Interior Equipment (Cabriolet): Overview Audi S5 I facelift

Seats 9 illustrations ~1405 words

Scheme 456

Scheme 456: STORAGE COMPARTMENTS AND COVERS OVERVIEW
Scheme 456: STORAGE COMPARTMENTS AND COVERS OVERVIEW
  1. Center Console Assembly overview, refer to «CENTER CONSOLE ASSEMBLY OVERVIEW»(ref-522367-S24195934402013011400000) Removing and installing, refer to «CENTER CONSOLE»(ref-522367-S27348856052013011400000)
  2. Driver Side Instrument Panel Cover Assembly overview, refer to «DRIVER SIDE INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW»(ref-522367-S26960356962013011400000) Removing and installing, refer to «DRIVER SIDE INSTRUMENT PANEL COVER»(ref-522367-S19242479642013011400000)
  3. Trim For steering column switch module Assembly overview, refer to «STEERING COLUMN SWITCH MODULE TRIM ASSEMBLY OVERVIEW»(ref-522367-S19309314852013011400000) Upper trim, removing and installing «STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL»(ref-522367-S20097306822013011400000) Lower trim, removing and installing «STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL»(ref-522367-S05868427522013011400000)
  4. Central Tube for instrument panel Assembly overview, refer to «INSTRUMENT PANEL CENTRAL TUBE ASSEMBLY OVERVIEW»(ref-522378-S41004480342013011400000) Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-522378-S35885578502013011400000)
  5. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS»(ref-522301-S31745711692013011400000) . Assembly overview, refer to «INSTRUMENT PANEL ASSEMBLY OVERVIEW»(ref-522378-S33709824812013011400000) Removing and installing, refer to «INSTRUMENT PANEL»(ref-522378-S27850286942013011400000)
  6. Glove Compartment Assembly overview, refer to «GLOVE COMPARTMENT ASSEMBLY OVERVIEW»(ref-522367-S10553116422013011400000) Removing and installing, refer to «GLOVE COMPARTMENT»(ref-522367-S08818831782013011400000)
  7. Front Center Armrest Vehicles with Assembly overview, refer to «FRONT CENTER ARMREST ASSEMBLY OVERVIEW»(ref-522367-S42178315902013011400000) Removing and installing, refer to «FRONT CENTER ARMREST»(ref-522367-S11333072982013011400000)

GLOVE COMPARTMENT ASSEMBLY OVERVIEW

Note. The glove compartment in a vehicle without a knee airbag is shown in the illustration. If the vehicle has a knee airbag, refer to GLOVE COMPARTMENT WITH KNEE AIRBAGS .

Scheme 457

Scheme 457: GLOVE COMPARTMENT ASSEMBLY OVERVIEW
Scheme 457: GLOVE COMPARTMENT ASSEMBLY OVERVIEW
  1. Glove Compartment Light -W6- Vehicles with Removing and installing, refer to «Removal and Installation»(ref-522299-S27854082502013011400000)
  2. Footwell Light Vehicles with Removing and installing, refer to «Removal and Installation»(ref-522299-S27854082502013011400000)
  3. Passenger Side Instrument Panel Cover Removing and installing, refer to «PASSENGER SIDE INSTRUMENT PANEL COVER»(ref-522367-S26248478342013011400000)
  4. Bolt 3 Nm
  5. Hinge Pin For securing the glove compartment cover
  6. Rubber Buffer For the glove compartment Quantity: 6
  7. Glove Compartment Removing and installing, refer to «GLOVE COMPARTMENT»(ref-522367-S08818831782013011400000) One some country versions with knee airbag with cut-out for the knee airbag Removing and installing, countries with knee airbags «GLOVE COMPARTMENT WITH KNEE AIRBAGS»(ref-522367-S39437528612013011400000)
  8. Threaded Clip
  9. Lid Dampening Mechanism For the glove compartment cover With glove compartment lamp switch -E26- Removing and installing, refer to «GLOVE COMPARTMENT COVER BRAKE COMPONENT»(ref-522367-S18563424892013011400000)
  10. Hinge Pin
  11. Bolt 3 Nm
  12. Bolt Quantity: 4 3 Nm
  13. Mount For striker pin
  14. Front Passenger Airbag -Off- Key Switch -E224- Not for North American market.
  15. Bracket
  16. Bolt 3 Nm
  17. Glove Compartment Cover Removing and installing, refer to «GLOVE COMPARTMENT LID»(ref-522367-S19968246352013011400000)
  18. Glove Compartment Opener Removing and installing, refer to «GLOVE COMPARTMENT OPENER»(ref-522367-S41753842742013011400000)
  19. Buffer For the glove compartment cover

