Interior Equipment (Coupe): Overview Audi S5 I facelift

Seats 7 illustrations ~1338 words

INTERIOR REARVIEW MIRROR GENERAL INFORMATION

There are different versions of the interior rearview mirrors, each with different features

  1. Manual dimming interior rearview mirror
  2. Automatic dimming interior rearview mirror -Y7
  3. Interior rearview mirror with digital compass
  4. Interior rearview mirror with rain/light recognition sensor -G397
  5. Interior rearview mirror with humidity sensor -G355

CENTER CONSOLE OVERVIEW

Vehicles with a Front Center Armrest

Scheme 3

Scheme 3: CENTER CONSOLE OVERVIEW
Scheme 3: CENTER CONSOLE OVERVIEW
  1. Converter with Socket, 12 V-230 V -U13- Special extra equipment version; for the center arm rest Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520042-S16151586192012123100000)
  2. Cupholder Removing and installing, refer to «CUPHOLDER»(ref-520128-S07440074652012123100000)
  3. Bracket For center console Removing and installing, refer to «CENTER CONSOLE BRACKET»(ref-520128-S39918810992012123100000)
  4. Nut Quantity: 4 8 Nm
  5. Bolt Quantity: 4 3 Nm
  6. Bolt Quantity: 8 1.4 Nm Tightening sequence «CENTER CONSOLE TRIM PANEL =>»(ref-520128-S18115589922012123100000)
  7. Front Ashtray Removing and installing, refer to «FRONT ASHTRAY»(ref-520128-S40840180562012123100000) Ashtray Trim, removing and installing «FRONT ASHTRAY TRIM»(ref-520128-S24356753942012123100000)
  8. Bolt Quantity: 2 2.5 Nm
  9. Decorative Frame
  10. Shift Lever or Selector Lever Shift Lever, removing and installing «Removal and Installation»(ref-520091-S00492665772012123100000) or to «[For engine(s) CAUA] Removal and Installation»(ref-520092-S25454589622012123100000) Selector Lever, removing and installing «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520046-S17176144922012123100000) or to «Removal and Installation»(ref-520048-S27475934952012123100000)
  11. Coin Holder
  12. Insert For center console Vehicles with special equipment Removing and installing, refer to «CENTER CONSOLE INSERT»(ref-520128-S03329999372012123100000) Multimedia System Control Head -E380- removing and installing «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  13. Trim Panel For center console Vehicles with special equipment Removing and installing, refer to «CENTER CONSOLE TRIM PANEL»(ref-520128-S18115589922012123100000)
  14. Clips Quantity: 6 Install on the center console insert
  15. Center Console Vehicles with special equipment Removing and installing, refer to «CENTER CONSOLE»(ref-520128-S35702320882012123100000)
  16. Rear Storage Compartment Vehicles with special equipment Removing and installing, refer to «CENTER CONSOLE REAR STORAGE COMPARTMENT»(ref-520128-S07190950122012123100000)
  17. Lining Mat
  18. Rear Vent Vehicles with special equipment Removing and installing, refer to «REAR VENT»(ref-520128-S05740595662012123100000)
  19. Bolt 2.5 Nm
  20. Rear Trim For center console Vehicles with special equipment Removing and installing, refer to «REAR CENTER CONSOLE TRIM»(ref-520128-S30159675782012123100000)
  21. Rear Ashtray Removing and installing, refer to «REAR ASHTRAY»(ref-520128-S25233797462012123100000)
  22. 12 V Socket Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520042-S16151586192012123100000)
  23. Lining Mat
  24. Bolt Quantity: 4 1.4 Nm
  25. Storage Compartment Vehicles with special equipment Removing and installing, refer to «STORAGE COMPARTMENT»(ref-520128-S07161022702012123100000)
  26. Bolt Quantity: 8 1.4 Nm
  27. Bolt Quantity: 2 Tightening specification, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520042-S16151586192012123100000) .

