Contact reel / driver airbag module, resetting
The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.
Scheme 226
Remove
- the battery lead. See «Battery, disconnecting»(ref-415278-S03862267492011081500000)
- the steering wheel. See «Steering wheel, replacing»(ref-445664-S11936197072012010600000) .
Scheme 227
Remove one Torx 20 screw.
Scheme 228
Turn the contact reel counter-clockwise to the limit position.
Scheme 229
Turn the contact reel clockwise two complete revolutions. Then turn clockwise until the screw hole is in position "one o'clock" as shown.
Note. On later car models, the yellow marking must also be visible in the window.
Scheme 230
Install the screw when the contact reel is in the locked position.
The contact reel is now reset and locked (secured).