Scheme 458

Scheme 458: STEERING COLUMN SWITCH MODULE TRIM ASSEMBLY OVERVIEW
Scheme 458: STEERING COLUMN SWITCH MODULE TRIM ASSEMBLY OVERVIEW
  1. Gap Cover For instrument cluster Removing and installing, refer to «INSTRUMENT CLUSTER GAP COVER»(ref-522367-S15513043712013011400000)
  2. Upper Trim For steering column switch module Removing and installing, refer to «STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL»(ref-522367-S20097306822013011400000)
  3. Screws 2.0 Nm
  4. Lower Trim For steering column switch module Removing and installing, refer to «STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL»(ref-522367-S05868427522013011400000)
  5. Bolt 2.0 Nm
  6. Handle For the steering column adjustment
  7. Bolt 3 Nm

DRIVER SIDE INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW

Note. The driver side instrument panel cover on a vehicle without a knee airbag is shown in the illustration. For vehicles with a knee bag, refer to DRIVER SIDE INSTRUMENT PANEL COVER WITH KNEE AIRBAG .

Scheme 459

Scheme 459: DRIVER SIDE INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW
Scheme 459: DRIVER SIDE INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW
  1. Bolt 3 Nm
  2. Side Cover For instrument panel Removing and installing, refer to «INSTRUMENT PANEL SIDE COVER»(ref-522378-S15930967532013011400000)
  3. Clips Insert in the footrest
  4. Connector, 16-Pin -T16- Diagnostic connector
  5. Clips Install on the A/C unit
  6. Spring Clamp For the driver side instrument panel cover Quantity: 4 Press into the instrument panel
  7. Bolt 3 Nm
  8. Driver Side Instrument Panel Cover Removing and installing, refer to «DRIVER SIDE INSTRUMENT PANEL COVER»(ref-522367-S19242479642013011400000) One some country versions with knee airbag with cut-out for the knee airbag Removing and installing, countries with knee airbags. Refer to «DRIVER SIDE INSTRUMENT PANEL COVER WITH KNEE AIRBAG»(ref-522367-S40839084892013011400000)
  9. Bolt 3 Nm

