FASTENER TIGHTENING SPECIFICATIONS
| Components | Fastener Size | Nm |
|---|---|---|
| Console for Vehicles with a Front Center Armrest | ||
| Ashtray to Console | 2.5 | |
| Bracket to Center Console 1 | ||
| Bolt | 3 | |
| Nut | 8 | |
| Center Cross Support to Console | 1.4 | |
| Cupholder to Console | 1.4 | |
| Rear Trim to Console | 2.5 | |
| Storage Compartment to Console | 1.4 | |
| Console for Vehicles without a Front Center Armrest | ||
| Ashtray to Console | 2.5 | |
| Bracket to Center Console 2 | ||
| Bolt | 3 | |
| Nut | 8 | |
| Cupholder to Console | 1.4 | |
| Console to Floor Securing | 4 | |
| Steering Column Switch Module Trim | ||
| Bottom Trim to Column | 2 | |
| Handle to Column | 3 | |
| Driver Side Instrument Panel Cover | ||
| Side of Cover to Vehicle | 3 | |
| Right Front of Cover to Vehicle | 3 | |
| Left Front of Cover to Vehicle | 3 | |
| Front Center Armrest | ||
| Armrest Hinge to Pad | 2.2 | |
| Support Base Cross Member | 3 | |
| Support Base to Clip | 3 | |
| Support Base to Vehicle | 20 | |
| Glove Compartment | ||
| Compartment to Vehicle Right Side | 3 | |
| Compartment to Vehicle Upper | 3 | |
| Compartment to Vehicle Front | 3 | |
| Hinge to Glove Compartment | 3 | |
| 1 For bolt tightening clarification for vehicles with a front center armrest, refer to CENTER CONSOLE OVERVIEW and see items -4 and 5- 2 For bolt tightening clarification for vehicles without a front center armrest, refer to CENTER CONSOLE OVERVIEW and see items -2 and 3 | ||
Scheme 1
Remove the center console insert. Refer to CENTER CONSOLE INSERT
Remove the front ashtray. Refer to FRONT ASHTRAY
Vehicles with a 12V outlet: disconnect the connector -2-.
Remove the bolts -1- and -3-.
Vehicles with a front center armrest: remove the front center armrest. Refer to FRONT CENTER ARMREST .
Vehicles without a front center armrest: remove center console cover and nuts. Refer to CENTER CONSOLE COVER -1
Scheme 2
Vehicles with a telephone/cell phone: disconnect the connectors.
Lift the center console and remove it back out of the instrument panel and over the selector lever/shift lever.
