Climate Units - General Diagnostics and Tests: Other Volvo S60 I

Checking the Power Supply And Ground For the Control Module

Check climate control module (CCM) terminal #A1 and relay 2/29 (passenger compartment relay box) connectors. Check for contact resistance and oxidation.

Check fuses 23 and 24 in the passenger compartment fusebox for the climate control module (CCM). Check for contact resistance and oxidation.

Check the power supply cable between fuse 23 and the control module terminal #A8. Check for an open-circuit.

Check the function of relay 2/29 by replacing it with a new relay.

Check the cable for power supply (extended X supply) between fuse 24 and relay 2/29 terminal #3. Check for an intermittent open-circuit.

Check the cable for power supply (extended X supply) between relay 2/29 terminal #1 and climate control module (CCM) terminal #A1. Check for an intermittent open-circuit.

Check power supply cable between fuse 23 and the climate control module (CCM) terminal #A8. Check for an intermittent open-circuit.

Check the ground lead between control module terminal # A16 and ground terminal 31/84. Check for an intermittent open-circuit. Check ground terminal 31/84. Check for contact resistance and oxidation.

Remedy as necessary.

Other information

1. To access or replace the control module, see «Climate Control Module (CCM), Replacing»(ref-415276-S17373772772011081500000)
2. To connect the breakout box, see «Connecting the Breakout Box»(ref-415276-S35524919892011081500000)
3. For other values, see «Signal Description, Climate Control Module (CCM), Connector A»(ref-445660-S10649975302012010600000)
4. See «Checking Wiring And Terminals»(ref-415229-S12487452032011081500000)

Scheme 76

Scheme 77

Scheme 78

Was a fault detected?

1. YES OKAY: Troubleshooting has been completed.
2. NO FAULT NOT FOUND: Troubleshooting has been completed.

Check climate control module terminal #A1 and relay 2/29 (passenger compartment relay box) connectors. Check for contact resistance and oxidation.

Check fuse 23 and 24 in the passenger compartment fusebox for the climate control module.

Note. If the fuse is blown, check the circuit after the fuse for a short-circuit to ground before replacing the fuse. Then replace the fuse. For further information about the circuit after the fuse, refer to the appropriate SYSTEM WIRING DIAGRAM article.

Check the cable for power supply between fuse 23 in the passenger compartment fusebox and control module terminal #A8. Check for an open-circuit.

Check the function of relay 2/29 by replacing it with a new relay.

Check the cable for power supply (delayed X supply) between fuse 24 and relay 2/29 terminal #3. Check for an open-circuit. The voltage at the relay terminal must be battery voltage, measured to ground.

Check the cable for power supply (delayed X supply) between relay 2/29 terminal #1 and climate control module (CCM) terminal #A1. Check for an open-circuit. The voltage at the terminal must be battery voltage, measured to ground.

Check power supply cable between fuse 23 and the climate control module (CCM) terminal #A8. Check for an open-circuit.

Check the ground lead between climate control module (CCM) terminal #A16 and ground terminal 31/84. Check for an open-circuit. Check ground terminal 31/84. Check for contact resistance and oxidation.

Remedy as necessary.

Other information

1. To access or replace the control module, see «Climate Control Module (CCM), Replacing»(ref-415276-S17373772772011081500000)
2. To connect the breakout box, see «Connecting the Breakout Box»(ref-415276-S35524919892011081500000)
3. For other values, see «Signal Description, Climate Control Module (CCM), Connector A»(ref-445660-S10649975302012010600000)
4. See «Checking Wiring And Terminals»(ref-415229-S12487452032011081500000) .

Was a fault detected?

1. YES OKAY: Troubleshooting has been completed.
2. NO FAULT NOT FOUND: Troubleshooting has been completed.

Checking the Power Supply And Ground Terminals

Power supply, climate control module (CCM)

The climate control module (CCM) is powered via a power input on the control module.

Power input terminal #1 (#25) is +15-supplied via a relay and fuse from the central electronic module (CEM). In the event of an open-circuit, climate control functions cannot be activated.

Checking the power supply

Check the power supply cable from the central electronic module (CEM) to climate control module (CCM) terminal #1 (#25). Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. Check the fuse. The voltage must be approximately battery voltage.

Ground terminal, climate control module (CCM)

The climate control module (CCM) has a ground input. The ground input from the control module is power ground and is connected to the ground terminal in the car body. See the relevant wiring diagram for further information about the ground terminal.

Checking the ground terminal

Check the ground lead between climate control module (CCM) terminal #16 (#40) and the ground terminal. Check for an open-circuit. Check for loose connections. Check for contact resistance. Check for oxidation. With the ignition on, the drop in voltage between the ground connection and the ground terminal for the climate control module (CCM) must not be greater than 0.5 V.