CENTER CONSOLE ASSEMBLY OVERVIEW

Vehicles with a Front Center Armrest

Scheme 460

Scheme 460: CENTER CONSOLE ASSEMBLY OVERVIEW
Scheme 460: CENTER CONSOLE ASSEMBLY OVERVIEW
  1. Converter with Socket, 12 V, 230 V -U13- Extra equipment version; for the center arm rest only Removing and installing, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522300-S03756685252013011400000)
  2. Cup Holder Removing and installing, refer to «CUPHOLDER»(ref-522367-S18176583272013011400000)
  3. Bracket For center console Removing and installing, refer to «CENTER CONSOLE BRACKET»(ref-522367-S40471348092013011400000)
  4. Nut Quantity: 4 8 Nm
  5. Bolt Quantity: 4 3 Nm
  6. Bolt Quantity: 8 1.4 Nm Tightening sequence «CENTER CONSOLE TRIM PANEL»(ref-522367-S34909519492013011400000)
  7. Front Ashtray Removing and installing, refer to «FRONT ASHTRAY»(ref-522367-S33222043302013011400000) Ashtray Trim, removing and installing, refer to «FRONT ASHTRAY TRIM»(ref-522367-S31027549882013011400000)
  8. Bolt Quantity: 2 2.5 Nm
  9. Decorative Frame
  10. Shift Lever or Selector Lever Shift lever, removing and installing, refer to «Removal and Installation»(ref-522345-S40880904142013011400000) Selector lever, removing and installing, refer to «REMOVAL AND INSTALLATION»(ref-520048-S27475934952012123100000)
  11. Coin Holder
  12. Insert For center console Vehicles with Removing and installing, refer to «CENTER CONSOLE INSERT»(ref-522367-S09461595852013011400000) Multi-media controls -E380- removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000)
  13. Trim Panel For center console Vehicles with Removing and installing, refer to «CENTER CONSOLE TRIM PANEL»(ref-522367-S34909519492013011400000)
  14. Clips Quantity: 6 Install on the center console insert
  15. Mount For the convertible top opening switch/power window switches Removing and installing, refer to «CONVERTIBLE TOP OPERATION SWITCH AND CENTRAL WINDOW REGULATOR SWITCH MOUNT»(ref-522367-S39653168912013011400000)
  16. Convertible Top Operation Switch -E137- /Window Regulator Central Switch -E643- Removing and installing, refer to «Removal and Installation»(ref-522299-S27854082502013011400000)
  17. Center Console Vehicles with Removing and installing, refer to «CENTER CONSOLE»(ref-522367-S27348856052013011400000)
  18. Rear Storage Compartment Vehicles with Removing and installing, refer to «CENTER CONSOLE REAR STORAGE COMPARTMENT»(ref-522367-S20759423372013011400000)
  19. Inlay Mat
  20. Rear Vent Vehicles with Removing and installing, refer to «REAR VENT»(ref-522367-S26341277472013011400000)
  21. Bolt 2.5 Nm
  22. Rear Trim For center console Vehicles with Removing and installing, refer to «REAR CENTER CONSOLE TRIM»(ref-522367-S30334092652013011400000)
  23. Trim Removing and installing, refer to «TRIM»(ref-522367-S05978910242013011400000)
  24. 12 V Socket Removing and installing «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522300-S03756685252013011400000)
  25. Lining Mat
  26. Bolt Quantity: 4 1.4 Nm
  27. Storage Compartment Vehicles with Removing and installing, refer to «STORAGE COMPARTMENT»(ref-522367-S22633043312013011400000)
  28. Bolt Quantity: 8 1.4 Nm
  29. Bolt Quantity: 2 Tightening specification, refer to «[For engine(s) CAEB, CCBA] Removal and Installation»(ref-522300-S03756685252013011400000) .

Vehicles without a Front Center Armrest

Scheme 461

Scheme 461
Scheme 461
  1. Bracket For center console Removing and installing, refer to «CENTER CONSOLE BRACKET»(ref-522367-S40471348092013011400000)
  2. Nut Quantity: 4 8 Nm
  3. Bolt Quantity: 4 3 Nm
  4. Center Console Vehicles with Removing and installing, refer to «CENTER CONSOLE»(ref-522367-S27348856052013011400000)
  5. Front Ashtray Removing and installing, refer to «FRONT ASHTRAY»(ref-522367-S33222043302013011400000) Ashtray trim, removing and installing, refer to «FRONT ASHTRAY TRIM»(ref-522367-S31027549882013011400000)
  6. Bolt Quantity: 2 2.5 Nm
  7. Shift Lever or Selector Lever Shift lever, removing and installing, refer to «Removal and Installation»(ref-522346-S07502596702013011400000) Selector lever, removing and installing, refer to «REMOVAL AND INSTALLATION»(ref-520048-S27475934952012123100000)
  8. Decorative Frame
  9. Coin holder
  10. Insert For center console Vehicles with Removing and installing, refer to «CENTER CONSOLE INSERT»(ref-522367-S09461595852013011400000) Multi-media controls -E380- removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000)
  11. Clips Quantity: 6 Install on the center console insert
  12. Mount For the convertible top opening switch/power window switches Removing and installing, refer to «CONVERTIBLE TOP OPERATION SWITCH AND CENTRAL WINDOW REGULATOR SWITCH MOUNT»(ref-522367-S39653168912013011400000)
  13. Inlay Mat
  14. Backing
  15. Convertible Top Operation Switch -E137- /Window Regulator Central Switch -E643- Removing and installing, refer to «Removal and Installation»(ref-522299-S27854082502013011400000)
  16. Nut Quantity: 2 4 Nm
  17. Cover For center console Vehicles with Removing and installing, refer to «CENTER CONSOLE COVER»(ref-522367-S39731937332013011400000)
  18. Trim Removing and installing, refer to «TRIM»(ref-522367-S05978910242013011400000)
  19. Inlay Mat
  20. Bolt Quantity: 8 1.4 Nm
  21. Cup Holder Removing and installing, refer to «CUPHOLDER»(ref-522367-S18176583272013011400000)

