing, refer to «REAR HEADREST»(ref-522379-S22421018692013011400000)
2. Bolt 10 Nm Quantity: 3
3. Rivet Nuts Quantity: 6 Removing and installing, refer to «REAR HEADREST POP RIVET NUT»(ref-522379-S40648260342013011400000)

Scheme 558

1. Rear Seat Belt Latch Removing and installing, refer to «REAR BELT LATCH»(ref-522301-S15643330152013011400000)
2. Nut Tightening specification «REAR BELT LATCH ASSEMBLY OVERVIEW»(ref-522301-S31666121322013011400000)
3. Nut 4 Nm
4. Side Upholstery Removing and installing, refer to «SIDE UPHOLSTERY»(ref-522379-S33749679072013011400000)
5. Rear Seat Backrest Removing and installing, refer to «REAR BACKREST»(ref-522379-S28247886592013011400000)
6. Cover For the striker pin Removing and installing, refer to «STRIKER PIN COVER»(ref-522379-S06168129582013011400000)
7. Bolt 32 Nm
8. Bolt 3.5 Nm Quantity: 4
9. Hood Catch Removing and installing, refer to «STRIKER PIN»(ref-522379-S00475529442013011400000)
10. Backrest Shell Front side taped with double-sided adhesive tape Removing and installing, refer to «BACKREST PANEL»(ref-522379-S30456069332013011400000)
11. Bolt 4 Nm Quantity: 16
12. Bolt 32 Nm Quantity: 4
13. LATCH Child Seat Anchor Welded to the backrest frame. Remove the backrest frame to replace. Refer to «REAR SEAT BACKREST, REMOVING FROM BACKREST FRAME»(ref-522379-S26339920612013011400000)
14. Backrest Frame With child seat anchor Removing and installing, refer to «REAR SEAT BACKREST, REMOVING FROM BACKREST FRAME»(ref-522379-S26339920612013011400000)

Note. The illustration does not show the spring mat, the four-way lumbar support and the seat frame.

Scheme 559

1. Bolts For the backrest release Both sides Component of the backrest hinge
2. Bracket For the backrest release cable Quantity: 2 Component of the release cable Riveted to backrest frame
3. Release Cable For the backrest release One piece Removing and installing, refer to «BACKREST RELEASE CABLE»(ref-522379-S33993708712013011400000) Adjusting, refer to «BACKREST RELEASE CABLE, ADJUSTING»(ref-522379-S17440046342013011400000)
4. Mount For the backrest release cable Component of the release cable Clipped to the backrest frame
5. Bracket For the backrest release For the backrest release cable Riveted to backrest frame Removing and installing, refer to «BACKREST RELEASE BRACKET»(ref-522379-S29331563522013011400000)
6. Connecting Cable For the backrest release Between the handle and bracket Engaged in the handle and bracket Removing and installing, refer to «CONNECTING CABLE»(ref-522379-S24121537412013011400000)
7. Handle With bracket (entry assistance) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(ref-522379-S06261584432013011400000)
8. Screws Quantity: 2 3.5 Nm
9. Entry Assist Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(ref-522379-S05337448952013011400000)
10. Button With entry assist For power seats only
11. Bolt 3.5 Nm
12. Clip Quantity: 2
13. Cover With entry assist Removing and installing, refer to «ENTRY ASSISTANCE COVER»(ref-522379-S27229470922013011400000)
14. Support Plate Riveted to backrest frame Different versions for different equipment Standard seat Comfort seat Sport seat Super sport seat Removing and installing, refer to «SUPPORT PLATE»(ref-522379-S01390510962013011400000)
15. Rivet Quantity: 2
16. Backrest Frame

Entry Assistance Assembly Overview

Scheme 560

1. Seat rail release With bracket for the entry assist cables
2. Backrest With pin for engaging entry assistance cable B
3. >>Entry Assistance<< Release Cable B From the backrest hinge to the seat rail release Removing and installing, refer to «ENTRY ASSISTANCE CABLE B»(ref-522379-S31985006622013011400000)
4. Release cable adjuster Entry Assistance, cable A
5. Backrest With the strap for engaging cable A
6. release bracket For securing the release cable on the backrest frame Clipped to the backrest frame Component of the release cable
7. >>Entry Assistance<< Release Cable A From the backrest hinge to the seat rail release Removing and installing, refer to «ENTRY ASSISTANCE RELEASE CABLE A»(ref-522379-S34876767662013011400000) Adjusting, refer to «ENTRY ASSISTANCE RELEASE CABLE A, ADJUSTING»(ref-522379-S02342104612013011400000)
8. Front seat
9. Memory stop Removing and installing, refer to «MEMORY STOP»(ref-522379-S34592773552013011400000)
