REMOVING FRONT SEAT WITH FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR OR CONTROL MODULE
Test the seat forward/back adjustment motor -V28- / -V31- or control module -J136- / -J521-.
| WARNING | Follow all safety precautions when working on pyrotechnic components. Refer to RESTRAINT SYSTEM COMPONENTS . Before handling pyrotechnical components (for example, disconnecting the connector), the person handling them must "discharge static electricity". For example, by briefly touching the door striker pin. |
Move the seat as far up as possible.
Note. Check electrical and electronic components and wires before removing seat further to avoid unnecessary repair costs.
Perform the following tests
- Check the fuse. Refer to appropriate SYSTEM WIRING DIAGRAM.
- Check the voltage at the connector station and perform fault finding if necessary. Refer to appropriate SYSTEM WIRING DIAGRAM.
- Check the voltage to the control module. Refer to appropriate SYSTEM WIRING DIAGRAM.
- Check the voltage to the seat forward/back adjustment motor -V288-. Refer to appropriate SYSTEM WIRING DIAGRAM.
Replace the fuse if faulty. Refer to appropriate SYSTEM WIRING DIAGRAM.
If there is no voltage at the connector station, repair or replace the wire. Refer to appropriate SYSTEM WIRING DIAGRAM.
Replace the seat pan lower frame together with seat forward/back adjustment motor. Refer to UPPER SEAT FRAME .
Replace the memory seat/steering column adjustment control module -J136- or the passenger memory seat control module -J521- is faulty. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE .
Removing a faulty seat forward/back adjustment motor -V28- / -V31
| WARNING | Before handling pyrotechnical components (for example, disconnecting the connector), the person handling them must "discharge static electricity". For example, by briefly touching the door striker pin. |
Turn the ignition on.
Disconnect the battery ground cable with the ignition switched on. Refer to Removal and Installation .
Disconnect the electrical harness connectors at the coupling station. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .
Connect Airbag Adapter VAS 6281. Refer to Airbag Adapter VAS 6281, DISCONNECTING AND CONNECTING .
Remove the bolt -3-.
Scheme 561
Remove the seat position sensor -2- from the seat pan lower frame -1- at the hooks and move the electrical wire to the side -arrow-.
Disconnect the front safety belt latch connector. Refer to FRONT BELT LATCH .
Disconnect the electrical connector on the seat forward/back adjustment motor.
Scheme 562
Remove the bolt -3-.
| CAUTION | Danger of damaging the threaded the holes or the bushing in the bearing points (connecting the upper and lower frame). A second technician is needed to push on the seat via the backrest while removing the following screws. |
Remove the bolts -2-.
With a second technician, separate the upper seat frame -1- from the lower frame -4- and remove from the vehicle.
Note. Seat without the cushion, cover and backrest is illustrated.
Make sure the bushings -1- and the bearing points (connection upper and lower frame) -2- are not damaged.
Scheme 563
| CAUTION | The bushings cannot be replaced with workshop materials. If the bushings are damaged, the corresponding assembly parts must be replaced. |
Remove the bolts for the seat rail to the bracket.
Scheme 564
Remove the screws -2- and -5- and remove the seat forward/back adjuster motor -1- and bracket.
Slide the seat rail -3- and -4- back and forth until the screw is accessible.
Remove the screws and the seat rail.
Replace the lower seat pan frame with seat forward/back adjustment motor. Refer to UPPER SEAT FRAME .
Removing a faulty control module -J136- / -J521-.
| WARNING | Follow all safety precautions when working on pyrotechnic components. Refer to RESTRAINT SYSTEM COMPONENTS . Before handling pyrotechnical components (for example, disconnecting the connector), the person handling them must "discharge static electricity". For example, by briefly touching the door striker pin. |
Switch the ignition on.
Disconnect the battery Ground (GND) cable with the ignition switched on. Refer to Removal and Installation .
Disconnect the electrical connector on the seat forward/back adjustment motor.
Connect the seat forward/back adjustment motor to an external power source and move the seat forward or back until the bolts -1- (quantity: 4) are visible.
Scheme 565
Remove the bolts -1-.
Disconnect the electrical harness connectors at the coupling station; refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .
Connect airbag adapter. Refer to Airbag Adapter VAS 6281, DISCONNECTING AND CONNECTING .
Raise the front seat with a 2nd technician and remove it from the vehicle.
Attach the front seat to the fixture for seat repair VAS 6136. Refer to INSTALLING THE FRONT SEAT ON VAS 6136 .
Replace control module -J136- / -J521-. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE .
SWITCH UNIT, CALIBRATING
Special tools and workshop equipment required
- Vehicle Diagnosis Tester
Procedure
- Front seat installed
- Vehicle Diagnosis Tester connected
- Ignition switched on.
Choose "Guided Functions" under Vehicle Diagnosis Tester.
Select the "control module address" (06 front passenger seat or 36 driver seat)
Perform the "seat axis designation".