Remedy as necessary.

Other information

1. See «Connecting the breakout box»(ref-415276-S05299733262011081500000)
2. See «Signal Specification»(ref-415377-S00756076792011081500000)
3. See the relevant wiring diagram for information about circuit and ground terminals in the bodywork
4. See «Contents»(ref-415229-S18832573702011081500000)

1. Continue OKAY: Troubleshooting has been completed.

Connecting the Breakout Box

Special tools

9511463

9511428

9511508

1. Ignition off
2. To expose the climate control module (CCM) connector, see «Climate Control Module (CCM), Replacing»(ref-415276-S17373772772011081500000)
3. To expose the evaporator temperature sensor connector, see «Temperature Sensor Evaporator, Replacing»(ref-445662-S37835559672012010600000) .

Connect breakout box 9511428 to the adapter.

Climate control module (CCM)

1. Connect adapter «9511463»(ref-403953-S08826800642011061000000) to control module connectors A and B
2. For connector A, terminals #A1-#A16 correspond to terminals #25-#40 on the breakout box
3. For connector B, terminals #B1-#B22 correspond to terminals #1-#22 on the breakout box.

Evaporator temperature sensor

1. Connect adapter «9511508»(ref-403953-S37706977072011061500000) to the evaporator temperature sensor connector
2. Terminals #1-#5 on the connector correspond to terminals #26-#30 on the breakout box.

Special tools

9511463

9511428

9511428

1. Ignition off
2. To expose the climate control module (CCM) connector, see «Climate Control Module (CCM), Replacing»(ref-415276-S17373772772011081500000)
3. To expose the evaporator temperature sensor connector, see «Temperature Sensor Evaporator, Replacing»(ref-445662-S37835559672012010600000)
4. To expose the sun sensor connector, see «Sun Sensor/Alarm LED, Replacing»(ref-445682-S00443252092012010600000) .

Connect breakout box 9511428 to the adapter.

Climate control module (CCM)

1. Connect adapter «9511463»(ref-403953-S08826800642011061000000) to control module connectors A and B
2. For connector A, terminals #A1-#A16 correspond to terminals #25-#40 on the breakout box
3. For connector B, terminals #B1-#B22 correspond to terminals #1-#22 on the breakout box.

Evaporator temperature sensor

1. Connect adapter «9511463»(ref-403953-S08826800642011061000000) to the evaporator temperature sensor connector
2. Terminals #1-#5 on the connector correspond to terminals #26-#30 on the breakout box.

Sun sensor

1. Connect adapter «9511463»(ref-403953-S08826800642011061000000) to the sun sensor connector
2. Terminals #1-#5 on the connector correspond to terminals #26-#30 on the breakout box.

Climate Control Module (CCM), Replacing

The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information is always correct.

Scheme 79

Note. Read out the programmed data before replacing the climate control module. This is done in VIDA vehicle communication. After replacing the climate control module (CCM), the relevant parameters must be programmed.

Move the gear selector/gear selector lever to the rearmost position.

Ignition off.

Remove the key. The key must be removed to ensure that the ignition is not switched on by mistake.

Removing the climate control module (CCM)

Scheme 80

Detach the panel at the gear selector lever as illustrated.

Twist the panel so that it is as far from the center console as possible.

Scheme 81

Remove the lower screws from the bracket.

Angle out the entire infotainment control module (ICM) and the dashboard environment panel as illustrated.

Scheme 82

Disconnect the connectors.

Turn the infotainment module with the dashboard environment panel.

Remove the four screws as illustrated.

Scheme 83

Press the four clips and remove the infotainment control module by pulling it straight out as illustrated.

Scheme 84

Slacken off the two screws at the lower edge of the dashboard environment panel.

Pull the dashboard environment panel straight out from the bracket.

Installing the climate control module (CCM)

Scheme 85

Install

1. the dashboard environment panel using the two screws
2. the infotainment panel so that it hooks into the dashboard environment panel.

Screw the infotainment panel into place using the four screws.

Connect the connectors.

Angle in the upper section of the infotainment control module first. Then screw the lower edge into place using the two lower screws.

Front Panel, Replacing

Removing the front panel

Scheme 86

Release the catches. Pull off the front panel.

The front panel has double-sided adhesive tape. Ensure that any remains of the tape are removed from the black panel.

Installing the front panel

Remove the backing paper from the tape for the front panel.

Press the front panel into place.

Ordering software for the climate control module (CCM)

Order the software. See 8691285 .

Finishing

After replacing the climate control module (CCM), the following must be carried out

1. Reprogram the customer programmed data
2. Carry out self-adjustment of the damper motors' end positions. This is done in VIDA vehicle communication. Test drive the car. Check that the engine and climate control system are functioning.