Scheme 462

Scheme 462: FRONT CENTER ARMREST ASSEMBLY OVERVIEW
Scheme 462: FRONT CENTER ARMREST ASSEMBLY OVERVIEW
  1. Threaded Clip Quantity: 2
  2. Cover Clipped with -item 5
  3. Lower Trim For the hinge arm Clipped with -item 7- and -item 8- Removing and installing, refer to «HINGE ARM TRIM»(ref-522367-S08337708312013011400000)
  4. Bolt Quantity: 2 2.2 Nm
  5. Padding Removing and installing, refer to «FRONT CENTER ARMREST UPHOLSTERY»(ref-522367-S36120894222013011400000)
  6. Trim
  7. Upper Trim For the hinge arm Clipped with -3- Removing and installing, refer to «HINGE ARM TRIM»(ref-522367-S08337708312013011400000)
  8. Support Base Removing and installing, refer to «FRONT CENTER ARMREST»(ref-522367-S11333072982013011400000)
  9. Bolt Quantity: 2 3 Nm
  10. Nut Quantity: 4 20 Nm
  11. Bolt Quantity: 2 3 Nm

INTERIOR REARVIEW MIRROR GENERAL INFORMATION

There are different versions of the interior rearview mirrors, each with different features

  1. Manual dimming interior rearview mirror
  2. Automatic dimming interior rearview mirror -Y7
  3. Interior rearview mirror with digital compass
  4. Interior rearview mirror with rain/light recognition sensor -G397
  5. Interior rearview mirror with humidity sensor -G355

Scheme 463

Scheme 463: INTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW
Scheme 463: INTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW
  1. Interior Rearview Mirror Removing and installing, refer to «INTERIOR REARVIEW MIRROR»(ref-522367-S11707873022013011400000)
  2. Retaining Spring
  3. Rain/Light Recognition Sensor -G397- Removing and installing, refer to "Flush-Bonded Windows" in «Removal and Installation»(ref-522406-S33946003712013011400000)
  4. Upper Cover
  5. Retaining Plate Bonded to the windshield
  6. Upper Cover
  7. Electric Wire
  8. Lower Cover

Scheme 464

Scheme 464: INTERIOR REARVIEW MIRROR WITH LANE ASSIST ASSEMBLY OVERVIEW
Scheme 464: INTERIOR REARVIEW MIRROR WITH LANE ASSIST ASSEMBLY OVERVIEW
  1. Interior Rearview Mirror Removing and installing, refer to «INTERIOR REARVIEW MIRROR»(ref-522367-S11707873022013011400000)
  2. Retaining Spring
  3. Rain/Light Recognition Sensor -G397- Removing and installing, refer to "Flush-Bonded Windows" in «Removal and Installation»(ref-522406-S33946003712013011400000)
  4. Upper Cover
  5. Retaining Plate Bonded to the windshield
  6. Electric Wire
  7. Upper Cover
  8. Lower Cover
  9. Cover For the mirror base