Vehicles without a Front Center Armrest

Scheme 4

Scheme 4
Scheme 4
  1. Bracket For center console Removing and installing, refer to «CENTER CONSOLE BRACKET»(ref-520128-S39918810992012123100000)
  2. Nut Quantity: 4 8 Nm
  3. Bolt Quantity: 4 3 Nm
  4. Center Console Vehicles with special equipment Removing and installing, refer to «CENTER CONSOLE»(ref-520128-S35702320882012123100000)
  5. Front Ashtray Removing and installing, refer to «FRONT ASHTRAY»(ref-520128-S40840180562012123100000) Ashtray Trim, removing and installing «FRONT ASHTRAY TRIM»(ref-520128-S24356753942012123100000)
  6. Bolt Quantity: 2 2.5 Nm
  7. Shift Lever or Selector Lever Shift Lever, removing and installing «Removal and Installation»(ref-520091-S00492665772012123100000) or to «[For engine(s) CAUA] Removal and Installation»(ref-520092-S25454589622012123100000) Selector Lever, removing and installing «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520046-S17176144922012123100000) or to «Removal and Installation»(ref-520048-S27475934952012123100000)
  8. Decorative Frame
  9. Coin Holder
  10. Insert For center console Vehicles with special equipment Removing and installing, refer to «CENTER CONSOLE INSERT»(ref-520128-S03329999372012123100000) Multimedia System Control Head -E380- removing and installing «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(ref-520129-S15846927862012123100000)
  11. Clips Quantity: 6 Install on the center console insert
  12. Lining mat
  13. Backing
  14. Nut Quantity: 2 4 Nm
  15. Cover For center console Vehicles with special equipment Removing and installing, refer to «CENTER CONSOLE COVER»(ref-520128-S28000483352012123100000)
  16. Rear Ashtray Removing and installing, refer to «REAR ASHTRAY»(ref-520128-S25233797462012123100000)
  17. Lining mat
  18. Bolt Quantity: 8 1.4 Nm
  19. Cupholder Removing and installing, refer to «CUPHOLDER»(ref-520128-S07440074652012123100000)

Scheme 5

Scheme 5: FRONT CENTER ARMREST OVERVIEW
Scheme 5: FRONT CENTER ARMREST OVERVIEW
  1. Threaded Clip Quantity: 2
  2. Cover Clipped with -5
  3. Lower Trim For the hinge arm Clipped with -7- and -8- Removing and installing, refer to «HINGE ARM TRIM»(ref-520128-S17937908312012123100000)
  4. Bolt Quantity: 2 2.2 Nm
  5. Padding Removing and installing, refer to «FRONT CENTER ARMREST UPHOLSTERY»(ref-520128-S41238549332012123100000)
  6. Trim
  7. Upper Trim For the hinge arm Clipped with -3- Removing and installing, refer to «HINGE ARM TRIM»(ref-520128-S17937908312012123100000)
  8. Support Base Removing and installing, refer to «FRONT CENTER ARMREST»(ref-520128-S42044992392012123100000)
  9. Bolt Quantity: 2 3 Nm
  10. Nut Quantity: 4 20 Nm
  11. Bolt Quantity: 2 3 Nm

DRIVER SIDE INSTRUMENT PANEL COVER OVERVIEW

Note. The driver side instrument panel cover on a vehicle without a knee airbag is shown in the illustration. For vehicles with a knee bag, refer to DRIVER SIDE INSTRUMENT PANEL COVER WITH KNEE AIRBAG .

Scheme 6

Scheme 6: DRIVER SIDE INSTRUMENT PANEL COVER OVERVIEW
Scheme 6: DRIVER SIDE INSTRUMENT PANEL COVER OVERVIEW
  1. Bolt 3 Nm
  2. Side Cover For instrument panel Removing and installing, refer to «INSTRUMENT PANEL SIDE COVER»(ref-520145-S02326069182012123100000)
  3. Clips Insert in the footrest
  4. 16-Pin Connector -T16- Diagnostic connector
  5. Clips Install on the A/C unit
  6. Spring Clamp For the driver side instrument panel cover
  7. Bolt 3 Nm
  8. Driver Side Instrument Panel Cover Removing and installing, refer to «DRIVER SIDE INSTRUMENT PANEL COVER»(ref-520128-S41722069782012123100000) On some country versions with knee airbag with cut-out for the knee airbag Removing and installing, countries with knee airbags «DRIVER SIDE INSTRUMENT PANEL COVER WITH KNEE AIRBAG»(ref-520128-S31463275962012123100000)
  9. Bolt 3 Nm

GLOVE COMPARTMENT OVERVIEW

Note. The glove compartment in a vehicle without a knee airbag is shown in the illustration. If the vehicle has a knee airbag, refer to GLOVE COMPARTMENT, WITH KNEE AIRBAGS .