The switch unit microswitches are calibrated the same way on all power seat versions. Refer to SWITCH UNIT, CALIBRATING
The switch unit microswitches are calibrated the same way on all power seat versions. Refer to SWITCH UNIT, CALIBRATING
SUPER SPORT FRONT SEAT, REMOVING DUE TO FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR OR CONTROL MODULE
The removal of the power Standard front seat is described here. The procedure is similar for the super sport front seat. Refer to REMOVING FRONT SEAT WITH FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR OR CONTROL MODULE
The switch unit microswitches are calibrated the same way on all power seat versions. Refer to SWITCH UNIT, CALIBRATING
SEAT HEIGHT ADJUSTMENT HANDLE
Note. The seat height adjustment handle can be replaced with the front seat installed.
Special tools and workshop equipment required
- Hook 3438
Scheme 566
Note. Remove the seat height adjustment handle -1- as described. Do not drive it off the lever -2-. If the tab -arrow- is damaged when removing the seat height adjustment handle, the handle cannot be reinstalled. It must be replaced.
Pull the seat height adjustment handle -1- as far up as possible and hold it in that position.
Scheme 567
Carefully pull the seat height adjustment handle slightly away from the front seat.
Place the 3438 between the seat height adjustment handle and the trim -2-.
Unlock the release -3- using the 3438 and at the same time, pull the seat height adjustment handle in -direction of arrow- from the lever.
SEAT FORWARD/BACK ADJUSTMENT HANDLE
Note. Removal and Installation can be done with the seat installed.
Scheme 568
Bring headrest into lowest lock position.
Press the seat forward/backward handle and move the seat as far back as possible.
Pry handle -1- off of seat forward/back adjuster -2- by using a screwdriver to press down the clip locking spring.
Note. If it is not possible to remove the handle as described, then remove the storage compartment. Refer to STORAGE COMPARTMENT .
Scheme 569
Installation is reverse of removal, but note the following
Replace the clip on the seat forward/back adjustment handle. Note the installation position.
- The springs -arrows- on the clip -2- must be on the inner side of the lever -1-.
Make sure the seat height adjustment handle engages correctly with the clips.
SEAT ADJUSTMENT CONTROL HEAD
Note. Removal and installation can be done with seat installed.
Special tools and workshop equipment required
- Trim Removal Wedge 3409
Scheme 570
Carefully pry the seat adjustment actuator -1- from the retainer using a 3409.
BACKREST AND HEADREST ADJUSTMENT ACTUATOR
Note. Removal and installation can be done with seat installed.
Special tools and workshop equipment required
- Trim Removal Wedge 3409
Scheme 571
Carefully pry the actuator -1- out of the retainer using the 3409.
FORWARD/BACK ADJUSTMENT MOTOR
The seat forward/back adjustment motor can only be replaced together with the seat pan lower frame. Refer to UPPER SEAT FRAME
HEIGHT ADJUSTMENT MOTOR
Special tools and workshop equipment required
- Fixture for Seat Repair VAS 6136
SEAT ANGLE ADJUSTMENT MOTOR
Special tools and workshop equipment required
- Fixture for Seat Repair VAS 6136
BACKREST ADJUSTMENT MOTOR
Special tools and workshop equipment required
- Fixture for Seat Repair VAS 6136
- Locking compound
SWITCH UNIT, MICRO SWITCH FOR BACKREST ADJUSTMENT WHEEL
Special tools and workshop equipment required
- Fixture for Seat Repair VAS 6136
- Locking compound
LUMBAR SUPPORT ADJUSTMENT SWITCH
Removal and installation of the four-way lumbar support on a power Standard front seat is described here. The power standard seat is identical. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE
Special tools and workshop equipment required
- Trim Removal Wedge 3409
- Fixture for Seat Repair VAS 6136
FRONT SEAT WITH FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR OR CONTROL MODULE
The following describes the removal of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a manual sport front seat. The procedure is similar for a comfort front seat.
MEMORY SEAT/STEERING COLUMN ADJUSTMENT AND SEAT HEATING WITH INTEGRATED SEAT VENTILATION CONTROL MODULE
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat.
Removal and installation of the headrest guide on a manual Standard front seat is described here. Removal and installation of the manual Sport front seat is identical.
SEAT ANGLE ADJUSTMENT HANDLE
Note. Removal and installation can be performed with the front seat installed.
Scheme 572
Remove tunnel side trim panel. Refer to SILL SIDE TRIM .
Pry the handle -2- off the seat angle adjustment -1- by using a screwdriver to press down the clip locking spring.
Scheme 573
Installation is reverse of removal, but note the following
Replace the clip on the seat height adjustment handle. Note the installation position.
Make sure the seat height adjustment handle engages correctly with the clips.
- The springs -arrows- (quantity: 2) on the clip -2- must be on the inner side of the lever -1-.
Removal and installation of the headrest guide on a manual Standard front seat is described here. Removal and installation of the manual Sport front seat is identical.
RELEASE CABLE MOUNT LEVER AND SEAT FORWARD/BACK ADJUSTMENT SPRING
Removal and installation of the headrest guide on a manual Standard front seat is described here. Removal and installation of the manual Sport front seat is identical.
Removal and installation of the four-way lumbar support on a power Standard front seat is described here. Removal and installation of the manual Sport front seat is identical.