Scheme 7

Scheme 7: GLOVE COMPARTMENT OVERVIEW
Scheme 7: GLOVE COMPARTMENT OVERVIEW
  1. Glove Compartment Lamp -W6- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Interior Lights, Switches»(ref-520166-S24233765322012123100000)
  2. Footwell Light Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Interior Lights, Switches»(ref-520166-S24233765322012123100000)
  3. Passenger Side Instrument Panel Cover Removing and installing, refer to «PASSENGER SIDE INSTRUMENT PANEL COVER»(ref-520128-S29339090802012123100000)
  4. Bolt 3 Nm
  5. Hinge Pin For securing the glove compartment cover
  6. Rubber Buffer For the glove compartment Quantity: 6
  7. Glove Compartment Removing and installing, refer to «GLOVE COMPARTMENT»(ref-520128-S03222408832012123100000) On some country versions with knee airbag with cut-out for the knee airbag Removing and installing, countries with knee airbags «GLOVE COMPARTMENT, WITH KNEE AIRBAGS»(ref-520128-S07211896292012123100000)
  8. Threaded Clip
  9. Lid Dampening Mechanism For the glove compartment cover With Glove Compartment Lamp Switch -E26- Removing and installing, refer to «GLOVE COMPARTMENT COVER BRAKE COMPONENT»(ref-520128-S05786654602012123100000)
  10. Hinge Pin
  11. Bolt 3 Nm
  12. Bolt Quantity: 3 or 5 (depending on the equipment level) 3 Nm
  13. Mount For striker pin
  14. Front Passenger Airbag Deactivation Key Switch -E224- NOTE: Not applicable for North American market. WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «SAFETY PRECAUTIONS»(ref-520043-S07728518712012123100000) . Vehicles with special equipment Removing and installing, refer to «Front Passenger Airbag Deactivation Key Switch -E224»(ref-520043-S23221092272012123100000)
  15. Bracket
  16. Bolt 3 Nm
  17. Glove Compartment Cover Removing and installing, refer to «GLOVE COMPARTMENT COVER»(ref-520128-S09210737532012123100000)
  18. Glove Compartment Opener Removing and installing, refer to «GLOVE COMPARTMENT OPENER»(ref-520128-S39069665432012123100000)
  19. Rubber Stop For the glove compartment cover

Scheme 8

Scheme 8: STEERING COLUMN SWITCH MODULE TRIM OVERVIEW
Scheme 8: STEERING COLUMN SWITCH MODULE TRIM OVERVIEW
  1. Gap Cover For instrument cluster Removing and installing, refer to «INSTRUMENT CLUSTER GAP COVER»(ref-520128-S42886726432012123100000)
  2. Upper Trim For steering column switch module Removing and installing, refer to «STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL»(ref-520128-S37635119162012123100000)
  3. Screws 2.0 Nm
  4. Lower Trim For steering column switch module Removing and installing, refer to «STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL»(ref-520128-S08100018642012123100000)
  5. Bolt 2.0 Nm
  6. Handle For the steering column adjustment Vehicles with special equipment
  7. Bolt 3 Nm

Scheme 9

Scheme 9: STORAGE COMPARTMENTS AND COVERS OVERVIEW
Scheme 9: STORAGE COMPARTMENTS AND COVERS OVERVIEW
  1. Center Console Assembly overview, refer to «CENTER CONSOLE OVERVIEW»(ref-520128-S00055316292012123100000) Removing and installing, refer to «CENTER CONSOLE»(ref-520128-S35702320882012123100000)
  2. Instrument Panel Cover Driver side Assembly overview, refer to «DRIVER SIDE INSTRUMENT PANEL COVER OVERVIEW»(ref-520128-S17866097422012123100000) Removing and installing with knee airbag «DRIVER SIDE INSTRUMENT PANEL COVER»(ref-520128-S41722069782012123100000) Removing and installing with knee airbag «DRIVER SIDE INSTRUMENT PANEL COVER WITH KNEE AIRBAG»(ref-520128-S31463275962012123100000)
  3. Trim For steering column switch module Assembly overview, refer to «STEERING COLUMN SWITCH MODULE TRIM OVERVIEW»(ref-520128-S24509341792012123100000) Upper trim, removing and installing, refer to «STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL»(ref-520128-S37635119162012123100000) Lower trim, removing and installing, refer to «STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL»(ref-520128-S08100018642012123100000)
  4. Central Tube For instrument panel Assembly overview, refer to «INSTRUMENT PANEL CENTRAL TUBE OVERVIEW»(ref-520145-S11111366302012123100000) Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-520145-S17622673112012123100000)
  5. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «SAFETY PRECAUTIONS»(ref-520043-S07728518712012123100000) . Assembly overview, refer to «INSTRUMENT PANEL OVERVIEW»(ref-520145-S24796464022012123100000) Removing and installing, refer to «INSTRUMENT PANEL»(ref-520145-S34999297862012123100000)
  6. Glove compartment Assembly overview, refer to «GLOVE COMPARTMENT OVERVIEW»(ref-520128-S06825610822012123100000) Removing and installing, refer to «GLOVE COMPARTMENT»(ref-520128-S03222408832012123100000)
  7. Front Center Armrest Vehicles with special equipment Assembly overview, refer to «FRONT CENTER ARMREST OVERVIEW»(ref-520128-S25214478642012123100000) Removing and installing, refer to «FRONT CENTER ARMREST»(ref-520128-S42044992392012123100000)
